Moffat Waldorf GP8910GEC Instruction Manual

Technical data sheet for
GAS GRIDDLE CONVECTION ELECTRIC
OVEN RANGE 900mm
GP8910GEC
Heavy-duty thermostatic gas griddle
20mm thick griddle plate
Ribbed plate options
Chromed mirror plate options
Top weld sealed plates
80MJ thermostatic griddle burner system
Separate left and right heat zones
GN 2/1 6.6kW electric convection oven
Drop down door
Stainless steel exterior
Easy clean
Easy service
Fully modular
Controls
• Large easy use control knobs - heat resistant reinforced
• Easy view control settings on knobs
Griddle
• Separate left and right side heat zones
• Two 90-300˚C thermostats
• Flame failure pilot burners
• Piezo ignition to each pilot burner
Oven
• 50-320˚C thermostatic control
• Indicator lights for power and heating
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service and gas conversion through front of unit
• Burner service requires plate removal
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Door hinge spring adjustable on unit (door outer removed)
• Door disengages for lift off removal and increased service access
• Access to all parts from front of unit
Overall Construction
• Galvanized steel chassis
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet
Griddle
• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• Two 40MJ 3 bar even heat burners with dual thermostatic controls
• Full pilot and flame failure protection with piezo ignition
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• 100W heavy-duty motor
• 200mm diameter heavy-duty circulation fan
• Welded frame drop down door with heavy-duty spring hinge system
• 0.9mm 304 stainless steel door outer
• 1.0mm press formed vitreous enamelled door inner
• High density fibreglass insulated
• Stay cool stainless steel door handle with cast metal handle mounts
• Supplied with two chrome wire oven racks

Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone 03-951 3
Facsimile 03-951 3 33
[email protected]
New South Wales
Telephone [phone]
[email protected]
South Australia
Telephone 03-951 3
[email protected]
Queensland
Telephone [phone]
[email protected]
Western Australia
Telephone [phone]
[email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
[email protected]
Auckland
Telephone [phone]
[email protected]
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
ISO9001
All Waldorf products are designed and
manufactured by Moffat using the
internationally recognised ISO9001 quality
management system covering design
manufacture and final inspection ensuring
consistent high quality at all times.
ISO9001
Quality
Management
Standard
Designed and manufactured by
In line with policy to continually develop and
improve its products Moffat Limited reserves
the right to change specifications and design
without notice.
Specifications
Burners
Two 40MJ 3 bar chromed steel burners - Griddle
Individual pilot, flame failure and piezo ignition
Elements
4.5kW bottom heat element
2.0kW top heat element
Oven Fan Motor
100W
Gas power
80MJ/hr, 22.2kW
Electrical requirements
6.6kW
1 phase connection:
230-240Vac, 50/60hz, 1P+N+E, 27.7A
3 phase connection:
400-415Vac, 50/60hz, 3P+N+E
L19.4A
L2 9.4A
L3 8.3A
Plate
Cooking surface 892mm x 530mm, 4728cm2
Oven Dimensions
Width 665mm
Depth 590mm
Height 385mm
Rack size 660mm x 540mm
Rack positions 4
Gas connection
R 3/4(BSP) male
130mm from RH side, 32mm from rear,
and 655mm from floor
Optional underside connection
(refer specification drawing)
All units supplied with Natural and LP gas regulator
Electrical connection
25mm from RH side, 484mm from rear,
and 150mm from floor
Dimensions
Width 900mm
Depth 805mm
Height 915mm
Incl. splashback 1130mm
Packing data
1.02m3
Width 940mm
Depth 865mm
Height 1255mm
Gas types
Available in Natural gas and LP gas
Please specify when ordering
Units supplied complete with gas type
