H38DF Gas Fireplace
Part No. XG0131
Introduction
ThankYouforchoosingaMontigoGasFireplace.
About this Fireplace:
TheH38DFisa26,000BTUfireplacewithapan-styleburnerand
glowingembers.TheNaturalGasversioncanbeconvertedtobotha
TopVentorRearVentapplication,anditisavailableintwomodels.
H38DF;MillivoltPilot,LPModels TopVentOnly,
NGModelsToporRearVentConvertable
H38DF-I;IntermittentPilot(HSI),LPModelsTopVentOnly,
NGModelsToporRearVentConvertible
TheH38DFisratedforNaturalGasat26,000BTU/H(7.62Kilowatts)
InputorPropaneat21,000BTU/H(6.16 Kilowatts)Input.
How to use this manual:
Thismanualcoversinstallation,operationandmaintenance.Lighting,
operationandcareofthisfireplacecanbeeasilyperformedbythe
homeowner.However,allinstallationandserviceworkshouldbe
performedbyaqualifiedorlicensedinstaller,plumber,orgasfitterwho
isqualifiedorlicensedbythestate,province,region,orgoverning
bodyinwhichtheapplianceisbeinginstalled.
Thismanualcoversallmodelsandunlessotherwisespecified,the
designationH38DFreferstoallmodels.Sectionswhicharespecifictoa
particularmodelaremarkedwitha symbol,plustheappropriate
modelnumber.
Warranty and Installation Information:
TheMontigowarrantywillbevoidedby,andMontigodisclaimsany
responsibilityfor,thefollowingactions:
Modificationofthefireplaceand/orcomponentsincludingDirect-Vent
assemblyorglassdoors.
Useofanycomponentpartnotmanufacturedorapprovedby
MontigoincombinationwiththisMontigofireplacesystem.
Installationotherthanasinstructedinthismanual.
ConsultyourlocalGasInspectionBranchoninstallationrequirementsfor
factory-builtgasfireplaces.Installation&repairsshouldbedonebya
qualifiedcontractor.
InstallationsinCanadamustconformtothecurrentCAN/CGAB-
149.1and.2GasInstallationCodeandlocalregulations.Iftheoptional
air-circulatingfankitisinstalled,itmustbeelectricallygroundedin
accordancewithCSAC22.1CanadianElectricalCodePart1and/or
LocalCodes.
InstallationsintheUSAmustconformtolocalcodes,orinthe
absenceoflocalcodestotheNationalFuelGasCode,ANSIZ223.1-
1988.Iftheoptionalair-circulatingfanisinstalled,itmustbegroundedin
accordancewithlocalcodesor,intheabsenceoflocalcodes,withthe
NationalElectricalCode,ANSI/NFPA70-1987.
Table Of Contents
Introduction ............................................................................2
Installation
InstallingandFramingtheFireplace ...............................3
InstallingtheGasline.......................................................4
DirectVentInstallation ....................................................4
GeneralVentingRequirements ..........................4
Terminations......................................................5
ConvertingtoToporRearVentmodel...............6
VentingforTopVentmodels ..............................7
VentingforRearVentmodels...........................10
Constructionaroundthefireplace
Facing .............................................................12
MantelsandSurrounds....................................12
Wiring .......................................................................12
InstallingOptionalFans.................................................13
RemovingandInstallingtheDoor.................................13
InstallingtheLogset ......................................................14
InstallingtheHorizontalTrim .........................................15
Operation ........................................................................16 - 18
Maintenance ...................................................................18 - 19
Warranty ................................................................................20
Appendix
A.TerminationLocations ..............................................21
CAUTIONS
Duetoitshighoperatingtemperatures,theapplianceshould
belocatedoutoftraffic&awayfromfurnitureanddraperies.
Children and adults should be alerted to the hazards of
the high surface temperature, which could cause burns
or clothing ignition.
Young children should be carefully supervised when
they are in the same room as the appliance.
Clothing or other flammable materials should not be
placed on or near the appliance.
Important: Natural Gas equipped models may be
installed using Top or Rear Vent applications.
However, all Propane equipped models must be
installed in a top vent application only.

Page 3
H38DF Gas Fireplace
Part No. XG0131
Installing The Fireplace Shell
Thefireplacemaybeinstalledinanylocationthatmaintainsproper
clearancestoairconditioningducts,electricalwiringandplumbing.
Safety,aswellasefficiencyofoperation,mustbeconsideredwhen
selectingthefireplacelocation.Trytoselectalocationthatdoesnot
interferewithroomtraffic,hasadequateventilation,andoffersan
accessiblepathwayforDirectVentinstallation.Refertopage4-Vent
Installationformoreinformation.
Thefireplacedimensionsareshownbelow:
Installation
Wheninstallingashelfoverthetopof thefireplace,thefollowing
guidelinesmustbeadheredto: ForRearVentapplicationstheminimum
clearancefromthetopofthefireplacetoashelfis9".ForTopVent
applications,theminimumclearanceis171/2".(Minimum
2"clearancemuststillbemaintainedaroundtheventpipes.)
Figure 4. Framing for shelves over the fireplace.
TopVent
RearVent (NG Models Only)
Figure 3. Minimum Corner framing dimensions, using a 45° elbow.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
fireplace, framing
depth may be
reduced to 19 3/4"
Framing
WARNING:
When this appliance is installed directly on carpeting, tile
or any combustible material other than wood flooring, it
must be installed on a metal or wood panel extending the
full width and depth of the appliance.
Top View
Front View SideView
Clearances
Theseclearancesapplytoalldimensionsexcepttheframedopening,
wheretheclearancetocombustiblesis0".TheH38DFclearancesto
combustiblematerialsare:
Top-RearVent* 9"
Top-Top Vent 17 1/2"
Back 1"
Sides 1"
Floor 0"
Mantle** 4"
* Clearancefromthetopofthefireplacetoacombustible
ceilingwithinthefireplaceenclosure.
** Refertopage11.
Unprotectedcombustiblewallswhichareperpendiculartothefireplace
opening,mustnotprojectbeyondtheshadedareashowninFigure23.
Forprotectionagainstfreezingtemperatures,itisrecommendedthat
outerwallsofthechasebeinsulatedwithavapourbarrier.Thiswill
reducethepossibilityofacold-airconvectioncurrentonthefireplace.
Figure 1. Fireplace dimensions. All LP Models are Top Vent Only.
IMPORTANT: See page 5
forinstallationinstructionsabout
theNailingFlangeExtension
NailingFlangeExtention

