Monessen Hearth Artisan AVFL Series User manual

1
Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21
Models:
Owner’s Manual
Care and Operation
NOTICE: DO NOT discard this manual!
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas tter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
• DO NOT store or use gasoline or other am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor’s phone. Follow the gas sup-
plier’s instructions.
- If you cannot reach your gas supplier, call
the re department.
• Installation and service must be performed
by a qualied installer, service agency, or the
gas supplier.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
AVFL42NIP-BU/PIP-BU
AVFL42NIP-RB/PIP-RB
AVFL48NIP/PIP
AVFLST48NIP/PIP
AVFL60NIP-B/PIP-B
Artisan
Series
This appliance may be installed in an after-
market, permanently located, manufactured
(mobile) home, where not prohibited by local
codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appli-
ance is not convertible for use with other
gases.
• DO NOT install this appliance in a bedroom
or bathroom. Please refer to page 6 Sec-
tion F of the Installation Manual for proper
appliance placement.
This is an unvented gas-red heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion and ven-
tilation air must be provided. Refer to page 6
of the Installation Manual.

Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/212
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
Table of Contents
1 Welcome
A. Congratulations .................................3
B. Limited Lifetime Warranty ..........................4
2 Product Specic Information
A. Appliance Certication ............................6
B. BTU Specications ...............................6
3 Important Safety and Operating Information
A. Appliance Safety ................................7
B. General Operating Parts ..........................9
C. Fuel Specications ...............................9
D. Good Faith Wall Surface/TV Guidelines ............. 10
E. Before Lighting Appliance. . . . . . . . . . . . . . . . . . . . . . . . . 12
F. Lighting Instructions (IPI) .........................13
G. Initial Use .....................................14
H. Heat Management ..............................14
I. Operation During A Power Outage ..................14
4 Intellire Plus™ ODS
5 Maintenance and Service
A. Maintenance: Frequency and Tasks ................21
B. Maintenance Tasks: Homeowner ..................21
C. Maintenance Tasks: Qualied Service Technician .....21
6 Frequently Asked Questions and Troubleshooting
A. Frequently Asked Questions ...................... 23
B. Troubleshooting - Intellire Plus™ ODS ..............23
C. Troubleshooting—Screen/LEDs/Control Panel ........25
7 Reference Materials
A. Accessories ...................................26
B. Service Parts ..................................27
C. Massachusetts Residents Only .................... 38
D. Contact Information ............................. 39
 = Contains updated information.
WARNING! RISK OF FIRE OR EXPLOSION AND ASPHYXIATION HAZARD
Improper adjustment, alteration, service, maintenance, or installation of this heater
or its controls can cause death or serious injury.
Read and follow instructions and precautions in User’s Information Manual
provided with this heater.
►
►

3
Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21
Listing Label Information/Location
Gas and Electric
Information
Serial Number
Type of Gas
The model information regarding your specic appliance can be found on
the rating plate usually located in the control area of the appliance.
Model Number
Read this manual before operating this appliance.
Please retain this Owner’s Manual for future reference.
Read the Installation Manual before making any installation or nishing changes.
1 Welcome
Brand: ________________________________________________ Model Name: ___________________________
Serial Number:__________________________________________ Date Installed: __________________________
Appliance Information:
Dealer: Fill in your
name, address,
phone and email
information here and
appliance information
below.
Dealer Name: ________________________________________________________
Address: ____________________________________________________________
____________________________________________________________
Phone: _____________________________________________________________
Email: _____________________________________________________________
A. Congratulations
Congratulations and thank you for selecting a Monessen
vent free gas appliance, an elegant and clean alternative
to wood burning appliances. The gas appliance you
have selected is designed to provide the utmost in safety,
e󰀩ciency, and style.
As the owner of a new appliance, you’ll want to read and
carefully follow all of the instructions contained in this
owner’s manual. Pay special attention to all cautions and
warnings.
This owner’s manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this owner’s manual, unless
noted otherwise, applies to all models and gas control
systems noted on the cover page.
