Monacor SOUND-100SUB User manual

ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS
SOUND-100SUB
Bestell-Nr. • Order No. 25.0730
BEDIENUNGSANLEITUNG
INSTRUCTION MANUAL
MODE D’EMPLOI
ISTRUZIONI PER L’USO
MANUAL DE INSTRUCCIONES
INSTRUKCJA OBSŁUGI
VEILIGHEIDSVOORSCHRIFTEN
SIKKERHEDSOPLYSNINGER
SÄKERHETSFÖRESKRIFTER
TURVALLISUUDESTA
Aktiv-Subwoofer
Active Subwoofer System

ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS
2
Deutsch ..........Seite 4
English ...........Page 8
Français ..........Page 12
Italiano...........Pagina 16
Español ..........Página 20
Polski ............Strona 24
Nederlands .......Pagina 28
Dansk ............Sida 28
Svenska ..........Sidan 29
Suomi............Sivulta 29

3
VOLUME
CROSSOVER
MIN MAX
50 Hz 150 Hz
POWER ON
GREEN – ON
RED – STAND-BY
LINE IN
LFE
STAND BY
OFF AUTO ON
PHASE
0 180
HIGH LEVEL IN
HIGH LEVEL OUT
LEFT RIGHT
RIGHTLEFT
POWER
230V~/50Hz
R
L
200 WMAX /120 WRMS
F
U
S
E
1
2
3
7
8
4
5
6
9
10
11
12

4
English
English Page
Contents
Français
Français Page
Table des matières
Italiano
Italiano Pagina
Indice
Español
Español Página
Contenidos
Nederlands
Nederlands Pagina
Inhoud
Polski
Polski Strona
Spis treści
Deutsch
Deutsch Seite
Inhalt
Deutsch
Inhalt
1 Übersicht . . . . . . . . . . . . . . . 4
2 Hinweise für den sicherenGebrauch 5
3 Einsatzmöglichkeiten. . . . . . . . .5
4 Aufstellen und Anschließen . . . . . 5
4.1 Stereo-Eingang LINE IN . . . . . . . . . 5
4.2 Stereo-Eingang HIGH LEVEL IN . . . . . 6
4.3 Mono-Eingang LFE . . . . . . . . . . . 6
4.4 Stromversorgung . . . . . . . . . . . .6
5 Bedienung. . . . . . . . . . . . . . .6
5.1 Schutzschaltungen . . . . . . . . . . . 7
6 Technische Daten . . . . . . . . . . . 7
Aktiv-Subwoofer
Diese Anleitung richtet sich an Benutzer mit
Grundkenntnissen in der Audiotechnik. Bitte
lesen Sie die Anleitung vor dem Betrieb gründ-
lich durch und heben Sie sie für ein späteres
Nachlesen auf.
Auf der ausklappbaren Seite 3 finden Sie alle
beschriebenen Bedienelemente und Anschlüsse.
1 Übersicht
1 Betriebsanzeige
Grün in Betrieb
Rot Stand-by (Bereitschaftsmodus) oder
bei aktiver Schutzschaltung
2 Lautstärkeregler VOLUME
3
Regler CROSSOVER zum Einstellen der Grenz-
frequenz (50–150 Hz) des Tiefpassfilters für
die Eingänge LINE IN und HIGH LEVEL IN
4 Netzschalter POWER
5 Halterung für die Netzsicherung;
eine durchgebrannte Sicherung nur durch
eine gleichen Typs ersetzen
6
Kabel zum Anschluss an eine Netzsteckdose
(230V/50Hz)
7
Stereo-Signaleingang LINE IN als Cinch-
Buchsen
8 Mono-Signaleingang LFE als Cinch-Buchse
9 Phasenumkehrschalter PHASE
10
Umschalter STAND BY für den Bereitschafts-
modus
Position OFF: immer im Bereitschafts-
modus
Position ON: immer in Betrieb
Position AUTO: signalpegelabhängiges Um-
schalten zwischen Betriebs-
und Bereitschaftsmodus
11
Stereo-Signaleingang HIGH LEVEL IN zum
Anschluss an den Lautsprecherausgang
eines Verstärkers
Unter den Abdeckkappen der Schraubklem-
men befinden sich Bananenbuchsen.
12
Durchschleifausgänge HIGH LEVEL OUT,
verbunden mit den entsprechenden Buch-
sen HIGH LEVEL IN (11), zum Anschluss der
anderen Lautsprecher
Unter den Abdeckkappen der Schraubklem-
men befinden sich Bananenbuchsen.

5
Deutsch
2 Hinweise für den
sicherenGebrauch
Das Gerät entspricht allen relevanten Richtlinien
der EU und und trägt deshalb das -Zeichen.
WARNUNG
Das Gerät wird mit lebensgefähr-
licher Netzspannung versorgt.
Nehmen Sie deshalb niemals
selbst Eingriffe daran vor. Es
besteht die Gefahr eines elekt-
rischen Schlages.
•
Verwenden Sie das Gerät nur im Innenbereich
und schützen Sie es vor Tropf- und Spritzwas-
ser, hoher Luftfeuchtigkeit und Hitze (zulässi-
ger Einsatztemperaturbereich 0–40°C).
•
Stellen Sie keine mit Flüssigkeit gefüllten Ge-
fäße, z.B. Trinkgläser, auf das Gerät.
•
Die im Gerät entstehende Wärme muss durch
Luftzirkulation abgegeben werden. Decken
Sie die Lüftungsöffnungen (Bassreflexöffnun-
gen) nicht ab.
•
Nehmen Sie das Gerät nicht in Betrieb oder
ziehen Sie sofort den Netzstecker aus der
Steckdose,
1.
wenn sichtbare Schäden am Gerät oder am
Netzkabel vorhanden sind,
2.
wenn nach einem Sturz oder Ähnlichem
der Verdacht auf einen Defekt besteht,
3. wenn Funktionsstörungen auftreten.
Geben Sie das Gerät in jedem Fall zur Repa-
ratur in eine Fachwerkstatt.
•
Ein beschädigtes Netzkabel darf nur durch
eine Fachwerkstatt ersetzt werden.
•
Ziehen Sie den Netzstecker nie am Kabel aus
der Steckdose, fassen Sie immer am Stecker an.
•
Verwenden Sie für die Reinigung nur ein tro-
ckenes, weiches Tuch, niemals Wasser oder
Chemikalien.
•
Wird das Gerät zweckentfremdet, nicht rich-
tig angeschlossen, falsch bedient oder nicht
fachgerecht repariert, kann keine Haftung für
daraus resultierende Sach- oder Personen-
schäden und keine Garantie für das Gerät
übernommen werden.
Soll das Gerät endgültig aus dem Be-
trieb genommen werden, übergeben
Sie es zur umweltgerechten Entsor-
gung einem örtlichen Recyclingbetrieb.
3 Einsatzmöglichkeiten
Dieser kompakte aktive Subwoofer dient als tief
-
frequente Ergänzung bestehender Lautsprecher-
anlagen im Hi-Fi-, Heimkino- und Homerecording-
Bereich. Er ist mit einem 25-cm-Basslautsprecher
(10”) ausgestattet und sein Verstärker hat eine
Spitzenausgangsleistung von 200W.
Der Subwoofer verfügt über ein einstell-
bares Tiefpassfilter, einen Lautstärkeregler,
eine schaltbare Phasenumkehrung und eine
Stand-by-Automatik. Der eingebaute Verstärker
ist mit Schutzschaltungen gegen Überlastung
und Überhitzung ausgerüstet.
Es sind Eingänge für den Anschluss an
Stereo-Ausgänge mit Line-Pegel sowie für den
Anschluss an Lautsprecherausgänge (mit Durch-
schleifmöglichkeit für die anderen Lautsprecher)
vorhanden.
Zusätzlich verfügt der Subwoofer über einen
LFE-Eingang. In Mehrkanalsystemen aus dem
Kinobereich, z.B. „5.1“, dient der LFE-Kanal
zur Übertragung tieffrequenter Spezialeffekte
(„Low Frequency Effect“ oder „Low Frequency
Enhancement“).
4 Aufstellen und Anschließen
Den Subwoofer auf einen ebenen Untergrund
stellen. Die genaue Positionierung in der Mitte
zwischen den Stereo-Lautsprechern ist beim
Subwoofer nicht entscheidend, da die von ihm
wiedergegebenen sehr tiefen Frequenzen nicht
genau geortet werden können. Stellen Sie ihn
jedoch nicht zu dicht an Wände oder in Ecken,
weil dies den Frequenzgang verfälscht und die
Wärmeabfuhr des eingebauten Verstärkers be-
hindert. Ebenso dürfen die auf der Unterseite
befindlichen Bassreflex-Öffnungen nicht abge-
deckt werden.
Vor dem Anschluss bzw. vor dem Ändern
bestehender Anschlüsse den Subwoofer und die
anzuschließenden Geräte ausschalten.
Eine Signalquelle über eine der drei in den
Kapiteln 4.1 bis 4.3 beschriebenen Anschluss-
möglichkeiten mit dem Subwoofer verbinden.
4.1 Stereo-Eingang LINE IN
Ist ein Stereo-Ausgang mit Line-Pegel vorhan-
den (z.B. Ausgang eines Vorverstärkers oder
Mischpultes), diesen mit dem Eingang LINE IN
(7) am Subwoofer verbinden. Aus den beiden