Page 4
H38DF Gas Fireplace
Part No. XG0131
Vent Installation
Thissectioncoverstheinstallationofdirectventingandterminations.
Installation Requirements
H38DF fireplaces are certified for use with Montigo Standard
Series (5" / 8") venting components.
Minimum 2" clearance to combustibles required for vent pipes
Use only certified Montigo vent components. (Use of other parts will
void the Montigo warranty, and may impede the operation of the
fireplace.)
All joints must be secured with a minimum of two screws per joint
Vent terminations must not be recessed in walls or siding
Horizontal runs must be supported by a minimum of two supports
per horizontal run. A minimum of one screw on each side of
support is also required
Flex vent sections may be stretched up to 50% of their total length
(eg. a 24" section may be stretched to 36")
Maximum horizontal run for a flex section with no vertical rise is 3 feet.
Flex vent sections over 3 feet must fall within the limits set by the
venting graph and must have a minimum vertical rise of 3 inches
per foot of flex.
Solid vent sections may be cut less than half way from the female end
Venting components can be used in any combination of solid/rigid
pipe or flex pipe and in any orientation (Male connectors can face
in any direction)
Vent Terminations
Selecting A Termination Location
Choosingyourventterminationlocationwillhelptodeterminewhether
youneedtouseatopventorrearventfireplace.Figure6a,below,
showstypicalfireplacelocationsandtheventingoptionstheyprovide.
Foramoredetaileddiagramofallowedterminationlocations,see
AppendixA.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
ThegaslinemustbeinstalledbeforefinishingtheH38DFFireplace.
NaturalGasrequiresaminimum inletgassupply pressureof5.5"
W.C.&amanifoldpressureof3.5"W.C.PropaneGasrequiresa
minimuminletgassupplypressureof11"W.C.&amanifoldpressureof
10"W.C.Provisionmustalsobemadefora1/8"N.P.T.pluggedtapping
andbeaccessiblefortestgaugeconnectionimmediatelyupstreamofthe
gassupplycontrolstotheappliance.Thefireplacegasconnectionand
themainoperatinggasvalveislocatedunderneaththepanbaseatthe
bottomoftheunit,andneedonlybeattachedtothegasline withan
approvedfitting,asrequired bythe applicableinstallation codes.
To access the fireplace gas connection the main burner must be
removed as shown below in figure 5b.
•Onlyusegasshut-offvalvesapprovedforusebythestate,province,
region,orgoverningbody,inwhichtheapplianceisbeinginstalled,or
asrequiredbytheapplicableinstallationcodes.
•Flexiblegasconnectorsmustnotexceed3feetinlength,unlessitis
allowable withinapplicableinstallationcodes.
Installation
Figure 6a. Fireplace locations and vent terminations.
Note: After gas line is connected, each appliance connection,
valve and valve train must be checked while under
normal operating pressure with either a liquid solution, or
leakdetection device,to locate anysource of leak.Tighten
any areas where bubbling appears or leak is detected until
bubbling stops completely or leak is no longer detected.
DO NOT use a flame of any kind to test for leaks.
Figure 5a. Gas line access.
Theapplianceanditsindividualshutoffvalvemustbedisconnectedfrom
thegassupplypipingsystemduringanypressuretestingofthatsystem
attestpressuresinexcessof1/2psig(3.5kPa).
Theappliancemustbeisolatedfromthegassupplypipingsystemby
closingitsindividualmanualshutoffvalveduringanypressuretestingof
thegassupplypipingsystemattestpressuresequaltoorlessthan1/2
psig(3.5kPa). Vent terminations can be very hot. If the termination
is less than 7 feet above a public walkway, it should
befittedwithacertifiedMontigoHeatGuard.(Partno.
PTKOG)
Do not obstruct, or attempt to conceal, the vent
termination. These actions will affect the operation
of the fireplace, and may be hazardous.
Inheavysnowareas,takeextracaretopreventsnow
buildup from obstructing the vent termination.
Figure 5b. Removing the burner tray.

Page 5
H38DF Gas Fireplace
Part No. XG0131
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frametheterminationopeningto12"x12".
2. Fastentheterminationtothestudsusingaminimumof4screws.
11
11
1. Frametheterminationopeningto11"x11".
2. Fastentheterminationtothestudsusingaminimumof4screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frametheterminationopeningto12"x12".
2. FastentheMOSRframetotheinteriorsideofthestudsusinga
minimumof4screws.
3. InserttheterminationintotheMOSRframeasshownhere,and
attachbyscrewingthroughthefourpilotholesinthetermination.
MSR
PTO-3
PTO-3F
PTO-3
PTKOG
1. Ensurethatthetwolongmountingbracketsarefacingthebottomof
thetermination.(Seeinset).Thiswillprovidemoreheatprotectionat
thetopofthetermination,wheretemperaturesarehighest.
2. Attachtothefaceplateoftheterminationusingfoursheetmetalscrews.
Installing Heat Guards over Terminations
Installation
Installing The Standoffs And
Nailing Flange Extention
To avoid elevated mantel temperatures, all H38DF gas fireplaces
are required to have the supplied standoffs and nailing flange
extention installed.
Thefireplaceissuppliedwithtwostandoffs.Bendandinstallthese
standoffsontopofthefireplaceensuringthattheheightofthestandoff
maintainsa6"clearance.
Figure 6c. Installing the Nailing Flange Extension.
Installing The Remote Switch
TheH38DF'sgasvalve,locatedbehindthelowertrim,maybecon-
nectedtoawallswitch.Thevalvegeneratesitsownpowerona
millivoltcircuit. Use onlylow voltage wire,and DO NOTconnect
anyexternalpowertoit.
RefertoFigure30forwiringrequirements.
Note: Theswitchlocationmustnotexceed30'fromthefireplace.
Figure 6b. Installing the standoff's.
Oncethefireplaceisplacedintotheframedopening,thesuppliednailing
extentionmustplacedalongthetopedgeofthefireplace,andnailedin
placetotheframing,asillustratedbelow.