Your new Monessen gas appliance will give you years of
durable use and trouble-free enjoyment. Welcome to the
Monessen family. We are glad you joined us!
Local Dealer Information

Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/214
B. Limited Lifetime Warranty
Hearth & Home Technologies LLC
LIMITED LIFETIME WARRANTY
Hearth & Home Technologies LLC (“HHT”) extends the following warranty for HHT gas, wood, pellet and electric hearth appliances
(each a “Product” and collecvely, the “Product(s)”) and certain component parts set forth in the table below (“Component Part(s)”)
that are purchased from a HHT authorized dealer or distributor.
WARRANTY COVERAGE:
HHT warrants that the Products and their Component Parts will be free from defects in materials and workmanship for the applicable
period of Warranty coverage set forth in the table below (“Warranty Period”). If a Product or Component Parts are found to be
defecve in materials or workmanship during the applicable Warranty Period, HHT will, at its opon, repair the applicable Component
Part(s), replace the applicable Component Part(s), or refund the purchase price of the applicable Product(s). The maximum amount
recoverable under this Warranty is limited to the purchase price of the Product. This Warranty is transferable from the original purchaser
to subsequent owners, but the Warranty Period will not be extended in duraon or expanded in coverage for any such transfer. This
Warranty is subject to condions, exclusions, and limitaons as described below.
WARRANTY PERIOD:
Warranty coverage begins at the date of installaon. In the case of new home construcons, Warranty coverage begins on the date of
rst occupancy of the dwelling or six months aer the sale of the Product(s) by an independent, authorized HHT dealer or distributor,
whichever occurs earlier. However, the Warranty coverage shall commence no later than 24 months following the date of Product
shipment from HHT, regardless of the installaon or occupancy date.
The term “Lifeme” in the table below is dened as: 20 years from the beginning date of warranty coverage for gas appliances, and 10
years from the beginning date of warranty coverage for wood and pellet appliances. These me periods reect the minimum expected
useful lives of the designated Component Parts under normal operang condions.
Page 1 of 2
4021-645L 10/20
Component
Parts Labor Gas Pellet Wood Electric Venting Component Parts Covered by this Warranty
XAll parts except as covered by Warranty Conditions,
Warranty Exclusions, and Warranty Limitations listed
X X Igniters, Auger Motors, Electronic Components, and
Glass
X
Electrical components limited to modules, remotes/wall
switches, valves, pilots, blowers, junction boxes, wire
harnesses, transformers and lights (excluding light bulbs)
X X Molded Refractory Panels, Glass Liners
XVent Free Burners, Vent Free Logs
X X Castings, Medallions and Baffles
6 years 3 years XCatalysts
7 years 3 years X X Manifold tubes, HHT Chimney and Terminations
10 years 1 year XBurners, logs and refractory
Limited
Lifetime 3 years XXX Firebox and heat exchanger, FlexBurn®System
(engine, inner cover, access cover and fireback)
1 Year None XXXXX All purchased replacement parts
Warranty Period HHT Manufactured Appliances and Venting
All parts including handles, external enameled
components and other material except as covered by
Warranty Conditions, Warranty Exclusions, and
Warranty Limitations listed
2 years
X1 Year X X X
2 Years
5 years 1 year
Firepots, burnpots, mechanical feeders/auger
assemblies
3 years X

5
Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21
B. Limited Lifetime Warranty (continued)
WARRANTY CONDITIONS:
• Because HHT cannot control the quality of any Products sold by unauthorized sellers, this Warranty only covers Products that are
purchased through an HHT authorized dealer or distributor unless otherwise prohibited by law; a list of HHT authorized dealers
is available on the HHT branded websites.
• This Warranty is only valid while the applicable Product remains at the site of original installaon.
• This Warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the applicable Product is
authorized to sell applicable Product.
• Contact your installing distributor or dealer for Warranty service. If the installing dealer or distributor is unable to provide
necessary parts, contact the nearest HHT authorized dealer or supplier. Addional service fees may apply if you are seeking
Warranty service from a dealer other than the dealer from whom you originally purchased the applicable Product.
