Mooer Wi100 User manual

Owner'smanual
Wi100
IntelligentElectricWindInstrument

CONTENT
Precaution--------------------------------------------------------------------------------------------01
Feature------------------------------------------------------------------------------------------------02
Layout-------------------------------------------------------------------------------------------03-04
Instructions------------------------------------------------------------------------------------------05-10
Start---------------------------------------------------------------------------------------------05
Play----------------------------------------------------------------------------------------------------05
Setting---------------------------------------------------------------------------------------------06-07
Output Setup----------------------------------------------------------------------------------------08
Audio Playback-------------------------------------------------------------------------------------08
USB Recording------------------------------------------------------------------------------------09
Charging-------------------------------------------------------------------------------------09
App---------------------------------------------------------------------------------------------------10
Play Skills------------------------------------------------------------------------------------11
Tone Bank-----------------------------------------------------------------------------------12-13
Specifications---------------------------------------------------------------------------------------14

PowerSupply
●PleaseusethepowersupplywithUL,CSA,VED,orCCCstandard
●Pleaseusethepowersupplythatcanmeetthemanufacturer’spowerrequirement
●Pleaseunplugthepowersupplywhenthedeviceisturnedofforduringthunderstorm
●Pleasedonotexposethedevicewhichhasbatterypowertoheatorletitoverheat
●Whenthebatteryleakagehappens,pleasedonottouchtheliquidwithyourskinoreye.Ifyou
havetouchedthat,pleaseconsultwithdoctor
●Thebatterycomeswiththedevicemaycausefireorchemicalburnsduetoimproperhanding
Precaution
01
Pleasereadcarefullybeforeusing
Location
Toavoiddeformation,discoloration,orotherseriousdamage,donotexposethisunittothe
followingconditions:
●Directsunlight●Excessivedustyordirtylocation ●Extremetemperatureorhumidity
●Magneticfields ●Highhumidityormoisture ●Strongvibrationsorshocks
Cleaning
Cleanonlywithasoft,drycloth.Ifnecessary,slightlymoistenthecloth.Donotuseabrasivecleanser,
cleaningalcohol,paintthinners,wax,solvents,cleaningfluids,orchemical-impregnatedwipingcloths.
Operation
●Pleasedonottoggletheswitchorrotatetheknobheavily.
●Pleasedonotletpaperscraps,metaldebris,orotheritemsfallinsidetheunit.
●Pleasedonotlettheunitfallfromahighlevel,orpushorstriketheunitheavily.
●Pleasedonotmodifytheunitwithoutauthorization.
●Forrepairingservice,pleasecontactMOOERsupportteamformoreinformation.

Feature
02
●Easyrecorder-stylelayoutsuitableforbeginnersandprofessionals
●SwitchLEDwith7differentcolorstoindicatepresettonesorprovidetechniquetips
●7storablepresetslotsand30differentsampletonesandsynthesizertones,covering
everythingfromclassictomodernstyles
●Uniqueangelchorustone
●CanbepairedwithadedicatedAppforquickpresetadjustmentsandfirmwareupdates
●Learnandpracticeyournewperformanceskillsbyfollowingthebuilt-inswitchLEDs
●Threeoctaverangeandpitchshifterfor12differentpitches
●Built-inspeakers
●Bluetoothandauxiliaryaudiofunctionsforaudioplaybackfrommobileaudiodevices
●AudiooutputforconnectingtoFRFRsystemsforliveperformance
●Supportsheadphonesforsilentpractice
●SupportsOTGtodirectlyrecordonyourmobiledeviceforlivestreamingorvideorecording
●Built-inrechargeablebatterywithupto6.5hourbatterylifewhenusinginternalspeakerorup
to15hourswhenusingtheaudiooutputjack
●Sleepmodeforsavingbattery


Layout
03
15
17
16
10
12
14
11
13
06
08
09
07
01
02
03
05
04

Mouthpiece
PerformancekeysL1-L3(lefthand)
Skillkey
PerformancekeysR1-R4(Righthand)
Built-inspeaker
Octaveupkey
Octavedownkey
Functionkey
Cordhook/Thumbhook
Placeyourrightthumbunderthehookorattachacord/straptoit.
Powerswitch
Bluetoothswitch
Audiooutputjack
Headphoneoutputjack
AUXIN
USBport
Chargingindicator
Waterdrain
04
01
02
03
04
07
10
13
16
05
08
11
14
17
06
09
12
15

05
Instructions
Pressandholdthepowerswitchfor1second.ReleasetheswitchwhenyouseetheLEDturnon.
TheswitchLEDwillturnonandoffforthreetimes,afterthat,youcanstartplaying.
L1
L2
L3
Slide
Tremolo
R1
R2
R3
R4
Start
Play
PutyourlefthandfingersonL1-L3and
putyourrighthandfingersontheR1-R4.
Theleftlittlefingercontrolsthetwoskill
keys(slip/tremolo).
Notes:Fordetailedinstructions,referto
theplayingskillsection.