6
Deutsch
Stereo-Kanälen wird intern für den Subwoofer
ein Mono-Signal gebildet.
Sind die Ausgänge des Vorverstärkers oder
Mischpultes bereits durch den Anschluss der
vorhandenen Lautsprecheranlage belegt, kann
ein Adapter zur Verzweigung des Ausgangs-
signals verwendet werden (z.B. ACA-120 von
MONACOR).
4.2 Stereo-Eingang HIGH LEVEL IN
Steht kein Ausgang mit Line-Pegel zur Verfü-
gung, die Anschlüsse HIGH LEVEL IN (11) mit
den Lautsprecherausgängen des Verstärkers
verbinden (LEFT = linker Kanal, RIGHT = rech-
ter Kanal). Dabei die Polarität der Anschlüsse
beachten. Beim Anschließen unbedingt den Ver-
stärker ausschalten und darauf achten, dass die
Kabelenden für den Anschluss an die Schraub-
klemmen nicht zu weit abisoliert sind und keine
blanken Drähte herausragen (Berührungs- und
Kurzschlussgefahr). Die Durchschleifausgänge
HIGH LEVEL OUT (12) sind direkt mit den ent-
sprechenden Buchsen HIGH LEVEL IN verbun-
den. Hier können die anderen Lautsprecher-
boxen angeschlossen werden.
Unter den Abdeckkappen der Schraubklem-
men befinden sich Bananenbuchsen.
WARNUNG
Ist ein Verstärker mit den An-
schlüssen HIGH LEVEL IN (11)
verbunden, müssen alle nicht
belegten Bananenbuchsen mit
den Kappen abgedeckt sein. An-
derenfalls besteht bei Berührung
der Anschlüsse die Gefahr eines
elektrischen Schlages.
4.3 Mono-Eingang LFE
Den LFE-Ausgang eines Mehrkanalsystems oder
einen anderen Mono-Ausgang mit Line-Pegel
mit der Buchse LFE (8) verbinden.
Hinweis: Das Signal einer hier angeschlossenen Signal-
quelle wird nicht durch das einstellbare Tiefpassfilter be-
einflusst, da ein LFE-Signal in der Regel nur tieffrequente
Signale enthält.
4.4 Stromversorgung
Den Stecker des Netzkabels (6) in eine Netz-
steckdose (230V/50Hz) stecken.
5 Bedienung
VORSICHT
Stellen Sie die Lautstärke der
Audioanlage nie sehr hoch ein.
Hohe Lautstärken können auf
Dauer das Gehör schädigen! Das
Ohr gewöhnt sich an sie und
empfindet sie nach einiger Zeit als
nicht mehr so hoch. Darum eine
hohe Lautstärke nach der Gewöh-
nung nicht weiter erhöhen.
Hinweis: Um Schaltgeräusche zu vermeiden, den Sub-
woofer immer nach den angeschlossenen Geräten ein-
schalten und nach dem Gebrauch zuerst ausschalten.
1)
Den Regler VOLUME (2) zunächst auf MIN
(Linksanschlag) stellen und den Subwoofer
mit dem Schalter POWER (4) einschalten. Die
LED (1) leuchtet.
2)
Mit dem Schalter STAND BY (10) die Stand-by-
Automatik ein- oder ausschalten.
Position „AUTO“:
Die Stand-by-Automatik ist aktiv. Der Sub
-
woofer geht automatisch in Betrieb, wenn
ein Eingangssignal anliegt und der Regler
VOLUME (2) entsprechend weit aufgedreht
ist. Die Betriebsanzeige (1) leuchtet dann
grün. Fällt der Signalpegel für einige Minuten
unter einen bestimmten Wert, schaltet der
Subwoofer wieder in den Bereitschaftsmodus
zurück; die Betriebsanzeige leuchtet rot.
Position „ON“:
Die Stand-by-Automatik ist deaktiviert. Der
Subwoofer ist nach dem Einschalten immer
in Betrieb. Die Betriebsanzeige (1) leuchtet
grün.
Position „OFF“:
Der Subwoofer ist immer im Bereitschafts-
modus. Die Betriebsanzeige (1) leuchtet rot.
So lässt sich der Subwoofer sofort in den
Bereitschaftsmodus versetzen, um z.B. an-
schließend in der Position „AUTO“ die Ein-
schaltschwelle zu testen.
3)
Über die bestehende Lautsprecheranlage
z.B. Musik wiedergeben und mit dem Regler
VOLUME (2) den gewünschten Tiefbassanteil
dazumischen. Den Regler nur so weit auf-
drehen, dass der Ton nicht verzerrt wieder-
gegeben wird.

