Rtech TIG315 User manual

TIG315 AC/DC TIG WELDER
OPERATION INSTRUCTIONS
www.r-techwelding.co.uk

2

3
Thank you for selecting the R-Tech Tig315 Inverter AC/DC Tig Welder.
The Tig315 has many benefits over traditional tig welders, including 250Hz AC frequency
adjustment, squarewave balance control, full pulse welding, slope up/down, remote foot
option and an industrial 60% duty cycle
We want you to take pride in operating our TIG315 as much pride as we have taken in making
this product for you. Please read all information in this manual before operation
PLEASE EXAMINE THE CARTON AND EQUIPMENT FOR DAMAGE IMMEDIATELY
When this equipment is shipped, title passes to the purchaser upon receipt from the courier.
Consequently all claims for material damaged in shipment must be made by purchaser against
the transportation company used.
Please record your equipment identification below for future reference. This information can be
found on the data plate at rear of machine.
Product: TIG315
Serial No. ___________________________________
Date of Purchase _____________________________
Where Purchased _____________________________
Whenever you request replacement parts or information on this equipment please always
supply information you have recorded above.
This product is covered by a 2 year parts and labour warranty; we will cover the cost of collecting and
returning the item to you. External items, (torch, earth lead etc…) are covered by a 3 month warranty. Any
faults/damage found caused by a customer will be charged accordingly.
Pay particular attention to the safety instructions we have provided you for your protection
The level of seriousness to be applied to each section is explained below
WARNING
This statement appears where the information must be followed exactly to avoid serious personal injury.
CAUTION
This statement appears where the information must be following to avoid a minor personal injury or damage
to this equipment.

4
Introduction
The R-Tech TIG315 is a member of our field acclaimed family of welding products. Premium
features include:-
1. Inverter power source – more efficient to operate, provides smoother weld characteristics.
2. AC squarewave frequency adjustment to 250Hz
3. AC squarewave balance control
4. Full featured pulse welding in both AC and DC modes
5. Patented HF Microstart – Reduces electronic interference to local area
6. Slope up / slope down
7. Remote foot pedal option
8. Digital amp meter
9. Industrial 60% Duty cycle at 315 Amps @ 40C
Recommended Processes
The R-Tech TIG315 is recommended for the Tig welding processes within its output capacity of 315
Amps
Equipment Limitations
The R-Tech TIG315 is protected from overloads beyond the output ratings and duty cycle as per
machine specifications with thermostat protection of the output coils and rectifiers.
Welding Capability – Duty Cycle
The R-Tech TIG315 is rated at 315 Amps at 60% duty cycle on a ten minute basis. If the duty cycle
is exceeded a thermal protector will shut machine off until the machine cools.
Technical Specifications
Model No. R-Tech TIG315
Input (volts/amps) 415V 3 Phase AC 50/60Hz
MMA No-load Voltage 60V – 80V
Current Range 5A – 250A
Rated Output Current 250 Amps
Duty Cycle 35% @ 250Amps 60%@200Amps
TIG No-load Voltage 60V – 80V
Current Range (AC 20A – 315A) (DC 20-315A)
Rated Output Current 315A
Duty Cycle 315Amps @ 60%, 250 Amps@100% at 40C
SP% AC Balance 30 – 70
Up-Slope Time 10 Seconds
Down-Slope Time 10 Seconds
Pulse Current Range 5A – 315A
Pulse Width Range 0.1 – 0.9 Seconds
Pulse Frequency Range 0.5Hz – 25Hz
Gross Weight 45KG
Insulation IP21S
Dimensions mm 430 x 200 x 290

5
Safety Precautions
Read entire section before starting installation
WARNING!
Electric Shock can kill – Only qualified personnel should perform this installation. Turn off input
power at the fuse box before working on this equipment. Do not touch electrically live parts. Always
connect the machine to an earthed mains supply as per national recommended standards.
Select suitable location
Place the welder where clean cooling air can freely circulate in and out of the front & rear louver
vents. Dirt, dust or any foreign material that can be drawn through vents into welder must be kept to
a minimum. Failure to observe these precautions can result in excessive operating temperatures
which can lead to plant failure.
Grinding
Do not direct grinding particles towards the welder. An abundance of conductive material can cause
plant failure.
Stacking
This machine cannot be stacked.
Transport – Unloading
Never underestimate the weight of equipment, never move or leave suspended in the air above
people. Use recommended lifting equipment at all times.
WARNING!
Falling Equipment can cause injury. Never lift welder with gas bottle attached. Never lift above
personnel.
Tilting
Machine must be placed on a secure level surface or on a recommended undercarriage/trolley.
This machine may topple over if this procedure is not followed.
Environmental Rating
The welding power source carries the IP21S rating. It may be used in normal industrial and
commercial environments. Avoid using in areas where water / rain is around.
Read and follow the ‘Electric Shock Warnings’ in the safety section if welding must be performed
under electrically hazardous conditions such as welding in wet areas or water on the work piece.

