Moog EXVF5C-1 User manual

Moog Inc.
Sensor and Surveillance Systems
3650 Woodhead Drive, Northbrook, IL. USA 60062
+1.847.498.0700 Fax: [phone] www.moogS3.com
© 2013, Moog Inc. All Rights Reserved 81-IN5518 111913
EXO Fixed HD Camera System
High Denition Camera Systems for Harsh Environments
EXVF5C-1...................12x optical zoom, Vandal resistant with wall / pole mount, 24Vac or PoE power input
EXPF5C-1...................12x optical zoom, Pressurized with wall / pole mount, 24Vac or PoE power input
EXVF5C12-1...............12x optical zoom, Vandal resistant with wall / pole mount, 12Vdc power input
EXPF5C12-1...............12x optical zoom, Pressurized with wall / pole mount, 12Vdc power input
Installation and Operation Instructions
Before attempting to connect or operate this product,
please read these instructions completely.

IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS
UNPACKING
SERVICE
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with damp cloth.
7 Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions.
8 Cable Runs- All cable runs must be within permissible distance.
9 Mounting - This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit.
Accordingly:
a. This installation should be made by a qualied service person and should conform
to all local codes.
b. Care should be exercised to select suitable hardware to install the unit, taking into
account both the composition of the mounting surface and the weight of the unit.
10 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus ( including ampliers) that produce heat.
11 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
12 Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
13 Only use attachment/ accessories specied by the manufacturer.
14 Use only with a cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
15 Unplug this apparatus during lighting storms or when unused for long periods of time.
16 Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled of objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Be sure to periodically examine the unit and the supporting structure to make sure that the integrity
of the installation is intact. Failure to comply with the foregoing could result in the unit separating
from the support structure and falling, with resultant damages or injury to anyone or anything struck
by the falling unit.
Unpack carefully. Electronic components can be
damaged if improperly handled or dropped. If an item
appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper.
Be sure to save:
1 The shipping carton and packaging material.
They are the safest material in which to make future
shipments of the equipment.
2 These Installation and Operating Instructions.
If technical support or service is needed, contact us at
the following number:
The lightning ash with an arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of non-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk to persons.
Este símbolo se piensa para alertar al usuario a la presencia
del “voltaje peligroso no-aisIado” dentro del recinto de los
productos que puede ser un riesgo de choque eléctrico.
Ce symbole est prévu pour alerter I’utilisateur à la presence
“de la tension dangereuse” non-isolée dans la clôture de
produits qui peut être un risque de choc électrique.
Dieses Symbol soll den Benutzer zum Vorhandensein der
nicht-lsolier “Gefährdungsspannung” innerhalb der
Produkteinschließung alarmieren die eine Gefahr des
elektrischen Schlages sein kann.
Este símbolo é pretendido alertar o usuário à presença “di
tensão perigosa non-isolada” dentro do cerco dos produtos
que pode ser um risco de choque elétrico.
Questo simbolo è inteso per avvertire I’utente alla presenza
“di tensione pericolosa” non-isolata all’interno della
recinzione dei prodotti che può essere un rischio di scossa
elettrica
.
The exclamation point within an equilateral
triangle is intended to alert the user to
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Este símbolo del punto del exclamation se piensa para
alertar al usuario a la presencia de instrucciones importantes
en la literatura que acompaña la aplicación.
Ce symbole de point d’exclamation est prévu pour alerter
l’utilisateur à la presence des instructions importantes dans
la littérature accompagnant l’appareil.
Dieses Ausruf Punktsymbol soll den Benutzer zum
Vorhandensein de wichtigen Anweisungen in der Literatur
alarmieren, die das Gerät begleitet.
Este símbolo do ponto do exclamation é pretendido alertar o
usuário à presença de instruções importantes na literatura
que acompanha o dispositivo.
Questo simbolo del punto del exclamaton è inteso per
avvertire l’utente alla presenza delle istruzioni importanti nella
letteratura che accompagna l'apparecchio.