Page 6
H38DF Gas Fireplace
Part No. XG0131
Converting to Top Vent/ Rear Vent
H38DF Top Vent
UsethefollowinginstructionstoconvertanH38DFforTopVentuse:
1.Installthe5"innerfluecapontherearflueoutletandsecurethe
capinplacewithfivescrews,asshowninfigure7a.
2. Installthe8"outerfluecapontherearflueoutlet,andsecureit
withfivescrews,asshowninfigure7a.
3.Installthefluegasketmaterialandfluecoverplateontherear
ventoutlet.Fastentheplate withfourscrews,asillustratedbelow.
4.Installthe5" innerfluecollarandthe8"outerfluecollarinplace
onthetopventoutlet using5screws,asillustratedbelow.
Figure 7a. Flue cap installation for Top Vented fireplace.
Figure 7b. Flue collar installation for Top Vented fireplace.
Figure 8a. Flue cap installation for Rear Vented fireplace.
Figure 8b. Flue collar installation for Rear Vented fireplace.
Installation
H38DF Rear Vent
UsethefollowinginstructionstoconvertanH38DFforTopVentuse:
1.Installthe5"innerfluecaponthetopflueoutletandsecurethe
capinplacewithfivescrews,asshowninfigure8a.
2. Installthe8"outerfluecaponthetopflueoutlet,andsecureit
withfivescrews,asshowninfigure8a.
3.Installthefluegasketmaterialandfluecoverplateonthetopvent
outlet.Fastentheplate withfourscrews,asillustratedinfigure8b.
4.Installthe5" innerfluecollarandthe8"outerfluecollarinplace
ontherearventoutlet using5screws,asillustratedbelow.
Important: Natural Gas equipped models may be
installed using Top or Rear Vent applications.
However, all Propane equipped models must be
installed in a top vent application only.

Page 7
H38DF Gas Fireplace
Part No. XG0131
Installation
Top Vent Venting Runs
FortheH38DFTopVent,therearetwotypesofinstallations:A)
Through-The-WallInstallationsandB)Vertical(Through-The-Roof)
Installations.
A) Through-The-Wall Installations
Beforeyouinstallanyventing,youmustdeterminewhethertheventing
runwillbeacceptable.Unacceptableventingcanaffectthefireplace's
combustion.
The Venting Graph
Measuretheverticalheightfromthefireplacehearthtothecentreofthe
terminationandthehorizontalrunfromthefromthefireplacefluecollarto
thewallflangeofthetermination.PlotontheVentingGraph(Fig.9)with
an'X'.
Ifthe'X'fallsonorabovethetopboundaryoftheshadedarea,the
installationisacceptable.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 84" and the horizontal
run to the wall flange of the vent termination is 36", this would be
anacceptableinstallation.
Example B: (Acceptable Installation)
If the vertical dimension from the hearth is 90" and the horizontal
run to the wall flange of the vent termination is 126", this would be
anacceptableinstallation.
Example C: (Unacceptable Installation)
If the vertical dimension from the floor of the fireplace is 74" and
the horizontal run to the wall flange of the vent termination is 108",
this would NOT be an acceptable installation.
Figure 9. Venting Graph
Available Top Vent Components
ThefollowingventingcomponentsareavailablefortheH38DFTop
Vent:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
MOSR(stucco can)
BSR (brick can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Rigid sections PEXT-1 (12" m/f section)
PEXT-2 (24" m/f section)
PEXT-3 (36" m/f section)
PEXT-4 (48" m/f section)
PEXT-6 (72" m/f section)
E - Elbows PEL-90MM (m/m 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/m 90° elbow)
NOTES: Alldimensionlengthsforverticalorhorizontalrunsare
measuredfromcenteroftheventpipe.
Ventingrunsmustfallwithinthelimitssetbytheventing
graph (see Figure 8).
Example 1:
ForourshortestventingconfigurationusecomponentsAandE(see
Figure 9a).
Figure 10. Typical Top Vent installation. If the 90° elbow is installed
directly on the fireplace, the height to the center of the
termination is 45 3/4".
PEL-90F/F Elbow

Page 8
H38DF Gas Fireplace
Part No. XG0131
B. Vertical (Through-The-Roof) Installations
5/8" with option for 4/7"
Vertical rise >12' can be reduced, see next page.
VerticalTerminationsmustbeinstalled:
•minimum 2' (two feet) above the highest point where
vent passes through the roof.
•minimum 6' (six feet) from a mechanical air inlet
•minimum 18" (1 1/2 feet) from a parapet wall.
Maximumventheightis35feetabovefireplace.Note:Flame
characteristicswillchangeifthemaximumventheightisused.
Minimumclearances2"fromventtoallcombustiblematerialsmust
bemaintained.
A maximum of two offsets (each offset has two 90° bends) may be
madeandshallnotexceedtotallengthof25%oftheverticalventheight,
when measured center to center of piping.
Example: Typicalventinstallation.
20'verticalvent
2 - 2' offsets required
25% of 20' = 5' max. offset allowed
Thisventingconfigurationmeets requirements.
Installation
Horizontal Venting
Figure 11. Typical Top Vent installation. The solid sections can be used in
various combinations to obtain the desired vent run. The vent
run must fall within the limits set by the venting graph.
Figure 12. Extended Installation using a combination of solid and flex
venting. Use the vent graph to determine your allowable
run, then select appropriate components.
Figure 13. Retracted Installation using a combination of solid and flex
venting. Use the vent graph to determine your allowable
run, then select appropriate components.
Figure 14. Horizontal flex installation with no vertical rise.
90° Elbow
PEXT Section
Termination
Example2:
Rigidsectionsandanelbowusedinconjunctionwith3ft.flexsection
(PFL-3)will,whenextendedinafivefootchase,allowforamaximum
horizontalrunoftwelveandone-halffeetfromthecentreofthefireplace
tooutsidewallandaminimumof7'6"whenretractedinoppositedirection
(see Figure 10 and 11).
"C"flexsectionsand"D"rigidsectionsmaybeusedinconjunctionwith
oneanothertoobtaindifferentpossiblehorizontallengthinstallations.
NOTE:Flexsectionwithnoverticalrisemustnotexceedmaximum
horizontallengthof3feet(seeFigure14).Flexrunsover3feetmustfall
withinthelimitssetbytheventinggraph,andmusthaveaminimum
verticalriseof3"perfootofflex.

