MOKENEYE LB02Z User manual

20V CORDLESS LEAF BLOWER
Model LB02Z
Owner’s Manual
VERSION: LB02Z-EN-02
WARNING: Toreduce the risk of injury, the user must read and understand the
Owner
NOTICE: Get 1-year extended warranty by scanning the QR code to REGISTER.
's Manualbeforeusingthisproduct.Savetheseinstructionsforfuturereference.
For Customer Service
[e-mail]
www.facebook.com/MokeneyeTools

2
TABLE OF CONTENTS
GENERAL SAFETY WARNINGS................ 2
SAFETY WARNINGS FOR BLOWER .........3
SYMBOLS .............................................. 4
GET TO KNOW YOUR LEAF BLOWER......5
SPECIFICATIONS .................................... 5
OPERATING INSTRUCTIONS...................7
MAINTENANCE...................................... 9
TROUBLE SHOOTING .............................9
LIMITED WARRANTY ............................. 9
GENERAL SAFETY WARNINGS
Read all safety warnings,
instructions, illustrations and
specifications provided with this power tool. Failure
to follow all instrucons listed below may result in
electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE REFERENCE.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or baery-
operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distracons can cause
you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operang a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of a
GFCI reduces the risk of electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inaenon while operang power
tools may result in serious personal injury.
Use personal protective equipment. Always
wear eye protection. Protecve equipment such
as a dust mask, non-skid safety shoes, hard hat
or hearing protecon used for appropriate
condions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energizing power tools
that have the switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key le
aached to a rotang part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables beer control
of the power tool in unexpected situaons.
Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry
or long hair can be caught in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collecon can reduce dust- related hazards.
Do not let familiarity gained from frequent use of
tools allow you to become complacent and
ignore tool safety principles. A careless acon
can cause severe injury within a fracon of a
second.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job beer and safer at the
rate for which it was designed.
Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and
must be repaired.

3
Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such prevenve safety measures
reduce the risk of starng the power tool
accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools and accessories. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool's operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cung tools with sharp cung
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power
tool for operaons different from those
intendeds could result in a hazardous situaon.
Keep handles and grasping surfaces dry, clean
and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situaons.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of baery pack may create a risk of fire
when used with another baery pack.
Use power tools only with specifically designated
battery packs. Use of any other baery packs
may create a risk of injury and fire.
When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal
to another. Shorng the baery terminals
together may cause burns or a fire.
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the baery may cause
irritaon or burns.
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
baeries may exhibit unpredictable behaviour
resulng in fire, explosion or risk of injury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 265 °F may cause explosion.
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the baery and
increase the risk of fire.
SERVICE
Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the
power tool is maintained.
Never service damaged battery packs. Service of
baery packs should only be performed by the
manufacturer or authorized service providers.
SAFETY WARNINGS FOR BLOWER
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
This blower is intended for household use only.
Do not leave blower unattended when the
battery is inserted. Remove the baery when the
blower is not in use and before servicing.
Do not allow the blower to be used as a toy.
Close aenon is necessary when used by or
near children.
Use only as described in this manual. Use only
manufacturer’s recommended attachments.
Do not handle the charger, including charger
plug, or charger terminals with wet hands.
Do not put any object into any openings. Do not
use with any opening blocked; keep openings
free of dust, lint, hair, and anything that may
reduce air flow.
Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
Loose clothes, jewelry, or long hair can be drawn
into air vents.
Secure long hair above shoulder level to prevent
entanglement in moving parts.
Use extra care when cleaning on stairs.
Protect your lungs. Wear a face or dust mask if
the operation is dusty. Following this rule will
reduce the risk of serious personal injury.
Protect your hearing. Wear hearing protection
during extended periods of operation. Following
this rule will reduce the risk of serious personal
injury.
Wear heavy long pants, long sleeves and boots.
Avoid loose garments or jewelry that could get
caught in moving parts of the machine or its
motor.
Never use blower to spread chemicals, fertilizers,
or any other toxic substances. Spreading these
substances could result in serious injury to the
operator or bystanders