TECHNICAL SUPPORT
AVAILABLE 24 HOURS
1- 800-554 -1124
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER ( OR BACK). NO USER- SERVICE-
ABLE PARTS INSIDE. REFER SEVICING
TO QUALIFIED SERVICE PERSONNEL.
MADEIN
BUY AMERICA COMPLIANT • COUNTRY OF ORIGIN U.S.A.
USA

Product Warranty Registration
Register Your Products Online
www.moogS3.com/technical-support/product-registration
Moog values your patronage. We are solely committed to providing you with the highest quality products and
superior customer service. With 3-Year and 5-Year warranties (depending on the product purchased) we stand
behind every product we sell.
:
• Simple and Trouble-Free RMA process
• Product / software updates
• Special promotions
• Eliminate the need to archive purchase documents such as receipts, purchase orders,etc.
See full warranty details at www.moogS3.com/technical-support/warranty-plan/

Limited Warranty for Moog Products
Moog - Decatur Operations, subsequently referred to as “Manufacturer,” warrants these products to be free from defects in material or workmanship as follows:
During the labor warranty period, to repair the Product, Purchaser will either return the defective product, freight prepaid, or deliver it to Manufacturer at Moog Decatur
Operations, 2525 Park Central Boulevard, Decatur, Georgia, 30035. The Product to be repaired is to be returned in either its original carton or a similar package affording
an equal degree of protection with a RMA # (Return Materials Authorization number) displayed on the outer box or packing slip. To obtain a RMA# you must contact our
Technical Support Team at 800.554.1124, extension 101. Manufacturer will return the repaired product freight prepaid to Purchaser. Manufacturer is not obligated to
provide Purchaser with a substitute unit during the warranty period or at any time. After the applicable warranty period, Purchaser must pay all labor and/or parts charges.
The limited warranty stated in these product instructions is subject to all of the following terms and conditions.
TERMS AND CONDITIONS
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation
of the claim shall be given promptly by Purchaser to Manufacturer. All claims for warranty service must be made within the warranty period. If after investigation,
Manufacturer determines the reported problem was not covered by the warranty, Purchaser shall pay Manufacturer for the cost of investigating the problem at its then
prevailing per incident billable rate. No repair or replacement of any Product or part thereof shall extend the warranty period of the entire Product. The specic warranty on
the repaired part only shall be in effect for a period of ninety (90) days following the repair or replacement of that part or the remaining period of the Product parts warranty,
whichever is greater.
2. EXCLUSIVE REMEDY: ACCEPTANCE: Purchaser’s exclusive remedy and Manufacturer’s sole obligation is to supply (or pay for) all labor necessary to repair any Product
found to be defective within the warranty period and to supply, at no extra charge, new or rebuilt replacements for defective parts.
3. EXCEPTIONS TO LIMITED WARRANTY: Manufacturer shall have no liability or obligation to Purchaser with respect to any Product requiring service during the warranty
period which is subjected to any of the following: abuse, improper use, negligence, accident, or acts of God (i.e., hurricanes, earthquakes), modication, failure of the
end-user to follow the directions outlined in the product instructions, failure of the end-user to follow the maintenance procedures recommended by the International Security
Industry Organization, written in product instructions, or recommended in the service manual for the Product. Furthermore, Manufacturer shall have no liability where a
schedule is specied for regular replacement or maintenance or cleaning of certain parts (based on usage) and the end-user has failed to follow such schedule; attempted
repair by non-qualied personnel; operation of the Product outside of the published environmental and electrical parameters, or if such Product’s original identication
(trademark, serial number) markings have been defaced, altered, or removed. Manufacturer excludes from warranty coverage Products sold AS IS and/or WITH ALL FAULTS
and excludes used Products which have not been sold by Manufacturer to the Purchaser. All software and accompanying documentation furnished with, or as part of the
Product is furnished “AS IS” (i.e., without any warranty of any kind), except where expressly provided otherwise in any documentation or license agreement furnished with
the Product. ANY COST ASSOCIATED WITH REMOVAL OF DEFECTIVE PRODUCT AND INSTALLATION OF REPLACEMENT PRODUCT IS NOT INCLUDED IN THIS WARRANTY.