6
Electrical Installation
WARNING!
ELECTRIC SHOCK CAN KILL
Machine grounding and High Frequency Interference Protection
This welder must be grounded to earth. See national electrical codes fro proper grounding
methods.
The high frequency generator being similar to a radio transmitter may cause interference to radio,
TV and other electronic equipment. These problems may be the result of radiated interference.
Proper grounding methods can reduce or eliminate this.
Radiated interference can develop in the following ways
1. Direct interference from welder power source
2. Direct interference from the welding leads
3. Direct interference radiated from feedback into power lines
4. Interference from re-radiation by un-grounded metallic objects.
Keeping these contributing factors in mind, installing equipment as per following instructions should
minimize problems.
1. Keep the welder input power lines as short as possible and enclose as much of them as
possible in metal conduit or equivalent shielding. There should be a good electrical contact
between this conduit and ground (Earth).
2. Keep the work and electrode leads as short as possible. Tape the leads together where
practical.
3. Be sure the torch and earth leads rubber coverings are free from cuts and cracks that allow
welding power leakage
4. Keep earth lead connection to work in good condition – Clean area on workbench where
earth clamp is situated on a regular basis.
Input Connections
Make sure the voltage, phase and frequency of input power is as specified on machine rating plate
located at rear of machine.
Have a qualified electrician provide suitable input power as per national electrical codes. Make sure
machine is earthed / grounded.

7
Make sure fuse or circuit breaker is correct rating for machine. Using fuses or circuit breakers
smaller than recommended will result in ‘nuisance’ shut off from welder inrush currents even if
welding at low amperages.
Failure to follow these instructions can cause immediate failure within the welder and void
machines warranty.
Turn the input power OFF at the mains switch & fuse box before working on this equipment.
Have a qualified electrician install & service this equipment.
Allow machine to sit for 5 minutes minimum to allow the power capacitors to discharge before
working inside this equipment. Do not touch electrically live parts
The TIG315 Inverter Tig Welder requires a 415V 50/60Hz 3-Phase supply. It requires a 16A supply.
It comes with a 3 metre mains cable attached.
Connect wires according to national coding.
Brown wire – Live
Blue wire – Neutral
Green/Yellow Wire – Earth (Ground)
Connecting to a mains electrical supply
THIS MACHINE IS OF AN INDUSTRIAL SPECIFICATION AND MUST BE
FITTED TO A 16AMP 415V MAINS INPUT
Connecting to an Engine Driven Generator
If connecting this machine to an engine driven generator please ensure the
following
Minimum Generator KVA Output – 15 KVA continuous
Generator to be fitted with AVR (automatic voltage regulation)
DO NOT USE ON A GENERATOR WITHOUT AVR
Connecting to a generator without the above minimum requirements will in-
validate your warranty.

8
Connections for TIG315
Rear machine connections
Fig 1
1. On/Off Switch
2. Auxiliary 240V AC output
For water cooler – Maximum load 3A – Do not connect to power tools etc
3. Fuse Holder
3A fuse for water cooling socket
4. Mains input cable
Fit required plug as per your electrical installation
5. Gas input connector
Connect input gas hose ensuring connection is tight
6. Earth for chassis
If experiencing localized interference when using machine, connect workbench to this point
using correct graded earth wire (not normally used)

9
Connections for TIG (GTAW) Welding
Fig 2
1. Positive power connector +
Connect the earth lead to by inserting and twisting until tight and the earth clamp to
work/bench.
2. Gas outlet
Connect the torch gas hose
3. Negative power connector -
Connect Tig Torch Dinze to power connector by inserting and twisting until tight
4. Torch control socket 7-Pin
Connect torch control plug
To avoid a High Frequency shock keep the Tig torch in good condition and replace if any of the
insulation is damaged.
Connect the gas input hose to gas regulator and use ‘Pure Argon’ Gas, available from local
suppliers. Set gas flow/pressure to 8-12 LPM.
Make sure gas bottle is secured to avoid injury.
Remote Foot Pedal connection.
Disconnect Tig Torch switch plug from torch control socket (Fig2.4) and connect plug from foot
pedal.

