American DJ ScanTron User manual

American DJ
4295 Charter Street
Los Angeles CA. 90058
www.americandj.com
Revised 8/02
User Instructions
Unpacking:
Thank you for purchasing the ScanTron™ by American
DJ
®
. Every ScanTron™ has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your  xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without  rst
contacting customer support.
Introduction:
This unit is five channel DMX intelligent scanner that
may be easily converted to an intelligent color changer by removing
the mirror unit. This unit can also run as a stand alone, sound-active
unit, or in a Master/Slave configuration as either a scanner or color
changer. The ScanTron
™
comes with several build in programs and is
best used in multiples of four. When used as a stand alone unit or when
used in multiples linked in a master/slave configuration the optional
IRC/1 controller may be used. The optional controller will access dif-
ferent programs and control a blackout function.
For best results use
fog or special effects smoke to enhance the beams projections.
Customer Support:
American DJ
®
provides a toll free customer
support line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. Service Hours are Monday through Friday 9:00
a.m. to 5:00 p.m. Paci c Standard Time.
Voice:
[phone]
Fax:
[phone]
E-mail:
[email protected]
Warning!
To prevent or reduce the risk of electrical shock or  re, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
Caution! There are no user serviceable parts inside this unit. Do not Caution!
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact your nearest American DJ
®
dealer.
ScanTron™ General Information
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 2

©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 3
ScanTron™ Halogen Lamp Warning
This fixture is fitted with halogen lamps which are
highly susceptible to damage if improperly han-
dled. Never touch the lamps with your bare fin-
gers as the oil from your hands will shorten lamp
life. Also, never move the fixture until the lamps
have had ample time to cool. Remember, lamps
are not covered under warranty conditions.
•
Micro-Stepping Motors for Smooth Color and Gobo Transitions
•
DMX-512 Protocol Compatible (Uses Five DMX Channels)
•
14 Gobo Patterns Plus Spot/11 Colors Plus White
•
Master/Slave Operation
•
Internal Microphone with Volume Sensitivity Knob
•
Removable Head for Color Changer Operation
•
Variable Speed Strobe Function
•
Optional IRC/1 Remote Controller
ScanTron™ Features
The ScanTron™ carries a one year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our toll free customer support number. All
packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
ScanTron™ Product Registration
•
To reduce the risk of electrical shock or  re, do not expose this unit
rain or moisture
•
Do not spill water or other liquids into or on to your unit.
•
Be sure that the local power outlet match that of the required volt-
age for your unit.
•
Do not attempt to operate this unit if the power cord has been
frayed or broken.
•
Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and  re in case of an internal short.
•
Disconnect from main power before making any type of connection.
•
Do not remove the cover under any conditions. There are no user
serviceable parts inside.
•
Never operate this unit when it’s cover is removed.
•
Never plug this unit in to a dimmer pack
•
Always be sure to mount this unit in an area that will allow proper
Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
•
Do not attempt to operate this unit, if it becomes damaged.
•
This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
•
During long periods of non-use, disconnect the unit’s main power.
•
Always mount this unit in safe and stable matter.
Always mount this unit in safe and stable matter.
•
Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 7 for cleaning details.
•
Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
•
The fixture should be serviced by qualified service personnel when:
The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
ScanTron™ Safety Precautions
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 4
To optimize the performance of this product, please read these operating
instructions carefully to familiarize yourself with the basic operations of
this unit. These instructions contain important safety information regard-
ing the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
ScanTron™ General Instructions

©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 6
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 5
ScanTron™ Controls and Functions
REAR
FRONT
2
6
7
8
4
3
9
1
5
1.
Thumb Screw -
This thumb screw holds the lamp socket assem-
bly cover (16) into place.
2.
Audio Sensitivity Knob -
Audio Sensitivity Knob -
This adjust audio sensitivity of the
INTERNAL MICROPHONE (3)
. Turning the sensitivity knob in the
clockwise direction will increase the sensitivity to sound. Turning the
knob in the counter clockwise direction will decrease the  xture’s sen-
sitivity to sound.
3.
Dip Switches -
Dip Switches -
These switches serve two functions. In DMX mode
each switch corresponds to a speci c value based on binary code.
See page 7 for a detailed explanation of DMX binary code. When the
unit is operating in master/slave mode the pan and tilt movements may
ScanTron™ Controls and Functions
13
14
1
11
10
12
be inverted by moving dip switch 10 to the “on” position. All other dip
switches have no function in master/slave mode.
4.