7
Deutsch
4)
Ist die Signalquelle über die Eingänge LINE IN
(7) oder HIGH LEVEL IN (11) angeschlossen,
mit dem Regler CROSSOVER (3) die Grenz-
frequenz des Tiefpassfilters so einstellen,
dass der Subwoofer den Frequenzgang der
anderen Lautsprecher optimal ergänzt. Auf
den Eingang LFE (8) hat dieses Filter keine
Auswirkung.
Wenn erforderlich, die Lautstärkebalance
mit dem Regler VOLUME (2) korrigieren.
5)
Bei unterschiedlichen Abständen der Laut-
sprecher zum Hörer kann es zu Phasenaus-
löschungen kommen (bestimmte Frequenzen
werden dadurch leiser). Zum Ausgleich kann
mithilfe des Schalters PHASE (9) die Phase des
Subwoofersignals umgekehrt werden.
Durch Probieren herausfinden, bei wel-
cher Schalterstellung an der Hörposition
die lauteste Basswiedergabe erreicht wird.
Wenn erforderlich, anschließend die Laut-
stärkebalance mit dem Regler VOLUME (2)
korrigieren.
6)
Ist die Stand-by-Automatik deaktiviert
(☞Bedienschritt 2), nach dem Gebrauch
den Subwoofer mit dem Schalter POWER
(4) wieder ausschalten.
In jedem Fall empfiehlt es sich, bei län-
geren Nutzungspausen den Subwoofer zur
Vermeidung unnötigen Stromverbrauchs
auszuschalten.
5.1 Schutzschaltungen
Der Verstärker des Subwoofers ist mit Schutz-
schaltungen gegen Überlastung und Überhit-
zung ausgestattet. Leuchtet die Betriebsanzeige
rot, obwohl der Schalter STAND BY (10) in der
Position „ON“ steht oder wechselt die Farbe
der Betriebsanzeige während des Betriebs trotz
eines ausreichenden Signals auf Rot, ist eine
Schutzschaltung aktiv. In diesem Fall muss der
Subwoofer ausgeschaltet und die Fehlerursache
behoben werden.
6 Technische Daten
Frequenzbereich: . . . . . . ☞Diagramm unten
Verstärkerleistung
Sinusleistung: . . . . . . . . 120W
Maximale Leistung: . . . 200W
Lautsprecher-
Kennschalldruck:. . . . . . . 88dB (1 W/1 m)
Max. Schalldruck: . . . . . . 108dB
Eingänge (Empfindlichkeit, Impedanz, Anschluss)
LINE IN: . . . . . . . . . . . . 150 mV, 24 kΩ, Cinch
LFE: . . . . . . . . . . . . . . . 55mV, 16 kΩ, Cinch
HIGH LEVEL IN:. . . . . . . 2,3 V, 440 Ω,
Schraubklemme mit
4-mm-Bananenbuchse
Stromversorgung: . . . . . . 230V/50Hz
Leistungsaufnahme: . . . . max. 240VA
Einsatztemperatur: . . . . . 0– 40 °C
Abmessungen
(B × H × T):. . . . . . . . . . . 330 × 360 × 360mm
Gewicht:. . . . . . . . . . . . . 13 kg
Änderungen vorbehalten.
Diese Bedienungsanleitung ist urheberrechtlich für MONACOR
®INTERNATIONAL GmbH & Co. KG geschützt.
Eine Reproduktion für eigene kommerzielle Zwecke – auch auszugsweise – ist untersagt.
Frequenzgang bei Verwendung der Eingänge LINE IN oder HIGH LEVEL IN
mit minimal und maximal eingestellter Tiefpassfrequenz
[dB]
[Hz]

8
Deutsch
Deutsch Seite
Inhalt
Français
Français Page
Table des matières
Italiano
Italiano Pagina
Indice
Español
Español Página
Contenidos
Nederlands
Nederlands Pagina
Inhoud
Polski
Polski Strona
Spis treści
English
English Page
Contents
English
Contents
1 Operating Elements
and Connections . . . . . . . . . . . 8
2 Safety Notes . . . . . . . . . . . . . 9
3 Applications. . . . . . . . . . . . . .9
4 Setting Up and Connecting . . . . . 9
4.1 Stereo input LINE IN . . . . . . . . . 10
4.2 Stereo input HIGH LEVEL IN . . . . . 10
4.3 Mono input LFE. . . . . . . . . . . . 10
4.4 Power supply . . . . . . . . . . . . . 10
5 Operation . . . . . . . . . . . . . . 10
5.1 Protective circuits . . . . . . . . . . . 11
6 Specifications . . . . . . . . . . . . 11
Active Subwoofer System
These operating instructions are intended for
users with basic knowledge in audio technol-
ogy. Please read the instructions carefully prior
to operating the unit and keep them for later
reference.
All operating elements and connections
described can be found on the fold-out page 3.
1 Operating Elements
and Connections
1 POWER LED
green subwoofer in operation
red subwoofer in standby mode or pro-
tective circuit activated
2 VOLUME control
3
CROSSOVER control to adjust the cutoff fre-
quency (50–150Hz) of the low pass filter for
the inputs LINE IN and HIGH LEVEL IN
4 POWER switch
5 Support for the mains fuse;
always replace a blown fuse by one of the
same type
6
Cable for connection to a mains socket
(230V/50Hz)
7 Stereo signal input LINE IN (RCA jacks)
8 Mono signal input LFE (RCA jack)
9 PHASE reversal switch
10 STAND BY selector switch
position OFF: always in standby mode
position ON: always in operation
position AUTO: switching between the
modes operation and
standby depending on
the signal level
11
Stereo signal input HIGH LEVEL IN for connec-
tion to the speaker output of an amplifier
There are banana jacks under the protective
caps of the screw terminals.
12
Feed-through outputs HIGH LEVEL OUT,
connected to the corresponding jacks
HIGH LEVEL IN (11), for connecting the
other speakers
There are banana jacks under the protective
caps of the screw terminals.

9
English
2 Safety Notes
This unit corresponds to all relevant directives of
the EU and is therefore marked with .
WARNING
The unit uses dangerous mains
voltage. Leave servicing to skilled
personnel only. Inexpert han-
dling or modification of the unit
may result in electric shock.
•
The unit is suitable for indoor use only. Protect
it against dripping water and splash water,
high air humidity and heat (admissible ambi-
ent temperature range 0–40°C).
•
Do not place any vessel filled with liquid on
the unit, e.g. a drinking glass.
•
The heat generated inside the unit must be
dissipated by air circulation. Do not cover the
air vents (bass-reflex openings).
•
Do not operate the unit or immediately dis-
connect the mains plug from the socket
1.
if the unit or the mains cable is visibly dam-
aged,
2. if a defect might have occurred after the
unit was dropped or suffered a similar
accident,
3. if malfunctions occur.
In any case the unit must be repaired by skilled
personnel.
•
A damaged mains cable must be replaced by
skilled personnel only.
•
Never pull the mains cable to disconnect the
mains plug from the socket, always seize the
plug.
•
For cleaning only use a dry, soft cloth; never
use water or chemicals.
•
No guarantee claims for the unit and no liabil-
ity for any resulting personal damage or mate-
rial damage will be accepted if the unit is used
for other purposes than originally intended, if
it is not correctly connected or operated, or if
it is not repaired in an expert way.
•
Important for U. K. Customers!
The wires in the mains lead are coloured in
accordance with the following code:
blue = neutral
brown = live
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows:
1.
The wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black.
2. The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
If the unit is to be put out of operation
definitively, take it to a local recycling
plant for a disposal which is not harm-
ful to the environment.
3 Applications
This compact active subwoofer is used as a
low-frequency complement of existing audio
systems for hi-fi applications, home cinema and
home recording applications. It is equipped with
a 25cm (10”) bass speaker. Its amplifier offers a
peak output power of 200W.
The subwoofer features an adjustable low
pass filter, a volume control, a phase reversal
switch and an automatic standby mode. The
integrated amplifier is provided with protective
circuits to prevent overload and overheating.
Inputs are provided for connection to stereo
outputs with line level and for connection to
speaker outputs (with feed-through facility for
the other speakers).
The subwoofer also features an LFE input. In
multi-channel systems for cinema applications,
e.g. “5.1”, the LFE channel (“Low Frequency
Effect” or “Low Frequency Enhancement”) is
used for low-frequency special effects.
4 Setting Up and Connecting
Set up the subwoofer on a flat surface. It is
not important to place the subwoofer exactly
in the middle between the stereo speakers as it
will not be possible to precisely locate the very
low frequencies reproduced by the subwoofer.
However, do not place it too close to walls or
in corners; this would distort the frequency re-
sponse and prevent the heat dissipation of the
integrated amplifier. Likewise, do not cover the
bass-reflex openings on the lower side.
Prior to making connections or changing
any existing connections, switch off the sub-
woofer and the units to be connected.

