montpellier MAB2030PB User manual

Under Counter Retro Fridge Freezer
MAB2030 - 48cm Wide
Red/Black/Cream/Pure Blue
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Description Of
The Appliance
1
This diagram is only for informative purposes about
parts of the appliance. Parts may vary according to
the appliance mode.
1. Freezer Compartment
2. Thermostat Control
3. Interior Light
4. Interior Glass Shelf
5. Door Storage – Specic Areas for
Bottles & Dairy Products
6. Salad Crisper Box with Glass Shelf
7. Two Levelling Feet
1
2 / 3
4
5
6
7
Coldest
zone
Warmest
zone

2
Introduction and
2 Year Guarantee
Thank you for choosing this Montpellier appliance.
It has been designed to give years of trouble-free
use provided it is installed and maintained correctly.
Please read these instructions carefully before
installing or using your appliance. It is advisable to
keep your purchase and installation receipts with
these instructions in a safe place for future reference.
Included is some important safety information in addition
to guidelines and recommendations that will enable you
to take full advantage of all the functions available.
This quality appliance has been tested and
certied to meet all applicable UK electrical
and safety standards.
This appliance must be installed and connected
in accordance with current regulations by a
qualied electrician.
After unpacking the appliance ensure that there is
no visible damage. If the appliance has been
damaged during transit, do not use it, contact
your retailer immediately.
THE 2 YEAR MANUFACTURERS GUARANTEE
DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free
guarantee which protects you against the cost
of repairs during the rst 24 months from date
of purchase provided that:
Any claim is accompanied by evidence of the model
reference, model serial number and proof of purchase,
such as a Sales Receipt, showing that the appliance
was purchased within the 24 months prior to the
date of claim.
What is not covered under the Guarantee:
• Any appliance not correctly installed and operated in
accordance with the manufacturer’s instructions.
• Any appliance that is used for anything other than
domestic purposes.
• Any defect caused by accident, misuse, unauthorized
modication or inexpert repair.
• Cost of Call-out where a fault cannot be found with
the appliance.
• Cost of Call-out for work covering routine maintenance,
such as, but not exclusively, cleaning of lters
or defrosting.
• Cost of Call-out for work required to correct the
alignment of doors following door reversal procedures
carried out by you.
• Use of the appliance by anyone other than the
Householder.
•Use in any commercial environment.
• Consumable items, such as, but not exclusively, fuses
in plugs, bulbs and breakable items which require
routine replacement.
• Repair costs incurred that have not been authorised
by Warranty Solutions.
• Repairs carried out by a non-approved Warranty
Solutions engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK & ROI.
To Register your Appliance
Simply complete the card in your appliance pack and
return it with a stamp axed or Alternatively you can
Register online (please see link below).
Service Helpline
Should your appliance develop a fault, please call
Montpellier Service on: 01759 487839
Please remember to have all your product details
available, including the serial number, before
registering a fault.
Your service call cannot progress without
this information.
Register your product online
www.montpellier-appliances.com/support/register-your-product

Contents
3
Section 1 : Safety Advice
Section 2: Installation
Section 3: Operating The Appliance
Section 4: Maintenance
4
5
6 - 8
9 - 10

4
Section 1: Safety Advice
• Please read this booklet thoroughly before installing
and switching on the appliance. The manufacturer
accepts no responsibility for incorrect installation
and usage.
• If this appliance is to replace an old appliance with a
lock, as a safety measure break or remove the lock
and/or door before disposal.
• Your old appliances contain insulation gases and
refrigerant that must be disposed of correctly.
Please ensure that the refrigerant circuit is not
damaged before the appliance is taken away for
correct disposal in line with current legislation.
If there is any doubt contact your Local Authority
for instructions.
• This appliance may contain the refrigerant isobutene
(R600a). This is a natural gas with a high level of
environmental compatibility; however, caution is
required as isobutene is a ammable gas. It is
essential to ensure that refrigerant tubes are not
damaged during transportation and the installation
of the appliance. In the event that the refrigerant
circuit is damaged, avoid naked ames or sources
of ignition and ventilate the room in which the
appliance is situated.
• Do not damage the refrigerant circuit.
• Do not allow children to play with plastic bags – tear
the bag(s) immediately and ensure that they are
placed in a dust-bin out of reach.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning the use of the appliance
by a person responsible for their safety. Children
should be supervised to ensure that they do not play
with the appliance.
• If using an adaptor, this must be used in accordance
with the manufacturers instructions and ensure that
the electrical circuit is not overloaded as this could
cause overheating.
• Do not twist or bend the cables, and keep them
away from hot surfaces.
•Do not plug ın or unplug this appliance with wet
hands.
• Following installation make sure that the power cable
is not trapped underneath the appliance.
• If the power supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
•Ensure the appliance is left in an upright position for
at least 4 hours before you switch it on.

