MobilePower 4035 User manual

Model No. 4035
CODE-RESQ
20MCP Searchlight with 12 LED Area Light
and Vehicle Jump Starter
Instruction Manual
Sheet 1 of 8

CODE-RESQ
20MCP Searchlight with 12 LED Area Light
and Vehicle Jump Starter
Instruction Manual
Model No. 4035
On/Off Switch
BEAM
LED
H4 Quartz
Halogen Bulb
LED Area Light
LED Area Light Adjustable Head
12 Volt Vehicle
Jumpstart System
with Heavy Duty Cable
and Clamps
Charging Port
IMPORTANT INFORMATION
READ AND UNDERSTAND ALL WARNINGS AND ADVISORY NOTES
INCLUDED IN THIS MANUAL. FOLLOW INSTRUCTIONS PROVIDED
BY YOUR VEHICLE MANUFACTURER AND MAN-UFACTURER OF
THE DEVICES INTENDED TO BE USED WITH THIS POWER SUPPLY.
MAKE CERTAIN THIS DEVICE IS FULLY CHARGED PRIOR TO FIRST
USE.
Sheet 2 of 8

Sheet 3 of 8
WARNINGS
THIS PRODUCT CONTAINS A SEALED LEAD-ACID BATTERY
AND MUST BE DISPOSED OF PROPERLY. YOU MAY CONTACT
YOUR LOCAL GOVERNMENT RECYCLING AUTHORITY FOR
APPROPRIATE DISPOSAL. FAILURE TO FOLLOW THE
INSTRUCTIONS MAY CAUSE DAMAGE TO THE PRODUCT AND OR
PERSONAL INJURY.
IMPORTANT ADVISORY NOTES
• Thespotlightbecomesveryhotduringuse.DONOTtouchlensor
block lens area during operation.
• Light beam is extremely powerful. DO NOT shine directly into
eyes.
• Unit is not waterproof. DO NOT use Spotlight under water or
immerse in water.
• Donotusewithdrycellbatteries.Thesebatteriesmayburstand
cause injury to person or damage personal property.
• Donotattempttofacethebatterybeingjumped.Stayawayasfar
as possible from the battery when making the final connection.
• DONOTCONNECTTOorjumpstarta6or24Voltbattery.
If battery acid comes in contact with skin or eyes, rinse
immediately with water for 20 minutes. Seek medical attention if
redness, irritation or pain is present.
• DO NOT smoke, use matches, lighters or an open ame near
batteries.
• Thisproductcontainschemicalsubstancesincludinglead.Wash
hands thoroughly after handling Lead Acid Batteries.
• Neverallowred(Positive)andblack(Negative)clampstocome
in contact with each other or contact with metal object at the
same time.
• To protect against electrical hazards, do not immerse charger,
adapters, or unit in water or other liquid.
• Closesupervisionisnecessarywhenworkingnearchildren.
• Donotuseunitforapplicationsotherthanitsintendeduse.
• Alwaysconnectthered(+)clamptothepositivebatteryterminal
 rst.Connectblack(-)clamptothevehicleengineblock,ora
metal part of the vehicle which is connected to the vehicle main
ground system as final connection.
• Jumpstartvehiclesinawellventilatedareaonly.
• Do not expose the unit to moisture or use it in extremely hot
conditions.
• Neverworkalonewiththisproduct.Makesurethatsomeoneis

Sheet 4 of 8
available to give assistance if needed.
• Wearcompleteeyeandclothingprotection.Donottoucheyes
while working near battery.
• Do not attempt to remove or replace the battery used in this
device. When the battery has reached the end of its useful
lifetime, take the entire unit to a battery recycling facility.
• Remove metal and personal jewelry such as: rings, bracelets,
necklaces and watches, while working with a lead acid battery.
This can produce a short-circuit that may cause severe burns.
Never charge or jump-start a frozen battery.
• Do not operate this device while wearing vinyl clothing. Static
electricity may be generated when vinyl clothing is rubbed.
• Thisproductisnotintendedforuseintherainortemperatures
above 150ºF.
• Useonlytheprovidedchargers,cablesandclamps.Unauthorized
parts may damage the unit. This product has no consumer
 serviceablepartsexceptthereplaceablefuses.
• Keepoutofthereachofchildren.
• Keepbatteryterminalsclean.Becarefultokeepcorrosionfrom
coming in contact with eyes.
• Donotletthecordsoftheunitorjumperclampsgetwet.
• UseofDAMAGEDorIMPROPERextensioncordtochargethis
unit could result in risk of fire and/or electric shock. Make certain
 thattheextensioncordinsafeandingoodelectricalcondition.
• Preventwatertogetintotheunithousing.Waterwilldamagethe
internal electronics board.
• Thisunithasabuilt-inleadacidbattery.Althoughthisunitarrives
partially charged from the factory, it MUST be fully charged before
the first use.
• Rechargetheunitaftereachuseorevery3monthstopreventthe
 batteryvoltagetobecomeextremelylow.
ADJUSTABLE HEAD
To adjust head angle, gently pull up on rim at bottom. Angle can be
adjusted to 4 different positions indicated by a “click” sound. Do not
force head beyond final point. Return head to closed position for
storage to prevent damage to mechanism.
SPOTLIGHT
Press the switch on handle of the spotlight to “BEAM” position.
Theoperationtimeisuptoapproximately35minutes.
Press the switch to “O” to turn off the spotlight.

