montpellier MAC9000W User manual

Portable Air Conditioner
MAC9000W
MAC12000W
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THEPERFECT BALANCEOF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your appliance to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
• Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
•By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation and
maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this book for
future reference.
The design and specifications are subject to change without prior notice for product improvement.

CONTENT
Important Safety Tips
Precautions ..................................................................1
Product Introduction
Main Parts and Components.....................................3
Control Panel and Remote Controller..................... 4
Product Operation
Placement and Installation.........................................5
Operation Method ....................................................... 7
Clean and Maintenance
Drainage Method......................................................... 8
Maintenance................................................................ 8
Common Failures and Diagnosis
Intelligent Error Detection ........................................10
Fuse Parameters.......................................................10
Trouble-shooting.......................................................10

Please read the Manual carefully before operating the machine:
 This machine is for household use only.
 This machine is for indoor use only. Please place it in dry environment.
 Check power cord frequently. When power cord, plug or A/C is damaged, please
don’t operate.
If the power cord is not long enough, power extension cable can be used. Cable should
not scatter at places where power cord may be pulled out or people may be stumbled.
 The A/C should be away from heat source and avoid direct sunlight.
 Turn off the A/C before unplugging.
 Turn off and unplug the A/C before removing or cleaning it, or replacing its parts or
when it is not used.
 Clean the A/C according to the Manual.
 Voltage of the A/C should meet requirements. Any damage incurred by incorrect power
isn’t included in the warranty.
 Children are not allowed to play with the A/C.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
 Don’t insert your fingers or any hard object to wind guide bar of the air outlet.
 Don’t place the A/C at any place with water or other liquid. Prevent water or liquid from
entering the A/C.
 Don’t repair the A/C by yourself. Any possible hazard incurred by maintenance of
laypeople will violate the warranty. If the supply cord is damaged, it must
be replaced by professional maintenance personnel.
 Please use the accessories provided by the A/C manufacturer; otherwise, the A/C may
be damaged.
 Suggest using environmental temperature for the air conditioner (Cooling/heating) ：
15－35℃/5-27℃.
 This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children without
supervision.
PRECAUTION

Special warning:
 Place the A/C on even ground and install it vertically, so as to ensure normal
operation of the compressor.
 The A/C should be at least 50cm away from surrounding objects. Keep air inlet and
outlet smooth.
 Don’t use the A/C beside gasoline or any other inflammable liquid.
 Don’t use spraying agent and other solvent or flammable substances near the A/C;
otherwise, its plastic may deform and electric parts may be damaged.
Power
 The plug should be in good condition and can’t be damaged. Don’t replace the plug
with power lug.
 In order to run the A/C, plug the power cord first, and then press the power key.

1. Handle
2. Air inlet (L)
3. Control panel
4. Wind guide bar
5. Caster
6. Remote controller
7. Air inlet (R)
8. Air outlet
9. Dehumidification drainage nozzle
10. Air inlet grille
11. Exhaust duct assembly
12. Window sealing plate assembly
PRODUCT INTRODUCTION
MAIN PARTS AND COMPONENTS

1. Power key
Press the key to turn ON/OFF the A/C.
2. Mode key
Press the key to choose cooling,wind ,dehumidification and
heating(cooling only model has no heating) mode.
3. Temperature/ time adjusting key
Press the key at cooling mode to increase/reduce the
setting temperature; press it at timing mode to adjust timing
ON/OFF time; press Up and Down keys simultaneously to
switch Fahrenheit and Centigrade degree temperature.
4. Fan key
Press the key to choose high/ low gear wind speed.
5. Timer Key
press this key to set a timer for auto start or auto stop.
6. Swing key
Press this key at any time after turning on the A/C to swing
the wind guide bar automatically.
7. ℃/ ℉switching key
Press the key to switch ℃and ℉.
CONTROL PANEL AND REMOTE CONTROLLER
6
7

Placement
 Place it at even and dry place, and keep it at least 50cm away from its surrounding
object.
Installation
 Screw the exhaust duct assembly in the air outlet behind the panel (anticlockwise).
PRODUCT OPERATION
PLACEMENT AND INSTALLATION

 Insert the air exhaust hose into the window sealing plate, adjust opening width of
window so that the window can match with the sealing plate properly; length of the
sealing plate is adjustable.
Incorrect installation
 It’s important to keep the exhaust duct smooth. Incorrect installation will affect work of
the A/C.
 Prevent the exhaust duct from seriously bending.
 Ensure air can flow smoothly in the duct.
Warning:
The exhaust duct is designed especially for this model.
Don’t replace or lengthen it; otherwise, it will result in
failure.
Notice:
Max. developed length of the exhaust duct is 1,500mm. It’s better to shorten it while use
and keep it horizontal while installation.

Cooling mode
 When the A/C enters cooling mode automatically or cooling mode is selected after
power ON, the cooling indicator lamp lights up.
 Press Up/Down key to adjust setting temperature (16℃~30℃).
 Press Speed key to choose High/Mid/Low speed.
Fan mode
 When pressing mode key or choosing Fan mode by pressing the remote controller,
the wind indicator lamp lights up.
 Press Speed key to choose High/Mid/Low speed.
 Temperature can’t be set.
Dehumidification mode
 When pressing mode key or choosing dehumidification
mode by pressing the remote controller, the
dehumidification indicator lamp lights up.
 Remove the dehumidification water wedge, insert water
manifold, place the other end of the water manifold into
the water vessel or drainage passage, as shown in the
right figure.
 After entering the dehumidification mode, if room
tempearture≥17℃(62℉), the compressor is ON. Then
control as follows: when room temperature ≤15℃(59℉)
the compressor is OFF; when temperature increases to room temperature≥17℃, the
compressor is started again (in order to protect the compressor, it will be restarted
3min. later).
 In dehumidification mode, the fan is defaulted to run at low speed, and wind speed
can’t be adjusted.
 Temperature can’t be set. （Note : when use dehumidify function, should remove
exit pipe components, otherwise, it will cause worse dehumidify performance,
and appear “FL” water full alarm ）
Timer mode
 In standby state, press the Timer key to set ON time. Press Up and Down keys to set
ON time (1~24H), and the timer indicator lamp lights up.
 In ON state, pressure the timer key to set OFF time. Press Up and Down keys to set
OFF time (1~24H), and the timer indicator lamp lights up.
OPERATION METHOD

