Modt i975Xa- YDG Installation guide

AOpen reserves the right to revise all the specifications and information contained in this
document, which are subject to change without notice.
Speaker Out
RJ45 LAN Jack
Line-In
MIC-In
Rear Surround
Sub-woofer
USB 2.0 Ports
Side Surround
IEEE 1394 Port
PS2 Mouse
PS2 Keyboard Serial ATA II S/PDIF In
S/PDIF Out
i975Xa– YDG
i975Xa– YDG
FDD Connector
Power Master II Connector
Power Switch Connector
Reset Switch Connector
Front Panel Connector
USB 2.0 Connector x 2
Power Master Ready II LED
IEEE 1394 Connector
Front Audio Connector
32-bit PCI Expansion Slot x 2
Stand by LED
COM Connector
PCI Express x 1 Slot x 2
Printer Connector
Realtek HDA CODEC
Marvell Gigabit LAN Chip
JP28 PS2 KB/Mouse Wakeup Jumper
4-pin 12V ATX Power Connector
1x4 Peripheral Connector
J4, J5 Front Side Bus Frequency Jumper
PCI Express x16 Slot x 2
479 PIN Socket Supporting Intel Core
Due/Solo Processor
Intel 975X / ICH7
CPU Fan Connector
240-pin DDR II DIMM x 4
Boot LED
24-pin ATX Power Connector
System Fan1 Connector
ATA100 IDE Connector
Serial ATA II Connector x 4
ATA133 IDE Connector x 2
JP14 CMOS Data Clear Jumper
CD_In Connector
Power Fan Connector
Power Master II Jumper
May the Dual Force be with you

Easy Installation Guide x 1
Enhanced Full Pictured Manual x 1
80-Wire IDE Cable x 1
Floppy Drive Cable x 1
Serial ATA Cable x 1
Serial ATA Power Cable x 1
Hot Plug Serial ATA Cable x 1
Back Panel I/O Shield x 1
CPU Cooler x 1
IR Receiver x 1
IR Remote Control x 1
Bonus Pack CD x 1
ITE IDE RAID Driver Diskette x 1
PART NO: 49.8EM0E.EE10 DOC. NO: I975XAYDG-EG-E0601A
Everything you need is included in
this Easy Installation Guide. For
more information, please refer to
our complete User's Manual in the
Bonus Pack CD.
1. Installing CPU
2. Installing CPU Fan
3. Installing
Memory Module
4. Installing HD,
CD-ROM and SATA
6. Connecting ATX
Power Cable
5. Connecting Front
Panel Cable
7. Installing PCI Express x16
Graphics card & PCI Express
x1 Cards & PCI Cards
8. Installing Other
Devices (USB, Front
Audio, etc)
9. Connecting
Back Panel Ports
(Keyboard, Mouse,
etc)
10. Enter BIOS
setup and setting
CPU Frequency
11. Installing Operating
System such as
Windows XP
12. Installing Drivers & Utilities
Before You Start
Installing By Yourself
Accessory Checklist

4
5
6
1
This socket supports uFCPGA package CPU, which is the latest Yonah Core Duo/Solo
CPU package developed by Intel.
1. Unscrew socket screw counter- clockwise.
2. Locate Pin 1 in the socket and look for a
golden arrow on the CPU upper interface.
Match Pin 1 and golden arrow. Then insert
the CPU into the socket.
3. Lock the socket screw clockwise to fasten
CPU.
Socket Screw
Pin 1
2
Paste the Glue on the center of
Cooler’s back side.
Plug CPU cooler power cable
into power connector.
1. Place CPU cooler properly into CPU retention
2. Plug CPU holder x 2 properly into CPU retention
1. Press CPU holder x 2 in the same time
2. Hook CPU Holder with the hole of retention to
fix CPU cooler
3
DIMM slots are designed in black and navy blue
which are very easy to recognize. Insert the module
straight down to the DIMM slot with both hands and
press down firmly until the DIMM module is securely
in place.
Note: The tabs of the DIMM slot will close-up to hold the
DIMM in place when the DIMM touches the slot’s bottom.
External Hot Plug SATA HDD:
1. Plug SATA cable to onboard External
SATA Connector properly
2. Plug SATA cable to SATA HDD
1. Plug IDE cable into IDE connector with IDE HDD
2. Take care the direction of cable to meet the hole in IDE slot
Internal SATA HDD Connection:
1. Plug SATA cable to onboard internal
SATA Connector properly
2. Plug SATA cable to SATA HDD
3. Plug Power connector to SATA HDD
Power Switch
1
Front Panel Connector
GND
Power LED-
GND
Power LED+
GND
NC
GND
RESET
GND
NC
NC
+5V
HDD LED
HDD LED
+5V
+5V
GND
NC
SPEAKER
Attach the power LED, speaker, and reset switch
connectors to the corresponding pins. If you enable
“Suspend Mode” item in BIOS Setup, the ACPI &
Power LED will keep flashing while the system is in
suspend mode. Locate the power switch cable from
your ATX housing. It is
2-pin female
connector from the
housing front panel.
Plug this connector to
the soft-power switch
connector marked
1. Plug CPU power 4pins cable to CPU power connector
2. Plug ATX power cable to power connector on board
Above two cables and connector had directional
mechanism. Please plug it according it. If not plug or not
plug properly, the MB will not work.