Page 9
H38DF Gas Fireplace
Part No. XG0131
Installation
Figure 15. Straight, vertical venting showing required MXT-10
adaptor (supplied with the PVTK-1 termination).
Figure 17. Vertical venting with 2 offsets (1 offset= two 90° bends).
Figure 16. Vertical venting with 1 offset (1 offset= two 90° bends).
Part Size 5"/8" Venting 4"/7" Venting
A - Termination n/a PVTK-1 MVTK-1
B - Flex sections 12" length PFL-1 MFL-1
24" length PFL-2 MFL-2
36" length PFL-3 MFL-3
48" length PFL-4 MFL-4
C - Solid sections 12" length PEXT-1 MEXT-1
24" length PEXT-2 MEXT-2
36" length PEXT-3 MEXT-3
48" length PEXT-4 MEXT-4
D - Support Ring
& Plate PSPXT-8 MSPXT-7
E - Firestop PS-8 FS-7
F - Roof Flashing (1/12-7/12 pt.) PRF-7 MRF-7
(7/12-12/12 pt.) PRF-12 MRF-12
G - Adaptor/ (5"/8" to 4"/7") PVA5487
Vent Reducer
Figure 18. Reducing Vertical Vent from 5/8" to 4/7".
Reduced Vertical Installation
Itispossibletoreduceverticalventrunsfrom5"/8"ventingto4"/7"
venting.Reducedverticalventing mayonlybeusedwhenthe
installationexceeds12feetandterminatesthroughtheroof,andif
theverticalventreducerisusedwiththefollowingventingconfigu-
ration.

Page 10
H38DF Gas Fireplace
Part No. XG0131
Installation
Figure 20a. Extended installation. (NG Models Only)
Figure 20b. Corner installation. (NG Models Only)
Figure 20c. Flex installation. (NG Models Only)
Rear Vent Venting Runs
TheH38DFRearVenthasthreepossibleinstallationswhichdonot
requireverticallift,alloftheseinstallationsrequirethatyouinstallthe
RHS101 heat sheild. Important: Rear Vent applications are only
for Natural Gas equipped models. All Propane equipped models
must be installed in a top vent application only.
1. Straight Installation.
Theheightfromthehearthtothecenteroftheterminationis32
½".Forstraightinstallationsusea20"extensionpipe(PXT-20)with
female/femaleconnections.Forshorterinstallations,cutthePXT-20
tothedesiredlength.Refertofigure20a.
Ensure that the RHS101 heat sheild is installed before
attaching the pipe to the termination.
Note: ForRearVentmodels,maximumhorizontalrunwithno
verticalliftmustneverexceed20".
PXT-20
2. 45° Corner Installation.
AttachanPEL-45(45°elbow)directlyontothefluecollar.CutthePXT-
20tosuit,andattachittothePEL-45.Slidethefireplaceintoposition
andattachtothetermination.EnsurethattheRHS101heatsheild
is installed before attaching the pipe to the termination.
3. Corner Installation — 45° or less.
UseanPTO-3 terminationandan PFL-1orPFL-2 (12"or24"
compressedlength)andaframe,ifappropriate.Flexmaybeturned
toobtaindesireddegreeofanglerequiredbutmustnotexceed45°.
Ensure that the RHS101 heat sheild is installed before
attaching the pipe to the termination.
PXT-20
PEL-45
Figure 19. Heat Shield. Install by sliding over the vent pipe where it
passesthrough combustibleconstruction.
Heat Shield
Theheat shield (RHS101)mustbe usedonall installationsstraight
throughthewall,atthepointwheretheventpipeconnectstothe
termination.Withtheheatshield,properventclearancescanbe
maintained. The heat shield is not included with the fireplace.
Toinstalltheheatshield,slideonesectionovertheventpipeonthe
insideofthewallopening,withthecircularportioninsidethewallcavity.
Screwtheshieldinplaceoverthewallopening.Installthesecond
sectionontheoutsideofthewallopeningslidingthecircularportioninto
thewallopening.RefertoFigure19.
Important: Natural Gas equipped models may be
installed using Top or Rear Vent applications.
However, all Propane equipped models must be
installed in a top vent application only.
Note: Through the wall venting kits are also available for
both the Straight and the Corner Installation. The Kit includes
aheatsheild,anPFL-18(f/f)flexiblepipe,andaterminationwithor
withoutamountingframe.