This product is equipped with automatic water vaporization system. The condenser
is cooled with the circulating of condensing water, so as to improve cooling
efficiency and save energy.
 If the internal vessel is full of water, the display screen will
display “FL”, and the compressor stops working
automatically. After power off, unscrew the water cover, pull
out the water wedge to drain off water, and it will become
normal after being restarted.
Notice: in order to avoid electric shock, please turn off the A/C and unplug before
maintenance or repair.
CLEANING
 Unplug before cleaning.
 Wipe with soft semi-dry cloth. Don’t use chemical reagent, such as benzene, alcohol
and gasoline etc.; otherwise surface of the A/C and even the whole A/C will be
damaged.
 Prevent water from spattering in the A/C.
FILTER SCREEN
 Wash the filter screen once every two weeks. If it is blocked by dust, efficiency of the
A/C will be reduced.
DRAINAGE METHOD
CLEAN AND MAINTENANCE
MAINTENANCE

 Take out the air inlet grille and pull out the filter screen at both sides according to the
direction shown in the following figures.
 Put the filter screen into the warm water (about 40℃) added with neutral detergent,
dry it at a shady place after cleaning.
SEASONAL CLEANING
If the A/C will not be used for a long time:
 Pull out the water wedge to drain.
 Run the A/C in fan mode for 2H till its inside is dry.
 Turn off the A/C and unplug.
 Wash the filter screen and reassemble it.
 Dismantle the exhaust duct and keep it properly.
 Cover the A/C with a plastic bag and place it at a dry place.

Error-detecting code Multi-functional defection
E1
Error of the coil’s temperature sensor
E2
Error of indoor temperature sensor
E4
Anti-freezing protection: temperature of the coil is too low and
the whole A/C is off. When temperature excesses 8℃, the
protection is released and previous working state is recovered.
Specification: Φ5×20mm
Voltage: 250VAC
Current: 3.15A
In case of any of the following trouble, please contact professional maintenance personnel
in time.
TROUBLE
CAUSE
SOLUTION
The A/C doesn’t
work
Not plug in
Plug in
The display panel displays
“FL”
Restart the A/C after power off and
draining, then it will become normal
Time OFF function is started
The A/C can be restarted 3 minutes
after being turning off.
The A/C starts
frequently
Direct sunlight
Draw the curtain
Doors and windows keep
open; there are lots of people
or heat source in room
Close doors and windows, remove
heat source
Filter screen is very dirty
Clean or replace it
Air inlet or air outlet is blocked
Remove the stem
Big noise of the
A/C
The A/C is placed unevenly
Place it at even and firm ground,
avoid shaking
The compressor
doesn’t work
Its delay protection is started
Wait for 3min., turn on it after
temperature decreases
Notice: When there is any abnormal to the A/C, turn it off and unplug, and then
contact professional maintenance personnel.
The above technical parameters are subject to change without notice.
COMMON FAILURES AND DIAGNOSIS
FUSE PARAMETERS
INTELLIGENT ERROR DETECTION
TROUBLE-SHOOTING

Meaning of crossed –out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities.
Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging your health and
well-being.

Here For You
After-sales assistance
If you continue to experience problems with your appliance, please call the Montpellier customer
service helpline on: 01527 888133
Please have all your product details available , including the model number, serial number, original
sales invoice (clearly showing model number,date of purchase and your retailer's details) before
registering a fault.
The service call cannot progress without this information.
Your 2 year Manufacturer's guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the co st of
repairs during the first 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof of
purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months
prior to the date of claim.
What is not covered under the Guarantee
• Any appliance not correctly installed and operated in accordance with the manufacturer's
instructions
• Any appliance that is used for anything other than domestic purposes.
Any defect caused by accident, misuse, unauthorised modification or inexpert repair.
• Cost of Call-out where a fault cannot be found with the appliance.
Cost of Call-out for work covering routine maintenance, such as, but not exclusively, cleaning
of filters or defrosting.
• Cost of Call-out for work required to correct the alignment of doors following door reversal
procedures carried out by you.
Use of the appliance by anyone other than the Householder.
Use in any commercial environment.
• Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items
which require routine replacement.
Repair costs incurred that have not been authorised by Montpellier service and/or carried out
by a nonapproved Montpellier engineer.
• Montpellier Appliances do not accept claims for consequential loss, rusting, corroding,
delivery damage or scratches.
YOUR GUARANTEE IS VALID ONLY IN THE UK & REPUBLIC OF IRELAND
To register your appliance simply complete the card in your appliance pack and return it with a
stamp affixed or alternatively you can register on line at www,montpellier-appliances.com/
support
SERVICE HELP-LINE
Should your appliance develop a fault, please call the Montpellier customer service helpline on:
01527 888133
Please remember to have all your product details available, including the model number, serial
number, date of purchase and your retailer's details before registering a fault.

Montpellier Domestic Appliances Ltd.
Unit 1, Tewkesbury Retail Park, Northway Lane,
Tewkesbury, Gloucestershire GL20 8JU
www.montpellier-appliances.com
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, your household waste disposal service or the shop where you
purchased the product.
