Monoprice Stage Right 612749 User manual

2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
This device uses a grounded power cord and requires a ground connection for safe
operation. Ensure that the power source has a proper ground connection. Do not
modify the plug or use a "cheater" plug to bypass the ground connection.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
Do not look directly into the light source.
Keep the original packaging material for use when transporting the device.
If the device will not be used for any lengthy period of time, it should be unplugged
from the wall.
When installing this device, ensure that the mount is sufficiently robust to support
the weight of the unit and to prevent unwanted movement.
INTRODUCTION
This light features nine 10-watt RGBW LEDs and has several built-in programs for dimming
and strobe effects, including a Strobe Follow mode, which allows multiple lights to strobe
in sequence, rather than all at the same time. It also supports standard DMX-512 control
signals for use as part of a larger light production.

3
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at [email protected]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Flat PAR stage light
1x AC power cord (NEMA 5-15P to IEC 60320 C13)
1x User's manual
CONTROLS AND MENU DISPLAY
The 4-digit LED display indicates the mode and the value for the selected function or
mode.
Press the MENU button to cycle
through the various modes and
functions.
Press the UP button to increase
the value of the selected function
or mode. Press and hold the
button to rapidly increase the
displayed value. The list will cycle
back to the beginning after the maximum value is reached.

4
Press the DOWN button to decrease the value of the selected function or mode.
Press and hold the button to rapidly decrease the displayed value. The list will cycle
back to the end after the minimum value is reached.
Once the desired value is displayed, press the ENTER button to set that value for the
displayed function or mode and allow for selection of another function or mode.
If you want to discard any changes made to the value of the selected function or
mode, simply press the MENU button to cycle to the next function or mode in the
list.
MENU MODES
Menu Display
Value Range
Function
d.001
001 ~ 512
DMX channel selection
hoSt or SLAu
hoSt or SLAu
Host (Master) or Slave mode
Eo.01
01 ~ 32
The total number of follow mode devices*
E-.01
01 ~ 32
Follow mode ID**
EE.00
00 ~ 08
Strobe follow mode color selection
09 ~ 21
Strobe follow mode effect selection
22
Recycle effect
t.000
000 ~ 255
Strobe follow mode speed (slow to fast)
A.000
000 ~ 255
Four color jumping change (slow to fast)
C.000
000 ~ 255
Full color jumping change (slow to fast)
J.000
000 ~ 255
Full color gradient mode (slow to fast)
L.000
000 ~ 255
Variable pulse mode (slow to fast)
n.000
000 ~ 255
Jumping change, gradient, and variable pulse
modes combined (slow to fast)
P.000
000 ~ 255
Gradient fast strobe mode (color change speed)

5
1S.00
00 ~ 20
Sound activated strobe mode (sensitivity)
2S.00
00 ~ 20
Sound activated jumping change mode
(sensitivity)
r.000
000 ~ 255
Red dimming (0 ~ 100%)
G.000
000 ~ 255
Green dimming (0 ~ 100%)
b.000
000 ~ 255
Blue dimming (0 ~ 100%)
u.000
000 ~ 255
White dimming (0 ~ 100%)
F.000
000 ~ 255
Strobe mode (slow to fast)
*Set this value to the total number of devices in Strobe Follow mode. Each device must be
set to the same value.
**This value represents the position of the current device within the Strobe Follow mode
sequence. Each device must be set to a unique value. The values set must be equal to or
less than the total number of Strobe Follow mode devices set using the Eo parameter.
Note that this menu selection is only available when the Eo parameter is set to a value
other than 1.
STROBE FOLLOW MODE EXAMPLE
As an example of setting the Eo and E- values, let's assume that you have four lights that
you want to strobe in sequence. Set the lights to use the following Eo and E- values:
Light #
Eo Value
E- Value
1
Eo.04
E-.01
2
Eo.04
E-.02
3
Eo.04
E-.03
4
Eo.04
E-.04

