Money Controls Ardac Configuration guide

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – September 2005
This document is the copyright of Money Controls Ltd and may not be reproduced in part or in total by any means,
electronic or otherwise, without the written permission of Money Controls Ltd. Money Controls Ltd does not accept
liability for any errors or omissions contained within this document. Money Controls Ltd shall not incur any
penalties arising out of the adherence to, interpretation of, or reliance on, this standard. Money Controls Ltd will
provide full support for this product when used as described within this document. Use in applications not covered
or outside the scope of this document may not be supported. Money Controls Ltd. reserves the right to amend,
improve or change the product referred to within this document or the document itself at any time.
Money Controls 2005. All rights reserved.

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 2 of 14
Contents
1. Introduction.................................................................................................................................................... 3
2. Getting Started............................................................................................................................................... 4
2.1 Using the cleaning card ........................................................................................................................... 5
2.2 Cleaning the sensors ............................................................................................................................... 6

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 3 of 15
1. Diary of Changes
Issue 2.0 .........................................................................................................................................................21st Sept 2005
 1st Official release

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 4 of 16
2. Introduction
The aim of these instructions are to aid the user in cleaning and general maintenance of the
Ardac note acceptors. These instructions are a general guide only, which apply to all variants of
the Ardac note acceptor range.
3. Getting Started
The equipment you need to get started is as follows:
 Ardac cleaning card (1 to a pack) = 49x313
 Cotton buds
 Lint free cleaning cloth
 70% or greater IsoPropyl Alcohol (IPA).
There are 2 methods of cleaning which are required.
 Using the cleaning card
 Cleaning the sensors (Opening the note acceptor and manually cleaning the
sensors)

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 5 of 7
3.1 Using the cleaning card
The cleaning card is something which should be used as part of a regular maintenance
routine. There is no specified time-scale for this maintenance but as a rough guide
 Maximum – Once a month
 Minimum – Once every 6 months.
Using the cleaning card is very simple.
 Remove power.
 Turn the head over so that you can see the DIP switches.
 Set Bank 2 Dipswitch 7 to ON.
 Power up the acceptor and wait until the stacker cycles ONCE.
 Insert the cleaning card in any direction and hold it in place in the note acceptor
for up to 5 seconds.
 Release the cleaning card and let it drive into the note acceptor. The cleaning
card will then reject back out to the user. A slight pull on the card will remove it
from the head.
 Power off.
 Remove the head and set BANK 2 DIPswitch 7 to OFF.
 Replace the head in the machine.
 Power up.
 Ensure the head cycles twice.
NB – The cleaning cards are saturated with alcohol, and will dry out very quickly. Therefore
Money Controls recommend that you use both sides of the card as quickly as possible (E.g.
on 4 note acceptors).

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 6 of 7
3.2 Cleaning the sensors
Cleaning of the sensors should be carried out as part of a regular maintenance routine.
There is no specified time-scale for this maintenance but as a rough guide
 Maximum – Once a month
 Minimum – Once every 6 months.
Cleaning the sensors requires the note acceptor head to be removed from the chassis. The
note acceptor does not need to be powered up at this stage.
There are 3 stages of cleaning the sensors.
Clean the sensors on the top plate (TOP TNT sensor and Grey scale) of the note
acceptor - using the lint free cleaning cloth and IPA.

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 7 of 8
Clean the sensors on the bottom plate (BOTTOM TNT sensor and Grey scale, the Left &
Right front sensor lenses and the Dual Density lense) of the note acceptor - using the lint
free cleaning cloth and IPA.
Clean the recessed sensors on both the top and bottom sensor plates (using a cotton bud
and IPA).
Following this basic cleaning procedure should maximise performance of the Ardac note
acceptor range.

Ardac Cleaning Instructions TSP133.doc Issue 2.0 – Sept 2005
Money Controls 2005. All rights reserved.
Page 8 of 8
This manual is intended only to assist the reader in the use of this product and
therefore Money Controls shall not be liable for any loss or damage whatsoever
arising form the use of any information or particulars in, or any incorrect use of the
product. Money Controls reserve the right to change product specifications on any
item without prior notice