4
SYMBOLS
SAFETY SYMBOLS
The purpose of safety symbols is to aract your
aenon to possible dangers. The safety symbols and
the explanaons with them deserve your careful
aenon and understanding. The symbol warnings do
not, by themselves, eliminate any danger. The
instrucons and warnings they give are no substutes
for proper accident prevenon measures.
Be sure to read and understand all
safety instrucons in this Owner's
Manual, including all safety alert symbols such as
"DANGER," "WARNING," and "CAUTION" before using
this tool. Failure to following all instrucons listed
below may result in electric shock, fire, and/or serious
personal injury.
The definions below describe the level of severity
for each signal word. Please read the manual and pay
aenon to thesesymbols.
This is the safety alert symbol. It is used to
alert you to potenal personal injury
hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates a hazardous
situaon which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous
situaon which, if not avoided,
could result in death or serious injury.
CAUTION, used with the safety
alert symbol, indicates a
hazardous situaon which, if not avoided, will result
in minor or moderate injury.
DAMAGE PREVENTION AND
INFORMATION MESSAGES
These inform the user of important informaon
and/or instrucons that could lead to equipment or
other property damage if they are not followed. Each
message is preceded by the word "NOTICE", as in the
example below:
NOTICE: Equipment and/or property damage may
result if these instrucons are not followed.
The operaon of any power tools
can result in foreign objects being
thrown into your eyes, which canresult in severe eye
damage. Before beginning power tool operaon,
always wear safety goggles or safety glasses with
side shields and a full-face shield when needed. We
recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side
shields. Always use eye protecon which is marked
to comply with ANSI Z87.1
SYMBOLS (CONTINUED)
IMPORTANT: Some of the following symbols may be
used on your tool. Please study them and learn their
meaning. Proper interpretaon of these symbols will
allow you to operate the tool beer and more safely.
Symbol
Designation/Explanation
V
Volts
A
Amperes
Hz
Hertz
W
Wa
kg
Kilograms
min
Minutes
s
Seconds
Wh
Wa-hours
Ah
Ampere-Hours
Ø
Diameter
n
0
No-load speed
n
Rated speed
…/min Revoluons or
reciprocaons per minute
0
Off posion
1,2,3, …
I, II, III,
Selector sengs
CFM
Cubic Feet Per Minute
MPH
Miles Per Hour
Infinitely variable selector with
off
Arrow
Direct current
Alternang current
Class II tool
Li-ion RBRC seal
Read manual symbol
Wear eye protecon symbol
Do not expose to rain.

5
GET TO KNOW YOUR LEAF BLOWER
1) BLOWER TUBE
2) TUBE-RELEASE
BUTTON
3) 6-SPEED DIAL
4) RUN HOLD BUTTON
5) HANDLE
6) BATTERY RELEASE
BUTTON
7) FUEL GAUGE
8) BATTERY PACK
9) AIR-INLET GRILLE
10) START/STOP
TRIGGER SWITCH
11) NOZZLE
SPECIFICATIONS
Rated voltage 20V d.c.
Speed Max. 18000 RPM
Air Volume Max. 350 CFM
Air Velocity Max. 120 MPH
Recommended working temperature 14~104°F (-10~40°C)
Recommended storage temperature 32~104°F (0~40°C)
Variable Speed Dial
Delivers variable speed. Adjusts and keeps the air
velocity of the blower according to your needs.
Increases the air velocity to the maximum by turning
the dial wheel to the max posion.
Tube-Release Button
Releases the tube from the blower.
Run Hold Button
For connuous operaon, press the trigger switch,
push in the lock buon and then release the trigger
switch.
Nozzle
Further spreads the air flow and increases the
cleaning area.
2
11
1
2 RELEASE
DETACH
1
3
4
5
6
7
8
9
10

6
3
4 5
6 7
TUBE-
RELEA
SE
BUTTON
RAISED
CEN
TRAL
RIB
ATTACH
DETACH
BLOWER
TUBE
NOZZLE
BLOWER
TUBE
RUN HOLD
BUTTON
START/STOP
TRIGGER SWITCH
65
6-SPEED DIAL

