MokerLink G092GSM User manual

Manual for G092GSM
Optical fiber convergence managed switch

01 Product introduction
Product overview
G092GSM has 11 ports full gigabit enterprise level multi-functional L2 network management switch. It is specially
designed for enterprise customers to optimize and enhance the design and has higher reliability. The device adopts
Realtek new generation high-performance platform and new self-developed switch system, supports flexible 802.1Q
VLAN, IGMP, port monitoring, port aggregation, bandwidth control, ring application and other network management
functions, and easily adapts to the current complex network application environment.
Port performance
Provide 9*1000M SFP ports.
Provide 2*10/100/1000M RJ45 uplink ports.
It supports the combination of multiple types of ports to facilitate users' flexible networking and meet the networking
requirements of various scenarios.
Each port supports MDI / mdix automatic flip and duplex / rate self negotiation.
Support IEEE 802.3x full duplex flow control and backpressure half duplex flow control.
Fiber Transmission
Flexible networking, single fiber, double fiber, single mode, multi-mode and other different optical fiber modules can be
configured on demand to adapt to different interface equipment.
The maximum transmission distance of single-mode single fiber is 100km.
The maximum transmission distance of single mode dual fiber is 100km.
The maximum transmission distance of multimode dual fiber is 850m/2km.
Security & Protection
STP / RSTP / MSTP spanning tree protocol is supported to eliminate layer-2 loops and realize link backup.
Support tree security function, prevent devices in tree network from being attacked by various forms of malicious.
It supports static aggregation and dynamic aggregation, effectively increases link bandwidth, realizes load balancing,
link backup, and improves link reliability.
Running and Maintenance
Support web management, CLI command line (console, telnet), SNMP (v1/v2/v3) and other diversified management
and maintenance methods.
It supports HTTPS, SSL V3, tlsv1, sshv1/v2 and other encryption methods, and makes management more secure.
It supports RMON, system log and port traffic statistics to facilitate network optimization and transformation.
Users can know the working status of the switch through the power indicator (PWR), port status indicator and system
status indicator (sys).
Functional features
Add a variety of new applications based on IPv6, easily adapt to modern complex network management applications
Support IEEE 802.1Q VLAN, users can divide VLAN flexibly according to their needs.
Support voice VLAN, configure QoS parameters for voice data stream, improve the transmission priority of voice data
stream and ensure the call quality.
It supports QoS, supports port based, 802.1p and DSCP based priority modes to optimize the bandwidth configuration.
It supports ACL, achieves packet filtering by configuring matching rules, processing operations and time permissions,
and provides flexible security access control policies
Support IGMP V1 / V2 multicast protocol, support IGMP snooping, meet the requirements of multi terminal HD video
monitoring and video conference access.
Support multicast VLAN, multicast filtering, efficient data transmission, save network bandwidth, reduce network load.
Support port monitoring, copy the data package of monitored port to the monitoring port to realize network monitoring.
Support the management and maintenance of equipment through web interface.
It supports port convergence, effectively increases link bandwidth, realizes link backup and improves link reliability.

02 Spare parts list
Switch DC adapter User manual
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
03 Product display
Front Back
F1200W-9S-2G
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Power
Uplink portIndicator and
Reset port Console port
Downlink SFP port DC Power
Indicator
Power indicator: PWR
Network indicator
Status Description
Green light is always on Power on normal
Always off No power
Orange Light is flashing The corresponding port works at 1000M speed
SFP indicator: 3~11 Light is on The corresponding port has data transmission
Green Light is flashing The corresponding port works at 10/100M speed
Indicator definition:
04 Installation&Points of attention
Checking before installation
1.Check whether the accessories are complete. If there is any omission, please contact us.
2.Check whether the power supply voltage is consistent with the working voltage of the switch,so as to avoid the
equipment burning out due to high voltage.
3.Ensure that the installation position of the switch has certain ventilation and heat dissipation conditions.
4.Please keep the power off during installation to avoid potential safety hazards.
5.Please install the switch on a stable plane to avoid falling and damage.
Port installation and connection
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Insert the data cable Install the SFP module
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9

As shown in the figure, insert the crystal head of
the data cable into the network port. When you
hear a clear click, it indicates that the crystal
head is successfully connected with the network
port of the switch. Just plug in all the network
cables of the network equipment in this way.
As shown in the figure, align the optical fiber
module with the optical port of the SFP and
insert it smoothly. When you hear a clear
click, it indicates that the optical fiber module
is installed successfully. Just install the two
optical fiber modules in this way.
Install to desktop
Place the switch on the desktop
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
The switch should be placed on a well ventilated
horizontal desktop, which is conducive to better
heat dissipation of the equipment
Power onPower on
Connected the power
Plug into
electricity supply
Power
Points of attention
1.Do not stack heavy objects on the switch to avoid danger.
2.In order to avoid the risk of electric shock, please do not open the machine box when the switch is working, even if it
is not powered on, please contact us in case of any problem.
3.Before cleaning the switch, pull out the power plug of the switch. Do not wipe it with wet fabric or clean it with liquid.
4.If the power adapter is damaged, do not replace it with other power adapters. This switch should be equipped with
original power adapter.

