Monaldi White Line ITA User manual

P
R
O
F
E
S
S
I
O
N
A
L
T
E
A
M
SRL
via Lazio, 9 - 61122 Pesaro Italy tel. [phone] - fax [phone]
www.monaldi.com - [email protected]
rev. 0.00
INSTRUCTION MANUAL
PLASTIC MENDER mod. ITA
Document protected by copyright. Total or partial reproduction is forbidden.

rev. 0.00
Plastic Mender mod. ITA
INDEX
1 – RAEE regulations
2 – General Safety Precautions
3 – “PLASTIC MENDER” components
4 – Technical specications
5 – Safety and handling
6 – How to operate
7 – Accessories and consumables
1 RAEE Regulations
The symbol on the product or on its packaging indicates that this pro-
duct should not be treated as household waste, but it must be handed in
a collection point for the recycling of electrical and electronic equipment.
By disposing of this product appropriately you will help prevent potential
negative consequences that could result from improper disposal of the
product. For more detailed information about recycling of this product,
please contact the municipal ofce, the local waste disposal service or
the shop where you purchased the product.

rev. 0.00
Plastic Mender mod. ITA
2. GENERAL SAFETY PRECAUTIONS
WELDING AND CUTTING CAN BE HARMFUL TO YOURSELF AND OTHERS
The user must therefore be educated against the hazards, summarized below,
deriving from welding operations.
ELECTRIC SHOCK - May be fatal
Install and earth the welding machine according to the regulations.
Do not touch live electrical parts or electrodes with bare skin, gloves or
wet clothing. Make sure your working position is safe. Make sure the circuit
breaker line has been dimensioned according to the power consumption of the
equipment. This switch should intervene in emergency situations. Inspect the
power cord frequently to check its integrity.
FUMES AND GASES - May be hazardous to health
Keep the nose, mouth and eyes away from smoke and noxious fumes.
Work in the presence of adequate ventilation.
RISK OF FIRE AND BURNS
Staples heated can become very hot and burn the skin; you should therefore
make sure there are no ammable materials in the area, and wear appropriate
protective clothing such as gloves and gowns.
NOISE
Do not operate near pressure vessels or in the presence of dust, gases or fu-
mes
3. “PLASTIC MENDER” components
– CASE TOOL
– CONTROL BOARD
– HANDLE FOR STAPLES WITH ELECTRIC WIRE
– STAPLES KIT
– MANUAL OF INSTRUCTIONS

rev. 0.00
Plastic Mender mod. ITA
4 – SPECIFICATIONS
Denomination : PLASTIC MENDER MOD. ITA
Code : 10 40 30 10 35
Voltage : 1 x 230Vac, 50/60 Hz
Energy consumption : max 5 Watt
Dimensions : 80x100x100h mm
Weight : 1,1 kg
IMPORTANT:
appearance and specications of the machine can change without notice by the
manufacturer.
ATTENTION !!!!
There is no guarantee for breakage or damage to the parts repaired with this pro-
duct.
5. SAFETY AND HANDLING
Strict adherence to this user manual is reccommended for your safety
ATTENTION
Once the tip is positioned on the handle and the switch is turned on, the tip tempe-
rature will be between 100 ° and 200 ° C. If touched by mistake, it can cause bur-
ns, blindness or res.
• Wear heat resistant gloves while working
• Before placing the tip, make sure that the ends of the handle are cold
• Do not touch the staple with bare hands when it is placed in position inside the
locking holes
• Do not use the tool near combustible material
• Do not allow unauthorized personnel to use the equipment
• Do not use with wet hands
• When you nish working, turn off the switch and make sure that the end of the
handle is completely cool before storing it in its case.
• The repair of plastic objects occurs by dissolution of the same: be careful of any
molten droplets.
OBSERVE THE FOLLOWING RULES TO AVOID INJURY OR DAMAGE
• This product is designed for the repair of plastic parts. Do not use it for purposes
other than those for which it was designed.
• The tool should be used with staples authorized by the manufacturer.
• Do not disassemble
• Do not use in wet places
• Do not put the tool in water
• When switched off, do not pull on the cord

rev. 0.00
Plastic Mender mod. ITA
6. HOW TO OPERATE
1. Connect the device to a normal power outlet (220 V).
2. Adjust the temperature control knob on:
- Low for thin plastic (bumpers, etc.)
- Medium for plastic parts with a thickness of 5 mm (projectors, etc.)
- High for thick and hard plastic parts
3. Turn on the main switch.
4. Choose the correct staple for repair and insert it in the tips.
5. Prepare the plastic parts for the repair matching the ends.
6. Heat the staple by holding for 10 seconds the red switch on the handle
7. When the clip is properly inserted in the plastic and wedged into place, turn it
10° -15°.
8. Release the button and hold the clip on the repair until it locks (it does not
move).
9. Slowly remove the tool, leaving the head of the staple into place.
WARNING
BEWARE OF THE FRAGMENTS. WEAR SAFETY GLASSES WHEN CUTTING
11. Cut the protruding ends of the staple.
12. Use a sander if you need to remove the remaining ends of the staple.

rev. 0.00
Plastic Mender mod. ITA
7. ACCESSORIES AND CUNSUMABLES
The "PLASTIC MENDER" comes with the following consumables supplied, whi-
ch can be re-ordered from your local dealer:
n° 25 pcs cod. 10 40 31 00 61
n° 25 pcs cod. 10 40 31 00 60
.
n° 25 pcs cod. 10 40 31 00 70
n° 25 pcs cod. 10 40 31 00 59

DICHIARAZIONE DI CONFORMITA’
il fabbricante: MONALDI PROFESSIONAL TEAM S.r.l.
Via Lazio, 9 - 61122 PESARO (PU) - ITALIA
dichiara sotto la propria responsabilità che la macchina:
KIT RIPARAZIONE PLASTICHE
MATRICOLA : ___________
ANNO DI COSTRUZIONE : ________
è conforme alle Direttive Comunitarie inerenti:
oltre che alla norma 2002/95/CE (RoHS9
e per quanto applicabili alle norme armonizzate:
Pesaro lì 01-10-12 MONALDI Professional team S.r.l.
L' Amministratore
Gambini Davide
rev. 0.00
COMPATIBILITA'
ELETTROMAGNETICA
MATERIALE ELETTRICO
DESTINATO AD ESSERE
ADOPERATO ENTRO TALUNI
LIMITI DI TENSIONE
2006/95/CE2004/108/CE
EN 61000-6-4:2007
EN 61000-6-3:2007
EN 61000-6-2:2006
EN 61000-6-1:2006
EN 55014-1:1999
EN 55014-2:1999
EN 60335-1/A1:2004