7
OPERATING INSTRUCTIONS
To reduce the risk of fire, personal
injury, and product damage due to
ashort circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them.
Corrosive or conducve fluids, such as seawater,
certain industrial chemicals, and bleach or bleach-
containing products, etc. can cause a short circuit.
If any parts are damaged or
missing, do not operate this
product until the parts are replaced. Use of this
product with damaged or missing parts could result
in serious personal injury.
Do not attempt to modify this tool
or create accessories not
recommended for use with this tool. Any such
alteraon or modificaon is misuse and could result
in a hazardous condion leading to possibleserious
injury.
To prevent accidental starting that
could cause serious personal injury,
always remove the battery pack from the tool when
assembling parts, making adjustments, or cleaning
the tool.
This cordless tool must be used only with the battery
packs and charger listed below:
MOKENEYE
Baery Pack
2.0Ah B202005MZ
B202010MZ
3.0Ah B203005MZ
4.0Ah B204005MZ
B204010MZ
MOKENEYE
Charger
1A C10MZ1US
2A C20M1US
2A C20MK1US
NOTICE: Please refer to the baery and charger
manuals for detailed operang informaon.
FUEL GAUGE BATTERY PACKS
Some MOKENEYE baery packs Models ending
with “Z” include a fuel gauge which consists of
four green LED lights that indicate the level of charge
remaining in the baery pack.
The fuel gauge is an indicaon of approximate levels
of charge remaining in the baery pack according to
the following indicators:
To actuate the fuel gauge, press and hold the fuel
gauge buon. A combinaon of the four green LED
lights will illuminate designang the level of charge
maintenance charge mode.
-LED lights up green = When an under-charged
CHARGING THE BATTERY PACK
Baery packs for this tool are shipped in a low
charge condion to prevent possible problems.
Therefore, you should charge it unl the green LED
on the front of the charger comes on.
CHARGING A COOL BATTERY PACK
If baery pack is within normal temperature range,
the red LED on charger will come on.
NOTE: If the charger does not charge the baery
pack under normal circumstances, return both the
baery pack and charger to your nearest Mokeneye
Authorized Service Center for electrical check.
-Charge the baery pack only with the charger
provided.
-Make sure the power supply is normal household
voltage, 110~240 volts, 50/60 Hz, AC only.
-Connect the charger to the power supply.
-For C20M1US/C20MK1US charger, place the
baery pack in the charger aligning raised rib on
the baery pack with the groove in the charger.
-Press down on the baery pack to be sure contacts
on the baery pack engage properly with contacts
in the charger.
-Normally the red LED on charger will come on. This
indicates the charger is in fast charging mode.
-Red LED should remain on for approximately 1 to 2
hours then the green LED will come on. Green LED
on indicates baery pack is fully charged and
charger is in maintenance charge mode.
NOTICE: The green LED will remain on unl the
charger is disconnected from the power supply.
-Aer normal usage, a minimum of 1 hour of
charging me is required to fully recharge baery
80-100% charged
60-79% charged
40-59% charged
Pack needs to be charged
le. When the level of charge in the baery is below
the usable limit, the fuel gauge will nolluminate
and the baery will need to be recharged.
NOTICE: The fuel gauge is only an indicaon ohe
charge leon the baery pack. It does nondicate
tool funconality and is subjeco variaon based on
product components, temperature and end-
user applicaon.
For more informaon regarding fuel gauge baery
packs, please send e-mail to Mokeneye Customer
Service
: [e-mail] / Facebook: www
.facebook.com/MokeneyeTools
LED FUNCTIONS OF CHARGER
LED WILL BE ON TO INDICATE STATUS OF CHARGER
AND BATTERY PACK:
Charging with C20M1US/C20MK1US charger
-LED lights up red = Fast charging mode.
-LED lights up green = Fully charged and in
baery pack is inserted into charger, indicates hot
baery pack or that baery pack is out of normal
temperature range or deeply discharged or
defecve baery pack.
-No LED on = Defecve charger.

