Mojo Frost M1-22 User manual

1
!
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
800-990-9775 P 610-200-6884 SMS for support
[email protected] mojowater.com
Frost
BottleLess Water Cooler
OPERATIONS MANUAL
Model Number: M1-S22

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including:"
1. Read all instructions before using. "
2. Do not let cord hang over edge of table or counter, or touch hot surfaces."
3. To protect against electric shock, do not immerse cord, plug, or cooler in water or any other liquid."
4. Close supervision is necessary when any appliance is used by or near children."
5. Unplug from outlet when not in use and before cleaning."
6. Do not operate any appliances with a damaged cord, plug or after the appliances malfunction, or has been
damaged in any manner."
7. The use of accessory attachments is not recommended by the manufacturer and may cause injuries."
8. Do not use outdoors."
9. Allow at least 2” (5cm) of space between the back of the water cooler and the wall to allow for proper air
circulation."
10. Install the water cooler on a level floor. Do not install where it will be subject to direct sunlight, heat or moisture."
11. Do not install water cooler where the temperature will go below 59°F (15°C) or above 100°F (38°C)."
12. Do not plug in the power cord or turn on the hot water on/offswitch when the water cooler is empty."
13. To disconnect the power cord, turn the hot water switch to “off“, then remove plug from wall outlet."
14. Always wash and dry your hands thoroughly before touching the water cooler."
15. Extreme caution must be used when moving an appliance that contains hot liquid."
16. Do not use this cooler to dispense anything other than water. (Yes, that means no beer….)"
17. Do not use with water that is micro biologically unsafe or of unknown quality.
SAVE THESE INSTRUCTIONS
18. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric
shock.
19. This appliance has a power cord with a grounding wire and a grounding plug. The plug must be plugged into a
standard 3-prong outlet that is properly installed and grounded. The water cooler is intended to be plugged into a
receptacle of the ground fault circuit interrupting type (GFCI) for water cooler installations in North America."
20. Consult a qualified electrician if the grounding instructions are not completely understood, or if doubt exists as
to whether the appliance is properly grounded."
21. If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet."
22. Do not under any circumstances cut or remove the third (ground) prong from the power cord."
23. Do not use an adapter plug with this appliance."
24. Do not use an extension cord with this appliance. If the power cord is too short, have a qualified electrician
install an outlet near the appliance."
25. Never place your fingers or any sharp metal object inside the water cooler, as doing so may damage the cooler,
and also increase the risk of electric shock."
26. Do not immerse the appliance in the water to clean."
27. The appliance should not be exposed to rain. "
28. If the power cord is damaged, it must be replaced by the manufacturer its service agent or similarly qualified
persons in order to avoid a hazard."
PLEASE FOLLOW THE STEPS IN THIS MANUAL IN ORDER !
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
Please visit mojowater.com/setup
For MOJO SET-UP & TROUBLESHOOTING VIDEOS &
updated installation manuals. Thank you.

3
IMPORTANT
DO NOT TURN ON HOT TANK SWITCH (ON THE BACK OF THE COOLER)
UNTIL THE COOLER’S RESERVOIRS ARE FILLED WITH WATER. THEY ARE
FULL WHEN WATER COMES OUT OF BOTH THE COLD AND HOT FAUCETS.
GENERAL OVERVIEW
!
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
Cold Water Button
Hot Water Selector
Water Outlet
Drain
Hot Water On/
Off Switch
Drip Tray
Lid
Filter
Location
Cold Water Thermostat
Water Inlet
Water
dispense
button

4
Float Kit Information:
The Float Kit sits inside of the cold water reservoir and shuts offthe water when the reservoir is
full. The Primary Float (the square one - and “lower” one) shuts offthe water first. If that Float
were to fail, the water level would keep rising and the Secondary Float would shut offthe water.
When this happens, water can not flow again unless the reset button is pressed. Please note:
this Secondary Float can be tripped by bumping or moving the cooler. So, if your water stops
flowing, you may just need to press reset. !
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
External Lid
Water Flow
From Filter
Water From Water Filter