10
Connections for STICK MMA (SMAW) Welding
Fig 3
1. Positive power connector +
Connect the electrode holder by inserting and twisting until tight
2. Negative power connector -
Connect the earth lead to by inserting and twisting until tight and the earth clamp to
work/bench.

11
Controls and Settings
Fig 4
1. Base current control
This adjusts the main welding current and is shown in L.E.D (Fig 4.11)
2. Pulse peak current adjustment
This sets pulse amperage and must be set above the base (main) current amperage. If set
to zero pulse welding is disabled.
3. LED Display
3 digit LED meter is used to display the pre-set (before welding) amperage and actual
amperage (when welding).
4. AC squarewave balance (SP%)
SP% AC Squarewave balance control 30% – 70%
Set at 50% this provides balanced control suitable for most AC Welding. 30% is max
cleaning and 70% is max penetration.
When welding dirty/contaminated material more cleaning may need to be selected.

12
Tip. If you are welding close to the tungsten limits, I.E 200amps on a 2.4mm tungsten and
the end of tungsten is wobbling and falling off, turning down the SP% will give better
tungsten stability
5. AC squarewave frequency adjuster
AC Squarewave frequency adjustment 20-250Hz.
Traditional tig welders have a fixed frequency of 60Hz, the TIG315 advanced technology
allows AC frequency adjustment from 20-250hz, as you turn up the frequency the width of
arc from tungsten decreases allowing more control of weld pool and an increase travel
speed
The pitch noise of weld will increase when AC frequency is turned up, this is normal.
100 - 120Hz is the ‘sweet spot’ for most AC welding.
6. Up slope
Adjustment 0-10 seconds. The main welding current raises from minimum amperage to
main current selected in time selected when weld started
7. Pulse frequency adjustment
This sets how often pulse will occur 0.5 – 25hz
8. Pulse width
Pulse width adjustment – This sets length of pulse 0.1 – 0.9 seconds
9. Down slope
Down-Slope adjustment 0-10 seconds. The main welding current decreases from main
amperage to minimum amperage in time selected when weld finished
10. Gas post flow adjustment
Gas post flow adjustment 1 – 25 seconds. The gas keeps flowing after weld has finished,
this cools & stops tungsten from getting contaminated.
Note: Gas pre-flow time is fixed at 0.5 seconds in TIG mode but no pre-flow time will occur
if the arc is restarted during post flow time as gas is already flowing.
11. MMA – Tig mode switch
MMA-TIG mode switch. Switches between TIG (GTAW) & MMA STICK (SMAW) welding
12. AC – DC Selector switch
This switch selects either DC for welding steels or AC for welding alloys
DO NOT SWITCH WHEN WELDING AS DAMAGE TO MACHINE CAN OCCUR.
13. 2/4 Way selector switch
2/4 Step trigger mode switch – tig welding can either be done in 2 or 4 step mode.

13
When the trigger mode is in the 2 step position the following sequence will occur
Press and hold the Tig torch switch to start sequence.
The machine will open gas valve to start flow of shield gas, after a 0.5 seconds pre-flow
time to purge air from torch hose the welding output of machine will be turned on and the
arc will be started. After the arc is started the output current will increase from the start
(min) current to base (main) current in time selected by slope-up.
Release the Tig torch switch to end sequence.
The machine will now decrease output to finish (min) current in time set by slope-down,
once at finish (min) current the machine will stop output and the gas valve will continue to
operate for the selected time (post flow)
Possible variations of this standard sequence are shown in diagram below. It is possible to
press and hold tig torch switch a second time during downslope time to restart. After the
switch is pressed the output current will raise to base (main) current
When the trigger mode is in the 4 step position the following sequence will occur
Press and hold the tig torch switch to start sequence.

