Modern Forms WS-24718 User manual

1Modern Forms retains the right to modify the design of our products at any time as part of the company's continuous improvement program.
modernforms.com
Phone [phone]
Fax [phone]
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
Central Distribution Center
1600 Distribution Ct
Lithia Springs, GA 30122
Western Distribution Center
1750 Archibald Avenue
Ontario, CA 91760
HARDWARE
WARNING
IMPORTANT: NEVER attempt any work without shutting o the electricity.
- Read all instructions before installing.
- System is intended for installation by a qualied electrician in accordance with the National Electrical Code and local regulations.
- Go to the main fuse box, or circuit breaker. Place the main power switch in the“OFF”position and unscrew the fuse(s) or switch ”OFF”
the circuit breaker switch(es) that control the power to the xture or room that you are working on.
- Place the wall switch in the“OFF”position.
CAUTION
- All parts must be used as indicated in these instructions. Do not substitute any parts, leave parts out, or use any parts that are
worn out or broken. Failure to follow this instruction could invalidate the ETL/CETL listing of this xture.
CAUTION When handling the xture, do not apply pressure to the LEDs. Hold the xture by the base only.
AVERTISSEMENT
IMPORTANT : Coupez l’électricité avant TOUTE manipulation.
- Lisez toutes les instructions avant d’installer.
- Système est destiné à être installé par un électricien qualié en conformité avec le code national de l’électricité et les
règlements locaux.
- Accédez au panneau central de disjoncteurs ou de fusibles de votre demeure et placez l’interrupteur principal en position d’arrêt
(« OFF »).
- Placez l’interrupteur mural en position d’arrêt (« OFF »).
MISE EN GARDE
- Toutes les pièces doivent être utilisées tel qu’il est indiqué dans ces instructions. Ne remplacez pas les pièces, n’en laissez pas de côté
et ne les utilisez pas si elles sont usées ou brisées. Le non-respect de ces instructions peut annuler l’homologation ETL/CETL du
luminaire. MISE EN GARDE Ors de la manipulation de l’appareil, ne pas appliquer de pression à la LED, tenir l’appareil par la seule base.
ADVERTENCIA
IMPORTANTE: NUNCA intente hacer trabajos sin desconectar el suministro eléctrico.
- Lea y comprenda todas las instrucciones e ilustraciones por completo antes de proceder con el ensamblaje e insta lación de esta
lámpara.
- Sistema está disenado para ser instalado por un electricista calicado, de acuerdo con el código eléctrico nacional y las normas locales.
- Diríjase a la caja de fusibles o a la caja del interruptor de circuito principal en su hogar. Coloque el interruptor de ali mentación
principal en la posición “OFF”(APAGADO).
- Coloque el interruptor de la pared en la posición“OFF”(APAGADO).
PRECAUCIÓN
- Todas las piezas deben usarse como lo indican estas instrucciones. No reemplace las piezas, noomita piezas durante la instalación ni
utilice piezas gastadas o rotas. El incumplimiento de esta indicación podría invalidar la calicación
ETL/CETL esta lámpara. PRECAUCIÓN Al manipular el aparato, no aplique presión a los LED, mantenga el aparato en la base sólo.
INSTALLATION INSTRUCTION
247 - LED Vanities & Wall Sconces
WS-24718, WS-24727, WS-24736
Wire
Connector
Qty: 3 pcs
+ 1 Extra
7EAC112201
P1
Junction
Box Screw
Qty: 2 pcs
+1 Extra
7MPF0825C1
#8-32x1
Nickel Plating
Mounting
Screw
Qty: 1 Extra
7MPF0412S1
5/32-32x1/2
Nickel Plating
Plastic
Anchor
Qty: 2 pcs
+1 Extra
7TDD082401
Wood
Screw
Qty: 2 pcs
+1 Extra
7MPF2204J2
Ø4x22
Driver
Qty: 1 pc
4LD-700MA28U-IS-P
Mounting
Ring
Qty: 1 pc
7MBC101501
Screw
Qty: 2 pcs
+1 Extra
7MPF0415C2
#8-32x9/16
SS
Spacer
Qty: 2 pcs
+1 Extra
7MBD076401
Conversion
Plate
Qty: 1 pc
7MBA151110 (18")
4MBA171110BA (27")
4MBA201104BA (36")
Wire
Connector
Qty: 2 pcs
+1 Extra
7EAC140901
P3
A1 B1 C1 D1 E1 F1 G1 H1 I1 J1 K1

