Moffat MCM5FX Operating instructions

MoffatAppliances.ca
Chest–Manual
Defrost Models:
MCM5FX
MCM7FX
MCM10FX
MCM15FX
Owner’s Manual and
Installation Instructions
Food Freezers
350A4502 749 AT 11/13
Safety Instructions
How to Connect Electricity . . . . . . . .3
Proper Disposal . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . .2
Use of Extension Cords . . . . . . . . . . .2
Installation Instructions
Preparing to Install the Freezer . . . .4
Operating Instructions
Care and Cleaning . . . . . . . . . . . . .7, 8
Defrosting Instructions . . . . . . . . . . .6
Features . . . . . . . . . . . . . . . . . . . . . . . . .5
Starting the Freezer . . . . . . . . . . . . . . .5
Troubleshooting Tips
Before You Call For Service . . . .9, 10
Normal Operating
Characteristics . . . . . . . . . . . . . . . . . . .9
Consumer Support
Consumer Support . . . . . . . . . . . . . .14
Production Registration . . . . . .11, 12
Warranty . . . . . . . . . . . . . . . . . . . . . . .13
Write the model and serial
numbers here:
Model__________________
Serial __________________
You can find them on a plate on the
top-center on the back of the unit.

IM ORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
AFETY PRECAUTION
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■This freezer must be properly installed and
located in accordance with the Installation
Instructions before it is used.
■
■Do not allow children to climb, stand or hang on
the shelves in the freezer. They could damage
the freezer and seriously injure themselves.
■
■After your freezer is in operation, do not touch
the cold surfaces, particularly when hands are
damp or wet. Skin may stick to these extremely
cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■Unplug the freezer before cleaning, making
repairs or changing the light bulb.
NOTE: We strongly recommend that any
servicing be performed by a qualified individual.
■
■Turning the control to the OFF position does not
remove power to the light circuit on models with
interior light.
■
■Do not refreeze frozen foods which have thawed
completely.
■
■The maximum amount of food your freezer is
designed to freeze at one time is approximately
3 pounds (1.5 kg) per cubic foot of freezer
capacity.In normal position, your freezer’s
temperature control will maintain sufficiently
low temperatures in the freezer to freeze
recommended quantities of food.
■
■Caution should be used when removing the
door of a freezer. Particular caution should be
used when removing the lid of a Chest freezer,
as most Chest freezer lids are under spring
tension. Contact the manufacturer’s
representative for a method of safe removal.
PROPER DI PO AL OF THE FREEZER
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators and freezers are still dangerous…even
if they will sit for “just a few days.” If you are
getting rid of your old refrigerator or freezer,
please follow the instructions below to help
prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may
not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior to
product disposal. If you are getting rid of an old
refrigeration product, check with the company
handling the disposal about what to do.
U E OF EXTEN ION CORD
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRA MENT
2
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips Installation
Instructions Safety InstructionsOperating InstructionsTroubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions

3
Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation
Instructions
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with
a 3-prong (grounding) plug which mates with a
standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If the outlet is a standard 2-prong wall outlet, it is
your personal responsibility and obligation to have
it replaced with a properly grounded 3-prong wall
outlet.
The freezer should always be plugged into its own
individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your freezer by pulling on the power
cord. Always grip plug firmly and pull straight out
from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do
not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the freezer away from the wall, be
careful not to roll over or damage the power cord.
READ AND FOLLOW THI AFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

4
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions Safety InstructionsOperating Instructions Safety InstructionsOperating Instructions
reparing to install the freezer.
Freezer Location
Read these instructions completely and carefully.
Your freezer should be conveniently located for
day-to-day use in a dry, well-ventilated room.
Do not install the freezer where the temperature
will go below 0°F or above 110°F, because it will
not maintain proper temperatures.
Be sure to install your freezer on a floor strong
enough to support it when it is fully loaded.
The freezer must be solidly positioned on the floor
if it is to function at its best. Shims may be used to
accomplish this wherever the floor is too uneven. If
the place selected for the freezer is damp or
moist, place 2 X 4’s (51 mm X 102 mm) under its
entire length to assure adequate support.
Clearances
This appliance is designed to be free standing
only, and should not be recessed or built-in.
On all models, allow 6” (15 cm) on top, back and
sides for proper air circulation.