• No HHT consumer should bear cost of warranty service or costs incurred while servicing warranty claims (i.e., travel, gas, or
mileage) when the service is performed within the terms of this Warranty. Check with your dealer or distributor in advance for
any costs to you when arranging a warranty call. Travel and shipping charges for parts are not covered by this Warranty.
WARRANTY EXCLUSIONS:
This Warranty does not cover the following:
• Changes in surface nishes as a result of normal use. As a heang appliance, some changes in color of interior and exterior surface
nishes may occur. This is not a aw and is not covered under the Warranty.
• Damage to printed, plated, or enameled surfaces caused by ngerprints, accidents, misuse, scratches, melted items or other
external sources and residues le on the plated surfaces from the use of abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the Warranty Period are not covered. These parts
include: paint, wood and pellet gaskets, rebricks, grates, ame guides, baeries and the discoloraon of glass.
• Minor expansion, contracon, or movement of certain parts causing noise. These condions are normal and complaints related to
this noise are not covered by this Warranty.
• Damages resulng from: (1) failure to install, operate, or maintain the applicable Product in accordance with the installaon
instrucons, operang instrucons, and lisng agent idencaon label furnished with the applicable Product; (2) failure to
install the applicable Product in accordance with local building codes; (3) shipping or improper handling; (4) improper operaon,
abuse, misuse, connued operaon with damaged, corroded or failed components, accident, or improperly/incorrectly performed
repairs; (5) environmental condions, inadequate venlaon, negave pressure, or draing caused by ghtly sealed construcons,
insucient make-up air supply, or handling devices such as exhaust fans or forced air furnaces or other such causes; (6) use of fuels
other than those specied in the operaon instrucons; (7) installaon or use of components not supplied with the applicable
Product or any other components not expressly authorized and approved by HHT; (8) modicaon of the appliance not expressly
authorized and approved by HHT in wring; and/or (9) interrupons or uctuaons of electrical power supply to the applicable
Product.
• Non-HHT venng components, hearth connecons or other accessories used in conjuncon with the applicable Product.
• Any part of a pre-exisng replace system in which an insert or a decorave gas applicable Product is installed.
• HHT’s obligaon under this Warranty does not extend to the Product’s capability to heat the desired space. Informaon is provided
to assist the consumer and the dealer in selecng the proper Product for the applicaon. Consideraon must be given to the
Product locaon and conguraon, environmental condions, insulaon and air ghtness of the structure.
This warranty is void if:
• The applicable Product has been over-red, operated in atmospheres contaminated by chlorine, uorine, or other damaging
chemicals. Over-ring can be idened by, but not limited to, warped plates or tubes, deformaon/warping of interior cast iron
structure or components, rust colored cast iron, bubbling, cracking and discoloraon of steel or enamel nishes.
• The applicable Product is subjected to prolonged periods of dampness or condensaon.
• There is any damage to the applicable Product due to water or weather damage which is the result of, but not limited to, improper
chimney or venng installaon.
LIMITATIONS OF REMEDIES AND LIABILITY:
• EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED
HEREIN. The owner’s exclusive remedy and HHT’s sole obligaon under this Warranty or in contract, tort or otherwise, shall be
limited to replacement of the Component Part(s), repair of the Component Part(s), or refund of the original purchase price of the
applicable Product(s), as specied above; provided, however, that (i) if HHT is unable to provide replacement of the Component
Part(s) and repair of the Component Part(s) is not commercially praccable or cannot be mely made, or (ii) the customer is
willing to accept a refund of the purchase price of the applicable Product(s), HHT may discharge all such obligaons by refunding
the purchase price of the applicable Product. In no event will HHT be liable for any incidental or consequenal damages caused
by defects in the applicable Product. Some States do not allow the exclusion or limitaon of incidental or consequenal damages,
so the above limitaon or exclusion may not apply to you. This Warranty gives you specic legal rights and you may also have
other rights which vary from State to State. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE
EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitaons on how long an
implied warranty lasts, so the above limitaon may not apply to you.