10
English
Connect a signal source via one of the three con-
nection options described in chapters 4.1 to 4.3.
4.1 Stereo input LINE IN
If a stereo output with line level is provided (e.g.
output of a preamplifier or mixer), connect this
output to the input LINE IN (7) on the subwoofer.
From the two stereo channels, a mono signal will
be created internally for the subwoofer.
If the outputs of the preamplifier or mixer
are already used for the existing audio system,
use an adapter to divide the output signal (e.g.
ACA-120 from MONACOR).
4.2 Stereo input HIGH LEVEL IN
If no output with line level is available, connect
the inputs HIGH LEVEL IN (11) to the speaker
outputs of the amplifier (LEFT = left channel,
RIGHT = right channel). Observe the correct
polarity of the connections. When connecting,
always switch off the amplifier. Make sure that
the cable ends used for connection to the screw
terminals are only stripped as far as necessary
and that no bare wires stick out (danger of con-
tact and short circuit). The feed-through outputs
HIGH LEVEL OUT (12) are directly connected to
the corresponding jacks HIGH LEVEL IN. Use
these jacks to connect the other speaker systems.
There are banana jacks under the protective
caps of the screw terminals.
WARNING
If an amplifier is connected to the
inputs HIGH LEVEL IN (11), cover
all banana jacks not used with
the protective caps; touching the
connections may result in electric
shock.
4.3 Mono input LFE
Connect the LFE output of a multi-channel sys-
tem or another mono output with line level to
the jack LFE (8).
Note: The adjustable low pass filter will not affect the
signal of a signal source connected to this input as an
LFE signal usually contains low-frequency signals only.
4.4 Power supply
Connect the plug of the mains cable (6) to a
mains socket (230V/50Hz).
5 Operation
CAUTION Never adjust the audio system to
a very high volume. Permanent
high volumes may damage your
hearing! Your ear will get accus-
tomed to high volumes which do
not seem to be that high after
some time. Therefore, do not fur-
ther increase a high volume after
getting used to it.
Note: To prevent switching noise, always switch on the
units connected before switching on the subwoofer and
switch it off first after use.
1)
Set the VOLUME control (2) to MIN (left
stop) for the time being and switch on the
subwoofer with the POWER switch (4). The
POWER LED (1) will light up.
2)
With the STAND BY switch (10), switch on or
off the automatic standby mode.
Position “AUTO”:
The automatic standby mode is activated.
The subwoofer will automatically be in oper-
ation once an input signal has been applied
and the VOLUME control (2) has been turned
up accordingly. The POWER LED (1) will show
green. If the signal level falls below a certain
value for a few minutes, the subwoofer will
return to the standby mode; the POWER LED
will show red.
Position “ON”:
The automatic standby mode is deactivated.
After switching on, the subwoofer will
always be in operation. The POWER LED(1)
will show green.
Position “OFF”:
The subwoofer is always in standby mode.
The POWER LED (1) will show red. Thus, it
will be possible to set the subwoofer to the
standby mode immediately, e.g. for test-
ing the switch-on threshold in the position
“AUTO” subsequently.
3)
Reproduce sound, e.g. music, via the existing
audio system and add the desired low bass
part with the VOLUME control (2). Only turn
up the control to such an extent that the
sound reproduced will not be distorted.

11
English
4) If the signal source is connected via the in-
puts LINE IN (7) or HIGH LEVEL IN (11), adjust
the cutoff frequency of the low pass filter
with the CROSSOVER control (3) so that the
subwoofer will optimally complement the
frequency response of the other speakers.
This filter will not affect the input LFE (8).
If required, readjust the volume balance
with the VOLUME control (2).
5)
Different distances of speakers to the listener
may result in phase cancelation (certain fre-
quencies will have a lower volume). To com-
pensate this, the phase of the subwoofer
signal is reversible with the PHASE reversal
switch (9).
Test both switch positions to find the
position offering the bass reproduction of
the highest volume at the listening position.
Then readjust the volume balance with the
VOLUME control (2), if required.
6)
If the automatic standby mode is deactivated
(☞step 2), switch off the subwoofer with
the POWER switch (4) after use.
To prevent unnecessary power consump-
tion, it is always recommended to switch off
the subwoofer when not in use for longer
periods.
5.1 Protective circuits
The amplifier of the subwoofer is provided with
protective circuits to prevent overload and over-
heating. If the POWER LED shows red although
the STAND BY switch (10) is set to “ON” or if
the colour of the POWER LED changes to red
despite a sufficient signal, a protective circuit
has been activated. In this case, switch off the
subwoofer and eliminate the cause of defect.
6 Specifications
Frequency range: . . . . . . ☞diagram below
Amplifier power
RMS power: . . . . . . . . 120 W
Maximum power:. . . . . 200 W
Sensitivity
of the speaker: . . . . . . . . 88dB (1 W/1 m)
Max. SPL: . . . . . . . . . . . . 108 dB
Inputs (sensitivity, impedance, connection)
LINE IN: . . . . . . . . . . . . 150mV, 24kΩ, RCA
LFE: . . . . . . . . . . . . . . . 55mV, 16 kΩ, RCA
HIGH LEVEL IN: . . . . . . 2.3 V, 440 Ω,
screw terminal with
4mm banana jack
Power supply: . . . . . . . . . 230V/50Hz
Power consumption:. . . . 240 VA max.
Ambient temperature: . . 0 – 40°C
Dimensions (W × H × D): 330 × 360 × 360mm
Weight: . . . . . . . . . . . . . 13 kg
Subject to technical modification.
Frequency response when using the inputs LINE IN or HIGH LEVEL IN
with the low pass frequency set to minimum and maximum
[dB]
[Hz]
All rights reserved by MONACOR
®INTERNATIONAL GmbH & Co. KG. No part of this instruction manual may
be reproduced in any form or by any means for any commercial use.

12
Deutsch
Deutsch Seite
Inhalt
English
English Page
Contents
Italiano
Italiano Pagina
Indice
Español
Español Página
Contenidos
Nederlands
Nederlands Pagina
Inhoud
Polski
Polski Strona
Spis treści
Français
Français Page
Table des matières
Table des matières
1 Eléments et branchements. . . . . 12
2 Conseils d’utilisation
et de sécurité . . . . . . . . . . . . 13
3 Possibilités d’utilisation . . . . . . 13
4 Positionnement et branchements . 13
4.1 Entrée stéréo LINE IN . . . . . . . . . 14
4.2 Entrée stéréo HIGH LEVEL IN . . . . . 14
4.3 Entrée mono LFE . . . . . . . . . . . 14
4.4 Alimentation . . . . . . . . . . . . . 14
5 Utilisation . . . . . . . . . . . . . . 14
5.1 Circuits de protection. . . . . . . . . 15
6 Caractéristiques techniques . . . . 15
Français
Subwoofer actif
Cette notice s’adresse aux utilisateurs avec des
connaissances techniques de base en audio.
Veuillez lire la présente notice avec attention
avant le fonctionnement et conservez-la pour
pouvoir vous y reporter ultérieurement.
Vous trouverez sur la page 3, dépliable, les
éléments et branchements décrits.
1 Eléments et branchements
1 Témoin de fonctionnement
vert en fonctionnement
rouge stand by (mode veille) ou si le circuit
de protection est activé
2
Potentiomètre de réglage de volume VOLUME
3
Réglage CROSSOVER pour régler la fré-
quence de coupure (50– 150 Hz) du filtre
passe-bas pour les entrées LINE IN et HIGH
LEVEL IN
4 Interrupteur secteur POWER
5 Porte-fusible ;
tout fusible fondu doit être remplacé im-
pérativement par un fusible de même type
6
Cordon à relier à une prise secteur 230 V/
50Hz
7 Entrée signal stéréo LINE IN, prises RCA
8 Entrée signal mono LFE, prise RCA
9 Inverseur de phase PHASE
10 Commutateur STAND BY pour le mode de
fonctionnement veille
position OFF : toujours en mode veille
position ON : toujours en fonctionne-
ment
position AUTO : commutation entre mode
de fonctionnement et veille
selon le niveau du signal
11
Entrée signal stéréo HIGH LEVEL IN pour
brancher à la sortie haut-parleur d’un am-
plificateur
Les prises bananes se trouvent sous les
caches de protection des bornes à vis.
12
Sorties pour repiquage HIGH LEVEL OUT, re-
liées aux prises HIGH LEVEL IN (11) correspon-
dantes, pour brancher les autres enceintes
Les prises bananes se trouvent sous les
caches de protection des bornes à vis.

