Moen TS370 series User manual

CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
Valve Sold Separately
TS374sp: Rev. 10/11
C
L
7"
(178mm)
7"
(178mm)
5-1/2"
(140mm)
2-1/4"
(57mm)
4-1/2"
(114mm)
WALL OPENING
Floor Line
Finished
Wall Line
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
DESCRIPTION
- Metal construction with various finishes identified by suffix
- Includes 7” rainfall showerhead, 8" arm, flange and diverter tub spout
- For use with S932 1/2”CC valve
OPERATION
- Handle operates counterclockwise through a 270° arc with off at
6 o’clock and maximum hot at the 9 o’clock position. Shut off in
clockwise direction
- Adjustable temperature limit stop to control maximum hot
water temperature
- Pressure balancing mechanism maintains selected discharge
temperature to ± 3.6˚F( ± 2˚C)
- Hot and cold indicators on escutcheon
FLOW
- Showerhead is limited to 2.5 gpm max. (9.5 L/min)
CARTRIDGE
- 1222 cartridge design
- Nonmetallic/nonferrous and stainless steel materials
- Accommodates back to back installations
STANDARDS
- Third party certified to CSA B125, ASME A112.18.1M, ANSI A117.1,
ASSE 1016, and all applicable requirements referenced therein
-ADA for lever handles
WARRANTY
- Lifetime limited warranty against leaks, drips and finish defects to
the original consumer purchaser
- 5 year warranty if used in commercial installations
Solace™Posi-Temp®
Single-Handle Tub/Shower (Trim Only)
Models: TS370 series-valve trim only
TS372 series-shower trim only
TS374 series-tub/shower trim
Valve: S932
