e-conolight E-XML1RCW User manual
Instructions for LED Emergency Lighting Fixture
IMPORTANT：
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
FLEXIBLE CONDUIT ONLY
INSTALLATION (J-BOX MOUNTING)
INSTALLATION (CONDUIT )
WARNING:
Let the battery charge up for at least 24 hours.Then normal operation of
this unit should take effect . To check, press the " TEST " button . The
LED lamps on the unit should turn ON. During an electrical power failure,
the led lamps will automatically come on for a minimum of 90 minutes. In
accordance with NFPA 101, your emergency lighting system must be
tested monthly for a minimum of 30 seconds and annually for 90 minutes.
Refer to your local codes for any additional requirements that may apply.
When using electrical equipment, basic safety precautions should always be followed including the following:
1. Do not use outdoors.
2. Equipment should be mounted in locations and at heights where it will not be subject to tampering by unauthorized personnel.
3. Do not mount near gas or electric heaters.
4. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
5. Do not use this equipment for anything other than its intended use.
6. Servicing of this equipment should be performed by qualified personnel.
7. Disconnect AC power before servicing.
1. Feed fixture leads through the back plate and connect to AC power supply (Fig A). For 120V use black and white wires and
for 277V, use red and white wires.
2. Attach back plate to J-Box and secure with screws.
3. Complete the battery connection. (Fig. B)
4. Align snaps and push housing directly onto the back plate (Fig. C). Apply continuous AC power and press "TEST" button
to check light.
1. Secure back plate to wall surface . Route wires through hole in conduit flange and make conduit connection. For 120V,
use black and white wires and for 277V, use red and white wires.
2. Complete the battery connection (Fig. B).
3. Align snaps and push housing directly onto the back plate (Fig. C). Apply continuous AC power and press "TEST" button to
check light.
Unused wires must be capped using enclosed wire nuts.
Fig.A (J-Box) Fig.B Fig.C
BATTERY CONNECTOR
PLUG IN
LED
POWERED!
Page 1 of 2
OPERATION
WIRING DIAGRAM
REGULAR
REMOTE CAPABLE
1. During an electrical power failure, the LED lamps will automatically come on for a minimum of 90 minutes.
2. To test, depress the "TEST" switch. The emergency LED lamps will illuminate. When the switch is released, the lamps will
go off.
BLUE(-)
YELLOW(+)
BLUE(-)
BLUE(-)
YELLOW(+)
LAMP
YELLOW(+)
LAMP
READY
TEST
BATTERY
RED
BLACK
RED
BLACK
WHITE
277V
120V
0V
CHARGER
BOARD
LAMP
READY
TEST
BATTERY
RED
BLACK
RED
BLACK
WHITE
277V
120V
0V
LAMP
YELLOW(+)
BLUE(-)
YELLOW(+)
BLUE(-)
CHARGER
BOARD
AC INPUT CONNECTOR
(MOUNTING PLATE)
AC INPUT CONNECTOR
(MOUNTING PLATE)
Note:
Unused input lead must
be properly insulated with
wire nut or other approved
method.
Note:
Use 18-22 AWG stranded
wire to connect remote lamp
heads.
TO REMOTE
Page 2 of 2
SELF‐DIAGNOSTICSTESTING:
1) Introduction
OncetheunitisproperlyinstalledaccordingtotheInstallationinstructionsheetandACpowerissupplied,theEXITwillcome
ON.Thedual‐colorLEDindicatorwillalsocomeON,automaticallyinitiatingtheself‐diagnostictestfunction.TheLEDindicator
pointsoutthecurrentunitstatus.ASTEADYGREENontheLEDindicatorindicatesanormalservice;BLINKINGGREEN
indicatesthattheunitisintestingmode;GREEN/REDFLASHINGindicatesthatthebatteryischarging;RED(STEADYand
BLINKING)wouldindicateafaultoraservicealert.Refertosection3–FaultIndicationformoredetails.TheLEDindicator
wouldbeOFFwhentheunitisinEmergencymode.
2) Self–DiagnosticService
Theself‐diagnosticfunctionisfactorypresetwithoutanyfieldadjustment.Theautomaticself‐diagnosticfeatureservesthe
followingtests–
a. On‐linerealtimemonitoringofbatteryandlamps:Identifiesbatterycharging,disconnectionandfailurealongwithlamp
failure.
b. Self‐testinganda30‐seconddischargeonceevery30days(conformingtoNFPAcoderequirements),afterACpowerhas
beensuppliedforaminimumof24hours.
c. Self‐testinganda30‐minutedischargeonceevery180days,afterACpowerhasbeensuppliedforaminimumof24hours.
d. Self‐testinganda90‐minutedischargeonceevery365days(conformingtoNFPAcoderequirements),afterACpowerhas
beensuppliedforaminimumof24hours.
3) FaultIndication
FunctionLEDIndication
UnitisinnormalmodeSTEADYGreen
BatteryDisconnectedSTEADYRed
BatteryRechargeRedandGreen(flashingalternatively)
BatteryRechargeFailure* FLASHINGRed
BatteryFailure** RedBLINKING‘2’times
LAMPFailure RedBLINKING‘4’times
RemoteLAMPFailure RedBLINKING‘5’times
*AbatteryrechargefailurewillcomeupifthebatteryisNOTabletorechargewithinthe24hrschargingtime
**AbatteryfailurewillcomeupifthebatteryisNOTabletooperatethelampsfortheperiodofadischargetest
4) ManualTesting
Thisunitalsoprovidesformanualtestingbypushingthetestswitchinaspecificpattern.Thedifferentpatternsandthe
resultingtestsarelistedinthetablebelow.
ACTIONREACTIONANDLEDINDICATION
Pushtestbuttononce(within2seconds)30‐secondtest;FLASHINGGreen
Pushtestbutton‘2’times(within2seconds)30‐minutetest;GreenBLINKING‘2’times
Pushtestbutton‘3’times(within2seconds)90‐minutetest;GreenBLINKING‘3’times
Push&Holdtestbutton(3‐5seconds)SystemInterruption
Push&Holdtestbutton(morethan6seconds)SystemReset
5) Operation
Duringanelectricalpowerfailure,thelampswillautomaticallycomeONforaminimumof90minutes.Totestthisunit,the
batteryneedstobechargedinitiallyfor2hoursbeforedepressingthetestswitch(todomanualtest).Onpressingthetest
switch,theLampswillilluminate.TheLampswillturnOFFafter30‐sec/3 0 ‐min/90 ‐mindependingonthenumberoftimes
theswitchhasbeenpressed.
