Monessen
B Vent F replace Systems
Model BBV400A
BTU / HR 16,000-22,000 NG / 14,500-22,000 LP
Thermal Efficie cy Up to 80%
Dime sio s (Actual) 40”W x 40”H x 14”D
Dime sio s (Frami g) 40 1/2”W x 40 3/4”H x 14 1/2”D
Viewi g Area 21 1/2"H x 36"W (774 sq. inches)
Model SBV400A SBV500A
BTU / HR 16,500-25,000 NG / 16,300-29,000 LP 19,000-31,500 NG / 20,000-31,500 LP
Thermal Efficie cy Up to 80% Up to 80%
Dime sio s (Actual) 40”W x 40 1/2”H x 21”D 46”W x 40 1/2”H x 21”D
Dime sio s (Frami g) 40 1/2”W x 40 3/4”H x 21 1/2”D 46 1/2”W x 40 3/4”H x 21 1/2”D
Viewi g Area 21 1/2"H x 36"W (774 sq. inches) 21 1/2"H x 42"W (903 sq. inches)
Model 724BV4536 724BV5142
BTU / HR 35,000-50,000 NG / 35,000-50,000 LP 35,000-50,000 NG / 35,000-50,000 LP
Thermal Efficie cy Up to 80% Up to 80%
Dime sio s (Actual) 45”W x 44 1/8”H x 23 1/2”D 51”W x 44 1/8”H x 23 1/2”D
Dime sio s (Frami g) 45 1/4”W x 48”H x 23 5/8”D 51 1/4”W x 48”H x 23 5/8”D
Viewi g Area 26"H x 36"W (936 sq. inches) 26"H x 42"W (1092 sq. inches)
Model (Desig er) 624BVST 624BVPF 624BVC(L)(R) 624BVBY
BTU / HR 42,000 NG / 42,000 LP 42,000 NG / 42,000 LP 42,000 NG / 42,000 LP 42,000 NG / 42,000 LP
Thermal Efficie cy Up to 80% Up to 80% Up to 80% Up to 80%
Dime sio s (Actual) 38”W x 42 3/8”H x 24 1/8”D 38”W x 42 3/8”H x 24 1/8”D 38”W x 42 3/8”H x 24 1/8”D 38”W x 42 3/8”H x 24 1/8”D
Dime sio s (Frami g) 39”W x 42 1/2”H x 23 1/8”D 38 1/2”W x 42 1/2”H x 23 1/8”D 38 1/2”W x 42 1/2”H x 24 5/8”D 37”W x 42 1/2”H x 24 5/8”D
Viewi g Area 22 1/4"H x 36"W (801 sq. inches) 22 1/4"H x 36"W (801 sq. inches) 22 1/4"H x 36"W (801 sq. inches) 22 1/4"H x 36"W (801 sq. inches)
Your Monessen Dealer:
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
STANDARD FEATURES:
• Glowing ceramic fiber logs featuring a patente
Natural Flame aluminize pan burner with ran om
ancing flames an large ember be
• Millivolt with on/off switch an variable flame
height control or electronic ignition in natural gas
or propane gas
• Natural or propane fiel convertible
• Flexible connector with On/Off valve inclu e
• Inclu es 15' of preinstalle millivolt wire with wall
switch an cover
• Junction box inclu e for electrical hook up
BBV
• 36" ra iant face unit 14" in epth
• Three piece log set with 22,000 BTU
• Available with 4” B-vent outlet
SVB
• 36" & 42" ra iant face esign units 21" in epth
• Three piece ceramic fiber log sets with 29,00 BTU
in SBV400 an 31,500 BTU in SBV500
• Shippe with refractory brick stan ar for true
masonry look
• Available with 6" B-vent outlet
724BV
• 36" & 42" ra iant face esign units 23 1/2" in epth
• Massive ceramic fiber log sets with 50,00 BTU
•Thermal operate safety shut off activates if flue
is blocke
• Manual on/off amper control
• Built in outsi e air kit
• Available with 8" B-vent outlet
DESIGNER FIREPLACES
• Available in See-Thru, Bay, Peninsula, Left an
Right Corner units
• Hi en control panel allows facing material to be
installe up to opening of units
• Realistic ceramic fiber log sets with 42,00 BTU
• Polishe brass oor panels stan ar
• Available with 6"B-vent outlet
Touch Light™ table top/wall mount TLM
on/off an TLT thermostat remote control
with receiver
Programmable wireless wall
thermostat with receiver
Thermostat ON/OFF remote control with
3-step flame height a justment an
3-spee blower control with receiver
See our Ambient Technologies®catalog for a complete line of remotes and thermostats.
Opt onal Accessor es
OPTIONAL FEATURES:
• Black, Polishe Brass an Stainless Steel single
panel oors for BBV & SBV fireplaces
• Black, Polishe Brass an Stainless Steel bi-fol
oors for BBV & SBV fireplaces
• Black, Polishe Brass bi-fol oors for 724BV
fireplaces (require on propane mo el)
• Cottage Clay firebrick for BBV fireplace
• Cottage Clay an Cottage Re firebrick for
724 fireplaces
• Firebrick back an si e panels for Designer units
• Outsi e air kits
• Multi-functional Ambient Technologies®remote
controls available for all units
Cottage Clay
firebrick
Cottage Re
firebrick

Noth ng nv tes or del ghts l ke
the danc ng flames of a f re. For
thousands of years f re has been the
focal po nt of hearth and home and,
l ke so many fam l es before, we
nv te you to s t by ours and enjoy
the r warmth and beauty.
B VENT DESIGNER
FIREPLACE SYSTEMS
The B vent Designer Series of
fireplace systems from Monessen
offer sophisticate options for to ay's
more contemporary homes. Available
in See-Thru, Peninsula, Corner or Bay
Front mo els, the Designer Series
takes fire to a whole new level.
The ra iant esign allows materials to
be place right up to the e ge of the
firebox an with optional firebrick
backs an si es as well as stan ar
black trim, these 42,000 BTU
fireplaces offer great heating ability
an exciting esign applications.
WARM
WELCOME B VENT FIREPLACE SYSTEMS
Easily incorporate into any esign requirement where the fireplace can be vente straight up an
out, a ing the beauty an elegance of fire to your home is simple with the B vent fireplace systems
from Monessen.
The BBV Series offers a 36 inch ra iant esign with a true 36 inch brick to brick opening that has
the largest viewing area in the in ustry. With 22,000 BTU's, optional bi-fol an single pane glass
oors, an a slim 14 inch eep esign, this B vent fireplace from Monessen is a perfect choice for
just about anywhere.
With 36 an 42 inch sizes, the SBV Series of B vent fireplace systems from Monessen also offer
an expansive view. Both sizes come with stan ar refractory brick an a black firescreen. With
an impressive BTU range from 29,000 to 31,000, the SBV Series are i eal choices for har to
heat rooms.
Our 7000 Series of B vent fireplace systems are giants in the in ustry. The only B vent fireplaces
of this size that can operate with the optional bi-fol oors close , the clean-face esign offers
a contemporary an uninterrupte view of the flames. Available in two sizes with either 936 or
1092 square inches of viewing area, the 7000 Series is truly the focal point of your room.
Designer
Peninsula
624BVPF
Designer Bay
624BVBY
724BV5142 with optio al Cottage Clay firebrick