5
Section 2: Installation
IMPORTANT! This appliance must be left to stand in
an upright position for at least 4 hours before being
switched on for the rst time.
•This appliance has been designed for Domestic Use
Only.
• Remove all packaging and securing tape from the
appliance.
• Wash the interior of the appliance with luke warm
water containing a small amount of bicarbonate
soda (5ml to 0.5 litres of water).
• Position the appliance in a dry atmosphere and out
of direct sunlight.
• Do not position next to a cooker or other sources of
heat, i.e. radiator.
• This appliance should not be sited in a cold atmos-
phere, i.e. garage or shed. Doing so may cause the
freezer unit to underfreeze.
• If positioned next to another fridge or freezer, leave
a minimum gap of 2cm between the appliances in
order to avoid condensation.
• A clearance of 50mm should be left above the appli-
ance. If this cannot be achieved you should ensure
a clearance of 25mm is maintained on each side of
the appliance.
• Do not place or store heavy items on the top of this
appliance.
•Ensure that the appliance is positioned on a rm at
oor.
• This appliance must be level. Adjust the level by
screwing the adjustable feet up or down (use your
ngers or a suitable spanner).
•Ensure that the appliance is upright and both feet
are in rm contact with the oor so that the cabinet
is stable.
• Connect the plug to an adjacent 13amp socket
outlet and ensure that the appliance is not standing
on the supply cable.
ELECTRICAL CONNECTION (FOR UK 3 PIN PLUG)
•For your safety please read the following information.
• Warning: This appliance must be earthed.
• This appliance operates from 220-240 volts and
should be protected by a 13 amp fuse in the plug.
• The appliance is supplied with a standard 13 amp
3-pin mains plug tted witha 13-amp fuse. Should
the fuse require replacement, it must be replaced
with a fuse rated at 13 amp and approved to
BS1362.
Fig 1
Fig 2

6
Section 3: Operating
The Appliance
3.1. Switching on the Appliance
•Allow the appliance to stand upright for a minimum
of 4 hours before you switch it on.
•Plug in the appliance and switch on at the mains
supply.
•Set the thermostat control to the required setting as
detailed in the Temperature Control section (3.2.).
•Leave the appliance for approximately 4 hours for
the correct temperature to be reached.
3.2. Temperature Control
The temperature selector knob is located on the r/h wall
inside the refrigerator (see
Description of the Appliance on page 1).
• Setting “0”: Unit O
•Setting “1”: Unit On – Warmest Temperature
•Setting “3” to “4”: Normal Operation (adequate for
most situations)
•Setting “7”: Coldest Temperature
Important!
During high ambient temperatures e.g. on hot summer
days, it may be necessary to set the thermostat to
the coldest setting (position 7). This may cause the
compressor to run continuously in order to maintain
a low temperature in the cabinet.
3.3. Storing & Freezing Food in the Freezer
This appliance has a four star freezer that is suitable for
the long-term storage of frozen food items. It can also be
used for freezing and storing fresh food items.
You should always follow the storage guidelines printed
on each food producers packaging, however the
following information is provided as a general guide
for the maximum storage life of frozen items:
•Fresh Meat and Poultry – up to 12 months
•Cooked Meats – up to 2 months
•Fresh Fish – up to 6 months
•Fruit and Vegetables – up to 12 months
•Bread and Cakes – up to 6 months
3.4. Normal Operating Sounds
You may hear faint gurgling or bubbling sounds when the
refrigerant is pumped to the cooling system and through
the coils or tubing at the rear of the appliance. When the
compressor is in operation you may hear a slight whirring
sound or pulsating noise.
The thermostat controls the operation of the
compressor, and you may hear a slight click as
it cycles in and out.
3.5. Energy Saving Advice
• Do not install the appliance close to sources of
heat, such as a cooker,dishwasher or radiator.
• Locate the appliance in a cool well-ventilated room
and make sure that the air vents are clear.
•Try to avoid keeping the doors open for a long time,
warm air will enter the cabinet and may cause a
build-up of ice as well as aecting the energy
consumption. Ensure there are no obstructions
preventing the doors from closing properly.
•Ensure that the door seals are clean and there are no
tears or splits.
•Keep the most perishable foods, (those with a short
shelf-life, such as cooked meats), in the coldest part
of the fridge. The Salad Crisper Box is the warmest
part of your fridge and should be used for
vegetables, salads and fruits etc. (see Description
of Appliance on Page 1)
•Do not overload the fridge: the cooling air that
circulates to keep the fridge cold gets blocked and
pockets of warm air form.
•Do not put hot food into the fridge or freezer – let it
cool down rst.
3.6. In the Event of a Power Failure
If there is a power failure, keep the doors closed. When
the power has been restored the appliance will start to
operate but it may take some time to achieve the pre-set
operating temperature. Check the condition of your
stored food items and liquids.

