MoDRN 8682M User manual

ASSEMBLY INSTRUCTIONS
Model: #8682M
MōDRN Retro Glam Marion Sleigh Base Media Console
1/20
Lot Number: _________________
Date of Purchase: ___ / ___ / ____
Manufactured by: Dimensions Furniture, Inc
341 Gradle Drive, Carmel, IN 46032
1-866-528-8364 / [email protected]
WARNING The maximum load capacity as listed above may not be exceeded and is assumed
to be distributed evenly. Exceeding load capacity may result in collapse and possible injury.
!
THIS INSTRUCTION BOOKLET CONTAINS IMPOR TANT SAFETY INFORM ATION. PLEASE READAND KEEP FOR FUTURE REFERENCE.
Thank you for your purchase. We want to make sure it is to your complete satisfaction. Hardware is separated individually for easy
Maximum load distributed
evenly, including television.
(Television: 50 lbs max. weight.)
100 lbs
Your satisfaction is our top priority. Our products are designed and manufactured to meet the highest quality. In the event that
you have assembly questions, or parts are missing or damaged, please do not return the product.
Our customer service department would appreciate the opportunity to provide any help necessary regarding assembly and to
provide any necessary parts.
If any parts are missing or defective please contact our customer service department.
all present.
Each shelf has a 25 lbs
Maximum Load, distributed evenly.
25 lbs
Customer Service - 1-866-528-8364 / [email protected]

!
Assembly should take place in a secure environment that is clean and dry.
Assembly can be done by one person, but two persons are recommended.
Allen wrench available for assembly.
Please check that all parts and hardware are included before beginning assembly.
Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or
hardware.
Please use CAUTION AND CARE WHEN LIFTING the product.
Never stand on the item or use it as a ladder.
Periodically re-tighten all exposed hardware.
If any parts become missing, damaged, or worn, discontinue use until they are replaced with identical parts.
l
l
l
l
l
l
l
l
l
l
CAUTION ! Please read below statements before beginning assembly.
PRE-ASSEMBLY PREPARATION:
2/20
HARDWARE LIST
8pcs
Wood Dowel
Long Bolt with Washers
(1/4” x 1-1/4”)
Medium Bolt
(1/4”x1”)
8pcs
Short Bolt with Washers
(1/4”x5/8”)
20pcs
Round-Head Screw 24pcs
Hinge 4pcs
Flat-Head Screw 24pcs
Round-Head Bolt 8pcs
16pcs
3
1
2
4
5
6
7
8

PRE-ASSEMBLY PREPARATION:
9
10
Left Handle 1pc
Right Handle 1pc
11 Shelf Pin 12pcs
HARDWARE LIST
12 Magnet 1pc
13 Metal Plate 2pcs
14 Small Flat-Head Screw 2pcs
15 Allen Wrench 1pc
PARTS LIST
C
B
D
Top Panel
Right Frame
Left Frame
Left Side Panel
1pc
1pc
1pc
1pc
A
3/20

PRE-ASSEMBLY PREPARATION:
4/20
PARTS LIST
IJ
Back Panel Left Door 1pc
1pc
KL
Right Door Central Leg 2pcs
2pcs
1pc
MN
Middle Shelf Side Shelf
1pc
G
F
H
Right Side Panel
Right Divider
Left Divider
Bottom Panel
1pc
1pc
1pc
1pc
E

Lay the Right Door on a at surface with the backside facing up as shown. Place the circular portions of the Hinges
into corresponding recessed areas on the door. Fasten each Hinge to the Right Door using two Flat-Head Screws
as shown. NOTE: Do not over tighten
STE P-BY-STEP ASSEMB LY
7Flat-Head Screw x4
6Hinge x2
K
6
7
5/20
Step 1 K
K
7
6
6

Fasten a Metal Plate to the corner of the Right Door using a Small Flat-Head Screw as shown.
NOTE: Do not over tighten
STE P-BY-STEP ASSEMB LY
13 Metal Plate x1
14 Small Flat-Head Screw x1
K
13
14
6/20
Step 2 K
13 14

Fasten the Right Handle to the Right Door using four Round-Head Bolts as shown. Leave bolts loose until all
bolts are properly inserted into the handle, then tighten evenly. NOTE: Do not over tighten
Repeat Steps 1, 2 & 3 for the Left Door . After the Right & Left Door Assemblies are complete, place them aside and
begin the Media Console Assembly.
STE P-BY-STEP ASSEMB LY
7/20
10 x1
8
8
Round-Head Bolt x4
Right Handle
K
10
Step 3
J
K
10 8

Begin the Media Console Assembly by laying the Top Panel on a at surface with the holes facing up. Insert eight
Dowels into the Top Panel in the hole locations shown below. Join the Right Side Panel , Left Side Panel , Right
Divider & Left Divider to the Top Panel by aligning the corresponding holes of the Side Panels & Dividers to the
Dowels in the Top Panel and pushing down rmly until the Side Panels & Dividers make contact with the Top Panel.
STE P-BY-STEP ASSEMB LY
1
1
1
Wood Dowel x8
E
AA
G
F
F
D
8/20
Step 4
GF
ED
A
A
A
1

