Moen T2113 Series User manual

CRITICAL DIMENSIONS
(DO NOT SCALE)
T2113sp: Rev. 4/10
THIN WALL APPLICATIONTHICK WALL APPLICATION
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
7" (178mm)
ESCUTCHEON
DIAMETER
2" CC (51mm)
1 7/8" IPS (48mm)
MAX WALL
HOT
INLET
COLD
INLET
FINISHED WALL LINE
FACE OF STUD
4-1/2" (114mm)
WALL OPENING
FLOOR
45" (1143mm)/
48" (1219mm)-SHOWER
32" (813mm)-TUB OR
TUB SHOWER
7-1/2"
(191mm)
MIN.
TUB RIM
6'-6"
(1981mm)
L
C
1 3/8" (35mm)
2 1/2" MAX. (63mm)
1/2" MIN. CC (13mm)
5/8" MIN. IPS (16mm)
FLOOR LINE
1 3/8"
(35mm)
1 1/2"
(38mm)
3/16" (typ) (5mm)
PLASTER GROUND
3-1/2" (89mm) MAX.
2-1/4" (57mm) MIN.
DIAMETER
WALL
OPENING
PLASTIC
TUB/SHOWER
SURROUND
L
C
5-7/8"
(149mm)
8-3/4"
(222mm)
4-3/8"
(111mm)
DESCRIPTION
• Metal construction with various finishes identified by suffix
• Includes showerhead, arm, flange and diverter tub spout
OPERATION
• Handle operates counterclockwise through a 270° arc with off at 6 o’clock
and maximum hot at the 9 o’clock position. Shut off in clockwise direction
• Adjustable temperature limit stop to control maximum hot water
temperature
• Pressure balancing mechanism maintains selected discharge
temperature to ± 3°
FLOW
• Showerhead is limited to 2.5 gpm (9.5 L/min) at 80 psi
• EP suffix models are limited to 1.75 gpm (6.6 L/min) at 80 psi
• NH suffix models contain no showerhead
CARTRIDGE
• 1222 cartridge design
• Nonmetallic/nonferrous and stainless steel materials
• Accommodates back to back installations
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B125.1 and all applicable
requirements referenced therein
• EP suffix models are IAPMO Green listed and third party certified to
WaterSense®
• ADA for lever handle
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
• 5 year warranty if used in commercial installations
KINGSLEY™POSI-TEMP®
Single-Handle Tub/Shower Trim Kit
Models: T2111 series - valve trim only
T2112 series - shower trim only
T2113 series - tub/shower trim
Valves: 62300 series
2500 series
Specifications
EP Suffix Models Only