After you finish the setting of
jumpers and connect correct
cables. Power on and enter
the BIOS Setup, press <Del>
during POST (Power On Self
Test). Choose "Load
Optimized Defaults" for
recommended optimal
performance.
You can use the auto-run menu of Bonus CD disc.
Choose the utility and driver from the icons at left
side, and then click on the “GO” button to complete
installation automatically.
7
10
8
12
11
9
1. Please plug ATX 4Pin Power to the onboard 4 Pins peripherals
connector. It is recommend and must plug while you want to use one
or two PCI Express VGA. This power can provide extra power from
power supply to make sure all peripherals run well. It is POWER IN
connector.
2. Plug PCI Express VGA card properly
3. This MB allow you plug two PCI Express x 16 VGA cards
1. Install remote control’s battery. Please
reference right side picture 1,2,3
2. Install remote control IR senor. Please plug
the sensor’s cable on the Power Master
connector properly. Notice sensor must had
no barriers to block IR signal receive. Please
reference Left top pictures for IR sensor
install
IR Sensor
1
2
3
Speaker Out
RJ45 LAN Jack
Line-In
MIC-In
Rear Surround
Sub-woofer
USB 2.0 Ports
Side Surround
IEEE 1394 Port
PS2 Mouse
Serial ATA II
S/PDIF In
S/PDIF Out
PS2 Keyboard
i975Xa-YDG provided back panel connectors to
connect PS/2 devices/ SATA HDD (Hot Plug)/ USB2.0
x 4/ 1394 devices/ Gigabit Ethernet Lan/ SPDIF IN/
OUT/ 7+1 Audio Racks
Install utility
Browse
Read me
Exit
Install driver
Click to install
Power-on and Loading BIOS Setup
Del
Window XP is default OS which
i975Xa-YDG design for. Please
install the Window XP according
Microsoft’s standard procedure.

CPU & System & Power Fans Connectors
Note: Some CPU fans
do not have sensor pin so
they cannot support fan
monitoring.
Plug in the CPU fan cable to the 4-pin CPUFAN connector. If you
have a chassis fan, you can also plug it in PWRFAN or SYSFAN1
connector.
Sensor
+12V
GND
Sensor
+12V
GND
PWR FAN
POWER FAN
Connector
Sensor
+12V
GND
System FAN
Connector
CPU FAN
Connector
SYSFAN1
CPUFAN
Primary Slave (2nd)
Primary Master (1st)
Connecting IDE and Floppy Cables
Connect 34-pin floppy cable and 40-pin, 80-wire, IDE cable to floppy
connector and IDE connector respectively Be careful of the pin1
orientation. Wrong orientation may cause system damage.
PIN 1
FDD Connector
PIN 1
ATA 133 IDE3/IDE2 Connector
ATA 100 IDE1 Connector
Connecting USB 2.0
This motherboard provides eight USB 2.0 ports for USB devices
such as mouse, keyboard, modem, printer, etc. There are four
ports on the back panel. You can use proper cables to connect
between Front USB connector and USB modules or chassis front
With IEEE1394 Chip on board (AGERE 1394), having its data transfer rate up
to 400Mb/s, this interface can connect to devices that require high data
transferring performance such as digital camera, scanner or others IEEE 1394
devices. Please use appropriate cables to connect IEEE1394 devices.
1394 Connector
1 2
TPA-
GND
TPB-
TPA
GND
SHIED GND
IEEE 1394 Connector
+12V (Fused)
TPB+
+12V (Fused)