8
pack.
-The baery pack and the charger will become
slightly warm to the touch while charging. This is
normal and does not indicate a problem.
-Do not place the charger and baery pack in an
area of extreme heat or cold. They will work best
at normal room temperature.
NOTICE: The charger and baery pack should be
placed in a locaon where the temperature is more
than 32°F but less than 100°F.
-When baeries become fully charged, unplug the
charger from power supply and remove the
baery pack.
CHARGING A HOT BATTERY PACK
When using the tool connuously, the baeries in
the baery pack will become hot. You should let a
hot baery pack cool down for approximately 30
minutes before aempng to recharge. When the
baery pack becomes discharged and is hot, this will
cause the green LED to come on instead of the red
LED. Aer 30 minutes, reinsert the baery pack in
the charger. If the green LED connues to remain on,
return baery pack to your nearest Mokeneye
Authorized Service Center for checking or replacing.
NOTICE: This situaon only occurs when connuous
use of the tool causes the baeries to become hot. It
does not occur under normal circumstances. Refer to
"CHARGING A COOL BATTERY PACK" for normal
recharging of baeries. If the charger does not
charge your baery pack under normal
circumstances, return both the baery pack and
charger to your nearest Mokeneye Authorized
Service Center for electrical check.
APPLICATION
-This tool has been designed to gather grass
clippings, straw, or leaves into piles.
-This tool has been designed for blowing dry leaves
and other dry garden rubbish such as grass and
twigs.
-This tool has been designed for sucking dry debris
such as wood chips and animal hair.
-This tool is intended for domesc use only and is
not designed to be used under wet condions.
-This tool is not intended for professional use.
TO ATTACH/DETACH BATTERY PACK
See Fig. 2
Battery tools are always in
operating condition. Therefore,
remove the battery when assembling parts, making
adjustments, cleaning, when the tool is not in use,
or when carrying it at your side. Removing the
battery pack will prevent accidental starting that
could cause serious personal injury.
To aach the baery pack
-Align the ribs of the baery pack with the
mounng slots in the blower's baery port.
-Press the baery pack toward the blower body
unl it snaps into posion.
NOTICE: Make sure that the baery pack is secured
to the blower before beginning operaon.
NOTICE: When placing the baery pack onto the tool,
be sure that the raised rib on the baery pack aligns
with the groove inside the tool and that the latches
snap into place properly. Improper aachment of
the baery pack can cause damage to internal
components.
To detach the baery pack
Depress the baery-release buon located on the
front of the baery pack to release the baery pack.
Pull the baery pack out and remove it from the tool.
TO ASSEMBLE THE BLOWER TUBE
Blower tube connecon
See Fig. 3
Align the groove in the tube with the raised central
rib on the blower housing. Push the tube onto the
blower housing unl it snaps into place. Pull on the
tube to ensure that it is securely aached to the
blower.
Nozzle connecon
See Fig. 4
Align the groove in the nozzle with the knob on the
tube and rotate anclockwise unl it snaps into
place.
TO START/STOP THE BLOWER
See Fig. 5
NOTICE: Before switching on the blower, ensure that
it is not in contact with any object.
-Presses trigger switch to start the blower.
-Release trigger switch to stop the blower.
RUN HOLD BUTTON
See Fig. 5
For connuous operaon, pull the trigger switch,
push in the run hold buon and then release the
trigger switch.
To stop the blower from the locked posion, pull the
trigger switch fully, then release it.
Always remove the battery pack
from the blower during work
breaks and after finishing work.
6-SPEED DIAL
See Fig. 6
The blower is equipped with a 6-speed dial.
-The variable-speed dial is used to adjust the air
flow.
-Turn the dial to increase or decrease the speed.
-Posion “1” selects the slowest speed.
-Posion “6” selects the fastest speed.
-Adjust the air flow of the blower to suit the task at
hand.
-As the speed increases, the baery duraon
decreases.