Page 11
H38DF Gas Fireplace
Part No. XG0131
Installation
B. Multi-Elbow Installations
Formorediffiicultinstallationsituations,theH38DFRearVentmaybe
installedwithtwo—90°elbowsandupto15'ofhorizontalrun.Ifusing
thisinstallationoption,youmustadheretothefollowingguidelines:
Important: Rear Vent applications are only for Natural Gas
equipped models. All Propane equipped models must be
installed in a top vent application only.
thefirst90°elbowmustbeplaceddirectlyonthefluecollar
youmusthaveaminimumverticalliftof50"(measuredfromthe
hearth)
yourventrunmustfallwithinthelimitssetbyFigure21
Beforeyouinstallanyventing,youmustdeterminewhethertheventing
runwillbeacceptable.Unacceptableventingcanaffectthefireplace's
combustion.
The Venting Graph
Measuretheverticalheightfromthefireplacehearthtothecentreofthe
terminationandthehorizontalrunfromthefromthefireplacefluecollarto
thewallflangeofthetermination.PlotontheVentingGraph(Fig.21)
withan'X'.
Ifthe'X'fallsonorabovethetopboundaryoftheshadedarea,the
installationisacceptable.
Example A: (Acceptable Installation)
Iftheverticaldimensionfromthehearthis84"andthehorizontal
runtothewallflangeoftheventterminationis36",thiswouldbean
acceptableinstallation.
Example B: (Acceptable Installation)
Iftheverticaldimensionfromthehearthis108"andthehorizontal
runtothewallflangeoftheventterminationis120",thiswouldbe
anacceptableinstallation.
Example C: (Unacceptable Installation)
Iftheverticaldimensionfromthefloorofthefireplaceis72"andthe
horizontalruntothewallflangeoftheventterminationis84",this
would NOT be an acceptable installation.
Figure 21. H38DF Multi-Elbow Venting Graph. (NG Models Only)
Figure 22. Multi-elbow installation. (NG Models Only)
Distance 'H' must be a minumum of 50". The vent run
must comply with figure 18a.
NOTES: Alldimensionlengthsforverticalorhorizontalrunsare
measuredfromcenteroftheventpipe.
Ventingrunsmustfallwithinthelimitssetbytheventing
graph (see Figure 21).
8"
H
L
18"
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Installation Of Rear Vent DV
ThefollowingventingcomponentsareavailableforanH38DFinaRear
Vent installation:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
BSR-4 (4" brick frame)
BSR-6 (6" brick frame)
MOSR(stucco can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Solid sections PEXT-1 (12" section)
PXT-20 (20" section)
PEXT-2 (24" section)
PEXT-3 (36" section)
PEXT-4 (48" section)
E - 90 degree elbow PEL-90MM (m/m 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/m 90° elbow)
PEL-45FM (f/m 45° elbow)

Page 12
H38DF Gas Fireplace
Part No. XG0131
Finishing Around the Fireplace
Combustiblemantelsandmouldingsmaybesafelyinstalledoverthetop
andonthefrontofthefireplaceprovidedthattheydonotprojectbeyond
shadedareashowninFigure23.Sidewallclearancesare3".Combus-
tiblesurroundsmaybeinstalledwith3"clearancetothesideofthe
fireplaceasshowninFigure24.
Fireplace Facing
Whenselectingthefinishmaterialforyourfireplace,itisimportantto
rememberthefollowing:THELOWER GASCONTROLPANELMUST
NOT BE OBSTRUCTED IN ANY WAY - to do so restricts the air
supply for the control compartments and heat exchanger it also
prevents access for servicing controls.
Thefaceofthefireplacemaybepaintedtomatchtheroomdecor,
providedyouuseaheat-resistantpaint. Decorativefacingmustnot
extendpastthefireplaceopeningatall,becauseitwillinterferewiththe
accesstoretainersforremovalofglassdoor.
Installation
Figure 23. Combustible mantles and facings.
Mantels & Surrounds
NOTE:NationalCanadianGasAssociationmanteltestrequirementsare
forfirehazardpreventiontocombustiblematerials.
Newtechnology,tomeetconsumerandgovernmentdemandsforthe
wiseuseofenergy,haspromptedustomanufacturemanymodelsof
fireplaceswhicharehot,fuelandenergyefficient.
Pleasebeaware;temperaturesoverthemantelwillriseabovenormal
roomtemperatureandwallsabovefireplacemaybehottotouch.
Werecommendcarefulconsiderationbegiventotheeffectsofelevated
manteltemperatureswhichmaybeinexcessofproductdesign,for
example:candles,plasticorpictures. Thiscancausemelting,deforma-
tion,discolorationorprematurefailureofT.V.andradiocomponents.
Painting:
SpecialcareisrecommendedbytheMasterPaintersandDecorators
Association,whenpaintingthefireplacesurrounds,toselectandapplya
qualityAlkydsealerpriortotheapplyingoflatexpaints. Thisisto
preventleachingofwaterfromevaporationandcausingabrownish
stainingeffecttopaintovercoats.
Figure 24. Combustible surrounds.
Wiring
Gas Control and Pilot Wiring H38DF-I
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector Fuse
Limit
Switch Wall
Switch
Fan Plug
Receptacle
Junction Box
Junction Box Cover
White
Black
Green
40 VA
Transformer
115VAC
24VAC
Grnd Screw
Figure 25. Wiring for the H38DF-I with Honeywell gas control and pilot.

Page 13
H38DF Gas Fireplace
Part No. XG0131
Installation
Wiring for the optional Fan Kit
AllH38DFfireplacesmaybeequippedwithoptionalfankits forcirculat-
ingheatintothelivingspace.
InstallationsinCanadawhichemploythefansmustbeelectrically
groundedinaccordancewithCSAC22.1CanadianElectricalCodePart
1and/orLocalCodes.
InstallationsintheUSAwhichemploythefansmustbegroundedin
accordancewithlocalcodesor,intheabsenceoflocalcodes,withthe
NationalElectricalCode,ANSI/NFPA70-1987.
FormoreinformationseetheFanKit InstallationGuideincludedwith
thefankit.
NOTE: If any of the original wire supplied with the appliance is replaced, it
must be replaced with the same type, or its equivalent.
Figure 26b. Wiring schematic for optional fans.
Figure 26a. Wiring for optional fans.
Removing and Installing
the Door
Removing the door:
Thedoorisheldinplacebyaliponthetopofthemetalframeandtwo
bucklesatthebottom.Releasethebucklesandliftthedoorcarefullyup
andawayfromthefrontofthefireplace.Seefigures27aand27a.
Installing the door:
Hookthetopedgeofthedoorframeintoplace.Lowerandrestthedoor
frameinplaceandfastenthebuckles.Seefigures27aand27b.
Figure 27b. Removing and installing the glass door.
Figure 27a. Removing and installing the glass door.
115/1/60 Supply
G L1 L2
G
L2-WH
L1-BLK
pg
Quick Connect
lu to motor