Microphone -
Microphone -
This microphone receives external low frequencies
to trigger the unit in Sound-Active and Master/Slave mode.
5.
IRC/1 Controller Jack -
IRC/1 Controller Jack -
This jack is for use with the optional IRC/1
controller only.
Do not attempt to connect an audio signal to this jack,
this will damage the PC board and void your manufactures warranty!
6.
XLR Output Jack -
XLR Output Jack -
This jack is used to transmit the incoming
DMX
signal to another DMX  xture, or transmit a Master/Slave signal
to the nest ScanTron™ in the chain. For best results in DMX or Master/
Slave mode terminate this jack if it is the last unit in the chain. See
“Terminator” on page 7.
7.
XLR Input Jack -
XLR Input Jack -
This jack is used to accept an incoming DMX
signal or Master/Slave signal.
8.
Fuse Holder -
This housing stores the 5 amp (3 amp 220v) protec-
tive fuse.
9.
Power Cord -
Power Cord -
Connect only to a matching power outlet. Never
use
this  xture is the ground prong has been removed or broken off.
10. Mirror -
This is a highly re ective surface mirror speci cally
designed to optimize and enhance beam output. Never use glass
cleaner that contain ammonia to clean the surface of the mirror (such
as Windex).
11.
Lens -
Lens -
This is a fully focusing high quality lens. Focus the lens by
manually turning the lens in a clockwise or counter-clockwise direc-
tion.
12. Mirror Interface -
This connection is used to create an interface
between the mirror head and the unit body. Disconnect this interface
when the unit is going to be used as a color changer with the mirror
piece removed.
13.
Lamp Socket Assembly -
Lamp Socket Assembly -
This assembly holds a LL-ELC (24v/
250w) lamp.
14.
Lamp Socket Assembly Plate -
This plate is used to protect and
accesses the lamp socket assembly.

Operating Modes:
•
Stand alone mode -
The unit will react to sound, chasing through
the built-in programs. You can also use the optional IRC/1 Remote
Control to blackout and other functions.
• Master/Slave mode -
You can daisy chain up to 16 units together
to get a synchronized light show that will react to sound chasing
through several built in programs.You can also use the optional IRC/1
Remote Control to blackout and other functions.
•
DMX control mode -
This function will allow you to control each
individual fixtures traits with a standard DMX--512 controller such as
the American DJ Show Designer.
™
•
Color Changer -
By removing the mirrored head this unit will func-
tion as a color change in all the preeceding modes. See page 14.
Universal DMX Control:
This function allows you to use a univer-
sal DMX-
512
controller such
as the American DJ
®
DMX Operator™
or Show Designer™ to control mirror movement, the color wheel, the
gobo wheel, and the shutter (strobe). A DMX controller allows you to
create unique programs tailored to your individual needs.
Special
Note:
Because these units are designed to automatically go in to
sound-active mode when they do not sense a DMX signal, these units
may activate when your DMX controller is turned off. To avoid this
problem leave your DMX controller on when the lights are powered on
and be sure the sound
sensitivity knob is always turned down
sensitivity knob is always turned down
(coun-
ter-clockwise) when running these units in DMX mode.
1.
The ScanTron™ uses five DMX channels. Channel 1 controls pan,
channel 2 controls tilt, channel 3 controls color channel 4 controls
gobo wheel, and channel 5 controls the strobe function. See page
14 for detailed description of the DMX traits.
2.
To control your fixture in DMX mode, follow the set-up procedures
on pages 5 - 7 as well as the set-up specifications that are includ-
ed with your DMX controller.
3.
Use the controller’s faders to control the various DMX fixture traits.
4.
This will allow you to create your own programs.
5.
When using a DMX controller and setting up for DMX operation
follow the dip switch settings on page 15.
6.
For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
ScanTron™ Operation
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 8
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 7
ScanTron™ Operation
7.
For help operating in DMX mode consult the manual included
with your DMX controller.
Stand-Alone Operation (Sound Active):
This mode allows a
single unit to run to the beat of the music. Only use this mode when
running a single unit, or when running several units as individuals.
1.
This unit is automatically designed to go into sound-active mode
when it does not sense a DMX signal. The unit will react to the
low frequencies of music via the internal microphone. You may
invert the pan and tilt functions by  ipping dip switch 10 to the
“on” position.
2.
Adjust the audio sensitivity knob on the bottom of the unit to make
the unit more or less sensitive to sound.
Turning the sensitivity knob
in the clockwise direction will increase the sensitivity, turning the
knob in the counter-clockwise direction will decrease the  xture’s
sensitivity to sound.