06
Toneselection
PressthefunctionkeyandL1/L2simultaneouslytoselectatone.TheWi100providesupto7
presetslotstostoreyourtonepreferences.Youcanswitchbetweendifferentinstrumenttonesin
thecontrolApp.Inthetoneselectionmode,the7switchLEDwillbeonandin7differentcolors.
VolumeAdjustment
PressthefunctionkeyandR1/R2simultaneouslytoadjustthevolumelevel.Thereare6volume
levels(displayedas0-5intheApp).0forminimumvolumelevel;5formaximumvolumelevel.
Setting
L1
Slide
Tremolo
L2 L3
R1 R2 R3 R4
Octaveup/down

07
SensitivityAdjustment
PressthefunctionkeyandR3/R4simultaneouslytoadjustthesensitivitytosuityourplaying.
Thehigherthesensitivityyouset,thelessforceyouneedforplaying.
Thereare6sensitivitylevels(displayedas0-5intheApp).0forminimumvolumelevel;5for
maximumvolumelevel.
ReverbAdjustment
Pressthefunctionkeyandslipskillkey/tremoloskillkeysimultaneouslytoadjustthereverb
volumelevel.
Thereare6reverbvolumelevels(displayedas0-5intheApp).0forminimumvolumelevel;
5formaximumvolumelevel.
Keyselection
PressthefunctionkeyandtheOctaveUp/OctaveDownkeysimultaneouslytoadjustthepitch.
ThefactorysettingisC.Thekeyrangesfrom:
G--Ab--A--Bb--B--C--C#--D--Eb--E--F--F#
Notes:
Whenutilizingthefunctionkeytoadjustthetone/key,theswitchwillplayasoundto
indicatethechange.Whenadjustingthevolume/sensitivity/reverb,theswitchwillplayasound
toindicatethecurrentvolumelevel.

08
OutputSetup
1.Connecttoexternalamplifier:ConnecttheWi100toanexternalamplifierusingtheaudio
outputjack.
2.Headphones:Pluginyourheadphonestotheheadphonejackforsilentpractice.
3.Built-inspeaker:Whentheaudiojackandtheheadphonejackarenotbeingused,thebuilt-in
speakerofWi100willactivatefornormalvolumelevelpractice.
AudioPlayback
Bluetooth:YoucanopentheBluetoothmenuofyourmobiledevice.SearchforWi100toplay
theaudiotracksviaBluetooth.
AUXIN:YoucanconnectanaudiocabletoWi100’sAUXINwithexternalaudiodevicetoplay
theaudiotracks.

09
USBRecording
Wi100supportdirectlyrecordingwithsmartphone/tabletviaUSBport,forlivestreamingor
videorecording.
Notes:Wi100onlysupportsUSB-CtoUSB-Acable.
Charging
WhentheWi100isinlow-batterystatus,thepowerindicatorwillblink.PleaseconnecttheUSB
cabletotheUSBporttochargeyourWi100.ThechargingLEDwillturnREDwhilechargingand
GREENwhenchargingiscomplete.
Notes:Wi100onlysupportsUSB-CtoUSB-AcableanditisrecommendedtousetheoriginalUSB
cable.

10
APP
Userscandownloadthe“Wind”Apponyoursmartphoneortablet.WiththeApp,youcan
easilymanagemethepresettones,learnhowtoplay,andupdatethefirmware.

11
PlaySkills
1.Fingeringsfordifferentkeys
Wi100isbasedonthelayoutofarecorder.ItrangesthreeoctavesfromC3toC6.Youcanutilize
theC4-C5fingerstylewiththeOctaveUp/OctaveDownkeytoexpandfromC3-C6.
2.Skillsforplaying
Tremolo:PresstheTremolokeywhileplayingviatheleftthumbtogetthetremoloeffect.
Releasetostoptheeffect.
Slip:PresstheSlipkeywhileplayingtoslipwithdifferentnotes.
C4
1#C4 #1D4 2#D4 #2E4 3F4 4G4 5#G4 #5A4 6B4 7C5 i
#F4
#4#A4 #6

12
ToneBank
Wi100PresetTone
Number SwitchLED InstrumentTone
1
2
3
4
5
6
7
Red
Orange
Yellow
Green
Tealblue
Blue
Purple
AltoSaxophone
Clarinet
BambooFlute
Trumpet
Xiao
Organ
AngelChorus

13
Thecompletetonebank
1.SopranoSaxophone
2.AltoSaxophone
3.BaritoneSaxophone
4.Trumpet
5.Trombone
6.Horn
7.Flute
8.Clarinet
9.BambooFlute
10.Xun
11.Xiao
12.CucurbitFlute
13.SuonaHorn
14.Organ
15.BluesOrgan
16.GlassBottle
17.Violin
18.Cello
19.Clarinet
20.Oboe
21.Ocarina
22.IvoryBambooFlute
23.IrishFlute
24.Harmonica
25.MaleChorus
26.FemaleChorus
27.AngelChorus
28.SawtoothWaveSynth
29.SquareWaveSynth
30.MixedSawtoothWaveSynth

14
Specifications
Brand:
Input:
Output:
Headphoneoutput:
USBcable:
Bluetoothversion:
Speaker:
Battery:
Batterylife:
Weight:
Dimensions:
Accessories:
Wi100
3.5mmstereoaudioinputjack
6.35mmmonoaudiooutputjack
3.5mmstereoaudiooutputjack
USB-CtoUSB-A
5.0(Dualmode)
1x1,1W
4000mA
6.5hours(usingbuilt-inspeakerinlabenvironment);
15hours(using6.35mmaudiooutput)
420g
62mm(D)X45mm(W)X450mm(H)
Owner’smanual,USBcable,Mouthpiecex2,cleaningcloth,strap,
instrumentbag,3.5mmaudiocabl

6F,UnitD,JinghangBuilding,Liuxian3rdRoad,
Bao’an71District,Shenzhen,China.518133
SHENZHENMOOERAUDIOCO.LTD
MadeinChina