6
DMX CONTROL
Channel
DMX Values
Control Functions
1
000 ~ 255
General dimming (0 ~ 100%)
2
000 ~ 255
Red dimming (0 ~ 100%)
3
000 ~ 255
Green dimming (0 ~ 100%)
4
000 ~ 255
Blue dimming (0 ~ 100%)
5
000 ~ 255
White dimming (0 ~ 100%)
6
000
No strobe
001 ~ 255
Strobe speed (slow to fast)
7
000
Macro function off
001 ~ 029
Four color jumping change mode
030 ~ 059
Full color jumping change mode
060 ~ 089
Full color gradient mode
090 ~ 119
Variable pulse mode
120 ~ 149
Jumping change, gradient, and variable pulse modes
combined
150 ~ 179
Gradient fast strobe mode (color change speed)
180 ~ 199
Save disabled
200 ~ 229
Strobe follow mode color selection (1 ~ 9)
230 ~ 243
Strobe follow mode effect selection (1 ~ 13)
244 ~ 245
Recycle effect
246 ~ 250
Sound activated strobe mode (sensitivity)
251 ~ 255
Sound activated jumping change mode (sensitivity)
8
000 ~ 255
Macro function LED speed (slow to fast)

7
MASTER/SLAVE OPERATION
Multiple lights can be daisy chained together, with one serving as the master and the
others configured as slaves to perform whatever actions are performed by the master unit.
The master light must be set to Host mode and then can be in any mode except DMX
mode, while all the slaves must be set to Slave mode and then set to DMX mode, using the
address d.001.
Note: If the daisy chain is longer than 60 meters or if it contains 20 or more light fixtures, a
DMX signal amplifier should be used to ensure that all devices get valid instruction
signals.
Note: The last device in any DMX chain must be terminated using a DMX Terminator. You
can purchase a DMX terminator (PID 601600) from Monoprice or you can make a
DMX terminator using a standard XLR male plug (PID 601651) by soldering a 120 ohm
(1/4 watt) resistor between pins 2 and 3.
3-PIN XLR TO 5-PIN DMX CONVERSION
While most DMX compatible equipment uses 3-pin XLR connectors, some devices use the
official 5-pin DMX connector. To make a 3-pin to 5-pin converter simply make a cable with
a 3-pin XLR connector on one end and a 5-pin DMX connector on the other. Connect the
pins as follows:
3-pin XLR to 5-pin DMX Adapter
Signal
3-pin XLR
5-pin XLR
Ground/Shield
1
1
Data Complement (- signal)
2
2
Data True (+ signal)
3
3
Do Not Use
4
Do Not Use
5

8
TROUBLESHOOTING
Following are some common problems and common solutions.
Problem:
The light will not turn on.
Solutions:
Check to ensure the power cord is connected to a power outlet.
Check to ensure that the connected outlet has available power.
Problem:
The light will not execute DMX instructions.
Solutions:
Check to ensure that the light is connected to the controller via a DMX cable.
Check to ensure that the DMX chain is properly terminated.
Check to ensure that the DMX cable is good; swap out a known good cable to test.
Check to ensure the light is in DMX mode (001 ~ 512).
Check to ensure the DMX controller is operating properly.
If you experience other problems with this light and cannot solve them on your own,
please contact Monoprice Technical Support for assistance.

9
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com or
through email by sending a message to [email protected]. Check the website for
support times and links.
SPECIFICATIONS
Model
612749
Lamp Type
9x 10-watt RGBW 4-in-1 LEDs
Control Modes
Stand alone, sound activated, DMX512
DMX Channels
8
Input Voltage
90~ 240 VAC, 50/60 Hz
Maximum Power Consumption
90 watts
Dimensions
9.8" x 3.9" x 9.8" (250 x 100 x 250 mm)
Weight
2.6 lbs. (1.2 kg)
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must

10
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice’s authorization may result in the equipment
no longer complying with FCC requirements for Class A digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a commercial installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own
expense.
Notice for Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
EU Conformity with applicable directives
This equipment complies with the essential requirements listed below:
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
RoHS Directive 2011/65/EU
WEEE Directive 2011/65/EU