7
Section 4: Maintenance
Before any maintenance or cleaning work is
carried out, DISCONNECT the appliance from the
ELECTRICITY supply.
4.1. Internal Cleaning
Clean the interior and accessories with warm water
and bicarbonate of soda (5ml to 0.5 litre of water).
Rinse and dry thoroughly. Do not use detergents,
abrasive powders, highly perfumed cleaning products,
wax polishes or cleaning products containing bleach
or alcohol.
4.2. External Cleaning
Wash the outer cabinet with warm soapy water. Do NOT
use abrasive products. There may be sharp edges on the
underside of the product, so care should be taken when
cleaning. Once or twice a year dust the rear of the
appliance and the compressor at the back of the
appliance, with a brush or vacuum cleaner, as an
accumulation of dust will aect the performance of the
appliance and cause increased energy consumption.
4.3. Defrosting
The fridge compartment will automatically defrost itself.
The rear inner wall of the fridge compartment will at
times appear wet, but this is part of the defrost
process and is quite normal. However, you will need to
defrost the freezer periodically. When ice build-up in
the freezer exceeds 3-5mm, empty the contents and
switch o the appliance, leave the
door open and allow the ice to melt.
Place the frozen foods items in a cool-bag or wrap
them in thick newspaper. Do not use sharp objects to
scrape the ice away. Clean and dry the interior, close the
door and turn on the power to the appliance. When the
power has been restored the appliance will start to
operate but it may take some time to achieve the pre-set
operating temperature.
4.4. When the appliance is not in use
When the appliance is not in use for long periods,
remove the contents, disconnectfrom the electricity
supply and clean the appliance, leaving the door ajar
until you wishto use the appliance again.
4.5. Changing the Interior Light
•Switch o the power supply to the appliance
•Remove the plastic light cover by sliding it towards
the rear of the fridge
•Unscrew and remove the bulb from the light unit.
•Replace the bulb with a ‘like for like’ suitable
replacement (E14,10W)
•Ret the cover and switch the appliance back on.

8
Section 4: Maintenance
4.6. What to do if something goes wrong
There is no power to the appliance:
• Check there is not a power cut.
•Check there is power to the electric
socket/appliance.
•Check the fuse in the plug (Must be 13 amp).
•Check that the thermostat is set to 1 or above
(see Section 3.2.)
The compressor runs continuously:
• Check the door is properly closed.
•Check that the Temperature Control has not
been set to maximum.
•Check that the fridge is not overloaded.
•There is excessive frost/ice build-up:
•Ensure that the door has been closed correctly
•Ensure that the door seal is clean and sealing
correctly
•Check that the Temperature Control has not been
set to maximum
•Check that the fridge is not overloaded
The appliance is making a noise:
• Refer to Normal Operating Sounds, section 3.4.
•Ensure that the appliance has been installed
correctly (see section 2).

Notes
9

Notes
10

11
Help-line
If after the previous checks there is still a
fault, please contact the Montpellier Service
Help-line below.
Please ensure that you have the model
number, serial number, date of purchase and
retailers information available before you
make the call.
Service Help-Line
Should your appliance develop a fault, please call
Montpellier Service on: 01759 487839
Electrical connection (for uk type plug)
For your safety please read the following information.
Warning: This appliance must be earthed.
This appliance operates from 220-240 volts and
should be protected by a 13amp fuse in the plug.
The appliance is supplied with a standard 13 amp 3-pin
mains plug tted with a 13-amp fuse. Should the fuse
require replacement, it must be replaced with a fuse
rated at 13 amp and approved to BS1362.
Insurance
The warranty provided with this product does not
cover loss of food content.
Any claim for loss, damage, costs or expenses of
an indirect or consequential nature including any
economic loss or damage to foodstus or any
other goods is excluded. We recommend that you
inspect your appliance regularly to check that it is
working correctly, losses can result from deterioration
following breakdown or accidental failure of the
appliance, fuses, plugs or public electricity supply,
these can be covered by your standard home
insurance or might require extra cover.
Check with your insurance provider.
Important Note:
This appliance is marked according to the
European directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handling of this product.
The symbol on the product, or on the documents
accompanying the product, the Crossed Out Wheelie
Bin, indicates that this appliance may not be treated
as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of
electrical and electronic equipment.
Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment,
recovery and recycling of this product, please
contact your local authority, your household
waste disposal service or the retailer where
you purchased the product.
We continuously try to improve our products for the
benet of our customers. For this reason we reserve
the right to make changes to any product at any time,
without notice
Issue: 01/11/2018.
THE PERFECT BALANCE OF FUNCTION, STYLE AND RELIABILITY
LAUNDRY - DISHWASHING - COOKING - COOLING

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product,
please contact your local city oce, your household waste disposal service or the shop where you purchased the product.
www.montpellier-appliances.com
Montpellier Domestic Appliances Ltd.
Unit 1, Tewkesbury Retail Park, Northway Lane,
Tewkesbury, Gloucestershire GL20 8JU