Page 2 of 2
4021-645L 10/20

Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/216
A. Appliance Certication
NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE.
This appliance is tested and approved as either supplemen-
tal room heat or as a decorative appliance. It should not be
factored as primary heat in residential heating calculations.
NOTICE: This installation must conform with local codes.
In the absence of local codes you must comply with the
National Fuel Gas Code, ANSI Z223.1—latest edition in
the U.S.A.
2 Product Specic Information
B. BTU Specications
This product is listed to ANSI standards for “Unvented
Gas Heaters” and applicable sections of “Gas Burning
Heating Appliances for Manufactured Homes and Recre-
ational Vehicles”, and “Gas Fired Appliances for Use at
High Altitudes”.
MODEL: AVFL42NIP-BU, AVFL42PIP-BU, AVFL42NIP-RB,
AVFL42PIP-RB, AVFL48NIP, AVFL48PIP, AVFLST48NIP,
AVFLST48PIP,AVFL60NIP-B, AVFL60PIP-B
LABORATORY: UNDERWRITERS LABORATORIES, INC.
(UL)
TYPE: Unvented Room Heaters
STANDARD: ANSI Z21.11.2:19
Models Maximum
Input
BTU/h
Minimum
Input BTU/h
Orice
Size (DMS)
AVFL42NIP-BU (NG) (0-2000 FT) 34,000 23,500 .1110(#34)
AVFL42PIP-BU (PROPANE) (0-2000 FT) 33,000 26,000 .070(#50)
AVFL42NIP-RB (NG) (0-2000 FT) 24,500 17,500 .096(#41)
AVFL42PIP-RB (PROPANE) (0-2000 FT) 24,000 19,000 .0595(#53)
AVFL48NIP (NG) (0-2000 FT) 39,000 27,500 .120(#31)
AVFL48PIP (PROPANE) (0-2000 FT) 38,000 31,000 .076(#48)
AVFLST48NIP (NG) (0-2000 FT) 39,000 27,500 .120(#31)
AVFLST48PIP (PROPANE) (0-2000 FT) 38,000 31,000 .076(#48)
AVFL60NIP-B (NG) (0-2000 FT) 40,000 28,000 .120(#31)
AVFL60PIP-B (PROPANE) (0-2000 FT) 39,000 30,500 .076(#48)
Installation and service of this appliance should
be performed by qualied personnel. Hearth
& Home Technologies recommends HHT
Factory Trained or NFI certied professionals.
NOTE: For higher elevations please see page 9.
WARNING: This product and the
fuels used to operate this product (liquid
propane or natural gas), and the products
of combustion of such fuels, can expose
you to chemicals including benzene, which
is known to the State of California to cause
cancer and reproductive harm. For more
information go to: www.P65Warnings.
ca.gov.
WARNING
This appliance is equipped for (natural or propane)
gas. Field conversion is not permitted.

7
Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21
3 Important Safety and Operating Information
Clear Space
WARNING! DO NOT place combustible objects in front
of the appliance. High temperatures may start a re. See
Figure 3.1.
Avoid placing candles, electronics and other heat-sensitive
objects on mantel or hearth. Heat may damage these
objects.
Figure 3.1 Clear Space
Over Firing
The appliance is considered to be over ring if the ames
are contacting the top of the rebox. Call a qualied service
technician to service the appliance.
CLEAR SPACE
3 FT. IN FRONT
OF APPLIANCE
WARNING! DO NOT operate appliance before read-
ing and understanding operating instructions. Failure
to operate appliance according to operating instructions
could cause re or injury.
Young children should be carefully supervised when they
are in the same room as the appliance. Toddlers, young
children and others may be susceptible to accidental
contact burns.
• A physical barrier is recommended if there are at risk
individuals in the house.
• To restrict access to an appliance or stove, install an
adjustable safety gate to keep toddlers, young children,
pets and other at risk individuals out of the room and
away from hot surfaces.
