Monport Note User manual
Product Profile
Smoke purification and filtration system is equipped with changeably single and double
station and a three-layer filter device of primary, medium, and main efficiency filters. The main
efficiency filter consists of activated carbon high-efficiency filtration and gas filtration. Mass
cushion-type primary efficiency filter can effectively filter larger particles in the dust, prolonging
the service life of the main efficiency filter.
The smoke purification and filtration system can effectively absorb and filter the smoke or
dust produced in the process like welding, laser marking, engraving. Simultaneously, it exerts the
same effect on 99.97% of harmful gases and dust (such as hydrocarbons, hydrogen compounds,
etc.) to prevent the environment from being polluted.
Monport Air Purifier
User manual
Product Features
Product Parameter Packing units:
Instructions:
1.Good-looking appearance, lightweight model, convenient to install, and excel at purifying air.
2.Excellent design with triple filtration ensures that harmful substances in the smoke are completely
filtered out, which helps keep users safe. The primary, medium, and main efficiency filters can be
replaced separately, increasing the use time of the main efficiency filter. (Specific standards of the
filter system change with the model design.)
3.The filter system is crafted delicately and strictly. A metal frame is adopted to protect the filter
element and prevent the filter system from being damaged effectively while moving the machine.
4.The built-in circulating air filtration avoids cool or warm air from being discharged to the outdoors,
in a genuine sense, complying with environmental standards.
5.High-power brushless DC generator, designed with eddy current wind wheel, large suction
air quantity, and long service life.
6.Changeably single and double station, large air amount and flexible in locating.
7.The handle on one side can withstand a gravity of 30kg, with features of anti-static and anti-scald.
All designs aim to ensure the safety of the machine and the users.
1.Open the cover of the main engine, correctly install the primary, medium, and main efficiency filters;
then close the top cover and buckle it.
2.Install the aluminum suction pipe and adjust it in the right direction.
3.Connect it to the power cord and check whether the power plug stays stable and firm.
4.Turn on the power switch on the case to check whether the power light is red.
If the red light is displayed, it means that the power is on and the smoke purification system can start
working; if the red light remains off, please check whether the power cord and the power interface
are properly connected.
Voltage
Power
Air flow
Speed
Filtration efficiency
Static pressure
Noise
Size
Weight
Product name
Main engine
Power cord
Instruction manual
Aluminum foil suction pipe
Note
110V
120W
5.5m3/min
2600r/min
99.97%
1000Pa
1
1
1
1
< 60dB
255x460x420mm
15.6KG
Maintenance and
Replacement of the Filters:
Contact Info
1.Regularly clean the aluminum foil suction pipe.
Thank you for choosing this product to upgrade your machine!Welcome to join in the official Facebook
group or visit our Monport website at www.monportlaser.com for more information! If you need any
after-sale support, please do not hesitate to contact customer service with your order number at help
support@monportlaser.com or visit https://app.helpdesk.com/tickets.Our teams will respond within
12 hours to make things right. Thank you and we hope you will choose us again for all your
laser needs.
2.Primary efficiency filter can be replaced as often as needed.
3.When the adsorbing ability decreases, please check if the aluminum foil suction pipe needs to be
cleaned. If the adsorption is running low after cleaning, please replace the main filter.
Primary efficiency filter
Activated carbon medium efficiency filter
Activated carbon high-efficiency filter
Service life: 5-30 days
Service life: 1 - 2 months
Service life: 1 - 3 months