Fasten the Left Panel , Right Panel , Left Divider & Right Divider to the Top Panel with the provided Allen
Wrench using eight Long Bolt with Washers in the locations shown.
NOTE: Do not over tighten
STE P-BY-STEP ASSEMB LY
6/18
15
15
Allen Wrench x1
2
2
Long Bolt with Washers
(1/4” x 1-1/4”) x8
E
A
F
G
D
9/20
Step 5 GFED A
15 2

Attach the Magnet to the Top Panel by aligning the holes on the Magnet to the pre-drilled holes on the Top
Panel . Fasten them together using two Round-Head Screws . NOTE: Do not over tighten
STE P-BY-STEP ASSEMB LY
5Round-Head Screw x2
12 Magnet x1
A
5
12
10/20
Step 6
A
A 1212
5

Insert eight Dowels into the Side Panels and Dividers in the hole locations shown below. Join the Bottom
Panel to the Side Panels and Dividers by aligning the corresponding holes of the Bottom Panel to the Dowels in the
Side Panels and Dividers and pushing down rmly until the Bottom Panel makes contact with the Side Panels and
Dividers.
STE P-BY-STEP ASSEMB LY
1Wood Dowel x8
A
H1
E
G
F
D
1
H
F
11/20
Step 7
H
G F
E D1

STE P-BY-STEP ASSEMB LY
15
15
Allen Wrench x1
2
2
x8
Long Bolt with Washer
(1/4”x1-1/4”)
Fasten the Bottom Panel to the assemby with the Allen Wrench using the Medium Bolt with Washer in the
locations shown.
NOTE: Tighten Evenly. Do not over tighten
H
12/20
Step 8 H 15 2

Insert two Wood Dowels into the Left frame , as shown below. Align the corresponding holes on the Left Frame
and Left Side Panel & fasten them together with the Medium Bolt using an Allen Wrench . Repeat this step for
attaching the Right Frame to the Right Side Panel .
NOTE: Tighten Evenly. Do not over tighten
B
E
D
STE P-BY-STEP ASSEMB LY
15 Allen Wrench x1
3x8
Medium Bolt
(1/4”x1”)
15
3
D
B
C
13/20
Step 9
E
D
C
B
153
1Dowel x4
1
3 B

Attach both Central Legs to the assembly, as shown, using eight Short Bolts with Washers . Be sure to leave bolts
loose until each bolt is inserted properly then go back and tighten evenly. NOTE: Do not over tighten.
With help, ip the console table upright.
STE P-BY-STEP ASSEMB LY
15 Allen Wrench x1
4x8
Short Bolt with Washers
(1/4”x5/8”)
L
L
4
15
14/20
Step 10 L 4

Attach the Back Panel to the assembly, as shown, using twenty-two Round-Head Screws . Start at the corners and
leave screws loose until the back panel ts inside the recessed area on the case, then go back and tighten evenly.
NOTE: Do not over tighten.
STE P-BY-STEP ASSEMB LY
5Round-Head Screw x22
15/20
Step 11 I 5
5
I

STE P-BY-STEP ASSEMB LY
16/20
11 Shelf Pin x12
11
11
11
Step 12 There are 3 shelf heights: High, Middle & Low. Insert four Shelf Pins at the same height (middle height shown) to
support each shelf.

M
STE P-BY-STEP ASSEMB LY
Insert & place the Middle Shelf on top of the shelf pins in the location shown below.Step 13 M
17/20

Fasten the Right Door and Left Door to the assembly with Flat-Head Screws in the locations shown below.
Leave the screws loose until the doors are parrallel to the Top and Bottom Panels of the case then tighten evenly. Note:
Do not overtighten. It may also be necessary to adjust the bind between the divider and the door using the Bind
Adjustment Screw and/or the gap between the two doors using the Gap Adjustment Screw as shown below.
STE P-BY-STEP ASSEMB LY
18/20
7Flat-Head Screw x16
Bind
Adjustment
Screw
Gap Adjustment
Screw
J
K
7
Step 14 J
K7

Insert & place the Side Shelves on top of the shelf pins in the locations shown below.
STE P-BY-STEP ASSEMB LY
19/20
N
N
Step 15 N

STE P-BY-STEP ASSEMB LY
Dimensions Furniture, Inc
341 Gradle Drive, Carmel, IN 46032
1-866-528-8364 / suppor[email protected]
LIMITED ONE YEAR WARRANTY
Warranty available to original purchaser only. Proof of purchase is required. This warranty is your sole remedy
for product defect and does not cover damage due to mishandling, misuse, or abuse. The manufacturer is not
responsible for incidental or consequential damages.
20/20
Step 16 Assembly is now complete.
It may be necessary to raise or lower leg height to
eliminate wobble. Rotate the adjustable foot glides right
to lower. Rotate left to raise. RAISE LOWER