9
TO OPERATE THE BLOWER
See Fig. 7
-While working, always hold the blower by the grip
area(s).
-To keep from scaering debris, blow around the
outer edges of a debris pile. Never blow directly
into the center of a pile.
-To reduce sound levels, limit the number of pieces
of equipment used at any one me.
-Use rakes and brooms to loosen debris before
blowing. In dusty condions, slightly dampen
surfaces if water is available.
-Conserve water by using power blowers instead of
hoses for many lawn and garden applicaons,
including areas such as guers, screens, paos,
grills, porches, and gardens.
-Watch out for children, pets, open windows, or
freshly washed cars, and blow debris safely away.
-Aer using blowers or other equipment, clean up!
Dispose of debris properly.
MAINTENANCE
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or
performing any maintenance.
SERVICE
Preventive maintenance
performed by unauthorized
personnel may result in misplacing of internal wires
and components which could cause serious hazard.
We recommend that all tool service be performed by
a MOKENEYE Factory Service Center or Authorized
MOKENEYE Service Staon.
GENERAL MAINTENANCE
When servicing, use only identical
replacement parts. Use of any
other parts could create a hazard or cause product
damage.
NOTICE: Periodically inspect the enre product for
damaged, missing, or loose parts such as screws,
nuts, bolts, caps, etc. Tighten securely all fasteners
and caps and do not operate this product unl all
missing or damaged parts are replaced. Please
contact customer service or an authorized service
center for assistance.
CLEANING
The tool may be cleaned most
effectively with compressed dry air.
Always wear safety goggles when cleaning tools
with compressed air. Venlaon openings and
switch levers must be kept clean and free of foreign
maer. Do not aempt to clean by inserng pointed
objects through openings.
Certain cleaning agents and
solvents damage plastic parts.
Some of these are: gasoline, carbon tetrachloride,
chlorinated cleaning solvents, ammonia and house
hold detergents that contain ammonia.
STORAGE
Store the tool indoors in a place that is inaccessible
to children. Keep away from corrosive agents.
TROUBLE SHOOTING
PROBLEM: TOOL DOES NOT WORK.
LIMITED WARRANTY
1 YEAR LIMITED WARRANTY- LEGAL
MOKENEYE warrants to the original purchaser only,
that all MOKENEYE consumer POWER TOOLS will be
free from defects in material or workmanship for a
period of one years from date of purchase.
BATTERIES AND CHARGERS are warranted for 1
years. Original purchasers should also retain their
receipt as proof of purchase.
Notwithstanding the foregoing, if a MOKENEYE
consumer portable power tool is used for industrial,
professional or commercial purposes, the foregoing
warranty will apply for a duraon of ninety days.
SELLER'S SOLE OBLIGATION AND YOUR EXCLUSIVE
REMEDY under this Limited Warranty and, to the
extent permied by law, any warranty or condion
implied by law, shall be the repair or replacement of
parts, without charge, which are defecve in
material or workmanship and which have not been
misused, carelessly handled, or repaired by persons
other than Seller or Authorized Service Staon. To
make a claim under this Limited Warranty, you must
return the complete product, transportaon prepaid,
to any MOKENEYE Factory Service Center or
Authorized Service Staon. For Authorized
MOKENEYE Power Tool Service Stations, please
contact Amazon Store Customer Service.
This limited warranty does not apply to accessory
items such as circular saw blades, drill bits, router
bits, jigsaw blades, sanding belts, grinding wheels,
blower nozzles and other related items.
In no event shall seller be liable for any incidental or
consequenal damages (including but not limited to
liability for loss of profits) arising from the sale or use
of this product. Some states in the U.S. and some
Canadian provinces do not allow the exclusion or
limitaon of incidental or consequenal damages,
so the above limitaon or exclusion may not apply to
you.
Cause
Remedy
B
aery pack is
depleted.
Charge the baery.
T
ool is over-
loaded.
Release the variable-speed
trigger switch and try again.
B
aery pack
is
o
ver
temperature.
Turn off the Tool and cool the
baery pack under air flow.
B
aery pack
is
n
otinstalled
properly.
Confirm baery is locked and
secured to the tool.
B
urned out
s
witch.
Have the switch replaced by an
Authorized MOKENEYE Service
Center or Service Staon.