13
Français
2 Conseils d’utilisation
et de sécurité
L’appareil répond à toutes les directives néces-
saires de l’Union européenne et porte donc le
symbole .
AVERTISSEMENT
L’appareil est alimenté par
une tension secteur dange-
reuse. Ne faites jamais de
modification sur l’appareil.
Une mauvaise manipulation
pourrait générer une dé-
charge électrique.
•
L’appareil n’est conçu que pour une utilisa
-
tion en intérieur.Protégez-le de tout type de
projections d’eau, des éclaboussures, d’une
humidité élevée de l’air et de la chaleur (plage
de température de fonctionnement autori-
sée: 0– 40 °C).
•
En aucun cas, vous ne devez poser d’objet
contenant du liquide ou un verre sur l’ap-
pareil.
•
La chaleur dégagée par l’appareil doit être
évacuée par une circulation d’air correcte. En
aucun cas, les ouïes de ventilation (ouvertures
bass-reflex) ne doivent être obturée.
•
Ne faites pas fonctionner l’appareil ou dé-
branchez immédiatement la fiche du cordon
du secteur lorsque :
1.
des dommages visibles apparaissent sur
l’appareil ou sur le cordon secteur,
2. après une chute ou un cas similaire, vous
avez un doute sur l’état de l’appareil,
3. des dysfonctionnements apparaissent.
Faites toujours appel à un technicien spécialisé
pour effectuer les réparations.
•
Tout cordon secteur endommagé ne doit être
remplacé que par un technicien habilité.
•
Ne débranchez jamais l’appareil en tirant
sur le cordon secteur, tenez-le toujours par
la fiche.
•
Pour nettoyer l’appareil, utilisez uniquement
un chiffon sec et doux, en aucun cas, de pro-
duits chimiques ou d’eau.
•
Nous déclinons toute responsabilité en cas de
dommages corporels ou matériels résultants
si l’appareil est utilisé dans un but autre que
celui pour lequel il a été conçu, s’il n’est pas
correctement branché, utilisé ou n’est pas
réparé par une personne habilitée, de même,
la garantie deviendrait caduque.
Lorsque l’appareil est définitivement
retiré du service, vous devez le déposer
dans une usine de recyclage à proxi-
mité pour contribuer à son élimination
non polluante.
CARTONS ET EMBALLAGE
PAPIER À TRIER
3 Possibilités d’utilisation
Ce subwoofer actif compact sert comme com-
plément basse fréquence d’installations audio
existantes pour applications Hi-Fi, home cinéma
et home recording. Il est équipé d’un haut-
parleur de grave 25cm (10”) et d’un amplifica-
teur avec une puissance de sortie crête de 200W.
Il dispose d’un filtre passe-bas réglable, d’un
réglage de volume, d’une inversion de phase
commutable et d’un mode stand by automa
-
tique. L’amplificateur intégré est équipé de
circuits de protection contre les surcharges et
surchauffes.
Des entrées pour brancher aux sorties stéréo
avec niveau ligne et pour le branchement à des
sorties haut-parleurs (avec possibilité repiquage
pour les autres haut-parleurs) sont prévues.
En plus, le subwoofer dispose d’une entrée
LFE. Dans des systèmes multicanaux pour ap-
plications cinéma, par exemple «5.1», le canal
LFE («Low Frequency Effect” ou «Low Frequency
Enhancement») permet de transmettre des
effets spéciaux basse fréquence.
4 Positionnement et
branchements
Positionnez le subwoofer sur un support plat.
Le positionnement précis au centre entre les
enceintes stéréo n’est pas capital puisque les
fréquences très graves qu’il restitue ne peuvent
pas être localisées avec précision. Cependant,
ne le positionnez pas trop près des murs ou
dans des coins car cela fausse la réponse en
fréquence et peut gêner la dissipation de chaleur
de l’amplificateur intégré. De même, les ouver-
tures bass-reflex situées dans la partie inférieure
ne doivent pas être obturées.

14
Français
Avant d’effectuer les branchements ou de
modifier les branchements existants, veillez à
éteindre le subwoofer et les appareils reliés.
Reliez une source de signal via une des trois
possibilités de branchement décrites dans les
chapitres 4.1 à 4.3, au subwoofer.
4.1 Entrée stéréo LINE IN
Si une sortie stéréo avec niveau ligne existe (par
exemple sortie d’un préamplificateur ou d’une
table de mixage), reliez-la à l’entrée LINE IN (7)
du subwoofer. A partir des deux canaux stéréo,
un signal mono est constitué en interne pour
le subwoofer.
Si les sorties du préamplificateur ou de la
table de mixage sont déjà utilisées pour le bran-
chement de l’installation audio existante, on
peut utiliser un adaptateur pour diviser le signal
de sortie (p.ex. ACA-120 de MONACOR).
4.2 Entrée stéréo HIGH LEVEL IN
Si aucune sortie avec niveau ligne n’est dispo-
nible, reliez les entrées HIGH LEVEL IN (11) aux
sorties haut-parleurs de l’amplificateur (LEFT =
canal gauche, RIGHT = canal droit). Veillez à
respecter la polarité des branchements. Lorsque
vous effectuez les branchements, éteignez im-
pérativement l’amplificateur et assurez-vous que
les extrémités de câble pour le branchement
aux bornes à vis ne sont pas trop dénudées et
qu’aucun fil nu ne sort (risque de contact et
de court-circuit). Les sorties pour repiquage
HIGH LEVEL OUT (12) sont directement reliées
aux prises correspondantes HIGH LEVEL IN. On
peut relier ici les autres enceintes.
Les prises bananes se trouvent sous les
caches de protection des bornes à vis.
AVERTISSEMENT
Si un amplificateur est relié
aux bornes HIGH LEVEL IN
(11), il faut protéger toutes
les prises bananes non utili-
sées avec les caches. Sinon, il
y a risque de décharge élec-
trique en cas de contacts des
branchements.
4.3 Entrée mono LFE
Reliez la sortie LFE d’un système multicanal ou
une autre sortie mono avec niveau ligne à la
prise LFE (8).
Remarque : Le signal d’une source de signal reliée à cette
entrée n’est pas influencé par le filtre passe-bas réglable
puisqu’un signal LFE contient, en général, uniquement
des signaux basse fréquence.
4.4 Alimentation
Reliez la fiche du cordon secteur (6) à une prise
secteur 230V/50Hz.
5 Utilisation
ATTENTION
Ne réglez jamais le volume de
l’installation audio trop fort. Un
volume trop élevé peut, à long
terme, générer des troubles de
l’audition ! L’oreille s’habitue à
des volumes élevés et ne les per-
çoit plus comme tels au bout d’un
certain temps. Nous vous conseil-
lons donc de régler le volume et
de ne plus le modifier.
Conseil : Pour éviter tout bruit fort de commutation,
allumez toujours les appareils reliés avant d’allumer le
subwoofer et éteignez-le en premier après utilisation.
1) Mettez le réglage VOLUME (2) tout d’abord
sur MIN (butée de gauche) et allumez le
subwoofer avec l’interrupteur POWER (4).
La LED (1) brille.
2)
Avec l’interrupteur STAND BY (10), activez
ou désactivez le mode stand by automatique.
Position «AUTO» :
Le mode stand by automatique est activé.
Le subwoofer se met automatiquement en
fonction lorsqu’un signal d’entrée est présent
et que le réglage VOLUME (2) est tourné en
conséquence. Le témoin de fonctionnement
(1) brille en vert. Si le niveau de signal di-
minue pendant quelques minutes sous un
certain seuil, le subwoofer revient au mode
stand by ; le témoin de fonctionnement brille
en rouge.
Position «ON» :
Le mode stand by automatique est désactivé,
le subwoofer est toujours en fonctionnement
une fois allumé; le témoin de fonctionnement
(1) brille en vert.
Position «OFF» :
Le subwoofer est toujours en mode stand
by; le témoin de fonctionnement (1) brille
en rouge. Ainsi, on peut mettre le subwoofer