3
.
The optional
IRC/1 Controller
may be used with this mode to
control blackout, slow scan, and strobe functions.
Master-Slave Operation (Sound Active):
This function will allow
you to link up to 4 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.
1.
Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The  rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2.
Follow the chart on page 14 for proper unit dip switch settings.
3.
The optional
IRC/1 Controller
may be used with in this opera-
tion for blackout, slow scan, and strobe function.
4.
After all the units settings have been set and are plugged in,
adjust the sensitivity knob on the rear of the master unit to make
them react to sound.
Note: In Stand-Alone and Master-Slave operation the units will black-
out to conserve lamp life when a sound source is not received.

sound activation or in this case pan/tilt inversion.
Each dip switch has a preset value. A specific DMX address is set by
combining the dip switches that sum your desired value. For exam-
ple: To achieve a DMX address of 21, combine dip switches 1, 3, and
5. Sense dip switch 1 has a value of 1, dip switch 3 has a value of 4,
and dip switch 5 has a value of 16, the combination of the create a
DMX value of 21.
Set DMX address 21:
Set DMX address 201:
Dip-switches #
1 = 1
Dip-switches #
1 = 1
3 = 4
4 = 8
5 = 16
7 = 64
= 21
8 = 128
= 201
Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation):
The ScanTron™ can be controlled via DMX-512 protocol.
The ScanTron™ is a  ve channel DMX unit. The DMX address is set
on the bottom panel of the ScanTron.™ Your unit and your DMX con-
troller require a standard 3-pin XLR connector for
data input and data output (Figure 1). If you are
making your own cables, be sure to use standard
two conductor shielded cable (This cable may be
purchased at almost all pro sound and lighting
stores). Your cables should be made with a male
and female XLR connector on either end of the
cable. Also remember that DMX cable must be
daisy chained and can not be split.
Figure 1
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 10
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 9
Power Supply:
Before plugging your unit in, be sure the source volt-
age in your area matches the required voltage for your American DJ
®
ScanTron.™ The American DJ
®
ScanTron
™
is available in a 120v and
220v version. Because line voltage may vary from venue to venue,
you should be sure your unit voltages matches the wall outlet voltage
before attempting to operate you  xture.
DMX-512:
DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers.
A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that trav-
els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter-
minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking:
DMX is a language allowing all makes and models of
different manufactures to be linked together and operate from a sin-
gle controller, as long as all  xtures and the controller are DMX com-
pliant.
To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Dip-switches in DMX mode:
This unit uses dip switches to assign a
DMX address. Each dip switch represents a binary value.
Dip Switch 1 address equals 1
Dip Switch 2 address equals 2
Dip Switch 3 address equals 4
Dip Switch 4 address equals 8
Dip Switch 5 address equals 16
Dip Switch 6 address equals 32
Dip Switch 7 address equals 64
Dip Switch 8 address equals 128
Dip Switch 9 address equals 256
Dip Switch 10 - Some unit omit dip switch 10, when a unit does
included dip switch 10 it is usually used for special functions such as
ScanTron™ Set Up ScanTron™ Set Up
ON
1
9
8
7
6
5
4
3
2
10
128
128
2
2
8
8
32
32
256
65
16
4
1
SF
SF
DMX CHANNEL
Notice:
Be sure to follow  gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
DMX512 IN
3-PIN XLR
1
2
3
1
2
3
DMX +
DMX -
COMMO
N
DMX512 OUT
3-PIN XLR
Figure 2

ScanTron™ Fuse & Lamp Replacement
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 11
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 12
Caution:
Always replace with the exact same type lamp and fuse,
unless otherwise specified by an authorized American
DJ
®
service
technician. Replacing with anything other than the specified part can
damage your unit and will void your manufactures warranty.
Warning:
If you continue to blow lamps or fuses, STOP using the
unit. Contact customer support for further instructions, you may have
to return the unit for servicing. Continuing to use the unit may cause
serious damage.
Lamp Replacement:
Caution! Never attempt to change the lamp
while the fixture is plugged in. Always disconnect the main power
and allow the unit ample time to cool before attempting to replace the
lamp. Lamp replacement has been made simple by incorporating the
use of a flip-up front cover that is retained by thumb screws.
1.
Be sure to follow the proper handling procedures that deal with
halogen lamps.
2.
Remove the thumb screw on the rear of the unit that holds the
lamp socket assembly cover in place.
3.
