Montigo H38VO-ST Instruction Manual

H38VO-ST
HL38VO-ST
Outdoor Ventless
See Through
Resi
dential
Gas Fireplace
®
C US
Read and understand this manual. Improper installation, adjustment, alteration,
service or maintenance can cause serious injury, property damage or even death.
For assistance or additional information consult a qualified installer, service
agency or the gas supplier.
DANGER
Glass doors on gas fireplaces are extremely hot while the fireplace is on and
remain hot even after the fireplace has been turned off. Safety screens are
available and can reduce the risks of severe burns. Please keep children away
from the fireplace at all times.
CAUTION
Installation & Maintenance Manual
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other gas burning appliance. A fire or explosion my occur causing serious
injury, property damage or even death.
WARNING
Installer: Leave this manual with the appliance. Do not remove.
Consumer: Retain this manual for maintenance and future reference. Do not Discard.
NOTICE
XG0817 080311
WARNING
FOR OUTDOOR USE ONLY.
WARNING
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has
no odor. Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a
camper, tent, car or home.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
Canadian Heating Products Inc. Langley, BC V4W 4A1 | Montigo Del Ray Corp. Ferndale, WA 98248

Page 2
You must read and understand this
manual prior to installation, operation or
troubleshooting this appliance. Please
retain this owner’s manual for furure
reference and maintenance.
NOTICE
XW2010
XG0817 - 080311
Table of Contents
H*38SVO-ST Outdoor Gas Fireplace
Introduction .................................................................................3
Models .................................................................................3
Installation
Before you Start .................................................................................4
Installation Checklist ...............................................................................4
Section 1: Installation Overview and Product Dimensions .....................5
Section 2: Framing the Fireplace ...........................................................6
Clearances ............................................................................6 - 7
Finishing around the Fireplace ...........................................................7
Section 3: Venting .............................................................................N/A
Section 4: Wiring .................................................................................8
▪ Honeywell gas control and pilot ..............................................8
Section 5: Installing the Gas Line ...........................................................9
Section 5-1: Fuel Conversion ..................................................................9
Section 5-2: Gas Pressure ......................................................................9
Section 5-3: Gas Connection ..................................................................9
Section 6: .............................................................................N/A
Section 7: Installing and Removing the Door .......................................10
Section 8: Installing the Accessories .............................................11 - 14
▪ Installing the H34VO Log Set ....................................................11
▪ Installing the H38VO Log Set ....................................................12
▪ Installing the H42VO Log Set ....................................................13
▪ Installing the HL38VO Firestones ..............................................14
Section 9: Operation ........................................................15 - 16
▪ Start-up Sequence with Continuous Pilot ..................................15
▪ Start-up Sequence with Honeywell Electronic Ignition .............16
Maintenance .......................................................................17 - 18
▪ General ...............................................................................17
▪ Cleaning ...............................................................................17
▪ Hi-Lo Burner Adjustment ............................................................17
▪ Pilot Burner Adjustment .............................................................17
▪ Replacement Parts ....................................................................18
Appendix
A. Termination Locations ..............................................................19
B. Warranty ...............................................................................20
C. State of Massachusetts. ..........................................................21

Page 3
XG0817 - 080311
Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE
H*38SVO-ST Outdoor Gas Fireplace
Safety Alert Key
Introduction
WARNING
Hot glass will cause
burns. Do not touch
glass until unit is cooled.
Never allow children to
touch glass.
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Congratulations on your purchase of a Montigo Fireplace.
With over 30 years of experience, Montigo is committed to providing you
with a gas replace that is not only a beautiful addition to your space, but
that is also designed and manufactured to the highest safety, reliability
and engineering standards.
We strongly encourage you to read and carefully follow the instructions
laid out in this Installation, Operation and Maintenance Manual and retain
it for your future reference. Pay special attention to all cautions, warnings,
and notices throughout this manual intended to ensure your safety.
This manual covers installation, operation and maintenance. Lighting,
operation and care of this replace can be easily performed by the
homeowner. All installation and service work should be performed by
a qualied or licensed installer, plumber or gas tter as certied by the
state, province, region or governing body where the replace is being
installed.
This installation, operation and maintenance manual is applicable to the
models described. Refer to your rating plate to verify included options.
How to use this manual:
This manual covers installation, operation and maintenance. Lighting,
operation and care of this replace can be easily performed by the
homeowner. However, all installation and service work should be
performed by a qualied or licensed installer, plumber, or gastter who
is qualied or licensed by the state, province, region, or governing body
in which the appliance is being installed.
Warranty and Installation Information: (See Appendix B)
The Montigo warranty will be voided by, and Montigo disclaims any
responsibility for, the following actions:
► Modication of the replace and/or components including
Direct-Vent assembly or glass doors.
► Use of any component part not manufactured or approved by
Montigo in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas replaces. Installation & repairs should be done by
a qualied contractor.
H38VOSTN X 45,000 X X
H38VOSTNI X 45,000 X X
H38VOSTL X 45,000 X X
H38VOSTLI X 45,000 X X
HL38VOSTN X 45,000 X X
HL38VOSTNI X 45,000 X X
HL38VOSTL X 45,000 X X
HL38VOSTLI X 45,000 X X
MODEL Natural Gas Liquid Propane Gas Rating (BTU hr) Traditional Burner / Logset Contemporary Burner w/River rock Linear Burner w/ Glass Accessories Standing Pilot Ignition Honeywell Hot Surface Ignition

H*38SVO-ST Outdoor Gas Fireplace
Page 4 XG0817 - 080311
