MOBISUN Pro User manual

Mobisun Pro
User manual
TECHNICAL SPECIFICATIONS
Charging time approx. 2.5 hours
Charging time approx. 15 hours
NMC
259 Wh (14.8V 17.5 Ah)
Approx. 5 years (1.500 charge cycles, 80% DOD)
6 kg
57 x 28 x 6.5 cm
12 months
0-40° C
Automatic
Automatic
Automatic
Automatic
Automatic
Charge with:
Wall socket (via battery charger)
29 W SunPower solar panel
Input
23V ~ 75V DC input with 2 pin GX16 DC-connection
Outputs
AC outlet, 230VAC, 50Hz, 250W continuous, 500W peak, pure sine wave
12V car plug up to 12.5A (150W)
1 x USB 5V, 2.4A 1 x USB Quick Charge 3.0
Battery
Battery type
Battery capacity
Battery life
General
Weight
Dimensions
Warranty
Certifications
Optimal operating temperature
Protections:
Battery voltage low
Battery voltage too full
Overload
Short circuit
Overtemperature
Overheating
5V light:
50+ hours
Charge
smartphone:
+30 times
Watch TV:
10+ hours
Charge laptop:
5+ times
USE CASES
• Small electrical appliances
• TV
• Laptop
• Soundsystem
• Refrigeration Equipment
• Electric bike
• Sander
• Lighting
• Slowcooker
• Slowjuicer
• 12V coffee machine
• Tablet
• Smartphones
• etc.
Avoid exposure to water
Caution: risk of electric shock
Keep out of reach of children
www.mobisun.com
Turn off the power switch and put the Mobisun Pro in a
cooler environment. Wait 5 to 10 minutes and turn on the
Mobisun Pro again.

Overview
1 2
Usage
The powerswitch (blue light on) activates 3 functions:
Turn the power switch off (blue light off) when no power is needed.
In the off position charging in the sun or via the adapter is still possible.
1. The integrated battery is
automatically charged by placing
the solar panel into direct sunlight.
Place the panel in a right (90°) angle
towards to sun for maximum charge
efficiency.
2. Charge the integrated battery in
2.5 hours with the supplied adapter.
The DC input can also be connected
to an external 23V Mobisun solar
panel (60W or 100W). This wil reduce
the solar charging time to 3 - 5 solar
hours.
90°
Charging
During charging the LED display on the back begins to flash.
Electrical devices can be powered during charging.
Mobisun Pro
User manual for correct use
12V USB
230V outlet
(250W continuous,
500W peak)
Powerswitch
12V outlet
5V outlet
Battery status
Time until battery
is full or empty
Power use or
power input
23V ~ 75V Solar/DC Input with
2 pin GX-16 DC-connection
12V USB 5V USB output
3
12V DC output230V AC output
1 2