JP14 Clear CMOS
You can clear CMOS to restore system default setting. Follow the procedure below.
Turn off the system and unplug the AC power.
Remove ATX power cable from connector PWR3.
Locate JP14 and short pins 2-3 for a few seconds.
Return JP14 to its normal setting by shorting pin 1 & pin 2.
Connect ATX power cable back to connector PWR3.
Normal
(Default)
Clear CMOS
1
1
Front Audio Connectors
Tip: When should I Clear CMOS?
1. Boot fails because of over-clocking…
2. Forget password…
3. Troubleshooting…
If the housing has been designed with an audio port on the front panel, you’ll be able to
connect onboard audio to front panel through this connector. By the way, please remove 5-6
and 9-10 jumper caps from the Front Audio Connector before connecting the cable. Please do
not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on the front panel.
JP28 Keyboard/Mouse Wakeup Jumper
This motherboard provides keyboard / mouse wake-up function. You can use JP28 to enable or
disable this function, which could resume your system from suspend mode with keyboard or
mouse. The factory default setting is “Disable” (1-2), and you may enable this function by setting
the jumper to 2-3.
Front_IO_Plug
AUD_GND
1
Front Audio Connector
KEY
AUD_FPOUT_L
Front_IO_Sense
AUD_FPOUT_R
AUD_MIC_R
AUD_MIC_L
AUD_RET_L
AUD_RET_R
Setting CPU Core Voltage
This motherboard supports Voltage ID (VID) function to detect CPU voltage automatically
during power-on.
Setting CPU Frequency
This motherboard is CPU jumper-less design, set CPU frequency through 1MHz stepping CPU
Overclocking in the BIOS. CPU Core Frequency = CPU external frequency x CPU Ratio.
However, all CPU now selling in the market belong to "Fixed Multiplier". That means users can
not adjust the CPU Ratio but only change CPU FSB clock to achieve over-clocking.
(Users do the over- clocking at their own risk!)
BIOS Setup > Frequency / Voltage Control > CPU Bus Frequency
Processor
Number
Architectur
e
Clock
Speed
Front
Side
Bus
Cache Rati
o
Core Duo T2700 65nm 2.33GHz 667MHz 2MB L2 14
Core Duo T2600 65nm 2.16GHz 667MHz 2MB L2 13
Core Duo T2500 65nm 2GHz 667MHz 2MB L2 12
Core Duo T2400 65nm 1.83GHz 667MHz 2MB L2 11
Core Duo T2300 65nm 1.66GHz 667MHz 2MB L2 10
Core Solo T1400 65nm 1.83GHz 667MHz 2MB L2 11
Core Solo T1300 65nm 1.66GHz 667MHz 2MB L2 10
Note:With CPU speed changing rapidly, there might be faster CPU on the market
by the time you received this installation guide. This table is kindly for your
references only.
Tip: When you fail to over-clock, you could:
Clear CMOS (JP14) to restore the default setting.
After turning power on, press “Home” immediately until the screen
appears.
1
1
FSB 800 MHz
(take off Jumpers)
Over-Clocking
Normal
(Default)
J4
1
1 J5
B
A
This motherboard provides FSB Jumper settings for users to adjust.
AOpen recommend on “A” default to ensure MB quality
Over-clocking not guarantee by AOpen. AOpen MB design is
under intel & industry standard. Over-clocking may cause your
system unstable and damage. Please be careful on using it.
Setting CPU Voltage & Frequency
1
EnableDisable
(Default)
1

If you encounter any trouble to boot you system, follow the
procedures accordingly to resolve the problem.
Phoenix - AwardBIOS v6.00PG, An Energy Star Ally
Copyright (C) 2004, Phoenix Technologies, LTD.
i975Xa-YDG R1.01 Feb. 09. 2006 AOpen Inc.
Model Name and BIOS Version
Model name and BIOS version can be found on upper left corner of first boot
screen (POST screen). For example:
i975Xa-YDG is model name of motherboard; R1.01 is BIOS version
Register Your Motherboard
Thanks for choosing AOpen product, please take time to register the product
registration, http://club.aopen.com.tw/productreg/ This will ensure that
you can receive the most updated information from AOpen in the future.
Please prepare the following information before you start: Model Name,
Part Number (P/N), Serial Number (S/N) and Purchase Date. The
Part Number and Serial Number are printed on the bar code label. You can
find this bar code label on the outside packing or on component side of PCB.
For example:
P/N: 91.88110.201 is part number, S/N: 91949378KN73 is serial number.
Part No. Serial No.
Phoenix-Award BIOS Error Message
Beep Sound Message
1 short (Beep) System booting is normally.
1 long - 1 short (Beep) DRAM error
1 long - 2 short (Beep) Display card or monitor connected error
1 long - 3 short (Beep) Keyboard error
Long (Beep) continuous DRAM hasn't insert correctly.
Trouble Shooting

Dear Customer,
Thanks for choosing AOpen products. We invite you to register at http://
www.aopen.com to become a Gold Member of Club AOpen so as to ensure quality
service in the future. In order to maintain the best service to every customer of
us., , we recommend you to follow the procedures below and seek help from our
branches according to the region you buy the product. With your help, we can
then continue to provide efficient and the best quality service to every customer.
Thanks very much for your understanding!
AOpen Technical Supporting Team
Europe http://www.aopen.nl/tech/default.htm
Pacific Rim http://www.aopen.com.tw/tech/default.htm
China: http://www.aopen.com.cn/tech/default.htm
Germany http://www.aopen.de/tech/default.htm
America http://usa.aopen.com/tech/default.htm
Japan http://aopen.jp/tech/index.htm
China
艾爾鵬國際貿易(上海)有限公司
Tel: [phone]
Fax: [phone]
Pacific Rim
AOpen Inc.
Tel: [phone]
Fax: [phone]
America
AOpen America Inc.
Tel: [phone]
Fax: [phone]
Japan
AOpen Japan Inc.
Tel: [phone]
Fax: [phone]
Germany
AOpen Computer GmbH.
Tel: [phone]
Fax: [phone]
Europe
AOpen Computer b.v.
Tel: [phone]
Email: [email protected]
Technical Support
