Monessen Hearth MCUF42D-R Magnum Installation instructions

PRODUCT SPECIFICATIONS
MCUF42D-R/MCUF42D-F Magnum Vent Free Firebox
74 7/8"
18"
16 3/8"
53"
47 7/16
38"
6"
2 1/2"
42"
5 1/4"
26 1/8"
47 1/16"
40"
20 1/2"
33 1/4"
38"
9 7/8"
8 1/4"
37 3/8"
18 1/16"
25"
37 1/2"
FRAMING DIM.
47 7/16"
FRAMING DIM.
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes.Contact local building or fire officials about restrictions and installation inspection requirements.All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit.Appearance and specifications of the product are subject to change without notice.© 2007 Monessen Hearth Systems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
MINIMUM HEARTH DIMENSIONS
Front opening width: 38-1/2"
Front opening height: 26"
Rear wall width:30-1/4"
Firebox depth: 16"
TECHNICAL INFORMATION
Clearance to Fireplace: Zero
CSA Design Certified
FACTORY INSTALLED OPTIONS
Refractory Herringbone firebrick (MCUF42D-R)
Cottage Clay firebrick (MCUF42D-F)
FIELD INSTALLED ACCESSORIES
CurvedTrim: Brass, Pewter, Black
VariableThermostat Controlled Forced Air Blower (160cfm) - BLOTMC
Brass Hood
Wide Profile Brass Hood
Classic and Designer Facings
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
