Car Alarm System MONGOOSE TT1.User’s Guide and Installation Manual.
Model: TT1
10 11
ENGLISH
Software Switch Function Default Key#1 Key#2
LED ON LED OFF
11 Passive ARM/DISARM Mode OFF ON OFF
12 Passive Arm with Lock OFF ON OFF
13 Auto Rearm ON ON OFF
14 Lock/Unlock With Ignition ON ON OFF
15 Siren Chirp ON/OFF ON ON OFF
23 Delayed Arming ON/OFF OFF ON OFF
24 Passive Arming Immobiliser OFF ON OFF
31 PIN Access 1÷9 Digit Code 1Press 1÷9 Press 1÷9
Press button 3 to entry the setting; press once more to exit. The LED to increase to reduce
will display current PIN Code with a respective number of flashes.
32 Erase OTHER transmitter Codes (Save code of Remote Being Used) Press button 3
33 Return Software Switches to Default Press button 3
34 Triggering the alarm if Passive Immobiliser remains armed OFF
after the alarm system disarming.
Press button 3 to entry the setting; press once more to exit
LED Indication:
15 s – LED single flashes
30 s – LED double flashes
60 s – LED threefold flashes
46 Move to Installer Switches Press Button 3
Press Button
required number of
times:
1 time – in 15 s
2 times – in 30 s
3 times – in 60 s
OFF
To switch this
function off press
button 2.
Software Switch Table
Installation Manual
General recommendations
Before you get down to installation, disconnect the ““ terminal of the car battery.
1. The main unit is to be installed inside the passenger compartment, away from sources of
moisture and heat.
2. The RF Base Station with antenna is to be mounted on the windscreen as high as possible
to reach maximal communication range between transceiver and vehicle.
3. The siren is installed in the engine compartment or in another location inaccessible for a
thief, with the megaphone down or sideward. The location must be away from heat sources and
protected from penetration of water. If the siren has a backup battery, access to the service
keyhole must be ensured.
4. The pin switches of the hood and trunk are mounted in locations protected from water and
inaccessible when the hood/trunk is closed.
5. The shock sensor is installed inside the passenger compartment on the car body’s metal
structures, as close to the car’s longitudinal axis as possible, and is fixed with screws or double
sided mounting pad.
6. All highpower circuits should be fused for respective currents.
Technical Data
Voltage 9…15V
Current Consumption 20 mA
RF Frequency 433,92 MHz
Working Temperature 40…+850C
Maximal Allowable Current via the Relay Contacts:
Immobiliser Relay 30A
Indicators Relay 10A
Central Door Lock Relays 15A
Transmission Range 30m
Wiring Description
1 Siren Output Brown
2 Pager Output White
3 Arm Output Brown/White
4 Negative Trunk Trigger Input Grey
Input 1
The mode operation of the Arm
Output you select with Installer’s
function 23.
5 Trunk Release Output “” 300 mA Blue/Black
6 Ignition Input Orange
7 Negative Door Trigger Input Green
8 Negative Programmable Output Brown/Black
One of two options can be
selected for this input with the
Installer Function 26.
9 Ground “” Black
10 Main Unit Power Supply Green/Brown
11 Lock Normally Closed Contact Grey/Yellow
12 Lock Common Contact Grey/Red
13 Lock Normally Opened Contact Red/Yellow
14 Unlock Normally Closed Contact Blue/Yellow
15 Unlock Common Contact Blue/Red
16 Unlock Normally Opened Contact Red/Black
17 Positive Programmable Input Yellow
The mode of the input operation is
set by the Installer function 25.
18 Indicators Output 1 Black/Green
19 Indicators Polarity Red
20 Indicators Output 2 Black/White
LED Output
Shock Senor and Optional Sensor
Inputs
Power Immobiliser Relay Two Side Exited
Black Wires
N Wire Destination Wire Color Note
+ 2 A
Connect “+” wire of the pager.
“”300 mA when Armed.
To control an extra normally closed blocking relay.
1. Trunk trigger input ()
(While remote trunk opening in armed stage the input
will be overridden until 10 seconds of trunk is closed.)
2. Central Door lock control input
(Connect to the masteractuator output, which
is grounded in “closed” position and stays free in “open” position.
Connect to the coil of the trunk release relay.
Connect the Ignition line, where +12V appears at switching the ignition on and stays
while cranking.
The input has the “Dome Light Cars” selectable option. (Installer function 22).
1. Latch output
2. NO blocking relay output
Connect to the car body.
Connect to +12V contact of the car battery via 5A fuse.
Builtin Relay
See Central Door Lock Connection Diagrams
Builtin Relay
1. Positive Door Trigger Input.
2. Remote starter output.
Builtin Relay Contact.
Connect to the right side indicators feed wire.
Connect to +12V contact of the car battery via 15A fuse.
(In case of negative polarity of the Indicator control wire connect to the car body
via 15A fuse).
Builtin Relay Contact.
Connect to the left side indicators feed wire.
2pin White Connectore
Two 4pin White Connectors
Builtin normally closed relay.