Sheet 5 of 8
LED AREA LIGHT
The Spotlight is equipped with bright LED lights embedded in
the rim. These will provide an area light for working and general
illumination. To operate,
Press the switch on handle of the spotlight to “LED” position.
Area light will operate continuously for many hours on a full charge.
Press the switch to “O” to turn off the LED lights.
VEHICLE JUMP START INSTRUCTIONS:
WARNINGS: Vehicles equipped with on-board computers may be
damaged if the vehicle is jump started. Review and understand
your vehicle owner’s manual instructions before attempting to
jumpstart your vehicle. Failure to follow these advisory instructions
may result in personal injury and property damage. Use Safety
Glasses to protect your eyes while working near battery during
jump-staring a vehicle. Jump start a vehicle in an open area without
any type of obstructions.
1. Turn off the vehicle ignition and all the accessories (Such as
 radios,lights,andairconditioners,etc).
2. Apply the emergency brake and put those vehicles with automatic
transmission in park position.
3. Determine the polarity of the vehicle battery terminals. The
 positive(+)batteryterminalnormallyislargerindiameterthanthe
 negative (-) terminal. If you are unsure, you must refer to the
vehicle owner’s manual.
4. Determine whether your vehicle designed with a negative or
 positivegroundedsystem:IntheNegativeGroundSystem,the
negative battery terminal is grounded to chassis of the vehicle.
Most vehicles use this type of system. Positive Grounded battery
terminal is grounded to chassis or any other part of the vehicle. If
you are not certain of this important information, YOU MUST
REFER TO YOUR VEHICLE OWNER’S MANUAL.
5. Removeclampsfromtheholders.Neverallowclamps(positive&
 negativeterminals)totouchtogetherorcontactthesamepiece
of metal to prevent short-circuits.
6. Follow the instructions for a Negative Grounded System or
 PositiveGroundedSystemasindicatedbelow:

Sheet 6 of 8
Negative Grounded System
I. ConnecttheREDCLAMP(positive+)tothepositiveterminalof
the vehicle battery or the remote positive terminal if available.
II. Connect the BLACK CLAMP (negative -) to the vehicle engine
block, or a metal part of the vehicle which is connected to the
vehicle main ground system. Do not clamp directly to negative
battery terminal, main fuel distribution module or sheet metal
parts.
MAKE SURE THE BATTERY POLARITY CONNECTIONS ARE
CORRECT.
Positive Grounded System:
I. ConnecttheBLACKCLAMP(negative-)tothenegativeterminal
of the vehicle battery.
II. ConnecttheREDCLAMP(positive+)tothevehicleengineblock,
or a metal part of the vehicle which is connected to the vehicle
ground system. Do not clamp directly to positive battery terminal,
main fuel distribution module or sheet metal parts.
MAKE SURE THE BATTERY POLARITY CONNECTIONS ARE
CORRECT.
7. Allow3to5minutesofchargetime.Itishighlyrecommended
having a second person to assist holding the unit securely in
 placeduringthenextsteps.
8. Starttheengine.Stopif the vehicle doesnotstartafter2 to 3
 secondsofenginecranking.Wait2to3minutesthentryagain.
Repeat the above steps several times until the vehicle starts.
9. If the vehicle starts, disconnect the clamps as far away from the
vehicle battery as possible.
For Negative Grounded System, disconnect the BLACK CLAMP
Negative first and then the RED CLAMP Positive.
For Positive Grounded System, disconnect the RED CLAMP
Positive first, and then the BLACK CLAMP Negative.
10. Stow the booster clamps into their storage compartment located
on sides of the Spotlight.
CHARGING INSTRUCTIONS:
CAUTIONS
• Priortochargingthisdevicereadandunderstandalltherelated
instruction indicated below. This product may arrive partially
charged from the factory. It is highly recommended to fully charge
the unit after purchase and before initial use.

Sheet 7 of 8
• MakecertainthatthePowerSwitchissettothemiddle“O”off
position.
• Do not charge near ammable material, open ames or any
 locationwhichmayaccumulateammablefumes.
• Makecertaintheelectricaloutletlocatedinapotentiallywetor
moist area that is to be used to charge this device, is protected by
 aGroundFaultCircuitInterrupter(GFCI).
• Makesurethatbothboosterclampsaresecurelyplacedintheir
designated storage compartments when not in use and during
the charging period.
A. AC Charging At Home with 110 Volt Charger
1. Keep the Power Switch in middle “O” off position while charging.
2. Insert the AC charger round plug into the Spotlight Charging Port
located at the back of the spotlight.
3. Connect the 110 Volt AC Charger into the 110 Volt AC home
receptacle.
4. Fully charge the spotlight according to the following charging
 schedule:
 Firsttimecharge:...................................................24hours
 Rechargeandsubsequentcharge:.......................18hours
5. Unplug the AC charger from the 110 Volt receptacle first and then
remove the round plug from the Spotlight Charging Port.
B. DC Charging In Your Vehicle with 12 Volt Charger
1. Keep the Power Switch in middle “O” off position while charging.
2. Insert the 12 Volt DC Charger round Plug into the Spotlight
Charging Port located at the back of the spotlight.
3. Connectthe12VoltDCChargerPlugintothevehiclecigarette
lighter or 12 Volt accessory port.
4. Fully charge the Spotlight internal battery for 8 hours while the
vehicle engine is running.
5. Unplug the DC charger from the vehicle cigarette lighter or 12 Volt
accessory port first and then remove the round plug from the
Spotlight Charging Port.
12 VOLT DC CHARGER ADAPTOR FUSE REPLACEMENT:
1. Unscrew the retainer ring at the tip of the 12 Volt DC charger
plug.
2. Replace the internal glass fuse with the same grade Fuse rated
at 2 AMP.

Sheet 8 of 8
SPECIFICATIONS:
Battery rated capacity 12 Volt - 8 Ah
Bulb H4-120 Watt Quartz Halogen Bulb
LEDarealight 360mA
Made in China
NOTE:Specicationsaresubjecttochangewithoutnotice.