4. PROOF OF PURCHASE: The Purchaser’s dated bill of sale must be retained as evidence of the date of purchase and to establish warranty eligibility.
PRODUCT CATEGORY PARTS \ LABOR
All Enclosures and Electronics Five (5) Years
Accessory Brackets Five (5) Years
Controllers Three (3) Years
Power Supplies / IR Illuminators Three (3) Years
Poles / PolEvators™ / CamEvator Three (3) Years
Warrior Series™ / Q-View™Three (3) Years
SView Series™Three (3) Years 6 months if used in auto scan / tour operation
DeputyDome™, NiteTrac™, Igloo Dome, PurgeDome™Three (3) Years 6 months if used in auto scan / tour operation
EXO Series™Dome and Fixed Camera Systems* Three (3) Years 6 months if used in auto scan / tour operation
EXO Series™GeminEye Visible and Thermal Camera Systems One (1) Year
DISCLAIMER OF WARRANTY
EXCEPT FOR THE FOREGOING WARRANTIES, MANUFACTURER HEREBY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO ANY AND/OR ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY WARRANTY WITH REGARD TO ANY
CLAIM OF INFRINGEMENT THAT MAY BE PROVIDED IN SECTION 2-312(3) OF THE UNIFORM COMMERCIAL CODE AND/OR IN ANY OTHER COMPARABLE STATE STATUTE.
MANUFACTURER HEREBY DISCLAIMS ANY REPRESENTATIONS OR WARRANTY THAT THE PRODUCT IS COMPATIBLE WITH ANY COMBINATION OF NON-MANUFACTURER
PRODUCTS OR NON-MANUFACTURER RECOMMENDED PRODUCTS PURCHASER MAY CHOOSE TO CONNECT TO THE PRODUCT.
LIMITATION OF LIABILITY
THE LIABILITY OF Manufacturer, IF ANY, AND PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR DAMAGES FOR ANY CLAIM OF ANY KIND WHATSOEVER, REGARDLESS
OF THE LEGAL THEORY AND WHETHER ARISING IN TORT OR CONTRACT, SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE OF THE PRODUCT WITH RESPECT
TO WHICH SUCH CLAIM IS MADE. IN NO EVENT SHALL MANUFACTURER BE LIABLE TO PURCHASER FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION, REPLACEMENT LABOR COSTS, REIMBURSEMENT, OR DAMAGES ON ACCOUNT OF THE LOSS
OF PRESENT OR PROSPECTIVE PROFITS OR FOR ANY OTHER REASON WHATSOEVER.
* NOTE
Moog will repair or replace, at its option, any equipment which is damaged by transient voltage surge/spike or lightning strike (an “Occurrence”), while properly connected
to wired AC power line with protective ground. Any repair or modication of the equipment done by someone other than Moog voids the warranty.
Form 500-911 081913

The Fixed EXO HD Camera System is designed to accept (3)
different power inputs. They are:
1). PoE - (Factory Ready - EX*F5C-1 models)
2). 24 Volt AC - (Factory Ready - EX*F5C-1 models)
3). 12 Volt DC – (Factory Ready - EX*F5C12-1 models)
PoE Midspan Sold Separately:
MS30WA
30 W midspan, 802.3at compliant, 100-240Vac Input,
3 prong power plug.
El fijo EXO sistema de cámaras HD está diseñada para recibir (3)
entradas de energía diferentes. Ellos son:
1). PoE - (Factory Ready - EX * 1 F5C los modelos)
2). 24 voltios de CA - (Factory Ready - EX * 1 F5C los modelos)
3). 12 Volt DC - (Factory Ready - EX-1 * F5C12 modelos)
PoE Midspan se vende por separado:
MS30WA
30 W midspan, 802.3af compatible, 100-240V de entrada,
3 enchufe clavijas.