15
Français
en mode stand by immédiatement pour, par
exemple, tester ensuite en position «AUTO»
le seuil de commutation.
3)
Via l’installation audio existante, restituez
par exemple la musique et avec le réglage
VOLUME (2), mixez la part de graves sou-
haitée. Tournez le réglage jusqu’à ce que le
son soit restitué de manière non distordue.
4) Si la source de signal est reliée via les entrées
LINE IN (7) ou HIGH LEVEL IN (11), réglez
la fréquence de coupure du filtre passe-bas
avec le réglage CROSSOVER (3) de telle sorte
que le subwoofer complète de manière op-
timale la réponse en fréquence des autres
haut-parleurs. Ce filtre n’a pas d’effet à l’en-
trée LFE(8).
Si besoin, corrigez la balance de volume
avec le réglage VOLUME (2).
5)
Des distances différentes des haut-parleurs
avec l’auditoire peuvent créer des annula-
tions de phase (certaines fréquences sont
moins fortes). Pour compenser, on peut, avec
l’interrupteur PHASE (9), inverser la phase du
signal du subwoofer.
Testez les deux positions de l’interrupteur
pour trouver celle proposant la reproduction
des graves avec le volume le plus élevé au
niveau de la position d’écoute. Si besoin, cor-
rigez en conséquence la balance de volume
avec le réglage VOLUME (2).
6) Si le mode stand by automatique est désac-
tivé (
☞
point 2), éteignez le subwoofer avec
l’interrupteur POWER (4) après utilisation.
Dans tous les cas, il est recommandé
d’éteindre le subwoofer en cas de non utili-
sation prolongée pour éviter toute consom-
mation inutile.
5.1 Circuits de protection
L’amplificateur du subwoofer est doté de cir-
cuits de protection contre les surcharges et
surchauffes. Si le témoin de fonctionnement
brille en rouge, bien que l’interrupteur STAND
BY (10) soit sur «ON», ou si la couleur du témoin
de fonctionnement change et passe au rouge
pendant le fonctionnement malgré un signal
suffisant, un circuit de protection est activé.
Dans ce cas, il faut éteindre le subwoofer et
résoudre le problème.
6 Caractéristiques techniques
Bande passante :. . . . . . . ☞diagramme
ci-dessous
Puissance amplificateur
Puissance RMS:. . . . . . . 120W
Puissance max. : . . . . . . 200W
Sensibilité haut-parleurs : 88dB (1 W/1 m)
Pression sonore
maximale : . . . . . . . . . . . 108 dB
Entrées (sensibilité, impédance, branchement)
LINE IN : . . . . . . . . . . . . 150mV, 24kΩ, RCA
LFE : . . . . . . . . . . . . . . . 55mV, 16kΩ, RCA
HIGH LEVEL IN : . . . . . . 2,3V, 440Ω, borne à
vis avec prise banane
4mm
Alimentation :. . . . . . . . . 230 V/50 Hz
Consommation :. . . . . . . 240VA max.
Température fonc. :. . . . . 0 – 40°C
Dimensions (L × H × P) : . 330 × 360 × 360 mm
Poid : . . . . . . . . . . . . . . . 13 kg
Tout droit de modification réservé.
Notice d’utilisation protégée par le copyright de MONACOR
®INTERNATIONAL GmbH & Co. KG. Toute repro-
duction même partielle à des fins commerciales est interdite.
Réponse en fréquence si on utilise les entrées LINE IN ou HIGH LEVEL IN
avec une fréquence passe-bas réglée au minimum et maximum
[dB]
[Hz]

16
Deutsch
Deutsch Seite
Inhalt
English
English Page
Contents
Français
Français Page
Table des matières
Español
Español Página
Contenidos
Nederlands
Nederlands Pagina
Inhoud
Polski
Polski Strona
Spis treści
Italiano
Italiano Pagina
Indice
Italiano
Indice
1 Gli elementi di comando e
icollegamenti. . . . . . . . . . . . 16
2 Avvertenze di sicurezza . . . . . . 17
3 Possibilità d’impiego . . . . . . . . 17
4 Collocamento e collegamento . . . 17
4.1 Ingresso stereo LINE IN . . . . . . . . 17
4.2 Ingresso stereo HIGH LEVEL IN . . . . 18
4.3 Ingresso mono LFE . . . . . . . . . . 18
4.4 Alimentazione . . . . . . . . . . . . 18
5 Funzionamento . . . . . . . . . . . 18
5.1 Circuiti di protezione . . . . . . . . . 19
6 Dati tecnici . . . . . . . . . . . . . 19
Cassa subwoofer attiva
Queste istruzioni sono rivolte a utenti con cono-
scenze base nella tecnica audio. Vi preghiamo
di leggerle attentamente prima della messa in
funzione e di conservarle per un uso futuro.
A pagina 3, se aperta completamente, ve-
drete tutti gli elementi di comando e i collega-
menti descritti.
1 Gli elementi di comando e
icollegamenti
1 Spia di funzionamento
verde in funzione
rosso stand-by o con circuito attivo di pro-
tezione
2 Regolatore VOLUME
3
Regolatore CROSSOVER per impostare la
frequenza di taglio (50– 150 Hz) del fil-
tro passa-basso per gli ingressi LINE IN e
HIGH LEVEL IN
4 Interruttore di rete POWER
5 Portafusibili;
sostituire un fusibile difettoso solo con uno
dello stesso tipo
6 Cavo per il collegamento con una presa di
rete (230V/50 Hz)
7
Ingresso dei segnali stereo LINE IN come
prese RCA
8 Ingresso dei segnali mono LFE come presa
RCA
9 Commutatore d’inversione di fase PHASE
10
Commutatore STAND BY per il modo
stand-by
Posizione OFF: sempre in stand-by
Posizione ON: sempre in funzione
Posizione AUTO: commutazione fra fun-
zione e stand-by a seconda
del livello dei segnali
11
Ingresso dei segnali stereo HIGH LEVEL IN
per il collegamento con l’uscita per altopar-
lanti di un amplificatore
Sotto i cappucci dei morsetti a vite si trovano
delle prese a banana.
12 Uscite passanti HIGH LEVEL OUT, collegate
con le relative prese HIGH LEVEL IN (11), per
il collegamento degli altri altoparlanti
Sotto i cappucci dei morsetti a vite si trovano
delle prese a banana.