14
The machine will open gas valve to start flow of shield gas, after a 0.5 seconds pre-flow
time to purge air from torch hose the welding output of machine will be turned on and the
arc will be started. After the arc is started the output current will be at start (min) current
This condition can be maintained as long as required.
Release the tig torch switch to go to step 2
The machine will now increase output to base (main) current in time set by slope-up.
Press and hold the tig torch switch when main weld is complete
The machine will now decrease the welding output current to finish (min) in down-slope
time set. Once at finish (min) output you can release the Tig torch switch to end weld the
gas post-flow will continue to run for set time.
14. Arc force (Stick – SMAW only)
This provides better arc starting when in MMA stick mode, useful when you are welding
dirty/rusty material or cold/damp welding electrodes

15
Operating machine
SAFETY PRECAUTIONS
WARNING!
ELECTRIC SHOCK CAN KILL
Do not touch electrically live parts or electrode with skin or wet clothing.
Insulate yourself from work and ground
Always wear dry insulating gloves
WARNING!
FUMES AND GASES can be dangerous
Keep your head out of fumes & gases produced from welding.
Use ventilation or exhaust to remove fumes & gases from breathing zone and general area.
WARNING!
WELDING SPARKS can cause fire or explosion
Keep flammable material away from work area.
Do not weld on containers that have held combustibles
WARNING!
ARC RAYS can burn
Wear eye, ear and body protection – Make sure work area is protected by proper shielding to
avoid injury to passers by.

16
Welding in TIG mode – No Pulse – No remote foot pedal
1. Connect the tig torch and earth lead to machine & work piece.
2. Set the TIG/MMA switch to TIG
3. Select either DC (steel) or AC (alloys)
4. Select 2 or 4 way torch operation
5. Connect Argon gas and set flow to approx 8-12 LPM
6. Set Gas post flow to 10 Seconds
7. Adjust Base current to desired welding current
8. Set Pulse current, width & Freq to minimum setting (pulse off)
9. If welding on AC set AC Frequency to 100hz and SP% to 50
10. Press the Tig torch switch to start welding
Welding in TIG mode – with Pulse – No remote foot pedal
1. Connect the Tig Torch to machine, connect earth lead to machine & work piece.
2. Set the TIG/MMA switch to TIG
3. Select either DC (steel) or AC (alloys)
4. Select 2 or 4 way torch operation
5. Connect Argon gas and set flow to approx 8-12 LPM
6. Set Gas post flow to 5 Seconds
7. Adjust Base current to desired welding current.
8. Adjust Pulse current to desired setting
9. Adjust Pulse width to desired setting
10. Adjust Pulse freq. to desired setting
11. If welding on AC set AC Frequency to 100Hz and SP% to 50
12. Press the Tig torch switch to start welding
Notes: When welding with Pulse, the pulse amperage must be set higher than the base amperage.
The LED display will show Pre-set amperage with base and pulse current settings.
The benefits of pulse welding is the ability to control the weld pool and amount of heat absorbed by
work resulting in a smaller heat affected zone which results in fewer deformations and reduced
chance of cracking.
There are no set rules for pulse welding as this is down to personal choice by the welder.
Welding in TIG mode – with Remote foot pedal
1. Connect the
Tig Torch to machine, connect earth lead to machine & work piece.
2. Connect remote foot pedal to machine
3. Set the TIG/MMA switch to TIG
4. Select either DC (steel) or AC (alloys)
5. Select 2 way torch operation – DO NOT USE 4-WAY WITH FOOT PEDAL
6. Connect Argon gas and set flow to approx 8-12 LPM
7. Set Gas post flow to 5 Seconds
8. If welding on AC set AC Frequency to 100Hz and SP% to 50
9. Adjust base current knob to desired maximum welding current that foot pedal will go to
10. Press the foot pedal to start welding.

17
Note: When welding with remote foot pedal
Pre-set amperage in LED display will show what the maximum amperage foot pedal will go to
(what base amperage control knob is set to), upon welding it will show actual welding amperage.
Upon pressing of foot pedal welding arc will start, if you find it hard to start arc push pedal down a
bit further to aid starting.
The benefits of welding with remote foot pedal is greater control of amount of heat going into work
especially beneficial on alloys as these absorb the heat much quicker than steel. Press pedal fully
to start weld, upon weld pool formation you can slightly release the pedal to decrease amperage to
sustain perfect weld pool and increase again as required to sustain weld characteristics.
The foot pedal adjusts from Start (min) current to Max current set on base current knob on front of
machine as shown in LED before welding.
When welding with foot pedal ensure the 2/4 way selector switch is in the 2 way position
Tips for AC Welding
The TIG315 offers two significant advantages over conventional silicon rectifier SCR transformer
power sources.
1. The AC square wave balance (SP%) can be set to a higher percentage electrode negative
(decrease below 50%) which minimizes tungsten heating and erosion
2. The AC square wave frequency can be varied to focus the arc and achieve quicker travel
speed
Increasing the AC frequency above 60Hz will narrow the cone shape arc from the
tungsten’s tip.
Decreasing the AC frequency below 60Hz will broaden the cone shape arc from tungsten’s
tip.
120 Hz 60 Hz
The two above benefits above can be used to maintain a tight focus of arc for precise heat control &
tight joint access. Because of the TIG315 Inverter Technology the following recommendations are
made as a starting point.
The other benefits are quicker travel speed the higher the AC frequency, thus increasing output
A 2% thoriated tungsten is recommended instead of pure tungsten normally used for AC welding.
Thoriated tungsten’s emit electrons easier and therefore will improve starting.