• Install a switch lock or a wall/remote control with child
protection lockout feature.
• Keep remote controls out of reach of children.
• Never leave children alone near a hot appliance, whether
operating or cooling down.
• Teach children to NEVER touch the appliance.
• Consider not using the appliance when children will be
present.
Contact your dealer for more information, or visit: www.
hpba.org/safety-information.
To prevent unintended operation when not using your ap-
pliance for an extended period of time (summer months,
vacations, trips, etc):
• Remove batteries from remote controls.
• Turn o󰀨 wall controls.
• Unplug 6 volt adapter plug.
A. Appliance Safety
WARNING! Choking Hazard! Keep crushed glass me-
dia out of reach of children.
Note: See appliance Installation
Manual for hearth, mantel and
nishing requirements.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
ammable materials.
• Clothing, furniture, draperies, and other flammable
materials must not be placed on or near the appliance.

Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/218
•Any change to this appliance or its controls can be dangerous.
• Improper installation or use of the appliance can cause serious injury or death from re, burns,
explosion or carbon monoxide poisoning.
• Do not allow fans to blow directly into the appliance. Avoid any drafts that alter burner ame patterns.
•Do not use a blower insert, heat exchanger insert or other accessory, not approved for use with
this heater where applicable.
OWNER
Please retain these instructions for future reference .
1. Due to high temperatures, the appliance should be
located out of tra󰀩c and away from furniture and
draperies.
2. Children and adults should be alerted to the hazard
of high surface temperature and should stay away
to avoid burns or clothing ignition.
3. Young children should be carefully supervised when
they are in the same room with the appliance.
4. Do not place clothing or other ammable material
on or near the appliance.
5. Any safety screen or guard removed for servicing
an appliance, must be replaced prior to operating
the heater.
6. Installation and repair should be done by a qualied
service person. The appliance should be inspected
before use and at least annually by a professional
service person. More frequent cleaning may be
required due to excessive lint from carpeting,
bedding material, etc. It is imperative that control
compartments, burners, and circulating air pas-
sageways of the appliance be kept clean.
7. This appliance is intended for supplemental heating.
8. CARBON MONOXIDE POISONING: Early signs of
carbon monoxide poisoning are similar to the u with
headaches, dizziness and/or nausea. If you have these
signs, obtain fresh air immediately. Have the heater
serviced as it may not be operating properly.
9. The installation must conform with local codes or, in
the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.l/NFPA54.
10. Do not install this appliance in a bathroom or bedroom.
11. Correct installation of the crushed glass media, optional
stone and ceramic ber logs, proper location of the
appliance, and annual cleaning are necessary to avoid
potential problems with sooting. Sooting, resulting
from improper installation or operation, can settle on
surfaces outside the appliance. Refer to log placement
instructions for proper installation.
12. WARNING: Do not allow fans to blow directly into the
appliance. Avoid any drafts that alter burner ame
patterns. Do not place a blower inside burn area of
appliance. Ceiling fans may create drafts that alter
burner ame patterns. Sooting and improper burning
will occur.
13. Caution: Candles, incense, oil lamps, etc. produce
combustion by-products including soot. Vent-free
appliances will not lter or clean soot produced by
these types of products. In addition, the smoke and/
or aromatics (scents) may be reburned in the vent-free
appliance which can produce odors. It is recommended
to minimize the use of candles, incense, etc. while the
vent-free appliance is in operation.
14. This heater shall not be installed in a room or space
unless the required volume of indoor combustion air is
provided by the method described in the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, the International
Fuel Gas Code or applicable local codes.
15. Keep room area clear and free from combustible mate-
rials, gasoline and other ammable vapors and liquids.
16. Unvented appliances emit moisture into the living
area. In most homes of average construction, this
does not pose a problem. In houses of extremely
tight construction, additional mechanical ventilation is
recommended.