17
Italiano
2 Avvertenze di sicurezza
L’apparecchio è conforme a tutte le direttive
rilevanti dell’UE e pertanto porta la sigla .
AVVERTIMENTO
L’apparecchio funziona con
pericolosa tensione di rete.
Non intervenire mai perso-
nalmente al suo interno! La
manipolazione scorretta può
provocare una scarica elettrica
pericolosa.
•
Usare l’apparecchio solo all’interno di locali
e proteggerlo dall’acqua gocciolante e dagli
spruzzi d’acqua, da alta umidità dell’aria e
dal calore (temperatura d’impiego ammessa
fra 0 e 40°C).
•
Non depositare sull’apparecchio dei conteni-
tori riempiti di liquidi, p.es. bicchieri.
•
Dev’essere garantita la libera circolazione
dell’aria per dissipare il calore che viene pro-
dotto all’interno dell’apparecchio. Non coprire
in nessun modo le fessure d’aerazione (per il
bass-reflex).
•
Non mettere in funzione l’apparecchio e stac-
care subito la spina rete se:
1. l’apparecchio o il cavo rete presentano dei
danni visibili;
2. dopo una caduta o dopo eventi simili sus-
siste il sospetto di un difetto;
3.
l’apparecchio non funziona correttamente.
Per la riparazione rivolgersi sempre ad un’of-
ficina competente.
•
Il cavo rete, se danneggiato, deve essere so-
stituito solo da un laboratorio specializzato.
•
Staccare il cavo rete afferrando la spina, senza
tirare il cavo.
•
Per la pulizia usare solo un panno morbido,
asciutto; non impiegare in nessun caso pro-
dotti chimici o acqua.
•
Nel caso d’uso improprio, di collegamenti
sbagliati, d’impiego scorretto o di riparazione
non a regola d’arte dell’apparecchio, non si
assume nessuna responsabilità per eventuali
danni consequenziali a persone o a cose e non
si assume nessuna garanzia per l’apparecchio.
Se si desidera eliminare l’apparecchio
definitivamente, consegnarlo per lo
smaltimento ad un’istituzione locale
per il riciclaggio.
3 Possibilità d’impiego
Questo subwoofer attivo compatto serve come
integrazione per frequenze basse in impianti
di altoparlanti nei settore hifi, home-cinema e
home-recording. È equipaggiato con un woofer
di 25cm (10”), e il suo amplificatore ha una
potenza di picco di 200W.
Il subwoofer possiede un filtro passa-basso
regolabile, un regolatore del volume, una com-
mutazione d’inversione di fase attivabile e
stand-by automatico. L’amplificatore integrato
è equipaggiato con circuiti di protezione contro
sovraccarico e surriscaldamento.
Esistono degli ingressi per il collegamento
con uscite stereo con livello Line nonché per il
collegamento con uscite per altoparlanti (con
possibilità di passaggio agli altri altoparlanti).
In più, il subwoofer dispone di un ingresso
LFE. Nei sistemi multicanali nel settore dei ci-
nema, p.es. “5.1”, il canale LFE serve per la
trasmissione degli effetti speciali a bassa fre-
quenza (“Low Frequency Effect” o “Low Fre-
quency Enhancement”).
4 Collocamento e collegamento
Collocare il subwoofer su un fondo piano.
L’esatta posizione nel centro fra gli altoparlanti
stereo non è decisiva con il subwoofer dato che
non è possibile localizzare con esattezza le basse
frequenze che riproduce. Ma non posizionarlo
troppo vicino a pareti o in angoli perché questo
fatto falsificherebbe la risposta in frequenza e
ostacolerebbe la dissipazione del calore pro-
dotto dall’amplificatore. Anche le aperture bass-
reflex poste sul lato inferiore non devono essere
coperte.
Prima di collegare il subwoofer o di modi-
ficare i collegamenti esistenti, spegnere il sub-
woofer e gli apparecchi da collegare.
Collegare una fonte di segnali con il sub-
woofer utilizzando una delle tre possibilità di
collegamento descritte nei capitoli 4.1 a 4.3.
4.1 Ingresso stereo LINE IN
Se è presente un’uscita stereo con livello Line
(p.es. uscita di un preamplificatore o mixer), col
-
legarla con l’ingresso LINE IN (7) del subwoofer.
Dai due canali stereo si genera internamente un
segnale mono per il subwoofer.

18
Italiano
Se le uscite del preamplificatore o mixer
sono già occupate dal collegamento dell’im-
pianto esistente di altoparlanti, si può usare un
adattatore per raddoppiare le uscite del segnale
audio (p.es. ACA-120 di MONACOR).
4.2 Ingresso stereo HIGH LEVEL IN
Se non è disponibile nessun’uscita con livello
Line, collegare i contatti HIGH LEVEL IN (11) con
le uscite per altoparlanti dell’amplificatore (LEFT
= canale sinistro, RIGHT = canale destro). Rispet-
tare la polarità dei contatti. Prima del collega-
mento spegnere assolutamente l’amplificatore e
fare attenzione che i terminali dei cavi ai morsetti
a vite non siano deisolati troppo con sporgenza
di fili spelati (pericolo di contatto e di cortocir-
cuito). Le uscite passanti HIGH LEVEL OUT (12)
sono collegate direttamente con le relative prese
HIGH LEVEL IN. Qui si possono collegare le altre
casse acustiche.
Sotto i cappucci dei morsetti a vite si trovano
delle prese a banana.
AVVERTIMENTO
Se è collegato un amplificatore
con i contatti HIGH LEVEL IN
(11), tutte le prese banana
non occupate devono essere
coperte con i cappucci. Altri-
menti, toccando i contatti,
esiste il pericolo di una scarica
elettrica.
4.3 Ingresso mono LFE
Collegare l’uscita LFE di un sistema multicanale
o un‘altra uscita mono con livello Line con la
presa LFE (8).
Nota: Il segnale della fonte collegata qui non è influen-
zato dal filtro passa-basso regolabile, dato che un segnale
LFE contiene di regola solo segnali a bassa frequenza.
4.4 Alimentazione
Inserire la spina del cavo (6) in una presa di rete
(230V/50Hz).
5 Funzionamento
AVVERTIMENTO
Mai tenere molto alto il vo-
lume dell’impianto audio. A
lungo andare, il volume ec-
cessivo può procurare danni
all’udito! L’orecchio si abitua
agli alti volumi e dopo un certo
tempo non se ne rende più
conto. Perciò non aumentare
il volume successivamente.
Nota: Per escludere rumori di commutazione, accendere
il subwoofer sempre dopo gli apparecchi collegati, e dopo
l’uso spegnerlo per primo.
1) Portare il regolatore VOLUME (2) per il mo-
mento su MIN (arresto a sinistra) e accendere
il subwoofer con l’interruttore POWER (4). Si
accende il LED (1).
2) Con il commutatore STAND BY (10) attivare
o disattivare lo stand-by automatico.
Posizione “AUTO”:
Lo standby automatico è attivo. Il subwoo-
fer si mette automaticamente in funzione
se è presente un segnale all’ingresso e se il
regolatore VOLUME (2) è aperto sufficiente-
mente. Allora, la spia di funzionamento (1) è
accesa di colore verde. Se il livello del segnale
cade per alcuni minuti sotto un determinato
valore, il subwoofer ritorna nel modo di
stand-by: la spia di funzionamento prende
il colore rosso.
Posizione “ON”:
Lo standby automatico è disattivato. Dopo
l’accensione, il subwoofer è sempre in fun-
zione. La spia di funzionamento (1) è verde.
Posizione “OFF”:
Il subwoofer è sempre in stand-by. La spia di
funzionamento (1) è rossa. In questo modo
si può attivare immediatamente lo stand-by,
p.es. per testare la soglia d’inserimento nella
posizione “AUTO”.
3)
Riprodurre p. es. della musica per mezzo
dell’impianto esistente di altoparlanti e ag-
giungere la parte di frequenze basse per
mezzo del regolatore VOLUME (2). Aprire
il regolatore solo al punto da non aver delle
distorsioni del suono.
4) Se la fonte di segnali è collegata per mezzo
degli ingressi LINE IN (7) o HIGH LEVEL IN (11),