Le système de caméra HD EXO fixe est conçu pour accepter (3)
différentes entrées d'alimentation. Ils sont les suivants:
1). PoE - (usine Ready - EX * Les modèles F5C-1)
2). 24 Volt AC - (usine Ready - EX * Les modèles F5C-1)
3). 12 Volt DC - (usine Ready - EX * F5C12-1 modèles)
Injecteur PoE vendu séparément:
MS30WA
30 W mi-portée, 802.3at conforme, 100-240VAC Input,
3 broches prise d'alimentation.
Die Feste EXO HD Camera System wurde entwickelt, um (3)
unterschiedlichen Eingangsleistungen zu akzeptieren. Es sind dies:
1). PoE - (Fabrik Ready - EX * F5C-1-Modelle)
2). 24 Volt AC - (Fabrik Ready - EX * F5C-1-Modelle)
3). 12 Volt DC - (Fabrik Ready - EX * F5C12-1-Modelle)
PoE Midspan Separat erhältlich:
MS30WA
30 W midspan, 802.3at-konform, 100-240VAC Eingang,
3 Zinken Netzstecker.
O EXO Sistema de Câmera HD fixo é projetado para aceitar (3)
entradas de energia diferentes. Eles são:
1). PoE - (Fábrica de Pronto - EX * F5C-1 modelos)
2). 24 Volt AC - (Fábrica de Pronto - EX * F5C-1 modelos)
3). 12 Volts DC - (Fábrica de Pronto - EX * F5C12-1 modelos)
PoE Midspan vendido separadamente:
MS30WA
30 W midspan, 802.3at compatível, 100-240V de entrada,
3 plugue pinos.
Il sistema di telecamere fisse EXO HD è progettato per accettare (3)
ingressi di potenza differenti. Essi sono:
1). PoE - (Fabbrica Pronti - EX * F5C-1 modelli)
2). 24 Volt AC - (Fabbrica Pronti - EX * F5C-1 modelli)
3). 12 Volt DC - (Fabbrica Pronti - EX * F5C12-1 modelli)
Midspan PoE venduti separatamente:
MS30WA
30 W midspan, 802.3at compliant, 100-240Vac Input,
3 spina tripolare.
EXO Fixed
Power Input:
- 24VAC model 30W max. (with heater)
- PoE IEEE 802.3-AT
- 12VDC model 18W max. (with heater)
Entrada de energía:
- 24VAC modelos 30W max. (con calefacción)
- PoE IEEE 802.3-AT
- 12VDC modelos 18W max. (con calentador)
Entrada de energía:
- 24VAC modèles 30W max. (con calefacción)
- PoE IEEE 802.3-AT
- 12VDC modèles 18W max. (con calentador)
Entrada de energía:
- 24VAC Modelle 30W max. (con calefacción)
- PoE IEEE 802.3-AT
- 12VDC Modelle 18W max. (con calentador)
Entrada de energía:
- 24VAC modelos 30W max. (con calefacción)
- PoE IEEE 802.3-AT
- 12VDC modelos 18W max. (con calentador)
Entrada de energía:
- 24VAC modelli 30W max. (con calefacción)
- PoE IEEE 802.3-AT
- 12VDC modelli 18W max. (con calentador)
Electrical Specifications
!!
Français
Deutsch
Italiano
Portuguese
Español
English

Suggested Hardware for the Mounting Holes: (4) 5/16” - 18 (or M8 for metric) x minimum 1 ¼” Hex Head Bolt
• (4) 5/16” Flat Washer • (4) 5/16” Lock Washer
CAUTION: When assembling the mounting bracket,
make sure all the wiring access holes are facing
towards the rear of the base mount.
• PRECAUCIÓN: Al montar la consola de montaje, cerciórese de que todos los
agujeros de acceso del cableado son revestimiento hacia la parte posterior del portal
bajo del acceso de los montaje.
• ATTENTION : En assemblant le support, assurez-vous que toutes les ouvertures
d'accès de câblage sont revêtement vers l'arrière du portail bas d'accès de bâtis.