Page 14
H38DF Gas Fireplace
Part No. XG0131
Installation
Cautions:
■If logs are not placed properly, excessive sooting
will result.
■The surface of the logs will crack due to the heat
from the flames. This is a normal occurance.
Installing the Log Set
Installing the Logs:
TheH38DFissuppliedwiththreeceramicfibrelogsandaceramicfibre
logsetbase.Unpackthelogsandhandlethemverycarefully.
1. Removetheglassdoor.
2. Thebaselogisfactory-installed,asshownbelowinfigure28b.
3. Placethebottomlogasshownbelowinfigure28c.
Figure 28a. H38DF's five piece logset.
Figure 28b. Base log placement.
Figure 28c. Bottom log placement.
Figure 28e. Top left log placement.
Base Log
Bottom Log
Top Left Log Top Right Log
Bottom Log
Top Right Log
Base Log
Top Left Log
Figure 28f. Top right log placement.
4. Arrange the ember chips on top of the burner tray. Care should
be taken when placing the ember chips, as blocked burner ports
may cause an incorrect flame pattern, carbon deposits and
delayed ignition. Also, the chips must never be placed in a way
that obstructs any of the air inlet ports, located at the rear of the
burner, as shown in figure 28d.
Air Inlet Ports
Ember Chips
5. Place the top left log as shownin figure 28e.
6. Place the top right log as shown below infigure 28f.
7. Start the fireplace. If the flame appears satisfactory, replace the
glass door. If the flame does not appear satisfactory, double-check
the air inlet and exhaust outlet pipe to ensure that they are
unobstructed.
Figure 28d. Ember Chip placement.

Page 15
H38DF Gas Fireplace
Part No. XG0131
WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
■If you cannot reach your gas supplier, call the Fire
Department.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service
technician. Force or attempt to repair may result in a fire or
explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system,
and any gas control which has been under water.
A. This appliance has a pilot which must be lighted by hand.
When lighting the pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any
phone in your building.
■Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
To Turn Off Gas To Appliance:
Operation - Model H38DF
3. Push in gas control knob slightly and turn clockwise
to "Off". Do not force.
4. Replace the lower gas control panel.
1. Turn off remote switch.
2. Remove the lower gas control panel.
1. STOP! Read the safety information above on this label.
2. Remove the lower gas control panel.
3. Push in gas control knob and turn clockwise to
"OFF."
4. Wait five (5) minutes to clear out any gas. Smell for gas,
including near the floor. If you then smell gas, STOP!
Follow "B" in the safety information above on this label. If
you don't smell gas, go to the next step.
5. Locate pilot burner (See illustration at right.) and follow
steps below.
6. Turn knob on gas control counterclockwise to
"PILOT."
7. Push in gas control knob completely and hold. Light with
Piezo Igniter button. Continue to hold the control knob in for
about (1) minute after the pilot is lit. Release the knob and it
will pop back up. Pilot should remain lit. If it goes out repeat
steps 3 through 8.
■If knob does not pop up when released. Stop and
immediately call your service
technician or gas supplier.
■If the pilot will not stay lit after
several tries, turn the gas control
knob to "OFF" and call your service
technician or gas supplier.
8. Push in gas control knob and turn counterclockwise
to "ON."
9. Replace the lower gas control panel.
10.Turn on remote switch to ignite fire.
Lighting Instructions:
H38DF
with Continuous Pilot
For Your Safety - READ BEFORE LIGHTING:
NOTE: Gascontrolknobcannotbeturnedfrom
"PILOT"to"OFF" unlessknobis pushed
inslightly. Donotforce.
Gas Control Knob
(Shown in "Pilot" postion.)

Page 16
H38DF Gas Fireplace
Part No. XG0131
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:
■If you cannot reach your gas supplier, call the Fire
Department.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service techni-
cian. Force or attempt to repair may result in a fire or
explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the control
system, and any gas control which has been under water.
A. This appliance is equipped with an ignition system that
lights the pilot burner automatically. Do not attempt to
light the pilot by hand.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any
phone in your building.
■Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
1. Turn off remote switch.
2. Remove the lower gas control panel.
3. Turn the switch on the gas control to "Off".
4. Replace the lower gas control panel.
1. STOP! Read the safety information above on this label.
2. Remove the lower gas control panel.
3. Turn switch on the gas control to OFF".
4. Wait 5 minutes to clear out any gas. If you smell gas,
STOP! Follow "B" in the safety information above on this
label. If you don't smell gas, go to the next step.
5. Turn switch on the gas control to "ON". NOTE: This unit is
equipped with an ignition system that lights the pilot burner
automatically. Do not attempt to light the pilot by hand.
6. Turn on wall switch.
7. Replace the lower gas control panel.
8. If the fireplace does not operate, follow the instructions "To
Turn Off Gas To Appliance" and call your service techni-
cian or gas supplier.
with Honeywell Electronic Ignition
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Operation - Model H38DF-I
H38DF-I
Gas
Inlet
Gas Control Switch
Shown in "On"Position