19
Italiano
con il regolatore CROSSOVER (3) impostare la
frequenza di taglio del passa-basso in modo
che il subwoofer completi in modo ottimale
la risposta in frequenza degli altri altoparlanti.
Questo filtro non influenza l’ingresso LFE (8).
Se necessario, correggere il bilanciamento
del volume con il regolatore VOLUME (2).
5)
In caso di distanze differenti degli altoparlanti
dall’ascoltatore, si possono manifestare delle
cancellazioni di fasi (determinate frequenze
diventano più deboli). Per compensare que-
sto effetto, con il commutatore PHASE (9)
è possibile invertire la fase del segnale del
subwoofer.
Con delle prove pratiche si può compren-
dere con quale posizione del commutatore
si ottiene la migliore riproduzione dei bassi
al posto dell’ascoltatore. Se necessario, cor-
reggere successivamente il bilanciamento del
volume con il regolatore VOLUME (2).
6)
Se lo stand-by automatico è disattivato
(☞punto 2), dopo l’uso spegnere il sub-
woofer con l’interruttore POWER (4).
In ogni caso è consigliabile spegnere il
subwoofer quando non è usato per un certo
periodo per evitare consumi inutili di energia
elettrica.
5.1 Circuiti di protezione
L’amplificatore del subwoofer è equipaggiato
con circuiti di protezione contro sovraccarico e
surriscaldamento. Se la spia di funzionamento
si accende di rosso nonostante il commuta-
tore STAND BY (10) si trovi in posizione “ON”,
oppure se durante il funzionamento il colore
della spia di funzionamento diventa rosso alla
presenza di un segnale sufficientemente po-
tente, significa che un circuito di protezione è
attivo. In questo caso occorre spegnere il subwo-
ofer e eliminare il guasto.
6 Dati tecnici
Banda passante :. . . . . . . ☞vedere il dia-
gramma in fondo
Potenza dell’amplificatore
Potenza RMS:. . . . . . . . 120W
Potenza max. . . . . . . . . 200W
Sensibilità
dell’altoparlante:. . . . . . . 88 dB (1 W/1 m)
Pressione sonora max.: . . 108dB
Ingressi (sensibilità, impedenza, contatto)
LINE IN: . . . . . . . . . . . . 150mV, 24kΩ, RCA
LFE: . . . . . . . . . . . . . . . 55mV, 16 kΩ, RCA
HIGH LEVEL IN: . . . . . . 2,3 V, 440 Ω,
morsetto a vite con
presa a banana 4mm
Alimentazione: . . . . . . . . 230V/50Hz
Potenza assorbita:. . . . . . max. 240 VA
Temperatura d’esercizio: . 0– 40°C
Dimensioni (l × h × p): . . 330 × 360 × 360mm
Peso:. . . . . . . . . . . . . . . . 13kg
Con riserva di modifiche tecniche.
La MONACOR
®INTERNATIONAL GmbH & Co. KG si riserva ogni diritto di elaborazione in qualsiasi forma
delle presenti istruzioni per l’uso. La riproduzione – anche parziale – per propri scopi commerciali è vietata.
Riposta in frequenza con gli ingressi LINE IN o HIGH LEVEL IN
con frequenza di taglio regolata sul minimo e sul massimo
[dB]
[Hz]

20
Deutsch
Deutsch Seite
Inhalt
English
English Page
Contents
Français
Français Page
Table des matières
Italiano
Italiano Pagina
Indice
Nederlands
Nederlands Pagina
Inhoud
Polski
Polski Strona
Spis treści
Español
Español Página
Contenidos
Sistema Subwoofer Activo
Estas instrucciones de funcionamiento van diri-
gidas a usuarios con conocimientos básicos en
audio. Lea atentamente estas instrucciones de
funcionamiento antes de utilizar el aparato y
guárdelas para usos posteriores.
Puede encontrar todos los elementos de
funcionamiento y las conexiones que se descri-
ben en la página3 desplegable.
1 Elementos de Funcionamiento
y Conexiones
1 LED POWER
Verde Subwoofer en funcionamiento
Rojo Subwoofer en modo Standby o
circuito de protección activado
2 Control de volumen VOLUME
3
Control CROSSOVER para ajustar la frecuen-
cia de corte (50– 150 Hz) del filtro pasa bajo
para las entradas LINE IN y HIGH LEVEL IN
4 Interruptor POWER
5 Soporte para el fusible de corriente;
cambie siempre un fusible fundido sólo por
otro del mismo tipo
6
Cable de corriente para conectar a una toma
(230V/50Hz)
7
Entrada de señal estéreo LINE IN como tomas
RCA
8
Entrada de señal mono LFE como toma RCA
9 Interruptor de inversión de fase PHASE
10
Interruptor selector STAND BY para el modo
Standby
Posición OFF: Siempre en modo Standby
Posición ON: Siempre en funcionamiento
Posición AUTO: Cambio entre los modos de
funcionamiento y Standby
dependiendo del nivel de
señal
11
Entrada de señal estéreo HIGH LEVEL IN para
conectar a la salida de altavoz de un ampli-
ficador
Hay tomas banana bajo las tapas de protec-
ción de los terminales de tornillo.
12
Salidas alimentadas HIGH LEVEL OUT,
conectadas a las tomas correspondientes
HIGH LEVEL IN (11), para conectar a los
demás altavoces
Hay tomas banana bajo las tapas de protec-
ción de los terminales de tornillo.
Español
Contenidos
1 Elementos de Funcionamiento y
Conexiones . . . . . . . . . . . . . 20
2 Notas de Seguridad. . . . . . . . . 21
3 Aplicaciones. . . . . . . . . . . . . 21
4 Colocación y Conexión . . . . . . . 21
4.1 Entrada estéreo LINE IN. . . . . . . . 21
4.2 Entrada estéreo HIGH LEVEL IN . . . . 22
4.3 Entrada mono LFE . . . . . . . . . . 22
4.4 Alimentación . . . . . . . . . . . . . 22
5 Funcionamiento. . . . . . . . . . . 22
5.1 Circuitos de protección . . . . . . . . 23
6 Especificaciones. . . . . . . . . . . 23
Table of contents
Languages:
Other Monacor Subwoofer manuals