17. During manufacturing, fabricating and shipping, various
components of this appliance are treated with certain
oils, lms or bonding agents. These chemicals are not
harmful but may produce annoying smoke and smells
as they are burned o󰀨 during the initial operation of the
appliance; possibly causing headaches or eye or lung
irritation. This is a normal and temporary occurrence.
The initial break-in operation should last three to four
hours with the burner at the highest setting. Provide
maximum ventilation by opening windows or doors to
allow odors to dissipate. Any odors remaining after this
initial break-in period will be slight and will disappear
with continued use.
Important Safety and Operating Information (continued)
WARNING

9
Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21
Figure 3.2 General Operating Parts
B. General Operating Parts
C. Fuel Specications
WARNING! Risk of Fire or Explosion! Appliance must
be set up for compatible gas type!
• This appliance is designed to operate on either natural
gas or propane. Make sure the appliance is compatible
with gas type selected for installation site.
Figure 3.2 references the general operating parts of the
appliance and the section of this manual in which they are
discussed.
CLEAR SPACE
SECTION 3.A.
DECORATIVE DOORS
SECTION 4
GLASS ASSEMBLY
SECTION 4
OPERATION DURING
A POWER OUTAGE
SECTION 3.I
WARNING! Risk of Fire! Comply with all minimum
clearances to combustibles as specied in the installation
instructions.
18. Input ratings are shown in BTU per hour and are for
elevations up to 2,000 feet. For elevations above 2,000
feet, input ratings should be reduced 4 percent for each
1,000 feet above sea level. Refer to the National Fuel
Gas Code.
19. The appliance and its appliance main gas valve must
be disconnected from the gas supply piping system
during any pressure testing of that system at test pres-
sures in excess of 1⁄2 psig (3.5 kPa).
20. The appliance must be isolated from gas supply piping
system by closing its equipment shuto󰀨 valve during
any pressure testing of the gas supply piping system at
test pressures equal to or less than 1⁄2 psig (3.5 kPa).
21. Do not use this room heater if any part has been under
water. Immediately call a qualied service technician
to inspect the room heater and to replace any part of
the control system and any gas control which has been
under water.
22. Never burn solid fuels in a appliance where a unvented
room heater is installed.
23. WARNING: Failure to keep the primary air opening
of the burner clean may result in sooting and property
damage.
24. WARNING: Do not use a blower insert, heat exchanger
insert or other accessory not approved for use with this
heater.
BUILDING CODE INFORMATION
Adhere to all local codes or, in their absence, the latest
edition of THE NATIONAL FUEL GAS CODE ANSI Z223.1
or NFPA54 which can be obtained from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
or
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269

Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/2110
Figure 3.3 Good Faith TV Guidelines
D. Good Faith Wall Surface TV Guidelines
(AVFL42N(P)IP-BU, AVFL48N(P)IP, AVFL60N(P)IP-B, AND AVFLST48N(P)IP appliances)
Combusble Mantel
A
inch
22.00
Non-Combusble Mantel
inch 20.00
Good Faith Guidelines for TV on’s above a Typical Gas Fireplace
TV on the wall TV recessed into the wall
Notes:
1. These are good faith recommended clearances only and not a guarantee of compliance with all TV
manufacturers’ maximum allowable operating temperatures.
2. Since every home has unique air ow characteristics and maximum allowable operating temperatures can
vary from manufacturer to manufacturer and from model to model, actual TV temperatures should be
validated at the time of each installation. TVs should not be used in situations where the actual TV
temperature exceeds the manufacturers’ maximum allowable operating temperatures identied in the
TV’s technical specications. Contact the TV’s manufacturer directly if you cannot locate this information
or have questions regarding the information.
3. Mantel height and depth must conform to mantel requirements specied in the replace installation
manual.
4. “A” dimension taken from the top of the rebox opening.
5. Suggestions on how to further reduce TV temperatures:
-Increase “A” and/or 28” minimum TV height dimensions.
6" Min.
A Min.
28" Min.
12" Min.
TV
28" Min.
A Min.
12" Min.
TV
Top of appliance
opening
Top of appliance
opening