• VORSICHT: Wenn Sie die Schienenplatte zusammenbauen, stellen Sie sicher, dass
alle VerdrahtungsZugangslöcher Einfassung in Richtung zur Rückseite des niedrigen
Einfassungszugangsportals sind.
• CUIDADO: Ao montar o suporte, certique-se que todos os furos de acesso da ação
são revestimento para a parte traseira do portal baixo do acesso das montagens.
• ATTENZIONE: Nel montare il montaggio - la staffa, si assicura che tutti i fori di
accesso dei collegamenti siano rivestimento verso la parte posteriore del portale
basso di accesso dei supporti.
EXO Fixed
Proper Assembly
of Mounting Bracket
!!
Wiring Access Holes:
Must be rear facing
Base Mount
Contents of Box
Main Camera
Wall Mount
(mount varies based on application)
Hardware Packet:
Mount Gasket
Screws

If running wire through a conduit to the housing mount, rst install
appropriate ttings to the mount base.
• Si se ejecuta a través de un cable de conducto a la carcasa de montaje, primero instale los
accesorios adecuados para la base de montaje.
• Si vous utilisez le câble dans un conduit à la monture logement, installez d'abord raccords
appropriés à la base de monture.
• Wenn Laufen Draht über eine Leitung mit dem Gehäuse montieren, installieren Sie zuerst
geeignete Armaturen an der Halterung Basis.
• Se você estiver executando o através de um canal para a montagem de habitação, primeiro
instale acessórios apropriados à base de montagem.
• Se l'esecuzione del lo attraverso un condotto al monte degli alloggi, prima installare raccordi
appropriati per la base di montaggio.
Attach mount to wall with suitable hardware (not provided).
• Ate el montaje a la pared con el hardware conveniente (no proporcionado).
• Attachez le bâti au mur avec le matériel approprié (non fourni).
• Bringen Sie Einfassung zur Wand mit der verwendbaren Hardware an (nicht bereitgestellt).
• Una a montagem à parede com a ferragem apropriada (não fornecida).
• Attacchi il supporto alla parete con ssaggi adatti (non forniti).
If attaching to pole, rst break away tabs with pliers and remove
(4) strap plugs.
• Si atan al poste, el primeros rompen lejos lengüetas con los alicates y quitan (4) los enchufes
de la correa.
• Si attachant au poteau, les premiers cassent loin des étiquettes avec des pinces et enlèvent
(4) des prises de courroie.
• Bei der Befestigung zum Pfosten, brechen erste weg Vorsprünge mit Zangen und entfernen
(4) Bügelstecker.
• Se unindo ao pólo, o primeiros quebram afastado abas com alicates e removem (4) plugues
da cinta.
• Se attaccando al palo, i primi rompono via le linguette con le pinze e rimuovono (4) la cinghia
tappa.
TAB
POLE MOUNTING
WALL MOUNTING
12
3
Thread straps (not provided) through the mount as shown.
• Pase las correas (no incluidos) a través del soporte como se muestra.
• Sangles de la discussion (non fournies) dans le support comme indiqué.
• Themen-Riemen (nicht mitgeliefert) durch die Halterung wie gezeigt.
• Correias do Tópico (não fornecidos) através da montagem imediata.
• Cinghie di discussione (non in dotazione) attraverso il supporto come illustrato.
4

Crimp the connectors as needed. Then use cable ties
on the nipples to secure, leave an extra 2” of cable.
• Crimp los conectores según sea necesario. A continuación, utilice bridas para cables en los
pezones para asegurar, deje un 2 extra "del cable.
• Sertir les connecteurs si nécessaire. Ensuite, utiliser des attaches câbles sur les mamelons
pour sécuriser, laisser un 2 supplémentaire "de câble.
• Crimp die Anschlüsse je nach Bedarf. Dann nutzen Sie Kabelbindern an den Brustwarzen zu
sichern, lassen einen zusätzlichen 2 "Kabel.
