Modern Forms 258-LED Flush Mount User manual

1
INSTALLATION INSTRUCTIONS

FM-25814


Phone [phone]
Fax [phone]

44 Harbor Park Drive
Port Washington, NY 11050

1600 Distribution Ct
Lithia Springs, GA 30122

1750 Archibald Avenue
Ontario, CA 91760

 !   "#"$"%&    "#"#'$(  )*$ "#"#( $% ( + ( ,##,-
• Read all instructions before installing.
• System is intended for installation by a licensed electrician in accordance with the National Electrical Code (NEC) and local regulations.
• When handling the xture, do not apply pressure to the LEDs. Hold the xture by the base only.
• Retain installation instructions for future maintenance reference.
.All parts must be used as indicated in these instructions. This product is designed for use only with the supplied parts and/or
accessories designated for use by Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern
Forms could result in personal injury or property damage, and will void the warranty. Contact an authorized dealer or the manufacturer if any
parts are damaged or missing.
Coastal conditions may cause mineral and residue build-up on the xture. We recommend that customers in coastal
areas clean all external surfaces of the xture once every two weeks with a wet cloth.
/.Pour éviter tout choc électrique, assurez-vous que le disjoncteur soit mis hors tension avant de commencer.
• Lisez toutes les instructions avant l’installation.
• Le système doit être installé par un électricien licensié conformément au code national de l’électricité (NEC), et également aux
règlements locaux.
• Lors de la manipulation du luminaire, n’appuyez pas sur les LED. Tenez-le uniquement par la base.
Toutes les pièces doivent être utilisées comme indiqué dans ces instructions. Ce produit est conçu pour être utilisé seulement
avec les pièces et/ou accessoires fournis pour être utilisés avec les produits Modern Forms. Remplacer des pièces ou accessoires non conçus
pour ce produit Modern Forms pourrait causer des dommages corporels ou matériels et pourrait également causer l’annulation de la
garantie. Veuillez contacter un revendeur autorisé ou le fabricant si des pièces manquent ou sont endommagées.
0 Les conditions côtières peut causer une accumulation de minéraux et de résidue sur le luminaire. Nous recommendons
aux clients qui resident dans les zones côtières de nettoyer toutes les surfaces externes du luminaire une fois toutes les deux semaines avec
un chion humide.
A
B
Wire Connector
Qty: 3PCS+1 Extra
Mounting Screw
Qty: 4+1 Extra

2
INSTALLATION INSTRUCTIONS

FM-25814


Phone [phone]
Fax [phone]

44 Harbor Park Drive
Port Washington, NY 11050

1600 Distribution Ct
Lithia Springs, GA 30122

1750 Archibald Avenue
Ontario, CA 91760
111
1. Shut o the power at the circuit breaker and remove existing xture,
including the crossbar.
2. Carefully unpack your new xture and lay out all the parts on a clear
area. Be careful not to lose any small parts necessary for installation.
.23#,-45
3. Remove the mounting ring from the xture.
4. Secure the mounting ring to the junction box using standard junction
box screws that comes with the junction box.
  the side of the mounting plate marked “GND” must face out.
./3#,-5
5. Connect the xture’s wires to house wires as shown in Fig.2,
making sure that all wire connectors (A) are secured. If your
outlet box has a green or bare copper ground wire, connect
the xture’s ground wire to it. Otherwise, tuck the xture’s
ground wire directly to the xture. After wires are connected,
tuck them carefully inside the junction box.
1./
6. Secure the back plate to the mounting ring using the assembly screw .
7. Place the sparking glass into the bracket, secure them to the back plate
with mounting screw (B) .
∅4"
13
4"
13
8"
GND

Black or
Smooth

White or
Ribbed

Bare wire
(Ground)

Black
(Hot)

White
(Neutral)

Green or Bare Copper
(Ground)
#,-##, #,#,#6 #
#,-4
Junction Box
Screw
Assembly
Screw
Sparkling Glass
RPL-GLA-25814
Mounting Screw
B
Junction Box
Mounting Ring
Black Wire
White Wire
Wire Connector
A
Ground Wire
Bracket
Back Plate