Page 17
H38DF Gas Fireplace
Part No. XG0131
Maintenance
WARNING:
Do not attempt to clean glass when hot.
Do not clean glass with abrasive materials as any
glass etching may cause premature glass failure.
CAUTIONS
Fireplace gas control must be in the “OFF” position and
pilot and main burners extinguished when cleaning
appliance with a vacuum.
Doorsandlogscangetveryhot.Handleonlywhencool.
General
Have the fireplace and installation inspected yearly. The
inspectionmustinclude,butisnotlimitedto,thefollowing:
•Avisualcheckoftheentireventsystemandtermination.
•Aninspectionof theexplosionreliefflappersandthedoor
gasketingtoensureaproperseal.
•Aninspectionoftheburner,venturi,andprimaryairopenings.
•Aninspectionofthegasvalve,gascomponents,andpilotflame.
Foryourconveniencea1/8"manifoldpressuretapissupplied
onthegasvalveforatestgaugeconnection.SeeFigure29.
•Ensureproperlogplacementasperthismanual.
•Inspectionofalloptionalequipment;fans,thermostats,ect.
ForNaturalGasthisappliancerequiresaminimuminletpressureof
5.5"W.C.andamanifoldpressureof3.5"W.C.
ForPropaneGasthisappliancerequiresaminimuminletpressureof
11"W.C.andamanifoldpressureof10"W.C.
Alwayskeepthefireplaceareaclearandfreeofcombustiblemateri-
als,aswellasgasolineandotherflammablevapoursandliquids.
Donotusethisapplianceifanyparthasbeenunderwater.Immedi-
atelycallaqualifiedservicetechniciantoinspecttheapplianceandto
replaceanypartofthecontrolsystemandanygascontrolwhichhas
beenunderwater.
Operation
Lighting Instructions
Seepages14and15.
Burner Adjustment
TheH38DFisequippedwithanadjustableburner,allowingyoutoraise
orlowertheflames.Toadjusttheflames,locatetheblackknobmarked
'Hi-Lo',inthecentreofthegascontrolvalve(SeeFigure29).Thefront
burnersarenotadjustable.
■Toraisetheflameheight,turntheblackknob(locatedbehindthe
lowertrim)counterclockwise.
■Tolowertheflameheight,turnclockwise.
Figure 29. 'Hi-Lo' Adjustment on the H38DF's gas valve.
Cleaning
Whenthefireplaceisfirstactivated,theremaybesomesmokinganda
visiblefilmmaybeleftontheglass.Thisisanormalcondition,andisthe
resultofburningofprotectivecoatingsonnewmetal.
Glassmustbecleanedperiodicallytoremoveanyfilm(whichisa
normalbiproductofcombustion)whichmaybevisible.Filmcan
easilyberemovedbyremovingthedoor,asshownonpage12.
Handlethedoorcarefully,andcleanitwithnon-abrasiveglass
cleaners.OneofthemosteffectiveproductsisKelKem.
Siliconesealsoninnerdoorduringinitialfiringwill"offgas",leavinga
visualdepositofawhitesubstanceoncombustionchamberwalls.
Thiscaneasilyberemovedusingnormalhouseholdproducts.
Useavacuumcleanerorwhiskbroomtokeepthecontrol
compartment,burner,andfireboxfreefromdustandlint.
Logsmaybecleanedperiodicallywithavacuumtoremovesootor
othercontaminates.
Note: H38DF-Imodels(electronicignition)donot
featurehi/loadjustment.
Gas Control Knob
(Shown in "Pilot" postion.)
'Hi-Lo'AdjustmentKnob

Page 18
H38DF Gas Fireplace
Part No. XG0131
Maintenance
Gas Control Valve
Pilot Burner Adjustment
1. LocatePilotAdjustmentScrew.(Seefigure30.)
2. Adjustpilotscrewtoprovideproperlysizedflameasshownin
figure 31).
3. Afterinstallingorservicing,leaktestwithasoapsolutionwithmain
burneron.Coatpipeandtubingjoints,gasketetc.withsoapsolution.
Bubblesindicateleaks.Tightenanyareaswherethebubbles
appearuntilthebubblingstopscompletely.
Figure 31. Pilot Burner.
Troubleshooting
Thefollowingisatroubleshootingchartofpossibleproblems:
PROBLEM CORRECTIVEACTION
NoisyPilotFlame Locatepilotadjustementscrewon
gascontrolvalve.Flameisdecreasedby
turningadjustmentscrewclockwise.
Pilotwon’tignite Disconnectremotewiresandtrytolight
pilot.Ifpilotnowworks,remote
connectionsarefaulty.Checkwiring
diagramfigure30.
Mainburnerwill 1.Checkwiring (seefigure30).
notlight 2.Checkwallswitchforproper
connection.
H38DF
Troubleshooting
Ifyourfireplacestilldoesnotoperatecorrectly,consultyourdealeror
themanufacturer.
All service and repairs should be performed by a qualified
agency.
Allspareparts,optionalfans,andoptionaltrimfinishesareavailablefrom
yourlocaldealerorthemanufacturer.
HONEYWELL SV 9500 /SV9600
Troubleshooting Sequence
NOTE: Before Troubleshooting, Familiarize Yourself With
The Startup And Checkout Procedure.
· Turn Gas Supply off
· Set thermostat to
call for heat
SV9500/SV9600
is powered
(24 VAC nominal)
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
START
Igniter warms up
and glows red.
Pilot Valve opens.
Turn gas on.
Pilot Burner lights?
Main Valve opens?
SYSTEM OK
Unplug Pilot Burner Cable,
Measure Voltage at
SV9500/SV9600 HSI
Terminals (24 VAC
Nominal, See INSET)
Replace Igniter/
Flame Rod Assembly.
Replace Igniter/
Flame Rod Assembly.
Replace SV9500/SV9600
Measure Voltage to SV9500
/SV9600. Voltage must
be at least 19.5 VAC
Discard old Igniter/
Flame Rod Assembly.
Replace Igniter/Flame
Rod Assembly and retain.
Restart Troubleshooting
Sequence. Does main
valve open?
Replace
SV9500/
SV9600
Check
Transformer
Line Volt
Supply
Replace
SV9500/
SV9600.
Save old
Igniter/Flame
Rod Assembly
for service.
INSET
HSI
Terminals
CHECK:
· Line voltage power
· Low voltage transformer
· Limit Controller
· Thermostat
· Wiring
· Air proving switch on
combustion air blower system
· Vent damper (if used) is open
and end switch made
H38DF-I
Figure 30. Sit Nova 820 gas valve.
Manifold Pressure
Test Connection
Pilot Adjustment Screw
Inlet
Pressure
Power
Generator
Wall Switch
Spill Switch