After removing the thumb screw, slide out the cove from the rear
of the unit to expose the lamp socket assembly.
4.
Carefully remove the old lamp and discard it in the trash.
5.
Replace the lamp with an exact match and reassemble in reverse
order.
Fuse Replacement:
Disconnect the unit from the main power supply.
Insert a standard flat head screw driver in to the fuse holder housing.
Turn the screwdriver in counter-clockwise direction to remove the fuse
holder. Remove the old fuse and discard it, replace the fuse with the
same type. Insert the fuse back into it’s housing.
ScanTron™ Set Up
Figure 3
1 Ground
1 Ground
XLR Male Socket
XLR Pin Con guration
3 Hot
2 Cold
2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination.
When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 90-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
1
2
3
Te
rmination
r
educes
signal
e
rrors
and
avoids
signal
transmission
problem
s
and
interference.
It
is
always
advisable
to
connect
a
DMX
terminal,
(Resistance
120
Ohm
1/4
W)
between
PIN
2
(DMX-)
and
PIN
3
(DMX
+)
of
the
last
fixture.
Figure 4
5-Pin XLR DMX Connectors.
Some manufactures use 5-pin XLR
connectors for DATA transmission in place of 3-pin. 5-pin XLR  xtures
may be implemented in a 3-pin XLR DMX line. When inserting stan-
dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be
used, these adaptors are readily available at most electric stores. The
chart below details a proper cable conversion.
Conductor
5-Pin XLR Male (In)
3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Thumb Screws
Lamp Cover
Lamp Socket
Assembly
Assembly

©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 14
ScanTron™ Cleaning
ScanTron™ Trouble Shooting
Fixture Cleaning:
Due to fog residue, smoke, and dust cleaning the
internal and external optical lenses and mirror should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.
1.
Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2.
Use a brush to wipe down the cooling vents and fan grill.
3.
Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4.
Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5.
Always be sure to dry all parts completely before plugging the unit
back in.
Trouble Shooting:
Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1.
Be sure you have connected your unit into a standard 120v wall
outlet.
2.
Be sure the external fuse has not blown. The fuse is located on
the bottom panel of the unit.
3.
Remove the lamp cover and be sure the lamp is seated in its
socket properly. Occasionally lamps become loose during ship-
ping be sure the lamp is push in to its socket all the way.
4.
Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1.
Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
2.
Be sure the
SENSITIVITY KNOB (5)
is not set to the minimum
position (full counter-clockwise).
©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 13
ScanTron™ Color Changer Conversion
ScanTron™ DMX Traits
This chart below details the DMX traits. The individual trait can only
be accessed an universal DMX controller.
The icons below detail the gobo pattern as well as their placement on
the gobo wheel, starting with 1 on the left and 15 on the right.
DMX512 CONFIGURATION
CHANNEL 2
TILTPAN
FLAT FLATBARREL BARREL
Stopped
Stopped
Stopped
CHANNEL 1 CHANNEL 3
0
White
255
11
22
33
44
55
66
77
88
99
110
121
Red
Blue
Green
Yellow
Amber
Pink
Lt. Blue
Purple
Lt. Green
Orange
Magenta
COLOR
128
Slow
Fast
Gobo 9
Gobo 7
Gobo 5
Gobo 3
Blackout
Gobo 1
0
Gobo 11
Gobo 13
Gobo 14
Gobo 12
Gobo 10
Gobo 2
Gobo 4
Gobo 6
Gobo 8
Open
CHANNEL 4
GOBO
8
16
24
32
40
48
56
64
72
80
88
96
104
112
120
255 Fast
128
Slow
CHANNEL 5
SHUTTER
0
255
Stopped
92
10
Gobo+Color
Color
Gobo
174
The ScanTron™ is designed with a remov-
able mirror head. When the head is removed
the unit can be used as a color changer with
gobo patterns. The unit will function normally
in all opperating modes with the exception
of mirror movements. To remove the head;
1 Disconnect the mirror interface cable, 2
Unscrew the three large thumb-screws sur-
rounding the output lenses that secure the
head assembly to the body. 3 Gently pull the
up and away from the output lens.