05 Application
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Server Router NVR
recorder
Camera Camera
Ethernet Switch
Wireless APIP Phone
Wireless AP IPTV
The uplink port can connect
routers, servers and other
devices. The downlink port can
be connected to the switch or
directly connected to the
network equipment. It also
supports port based VLAN,
which can be divided into up to
4096 VLANs.
VLAN application
VLAN1
VLAN2
VLAN3
VLAN4
Application of ring network
RPL Owner
RPL
Data stream
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9
Gigabit Managed Switch
Fiber Convergence Switch
RET PWR
11
4
3
6
5
8
7
10
Console
1
23 4 5 6 7 8 9 10 11
9

06 Common troubleshooting
The PWR indicator is not on after the power is connected Check whether the power adapter and plug are
connected correctly, whether the power cord is damaged, and whether the power adapter is damaged.
Switch cannot communicate after power up Check whether the switch indicator is on. If the indicator is off, the
network cable is not connected. If the indicator is on, the communication fault is indicated.
Switch network speed suddenly become very slow Take off the plug and restart the switch.
[If the above problems or other switch problems can not be solved, please contact us for technical support]

07 Product Parameter
Model
Product
G092GSM
11 Port Gigabit Fiber Managed Switch
Fixed Port 9*1000M SFP
2*10/100/1000Base-TX RJ45 port (Data)
Console port 1*console port
Reset Key 1
Port Specification 10/100/1000BaseT（X）Auto
Transmission Mode Store and Forward(full wirespeed)
Bandwidth 56Gbps
Packet Forwarding 40.32Mpps
MAC Address 8K
Buffer 4.1M
Transmission Distance
10BASE-T ： Cat3,4,5 UTP(≤250 meter)
100BASE-TX ： Cat5 or later UTP(≤100 meter)
1000BASE-TX ： Cat6 or later UTP(≤1000 meter)
1000BASE-SX:62.5μm/50μm MMF(2m~550m)
1000BASE-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)
Watt ≤20W
FLASH 128M
RAM 128M
LED Indicator
PWR: Power LED
3~11:(SFP LED)
Port:(Green_10/100M LED;Orange_1000M LED)
Power External power DC 12V 2.5A
Operating
Temperature/Humidity -20～+55°C；5%～90% RH Non coagulation
Storage
Temperature/Humidity -40～+75°C；5%～95% RH Non coagulation
Product size/ package size
（L*W*H）
245mm*110mm*40mm
300mm*205mm*55mm
N.W/G.W（kg）0.7kg/1kg
Installation Desktop
IEEE 802.3
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3x
IEEE 802.3ad
IEEE 802.3q 、IEEE 802.3q/p
IEEE 802.1w、IEEE 802.1d 、IEEE 802.1S
STP(Spanning Tree Protocol)
RSTP/MSTP( Rapid Spanning Tree Protocol)
EPPS ring network protocol
EAPS ring network protocol
Network Protocol

Network Protocol
IEEE 802.3x
IEEE 802.3、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3z
IEEE 802.3ad
IEEE 802.3q、IEEE 802.3q/p
IEEE 802.1w、IEEE 802.1d、IEEE 802.1S、IEEE 802.1X
MAC Support 16K MAC address,auto aging and learning
Port Aggregation Support 8 groups of aggregation, each group support up to 8 ports
Port Mirroring Support many-to-one port mirroring
Loop Guard Support loop protection, real-time detection, quick alram, concise location,
Intelligent blocking, automatic recovery
Port Isolation Support downlink ports isolate from each other and communicate with
uplink port as well
Speed Limitation Bandwidth management based on port input and output
DHCP DHCP Snooping
Security
Support User port+IP address+MAC address
ACL based on IP, MAC
Support security properties of number of MAC address based on port
Storm Suppression Support unknown unicast, multicast , unknown multicast, broadcast type
storm suppression;
Storm suppression based on bandwidth adjustment and storm filtering
Multicast Control
IGMPv1/2/3 and MLDv1/2 Snooping
GMRP protocol registration
Multicast address management, multicast VLAN, multicast routing port,
static multicast address
Flow Control Half duplex based on Back pressure;
Full duplex based on PAUSE frame
Spanning Tree
STP(Spanning tree protocol)
RSTP(Rapid spanning tree protocol)
MSTP(Rapid spanning tree protocol)
EPPS(Ring network protocol)
EAPS(Ring network protocol)
802.1x
VLAN Configuration
Support port-based VLAN
Up to 4096 VLANs
Support Voice VLAN, can configure Qos for voice data
802.1Q
Software Function
The followings are main functions not included in all the functions.Please contact with us for more other
information!（We support software development for customization requirement）
Lightning protection
/ protection level
3KV 8/20us；
IP30
Certificate CE mark, commercial；CE/LVD EN60950；
FCC Part 15 Class B；RoHS；
Warranty Whole device for 1 year(Accessories not included)

Cable Sequence Auto-MDIX; auto detection on straight-through and cross-over cable
Negotiation Mode Port support auto negotiation function(self-negotiation transmission rate
and duplex mode)
Network Management
WEB interface management
CLI management based on Telnet、TFTIP、Console
SNMP V1/V2/V3 management
RMONV1/V2 management
RMON management
System maintenance
Upgrade package upload
System log viewing
WEB recovery factory configuration
QOS
802.1p port queue priority algorithm
Cos/Tos,QOS remark
WRR(Weighted Round Robin), weighted priority rotation algorithm
WRR、SP、WFQ priority scheduling modes
Wuhan MokerLink Technology Co.,Ltd
Rm10,13/F,Main Building 7,Changhang Lanjing International,
No.116 Gaoxin Ave.,Hongshan Dist.,Wuhan,China
http://www.mokerlink.com
[email protected]
For technical support and other information, please visit
http://www.mokerlink.com/support/