Page 19
H38DF Gas Fireplace
Part No. XG0131
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
TheCompanies warrants the Montigo Gas Appliance to be free from defects in materials and workmanship at the time of manufacture. On the Montigo, there is a ten-
yearwarrantyonthefireboxanditscomponents,afive-yearwarrantyonthemainburnerandpilotburner,andaone-yearwarrantyonthegascontrolvalveandfibrelogs.
Glass,plated/paintedfinishes,andrefractoryliningareexempt.
Remedy And Exclusions
The coverage of this Warranty is limited to all components of the Gas Appliance manufactured by The Companies.
ThisWarranty only coversMontigo Gas Appliances installed in the United States or Canada.
IfthecomponentsoftheGasAppliancecoveredbythisWarrantyarefoundtobedefectivewithinthetimeframestated(seeTheCompaniesrightofinvestigationoutlined
below).TheCompanieswill,atitsoption,replaceorrepairdefectivecomponentsoftheGasAppliancemanufacturedbyTheCompaniesatnocharge,andwillalsopay
forreasonablelabourcostsincurredinreplacingorrepairingcomponents.Ifrepairorreplacementisnotcommerciallypractical,TheCompanieswill,atitsoption,refund
thepurchaseprice of the Montigo Gas Appliance.
ThisWarrantycoversonlypartsandlabourasprovidedabove.InnocaseshallTheCompaniesberesponsibleformaterials,components,orconstructionwhicharenot
manufacturedorsuppliedbyTheCompanies,orforthelabournecessarytoinstall,repairorremovesuchmaterials,componentsorconstruction.Allreplacementorrepair
componentswill be shipped F.O.B.the nearest The Companies factory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
TheGas ApplianceWarrantyoutlined aboveisfurther subjecttothefollowing qualifications:
(1) TheGasAppliancemustbeinstalledinaccordancewithTheCompaniesinstallationinstructionsandlocalbuildingcodes.TheWarrantyonthisMontigoGasAppliance
coversonlythecomponentpartsmanufacturedbyTheCompanies.TheuseofcomponentsmanufacturedbyotherswiththisMontigoGasAppliancecouldcreate
serioussafetyhazards,mayresultinthedenialofcertificationbyrecognizednationalsafetyagencies,andcouldbeinviolationoflocalbuildingcodes.Thiswarranty
doesnot cover anydamagesoccurringfromthe use ofanycomponentsnot manufactured orsuppliedbyTheCompanies
(2) TheMontigoGasAppliancemustbesubjectedtonormaluse.TheGasAppliancesaredesignedtoburngasonly.Burningconventionalfireplacefuelssuchaswood,
coal or any other solid fuel will cause damage to the Gas Appliance, will produce excessive temperatures and will result in a fire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
ItisexpresslyagreedandunderstoodthatTheCompaniessoleobligation,andpurchaser'sexclusiveremedyunderthisWarranty,underanyotherwarranty,expressed
or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above.
InnoeventshallTheCompaniesberesponsibleforanyincidentalorconsequentialdamagescausedbydefectsinitsproducts,whethersuchdamageoccursorisdiscovered
beforeor afterreplacementor repair,andwhether ornotsuch damageiscausedbyTheCompaniesnegligence. Somestatesdo notallowtheexclusion orlimitationof
incidentalorconsequentialdamages,sotheabovelimitationorexclusionmaynotapplytoyou.ThedurationofanyimpliedwarrantywithrespecttothisMontigoGasAppliance
is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
TheCompanies reserves the right toinvestigate any and allclaims against this Warranty andto decide upon methodof settlement.
The Companies Are Not Responsible For Work Done Without Written Consent
TheCompanies shall innoeventbe responsible foranywarrantyworkdone withoutfirstobtainingTheCompanies written consent.
Dealers Have No Authority To Alter This Warranty
TheCompanies employees anddealershavenoauthority to makeanywarrantiesnorto authorize anyremediesinadditionto or inconsistentwiththosestated above.
How THow T
How THow T
How T
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
Inorderfor any claim under thisWarranty to be valid, TheCompanies must be notified of theclaimed defect in writing orby telephone, as soon as reasonablypossible
after the defect is discovered. Claims against this Warranty in writing should include the date of installation, and a description of the defect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
NOTE: The Companies asstated above referto - Canadian Heating Products Inc. and/or Montigo Del Ray Corp.
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 20
H38DF Gas Fireplace
Part No. XG0131
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,deck,or
balcony[16inches(41cm)minimum]
B= clearancetodoor,orsidesandtopofwindow,thatmaybeopened[16
inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
C= clearancetobottomof windowthatmaybeopenedhorizontally[36inches
(92cm)minimumforappliances
≤ 100000BTU/H(30kW)]
D= noclearancetopermanentlyclosedwindowwheninstalledwithapproved
glasspenetrationtermination
E= clearancetopermanentlyclosed window[16inches41cmrecommended
topreventcondensationonwindow]
F= verticalclearancetoventilatedsoffitlocatedabovetheterminationwithina
horizontaldistanceof2feet(61cm)fromthecentrelineofthetermination
[22inches(56cm)minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimumtocombustibles]
H= clearancetooutsidecorner[9inches(23cm)minimum]
I= clearancetoinsidecorner[12inches(31cm)minimum]
J= *nottobeinstalledaboveameter/regulatorassemblywithin
40"(103cm)horizontallyfromthecentrelineoftheregulator
K= clearancetoserviceregulatorventoutlet[3feet minimumintheUnited
States][*6feet (1.8m)minimuminCanada]
L = clearancetononmechanicalairsupplyinlettobuildingorthecombustion
airinlettoanyotherappliance[16inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6feet (1.8m)minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
publicproperty[*7feet(2.1m)minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41cm)minimum‡tonon-combustibles]
[22inches(56cm)minimum‡tocombustibles]
Q= clearanceabovearoof[24inches(61cm)minimum]
R= clearancetoadjacentwallsandneighbouringbuildings
[18inches(46cm)minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31cm)minimum]
T= maximumdepthinrecessedlocation
[48inches(122cm)minimum]
U= minimumwidthforbackwallofrecessedlocation
[24inches(61cm)minimum]
V= nohorizontalclearancebetweentheframesoftwoterminationsthatare
level.
W= horizontalclearancebetweentheframesoftwoterminationsthatare
notlevel. [36inches(92cm)minimum]
†aventshallnotterminatedirectlyaboveasidewalkorpaveddriveway
whichislocatedbetweentwosinglefamilydwellingsandservesboth
dwellings
‡onlypermittedifveranda,porch,deck,orbalconyhasanopensidethat
isequaltoorgreaterthanthedepthoftheenclosedarea
*asspecifiedinCGAB149InstallationCodes.Note:localCodesor
Regulationsmayrequiredifferentclearances