18
Tig tungsten size / amperage guide
All values below are based on using pure argon shielding gas. Other current values may be
employed depending on the shielding gas and application
ELECTRODE RATINGS
Electrode Diameter (mm) 2% Thoriated on DC
(amps)
Red Tip – Grind to point
Pure Tungsten on DC
(amps) Zirconiated 0.8% Tungsten on AC (amps)
White Tip – No need to grind
1.0mm / 0.040” 5 - 80 30 20 - 60
1.6mm / 1/16” 40- 150 80 40 - 100
2.4 mm/ 3/32” 140 - 250 130 80 - 180
3.2mm / 1/8” 240 - 400 180 160 - 250
4.0mm / 5/32” 380- 500 240 220 - 320
4.8mm / 3/16” 500- 750 300 280 - 390
6.4mm / 1/4” 750 - 1000 400 360 - 525
Welding in STICK MMA (SMAW) Mode
1. Fit MMA electrode holder to machine
2. Fit earth lead to machine and to work piece
3. Select MMA on MMA/TIG switch
4. Select DC or AC (DC is most commonly used)
5. Place electrode in holder
6. Select desired welding base current
7. Select desired Arc Force
8. Strike arc and weld
WARNING!
ELECTRIC SHOCK CAN KILL
When machine is switched to MMA mode, output terminals are always live, take care and do not
touch electrode and earth by person at same time, otherwise electric shock will occur.
The foot pedal has no affect on welding current in MMA mode and the gas flow and high frequency
starting circuit is disabled.

19
Maintenance
Routine and periodic maintenance
WARNING!
ELECTRIC SHOCK CAN KILL
Turn the input power OFF at the mains switch & fuse box before working on this equipment.
Have a qualified electrician install & service this equipment.
Allow machine to sit for 5 minutes minimum to allow the power capacitors to discharge before
working inside this equipment.
Do not touch electrically live parts
1. Periodically remove the side/top panels of machine and clean out machine with a low
pressure dry air line paying particular attention to PC Boards, Fan blades, HF points
2. Inspect input and output cables & hoses for fraying, cuts & bare spots
3. Keep tig torch and cables in good condition
4. Clean air vents to ensure proper air flow and cooling
5. The fan motor has sealed bearings which requires no maintenance
Troubleshooting
Service & repair should only be performed by R-Tech welding trained personnel. Unauthorised
repairs performed on this welding equipment may result in danger or injury to the technician and
machine operator and will invalidate your warranty.
For your safety and to avoid electric shock, please observe all safety notes and precautions
detailed throughout this manual
The troubleshooting guide is provided to help you locate possible machine malfunctions
If fault / problem is not listed below check our Tig Welder Support page on our website
www.r-techwelding.co.uk/support.php
or contact R-Tech by phone. Contact details can be found on front of this manual and our website

20
Tig welding problems
•No output - Power light is not lit
Check machine on/off switch is in the ‘on’ position
Check Input power to machine
Check plug wiring
Check mains trip / fuses
•No output - Fan runs - Power light is lit
Check torch connections are secure and torch switch operation, try replacing tig torch.
If you have a multi-meter check continuity between pins 1 and 2 on torch switch plug when
pressing torch switch
•No output - Power light is lit - Warning light is lit
Welding application may have exceeded recommended duty cycle, allow machine to cool
down until the warning light goes out.
•No output – Power light is lit – Gas at torch end when trigger pressed
Check torch condition – possible break in torch power cable – replace torch
•Machine keeps overheating - Warning light is lit on machine
Check if fan is running – if not contact R-Tech for repair
Check the cooling vents for obstruction, blow out machine with clean dry low pressure air
supply. Check for adequate ventilation around machine
•Porosity in weld – No / low gas at torch tip
Check gas supply from gas bottle
Check flow rate on regulator
Check gas hose for restrictions
Check for draughts in local area, open doors etc
Replace tig torch – may have gas restriction
•Poor weld penetration
Check condition of earth lead and clamp and ensure clamp is connection via a clean area
on work piece
Check condition of tig torch, try other tig torch