Mirror
Interface
Thumb-
Screws

©
American DJ
®
- www.americandj.com - ScanTron™ Instruction Manual Page 15
X = OFF
O = ON
#9
#8
#7
#6
#1 #2 #3 #4 #5
3 64 96 128 160 192 224 256 288 320 352 384 416 448 480
1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481
2 34 66 98 130 162 194 226 258 290 322 354 386 418 450 482
3 35 67 99 131 163 195 227 259 291 323 355 387 419 451 483
4 36 68 100 132 164 196 228 260 292 324 356 388 420 452 484
5 37 69 101 133 165 197 229 261 293 325 357 389 421 453 485
6 38 70 102 134 166 198 230 262 294 326 358 390 422 454 486
7 39 71 103 135 167 199 231 263 295 327 359 391 423 455 487
8 40 72 104 136 168 200 232 264 296 328 360 392 424 456 488
9 41 73 105 137 169 201 233 265 297 329 361 393 425 457 489
10 42 74 106 138 170 202 234 266 298 330 362 394 426 458 490
11 43 75 107 139 171 203 235 267 299 331 363 395 427 459 491
12 44 76 108 140 172 204 236 268 300 332 364 396 428 460 492
13 45 77 109 141 173 205 237 269 301 333 365 397 429 461 493
14 46 78 110 142 174 206 238 270 302 334 366 398 430 462 494
15 47 79 111 143 175 207 239 271 303 335 367 399 431 463 495
16 48 80 112 144 176 208 240 272 304 336 368 400 432 464 496
17 49 81 113 145 177 209 241 273 305 337 369 401 433 465 497
18 50 82 114 146 178 210 242 274 306 338 370 402 434 466 498
19 51 83 115 147 179 211 243 275 307 339 371 403 435 467 499
20 52 84 116 148 180 212 244 276 308 340 372 404 436 468 500
21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501
22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502
23 55 87 119 151 183 215 247 279 311 343 375 407 439 471 503
24 56 88 120 152 184 216 248 280 312 344 376 408 440 472 504
25 57 89 121 153 185 217 249 281 313 345 377 409 441 473 505
26 58 90 122 154 186 218 250 282 314 346 378 410 442 474 506
27 59 91 123 155 187 219 251 283 315 347 379 411 443 475 507
28 60 92 124 156 188 220 252 284 316 348 380 412 444 476 508
29 61 93 125 157 189 221 253 285 317 349 381 413 445 477 509
30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510
31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 511
DMX DIP Switch Settings
DIP SWITCHES
OOO OOX OO OXX X X X X X
OOO OOOO OX X XXX X X X
OXO XOO XX OOX X X XOO
XOX XOO OX OXX O X O X O
OXXXX
X O X O X
O X X O X
XXXOX
OOOX X
X O O X X
XXOXX
O O X X X
XOXXX
O X O X X
X OOOX
O O X X O
XOXXO
OXXXO
XXXXO
OOOOX
OX OOX
X X O O X
OOX OX
XXXOO
OOOOO
X OOOO
OX OOO
X X O O O
OOX OO
X O X O O
O X X O O
OOOX O
X O O X O
O X O X O
XXOXO
XXXXX
DMX Address
DMX Address
DMX Address Quick Reference Chart
Dip Switch Position
Dip Switch Position
The center numbers of this chart (1-511) represent a DMX address. The "X"'s
and "O"'s along the top and side of the chart represent dip switch poistion ("X"
for off and "O" for on). Find your desired DMX address from the center chart.
Identify the position for dip switches 1-5 from the chart on the left and dip
switches 6-9 from the chart on the top. Adjust the dip switches on your fixture
to match the position settings of the chart. For fixtures with 10 dip switches;
dip switch 10 is reserved for special functions.
This chart list the DMX dip switch setting for DMX address 1 through
511. Follow the instructions below to configure fixture dip switches
with your desired DMX address.
ScanTron™ DMX Dip Switch Chart
©American DJ®
A Division of the American DJ® Group of Companies
World Headquarters:
4295 Charter Street Los Angeles, CA 90058 USA
Tel: [phone] Fax: [phone]
Web: www.americandj.com E-mail: [email protected]
Model:
ScanTron™
Voltage*:
120v/60Hz or 220v/50Hz
Lamp:
LL-ELC, 24v/250w
Dimensions:
19.75”(H) x 7.5”(W) x 6”(D)
500mm x 200mm x 155mm
Colors:
11 Plus White
Gobos:
14, Plus Spot
Weight:
25 Lbs.
Fuse:
5A (120v) / 3A (220v)
Duty Cycle:
None
DMX:
5 Channels
Sound Active:
Yes
Working Position:
Any Safe, Secure Position
Warranty:
1 Year (365 days)
*Voltage is preset at the factory and is not user selectable
Please Note:
Speci cations and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
ScanTron™ DMX Dip Switch Chart
