Moneual MR6800M-M3 Series User manual

Ver 1.0
MR6800M-M3** Series
Quick Start Guide
Robot Cleaner

What’s in
the Box
1
 Robot cleaner (1400mA built-in battery)
2
 Charger 
3
 Power adaptor
4
 Power cord
5
  Remote control
(included two AAA batteries)
6
 Side brushes (1 set)
7
 Cleaning brush
8
 User manual  Quick start guide
9

Water-supply big mop kit
What’s in the Box
2 3
4 5
1
6 7
8 9

Overview
2
3
4
8
7
6
5
1
 Control buttons and indicators 
2
 Dust bin cover 
3
 Bumper 
4
 Obstacle and signal detection sensors 
5
 Air outlet
6
 Adaptor jack 
7
 Power switch 
8
 Signal receiving sensor 
9
 Cli detection sensors 
10
 Charging terminals 
11
 Wheels
12
 Side brush installation pins 
13
 Dust inlet 
14
 Main brush 
15
 Mop plate installation holes
Robot cleaner
10
11
9
11
15
9
12
13
11
14
9
12
1
 Power/charging lamp 
2
 Guide signal transmission sensor 
3
 Charging terminals 
4
 Adaptor holder 
5
 Adaptor jack 
6
 Sensor’s signal distance selection switch
Charger
2
1
3
5
6
4
1

1
 Power button
Þ 
Press to turn the power on/o.
Þ 
Press to return the robot cleaner to the operation mode when it has
stopped due to failure.
2
 Mode button 
Þ 
Press to select the cleaning mode.
3
 Start/stop button
Þ 
Press to start the selected operation.
Þ 
Press to start/stop cleaning and driving.
4
 SELECT/MANUAL button 
Þ 
Press to conrm your selection. 
Þ 
Press to start manual cleaning.
5
 Direction buttons
6
 CHARGE button 
Þ 
Press to move robot cleaner to charger.
7
 MOP cleaning button
8
 INTENSIVE cleaning button 
9
 VACUUM button 
Þ 
Press to turn the turbo function on/o.
10
 SHADOW cleaning button 
11
 CORNER cleaning button 
12
 RESERVATION button
13
 MUTE button 
Þ 
Press to turn voice guidance on/o.
14
 ROOM SEL button 
Þ 
Press to select the room to clean.
Remote control
2
6
9
12
13
1
3
8
11
14
10
7
5
4
1
 Start/stop button 
2
 Power button 
3
 Cleaning mode selection
button

4
 Turbo mode indicator 
5
 Shadow cleaning mode
indicator 
6
 Auto cleaning mode indicator 
7
 Mop cleaning mode
indicator
8
 Timer (one time) indicator
9
 Timer (every day) indicator
10
 Room selection indicator
11
 Error indicator
12
 Charging mode
indicator
13
 Battery level indicator
Control buttons and indicators
6
5
11
13
12
21 3
4
10
9 8 7

Installing
Installing the Side Brushes
Þ
 Check for the L mark
under the side brush.
Þ
 Align with the L mark under
the robot cleaner and
install the L brush.
Þ
 Check for the R mark
under the side brush.
Þ
 Align with the R mark
under the robot cleaner
and install the R brush.
Installing the Charger
Ě
     If you install the robot cleaner in a place where it will be exposed to direct sunlight, the heat of the sun may interfere with the auto
charging, and the robot cleaner may become discolored over time.
Ě
   If your robot cleaner can’t return to the charger, reset the detection distance.
Þ
 Connect the power adaptor.
Þ
 Set the robot cleaner detection distance (5 m or 8 m).
Þ
 Place the power adaptor in the holder of the charger.
1
Þ
 Check the power connection (blue lamp).
2
Þ
 Check the location of the charger. 

Clear all obstacles in the area within 1 m in front, left,
and right of the charger.
3

Cleaning
Modes
Auto Cleaning
Corner Cleaning
Intensive Cleaning
ǘ The robot cleaner intensively cleans the surrounding area relative to its current location.
ǘ The robot cleaner runs along the walls of the current place where it is.
ǘ It is the normal cleaning mode.
Ě
   In the area in which there are many obstacles, the robot cleaner may not operate in normal cleaning modes.
4
4
or
2 43
or
3
3
2
or
2
or
Þ
 Turn the power
switch on.
1
Þ
 Turn the power
switch on.
1
Þ
 Turn the power
switch on.
1

Ě
   Before scheduling, you must install the charger.
Shadow Cleaning
ǘ You can clean under your bed or furniture.
Manual Cleaning
ǘ You can control the robot cleaner directly using the remote control.
Ě
   To use shadow cleaning mode, turn the room light on. In a dark room, the robot cleaner can’t
detect the space under the bed or furniture.

Þ
 Put the robot cleaner in front of a bed or furniture.
2
Þ
 Turn the power switch on.
1
Þ
 Stop the robot cleaner that
is operating by pressing the
Start/stop(
ĚĦ ) button.
1 2
Scheduled Cleaning
ǘ You can schedule the robot cleaner to start cleaning after 1 hour, or at the same time every day.
Þ
 Select the time (1 hour or
every day) by pressing the
RESERVATION button on the
remote control.
1 2 3
3
or
5
4
󱈺or
Þ
 Move the robot
cleaner by
pressing direction
keys on the
remote control.

3

Mop Cleaning
ǘ In mop cleaning mode, the robot cleaner can completely remove ne dust on the oor.
Þ
 Turn the power switch o.
2
Þ
 Attach the mop plate.
3
7
Þ
 Supply water into the mop plate and
attach the mop to it.
1
5
or
Þ
 After cleaning, remove the mop plate from the robot cleaner and the mop from
the mop plate.
8
Ě
   Remove water in the mop plate and let cover open to dry the mop plate.
Ě
   Wash and dry the mop for the next use.
Ě
 You may use the included cleaning brush for cleaning the mop more thoroughly.
󱈺󱈺
6
󱈺or
Selecting the mop cleaning mode
You can select the mop cleaning mode by pressing the Mode (M)
button when it is cleaning in mop cleaning mode.

The mode will be changed as follows:
Auto
mode
󱈺
Wave
mode
󱈺
Tornado
mode
󱈺
Zigzag
mode
󱈺
Auto
mode

Auto mop cleaning mode
In auto mop cleaning mode, the robot cleaner runs the
mop cleaning in the following patterns, without performing
vacuum cleaning.
or
Zigzag modeTornado modeWave mode
󱈺󱈺
󱈺
Þ
 Turn the power
switch on.
4
Ě
     If you apply excessive force to the
mop plate when you install it on the
robot cleaner, the joint parts of the
mop plate may be damaged.