5
Cooler Set-Up & Installation: Part 1 - Pre-Installation
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
1. REMOVE EXTERNAL LID
Remove the lid on the Frost cooler
to expose the top of the Float Kit
(it is blue and covers the
reservoir). There is a small,
rounded “cut out” in the back of
the lid to help you remove it.
2. LIFT OUT FLOAT KIT
When you remove the External Lid
(previous step), you’ll see the blue
Float Kit that seals the cold water
reservoir (and holds the 2 floats).
You need to remove that lid so
that you can check everything
inside the reservoir. "
Just grab the two handles on the
sides and pull straight up (see
diagram on previous page).
3. CHECK FLOATS
Look under the Float Kit. You will
see 2 air-filled “floats” - a main
“float” (square) that shuts offthe
water flow when reservoir is full,
and a round backup safety float if
the first float were to fail.
Occasionally, floats come loose in
transportation. If either float is not
attached, click it back into place.
Make sure that both floats can
freely move up and down.
FLOAT KIT
EXTERNAL LID
PRIMARY FLOAT
BACKUP FLOAT
4. CHECK BAFFLE
a) Inside the stainless steel
reservoir, you’ll find a 2-piece
baffle. Sometimes, this can come
loose in transportation. Push the
baffle down to make sure that it is
secure. (If it is loose, it can rise up
and trip the floats.) If the baffle is
dislodged, push it into the center
hole in the bottom of reservoir.
5. PRESS RESET BUTTON
a) Push the Float Kit back into the
reservoir to seal it. "
b) Press red reset button. If the
round Backup Float (from Step 3)
is tripped, it shuts offall water to
the cooler as a safety precaution.
This can also happen in
transportation or if cooler gets
bumped (after it is installed). "
In the future, if water does not
dispense, pushing the red button
usually fixes the issue.
6. REPLACE LID
Replace the external lid. You’re
now ready to proceed with set up.
BAFFLE
RESERVOIR
RESERVOIR

6
Cooler Set-Up & Installation: Part 2. FILTER SET UP
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
WRITE DATE
HERE
9. REMOVE DRIP TRAY
Remove the “Drip Tray” by pulling
it straight out. There are pegs in
the back of the drip tray to keep it
in place. It may be a little tight - so
just pull it straight out away from
the cooler.
8. PREPARE FILTER
Open the included MOJO Water
filter and remove the cap. "
Write the date on the front of the
filter so you know when you
installed/replaced the filter. "
Your Frost cooler uses M1000
filters that are always available on
MOJO Water's website or on
Amazon.
7. FROST LOCATION
Locate the Frost water cooler in a
well-ventilated space where
temperature is always above
freezing. The Frost should be 2
inches from the wall to allow for
proper ventilation. The electrical
cord plugs into a standard 3-
prong electrical outlet and is 6-
feet long. The Frost plugs into a
standard 1/4-inch water line (same
size as ice makers)
11. INSTALL FILTER
Insert the filter cartridge in the
filter head. Twist to the right to
lock it into place. Make sure that
the label is facing towards you.
12. LINE UP GUIDES
a) Make sure that you’ve rotated
the filter all the way in place so
that the guides line up. When the
guides are not lined up, water will
not flow. This makes changing the
filter much easier. "
b) Replace the Filter Cover (from
Step 10) and then the Drip Tray
(from Step 9).
10. REMOVE FILTER COVER
Just grab the filter cover by the
bottom (or by the front) and lift it up.
Then, remove it to reveal the filter
compartment.
FILTER HEAD