5
Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation
Instructions
About the operation of your freezer.
tarting the Freezer
Clean the inside of the freezer with a mild solution of baking soda and water (see Care and Cleaning).
Connect cord to power outlet.
ake sure the temperature control is set at mid point.
Allow freezer to operate for at least four hours before placing food inside.
Your freezer has one control for regulating temperature. The control is located in the lower right
hand corner.
Temperature Control
Freezing temperature selection is made by
setting the control from MIN to MAX
(coldest).
If you want colder or warmer
temperatures, adjust the control one step
at a time.
Allow several hours after each one-step
adjustment for the freezer temperature to
stabilize.
Turning the control to the OFF position
stops the cooling process but does not
shut off power to the freezer.
ower-On Light (on some models)
The green Power-On Light indicates that
the freezer is properly connected to the
electrical power.
The light glows even when the
temperature control is turned off.
Key-Ejecting Lock (on some models)
The key for the spring-loaded lock is
automatically ejected—key will not remain
in lock in either the open or closed
position.
Keep the key out of reach of children and
away from the freezer.
Helpful Hints
■
■Large amounts of frozen food will help
the cooling efficiency of the freezer.
■
■If the unit is unplugged, lost power
or turned off, you should wait at least
5 minutes before restarting the unit.
■
■When loading the freezer, freeze only
3 lbs (1.4 kg) of fresh food per cubic feet
of freezer space at one time.
■
■Distribute packages evenly throughout
the freezer.
■
■Place frozen food into the freezer as
quickly as possible after purchase.
Fast Freeze Switch (on some models)
The yellow switch overrides the thermostat
and will make the compressor operate
continuously, lowering the cabinet
temperature further than the thermostat
setting.
The yellow light glows when in the ON
position.

Defrosting instructions.
6
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips Installation
Instructions Safety InstructionsOperating InstructionsTroubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
In most climates, defrosting will be
necessary only about twice a year.
To have your freezer operate most
efficiently, do not permit more than 1/2”
(13 mm) of frost to accumulate on the
shelves.
Do not pour boiling water inside because it
may damage the plastic parts.
To remove frost, scrape with a plastic or
wood spatula or scraper.
Do not use an ice pick or sharp-edged
instrument as it may damage or scratch
the freezer.
Do not use any electrical device in
defrosting your freezer.
For Complete Defrosting
Turn the temperature control to the
OFF position and unplug the freezer.
Remove all food and place it in
corrugated boxes, insulated bags,
picnic coolers, etc. Use towels and
newspapers for insulation as needed.
With the door/lid open, use pans of
hot water to speed loosening of frost.
Remove large pieces before they melt.
Chest models have a defrost water
drain at the front or left side.
Place a shallow pan outside the drain
outlet to catch the defrost water.
NOTE: Water may drip from the back
flange of the lid cover during
defrosting. This is normal. Ice builds up
in the lid insulation when the lid is open
for adding or removing food, and melts
during the defrosting operation.
Sponge excess water from the bottom
of the freezer as it collects to prevent
overflowing.
After defrosting, clean the inside of the
freezer (see Care and Cleaning).
Replace the drain plug inside the
cabinet and the cap on the defrost
drain. Fold over and dry the gasket on
the hinge side of the lid.
Plug in the freezer. Return the
temperature control to its previous
position and return food to the freezer.

Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation
Instructions
7
Care and cleaning of the freezer.
Cleaning Your Freezer
■
■Outside. Protect the paint finish. The
finish on the outside of the freezer is a
high quality, baked-on paint finish. With
proper care, it will stay new-looking and
rust-free for years. Apply a coat of
appliance polish wax when the freezer is
new and then at least twice a year.
Appliance polish wax also works well to
remove tape residue from freezer
surfaces.
Some models have a condenser coil at
the back. It should be vacuumed when it
is dusty or dirty.
Keep the finish clean. Wipe with a clean
cloth lightly dampened with appliance
polish wax or mild liquid dishwashing
detergent. Dry and polish with a clean,
soft cloth. Do not wipe the freezer with a
soiled dishwashing cloth or wet towel.
Do not use scouring pads, powdered
cleaners, bleach or cleaners containing
bleach.
CAUTION: Care should be taken in
moving the freezer away from the wall.
All types of floor coverings can be
damaged, particularly cushioned
coverings and those with embossed
surfaces.
■
■Inside. Clean the inside of your freezer
at least once a year. We recommend
that the freezer be unplugged before
cleaning. If this is not practical, wring
excess moisture out of sponge or cloth
when cleaning in the vicinity of switches,
lights or controls.
Use warm water and baking soda
solution—about a tablespoon of baking
soda to a quart of water. Rinse
thoroughly with water and wipe dry. Do
not use cleaning powders or other
abrasive cleaners.
An open box of baking soda in the
freezer will absorb stale freezer odors.
Change the box every three months.

Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips Installation
Instructions Safety InstructionsOperating InstructionsTroubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
8
In Case of Extended ower Failure
■
■Keep freezer door/lid closed. Your
freezer will keep food frozen for 24
hours provided warm air is not admitted.
■
■If freezer is out of operation for 24 hours
or more, add dry ice. Leave ice in large
pieces. Add more ice as required.
WARNING: Handling of dry ice can cause
freezing of the hands—gloves or other
protection is recommended.
■
■If dry ice is not available, move food to a
frozen food locker temporarily—until
power is restored.
reparing to Move
Disconnect the power cord plug from the
wall outlet. Remove foods, defrost and
clean the freezer.
Secure all loose items such as grille and
shelves by taping them securely in place
to prevent damage.
Be sure freezer stays in upright position
during actual moving and in van. The
freezer must be secured in van to prevent
movement. Protect outside of freezer with
blanket.
reparing for Vacation
To maintain freezer in operation during
vacations, be sure your house power is not
turned off. For sure protection of freezer
contents, you may want to ask a neighbor
to check the power supply and freezer
operation every 48 hours.
For extended vacations or absences, you
may prefer to move your frozen foods to a
storage locker temporarily. If your freezer
is to be left empty, disconnect power cord
plug from wall outlet. To prevent formation
of odors, place open box of baking soda in
freezer and leave freezer door/lid open.
When the freezer is not operating, it can
be left in an unheated house or room
without damage to cabinet or mechanism.
Energy Saving Tips
■
■The freezer should be located in the
coolest area of the room, away from
heat producing appliances or heating
ducts, and out of the direct sunlight.
■
■Let hot foods cool to room temperature
before placing in the freezer. Overloading
the freezer forces the compressor to run
longer. Foods that freeze too slowly may
lose quality, or spoil.
■
■Be sure to wrap foods properly, and
wipe containers dry before placing them
in the freezer. This cuts down on frost
build-up inside the freezer.
■
■Freezer storage bin should not be lined
with aluminum foil, wax paper, or paper
toweling. Liners interfere with cold air
circulation, making the freezer less
efficient.
■
■Organize and label food to reduce door
openings and extended searches.
Remove as many items as needed at
one time, and close the door as soon as
possible.

9
Normal operating characteristics.
Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation
Instructions
These things are normal and
do not indicate a need for service.
■
■A warm cabinet exterior as the refrigeration system transfers heat from the inside to the outside through
the exterior cabinet walls.
■
■The sound of the high-efficiency compressor motor.
roblem ossible Causes What To Do
Freezer does not Temperature ontrol • ove the control to a temperature setting.
operate or ower-On in OFF position.
Light is not on Freezer is unplugged. • Push the plug completely into the outlet.
The fuse is blown/ ir uit • Replace fuse or reset the breaker.
breaker is tripped.
Freezer starts/stops Door/lid left open. • Check to see if package is holding door/lid open.
too frequently Too frequent or too long
door/lid openings.
Temperature ontrol • See About the operation of your freezer.
set too old.
Freezer operates Door/lid left open. • Check to see if package is holding door/lid open.
too long Too frequent or too long
door/lid openings.
Temperature ontrol • See About the operation of your freezer.
set too old.
Inadequate air ir ulation • See Preparing to install the freezer.
spa e around abinet.
Fast Freeze swit h is in the • See About the operation of your freezer.
ON position (on some models).
Noisy operation Floor may be weak, ausing • Placing 2 X 4’s (51 mm X 102 mm) under the length of
or cabinet vibrates freezer to vibrate when the freezer will help support it and may reduce
ompressor is on. vibration.
Cabinet is not positioned • See Preparing to install the freezer. Or use shims for
solidly on floor. uneven floor.
Freezer temperature Door/lid left open. • Check to see if package is holding door/lid open.
too warm Too frequent or too long
door openings.
Temperature ontrol set • See About the operation of your freezer
too warm.
Before you call for service…
Troubleshooting Tips
ave time and money! Review the charts on the following
pages first and you may not need to call for service.

10
roblem ossible Causes What To Do
Foods defrosting Temperature ontrol • ove the control to a temperature setting.
in OFF position.
Freezer is unplugged. • Push the plug completely into the outlet.
The fuse is blown/ ir uit • Replace fuse or reset the breaker.
breaker is tripped.
Door/lid left open. • Check to see if package is holding door/lid open.
Too frequent or too long
door openings.
Freezer temperature Temperature ontrol • See About the operation of your freezer.
too cold set too old.
Fast Freeze swit h is in the • See About the operation of your freezer.
ON position or has run for too
long (on some models).
Moisture forms on Not unusual during • Wipe surface dry.
outside of cabinet periods of high humidity.
Interior light does not No power at outlet. • Replace fuse or reset the breaker.
work (on some models) Freezer is unplugged. • Push the plug completely into the outlet.
Light bulb burned out. • Replace bulb.
Door/lid won’t fully Pa kage holding door/lid open..
close by itself
Slow starting time Built-in overload prote tion.
after being off
Excessive frost buildup Door/lid left open. • Check to see if package is holding door/lid open.
Too frequent or too long
door/lid openings.
Not unusual during
periods of high humidity.
opping/cracking Metal parts expand and • This is normal and should stop after unit has been
sound when running ontra t. running for a while.
Bubbling/gurgling Refrigerant in ooling system • This is normal.
sound is ir ulating.
NOTE: Do not return the freezer to the store where you purchased it. The freezer is eligible for in-home service. For
warranty service, contact us at 1.800.561.3344.
Before you call for service…
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions

11
OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY -
POUR RÉSIDENTS CANADIENS SEULEMENT)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :

12
CUT ALONG THIS LINE AND RETURN CARD – THANKS
DÉCOUPEZ ICI ET ENVOYEZ LA FICHE – MERCI
For Canadian
Customers
Pour les
consommateurs
canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
our warranty, should the need arise.
REGISTER ON-LINE: www.geappliances.ca
ENREGISTREMENT SUR INTERNET À : www.electromenagersge.ca
MAIL TO: P.O. BOX 1780, MISSISSAUGA
POSTEZ À : ONTARIO, L4Y 4G1
MR. / M. MRS. / MME
MISS/MLLE MS.
FIRST NAME / PRÉNOM
LAST NAME / NOM
STREET NO / NORUE
STREET NAME / RUE
APT.NO/APP./RR#
CITY / VILLE
PROVINCE
AREA CODE/
IND. RÉG.
TELEPHONE/TÉLÉPHONE
E-MAIL/COURRIEL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ?
YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A M D/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J
CORRESPONDENCE ENGLISH
CORRESPONDANCE FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit.
MODEL / MODÈLE
SERIAL / SÉRIE
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
POSTAL CODE/CODE POSTAL

This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within Canada.In-home warranty service will be provided in areas where it is available and deemed
reasonable by Mabe to provide.
Warrantor: Mabe Canada Inc., Burlington, ON L7R 5B6
EXCLUSION OF IM LIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
13
Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation
Instructions
Freezer Warranty.
All warranty service provided by our Factory ervice Centers, or
an authorized Customer Care®technician. To schedule service,
contact us at 1.800.561.3344. Please have serial number and
model number available when calling for service.
■Servi e trips to your home to tea h you how to use
the produ t.
■Improper installation, delivery or maintenan e.
■Failure of the produ t if it is abused, misused, or used
for other than the intended purpose or used
ommer ially.
■Loss of food due to spoilage.
■Damage aused after delivery.
■Repla ement of house fuses or resetting of ir uit
breakers.
■Damage to the produ t aused by a ident, fire,
floods or a ts of God.
■In idental or onsequential damage aused by
possible defe ts with this applian e.
■Produ t not a essible to provide required servi e.
What Mabe Will Not Cover:
taple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
For The eriod Of: Mabe Will Replace:
One Year Any part of the freezer which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty, abe will also provide, free of charge, all labor and related
original purchase service to replace the defective part.

Printed in China
Consumer Support.
Moffat Appliances Website MoffatAppliances.ca
Have a question or need assistance with your appliance? Try the offat Appliances Website, any day of the
year! For greater convenience and faster service, you can now download Owner’s anuals, order parts or even
schedule service on-line.
chedule ervice MoffatAppliances.ca
Expert repair service is only one step away from your door. Get on-line and schedule your service at your
convenience any day of the year! Or call 1.800.561.3344 during normal business hours.
Real Life Design tudio MoffatAppliances.ca
We support the Universal Design concept—products, services and environments that can be used by people of
all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental
abilities and impairments. For details of our Universal Design applications, including kitchen design ideas for
people with disabilities, check out our Website today.
In Canada, contact: anager, Consumer Relations, abe Canada Inc.
Suite 310, 1 Factory Lane
oncton, N.B. E1C 9 3
Extended Warranties MoffatAppliances.ca
Purchase an extended warranty and learn about special discounts that are available while your warranty is still
in effect. You can purchase it on-line anytime, or call 1.888.261.2133 during normal business hours. Consumer
Home Services will still be there after your warranty expires.
Parts and Accessories MoffatAppliances.ca
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, asterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone
during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Customers in Canada should consult the yellow pages for the nearest abe service center, or call 1.800.661.1616.
Contact Us MoffatAppliances.ca
If you are not satisfied with the service you receive, contact us on our Website with all the details including
your phone number, or write to: Director, Consumer Relations, abe Canada Inc.
Suite 310, 1 Factory Lane
oncton, NB, E1C 9 3
Register Your Appliance MoffatAppliances.ca
Register your new applian e on-line—at your onvenien e! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail
in the pre-printed registration card included in the packing material. In Canada: www.moffatpplian es. a.
14
