Monessen Hearth Direct Vent BLDV500 Installation instructions

PRODUCT SPECIFICATIONS
BLDV500 Direct Vent
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes.Contact local building or fire officials about restrictions and installation inspection requirements.All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit.Appearance and specifications of the product are subject to change without notice.© 2007 Monessen Hearth Systems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
GLASS VIEWING AREA
33”W x 25 13/16”H (858 Square Inches)
TECHNICAL INFORMATION
Max. Btu Input: 28,000 BTU/HR
Ignition System: Standing Pilot or Signature Command™System
Gas Type: Natural or LP
FlueType: Simpson Dura-Vent, Selkirk Metalbestos, MetalFab
Termination: Top vent
Clearance to Flue for interior: 3"Top 1" Bottom and Sides
Clearance to Flue for OutsideWall: 1"
Clearance to Fireplace: 1"
MinimumVent Height Before Elbow: 12”
CSA Design Certified
FIELD INSTALLED ACCESSORIES
Firebrick: Cottage Clay or Cottage Red
Options: Andirons, Mesh Glass Cover, Remote
Variable Thermostat Controlled Dual Forced
Air Blower (160 cfm): BLOTBLDV
AmbientTechnologies™Remote Controls and Thermostats
34-1/4"
7-5/16"
17-9/16"
20-9/16"
41-1/16"
33"
35-15/16"
25-13/16"
40-5/8"
31-7/8"
3"
1"
7-3/4" 2-9/16"
37-1/2"
11-3/8"
40-5/8"
15/16"
41-7/16"
68-3/4"
34-3/8"
16-13/16"
17-9/16"
34-1/4"
48-5/8"
40-7/8"
FRAMING
DIMENSION
FRAMING DIMENSIONS
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