7
Cooler Set-Up & Installation: Part 3. FINAL SET UP
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
15. PLUG INTO OUTLET
Plug Frost cooler into standard 3-
prong electrical outlet. You do not
need to wait for the cooler to fill
completely from the previous step.
14. TURN WATER ON
Turn the water on by turning the
valve so that it is parallel with the
waterway. (Water is offwhen it is
perpendicular.) "
You will hear the water start to fill
the internal cold water reservoir.
13. PUSH IN WATERWAY
Push the waterway coming from
the wall into the Water Inlet
(marked Water In). You will feel a
slight resistance when you first
push the waterway into the Water
Inlet. Push the waterway past that
initial slight resistance (all the way
in). The waterway locks/seals
automatically. No tools are
needed. "
Do NOT turn on hot water switch.
18. FLUSH FILTER
a) Place a bucket, trash can,
coffee pot or even a large cup
under the dispensing area. "
b) Press the BLUE button on the
front. (The top water dispensing
button will turn blue.)"
c) Press the water dispensing
button and fill about a half gallon
of water into the bucket. "
Wait up to 30 minutes for initial
cooling and heating of your water. "
Enjoy!
17. TURN ON HOT SWITCH
After water comes out of hot
faucet (previous step), remove
label and turn on hot tank switch. "
TIPS: If you do not want hot water
to be dispensed from your cooler,
leave this switch off. Please note
that the red switch will light up
when the water heater is
activated. Once hot water
reaches desired temperature,
heater turns offand switch does
not illuminate.
WATER ON
POSITION
HOT SWITCH:
DO NOT TURN
ON UNTIL YOU
COMPLETE STEP
16
16. FILL HOT TANK
a) Place a bucket, trash can, or
other container under the
dispensing area. "
b) Press the red button on the front.
(Water dispensing button turns red.)"
c) Press the water dispensing
button on the top & hold it until
water comes out of the dispensing
area (may take 3+ minutes). Once a
steady stream of water comes out,
release button and let cooler refill.
Water must come out of cooler
before moving to Step 17.
1
2
1
2
FILL HOT TANK
FLUSH FILTER
THROUGH COLD
FAUCET

8
BASIC OPERATION/TIPS:!
©MOJO Pure Water, LLC All Rights Reserved. 1-800-990-9775 mojowater.com
TO DRAIN COOLER
The dispensing button does not
drain the cooler completely. To
remove all water from cooler: "
1) Unplug cooler from electrical
outlet & let the hot water cool
down for an hour+. Then, 2)
remove drain plug on the back of
the cooler by pulling it straight out
and let the water flow into a
bucket or trash can. Be careful -
water may still be hot.
cold temp adjustment
Adjust the temperature of the cold
water by rotating the thermostat
control located on back of the
cooler. Use a “flat-head”
screwdriver. Clockwise is colder. "
TIP: If you turn the thermostat all
the way counterclockwise, you’ll
turn offthe cold function. The
Frost will now dispense Hot
(assuming the hot tank switch is
on) and room temperature water.
TO REMOVE WATERWAY
When the waterway was pushed
into the Water Inlet (marked Water
In), it locks into place. If you pull
the waterway out without
unlocking it, leaks can occur. "
To remove the waterway: Push on
ring around the Water Inlet while
you simultaneously pull the
waterway out. Pushing on the ring
unlocks the Water Inlet.
LINE UP FILTER GUIDES
When changing filter, make sure
that you’ve rotated the filter all the
way in place so that the guides
line up. When the guides are not
lined up, water will not flow. "
Also, please note the model
number when ordering
replacements. They’re always
available on our website or on
amazon.com.
TURNING WATER OFF
To turn the water off, turn the
valve so that it is perpendicular to
the waterway.
TURN
CLOCKWISE FOR
WITH A
SCREWDRIVER
COLDER
WATER VALVE
IN OFF
POSITION
HEATING ON/OFF SWITCH
If you do not want hot water to be
dispensed from your cooler, turn the
hot water switch off. Please note
that the hot on/offswitch will
illuminate (red) when the water
heater is activated. Once hot water
reaches desired temperature, heater
turns offand light inside the switch
turns off.
PUSH IN ON
RING TO
UNLOCK