2Modern Forms retains the right to modify the design of our products at any time as part of the company's continuous improvement program.
modernforms.com
Phone [phone]
Fax [phone]
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
Central Distribution Center
1600 Distribution Ct
Lithia Springs, GA 30122
Western Distribution Center
1750 Archibald Avenue
Ontario, CA 91760
INSTALLATION INSTRUCTION
247 - LED Vanities & Wall Sconces
WS-24718, WS-24727, WS-24736
Spacer
Wood Screw
Mounting Screw
Back Plate Dimensions
Wire Connector
Plastic Anchor Mounting
Screw
Wire Connector
Junction Box Screw
Wood Screw
Mounting Ring Dimensions
Screw
Plastic Anchor
Driver
Junction Box Screw
Conversion Plate
Driver
Mounting Plate
Mounting Ring
Wire Connector
Wire Connector
Mounting Plate
Junction Box
Switch Box
I1
E1
C1
K1
D1 C1
K1
B1
E1
H1
D1
F1
B1
J1
F1
G1
A1
A1
FIG. 1 JUNCTION BOX
FIG. 2 SWITCH BOX
Ø 3 1/4"
Ø 2 3/4"
3"
WS-24718: 11 13/16"
WS-24727: 17 5/16"
WS-24736: 22"
WS-24718: 17 7/8"
WS-24727: 26 7/8"
WS-24736: 35 7/8"
1 3/4"
1 1/8"

3Modern Forms retains the right to modify the design of our products at any time as part of the company's continuous improvement program.
modernforms.com
Phone [phone]
Fax [phone]
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
Central Distribution Center
1600 Distribution Ct
Lithia Springs, GA 30122
Western Distribution Center
1750 Archibald Avenue
Ontario, CA 91760
INSTALLATION INSTRUCTION
247 - LED Vanities & Wall Sconces
WS-24718, WS-24727, WS-24736
PREPARATION
1. Shut o the power at the circuit breaker and remove existing xture, including the crossbar.
2. Carefully unpack your new xture and lay out all the parts on a clear area. Be careful not to lose any small parts necessary for installation.
INSTALLATION
MOUNT ON SWITCH BOX (Fig. 1)
3. Remove the mounting screws (C1) from the xture.
4. Drill holes in the wall aligned with the key hole located in the mounting plate, insert the plastic anchor (D1).
5. Connect the driver (F1) input wire to switch box wires as shown in Fig. 3, making sure that all wire connectors (A1) are secured.
If your outlet box has a green or bare cooper ground wire, connect the xture’s ground wire to it. Otherwise, connect the xture’s ground
wire directly to the back plate using the green screw provided. After wires are connected, tuck them carefully inside the switch box.
*Required Driver to be recessed within the switch box.
6. Secure the mounting plate to the switch box using the junction box screws (B1), fasten it to the wall using wood screws (E1) and
spacers (I1). The side of the mounting plate marked “GND”must face out.
7. Pull-out the driver’s output wire, secure it to xture wire as shown in Fig. 3. making sure that all wire connectors (K1) are secured.
8. Place the xture over the mounting plate, and secure it with mounting screws (C1).
OR
MOUNT ON JUNCTION BOX (Fig. 2)
3. Remove the mounting screws (C1) from the xture.
4. Drill holes in the wall aligned with the key hole located in the mounting plate, insert the plastic anchor (D1)
5. Connect the driver (F1) input wire to junction box wires as shown in Fig. 3, making sure that all wire connectors (A1) are secured.
If your outlet box has a green or bare cooper ground wire, connect the xture’s ground wire to it. Otherwise, connect the xture’s ground
wire directly to the back plate using the green screw provided. After wires are connected, tuck them carefully inside the switch box.
*Required Driver to be recessed within the junction box.
6. Secure the mounting ring (G1) to the junction box using the junction box screws (B1). Make sure the two holes (Spacing 2-3/4”) are
horizontal as shown in Fig. 2. The side of the mounting plate marked“GND”must face out.
7. Secure the mounting plate and conversion plate (J1) to the mounting ring with screws (H1). Fasten the mounting plate to the wall using
wood screws (E1) and spacers (I1).
8. Pull-out the driver’s output wire, secure it to xture wire as shown in Fig. 3, making sure that all wire connectors (K1) are secured.
9. Place the xture over the mounting plate, and secure it with mounting screws (C1).
Fixture Wires
Black or
Smooth
Fixture Wires
White or
Ribbed
Fixture Wires
Bare wire
(Ground)
House Wires
Black
(Hot)
House Wires
White
(Neutral)
House Wires
Green or Bare Copper
(Ground)
Fig. 3 Wiring