• Cravar os conectores conforme necessário. Em seguida, use abraçadeiras nos mamilos para
garantir, deixe um 2 extra "de cabo.
• Crimpare i connettori se necessario. Quindi utilizzare fascette sui capezzoli per ssare, lasciare
un 2 in più "di cavo.
Cable
Crimp
Cable Ties
Pierce the gasket nipples (as needed). Place the gasket as shown.
Pass wires without connectors thru gasket and nipples.
• Alimente el cable a través del soporte, perfore las entrerroscas de la junta (según lo necesitado).
Coloque la junta como se muestra.
• Alimentez le câble par la parenthèse, percez les mamelons de garniture (comme nécessaire).
Placez la garniture comme montrée.
• Ziehen Sie Kabel durch Haltewinkel ein, durchbohren Sie die Dichtungsnippel (wie gebraucht).
Setzen Sie die Dichtung wie gezeigt.
• Alimente o cabo através do suporte, perfure os bocais da gaxeta (como necessário). Coloc a
gaxeta como mostrada.
• Alimenti il cavo tramite la staffa, perfori gli ugelli della guarnizione (come stato necessario).
Disponga la guarnizione come indicata.
Cable
Gasket Nipples
56
Place the camera on the bracket, carefully feed the wires and connectors through the housing and into the rear cavity.
Use the provided captive screws and the 5mm Allen key (included) to mount.
• Coloca la carcasa en el soporte, se alimentan cuidadosamente los cables y conectores a través del alojamiento y dentro de la cavidad trasera. Use los tornillos suministrados y la llave Allen de 5 mm (incluido) para montar.
• Placer le boîtier sur le support, nourrir soigneusement les câbles et les connecteurs à travers le boîtier et dans la cavité arrière. Utilisez les vis imperdables fournies et la clé Allen de 5mm (inclus) pour monter.
• Legen Sie das Gehäuse auf der Konsole, es vorsichtig die Kabel und Stecker durch das Gehäuse und in den hinteren Hohlraum. Verwenden Sie die mitgelieferten unverlierbaren Schrauben und die 5mm
Inbusschlüssel (im Lieferumfang) zu montieren.
• Colocar a caixa do suporte, com cuidado alimentar os os e ligações através do invólucro e para dentro da cavidade traseira. Use os parafusos fornecidos ea chave Allen de 5 mm (incluído) para montar.
• Posizionare la custodia sulla staffa, fare avanzare i cavi e connettori attraverso l'alloggiamento e nella cavità posteriore. Utilizzare le viti fornite e la chiave Allen da 5 mm (in dotazione) per montare.
7
Pole or Wall Mount (Use Steel Straps to Mount to Pole)

Make all nal connections in the rear cavity. To do so, rotate the rear cover by slightly loosing the screw marked (A) and completely loosing the
screw marked (B). Then, make all of the necessary wiring connections. If using 24Vac (or 12Vdc for 12V model) ensure the power select switch
is turned to “OTHER”. If using a PoE device to power the unit, ensure the power select switch is turned to “POE” (24Vac models only).
• Haga todas las conexiones nales en la cavidad trasera. Para ello, gire la tapa trasera ligeramente perder el tornillo con la marca (A) y perder por completo el tornillo con la marca (B). A continuación, hacer que
todas las conexiones de cableado necesarias. Si utiliza 24Vac (o 12Vdc para el modelo 12V) garantizar el selector de alimentación está en la posición "OTRO". Si se utiliza un dispositivo PoE para alimentar la
unidad, asegúrese que el interruptor de selección de alimentación está en la posición "POE" (Sólo 24Vac modelos).
• Assurez-vous que toutes les connexions nales dans la cavité arrière. Pour ce faire, faites pivoter le couvercle arrière en perdre un peu la vis marquée (A) et de perdre complètement la vis marquée (B). Ensuite,
faire tous les raccordements nécessaires. Si vous utilisez 24Vac (ou 12V pour le modèle 12V) assurer le sélecteur d'alimentation est mis à "AUTRE". Si vous utilisez un dispositif PoE pour alimenter l'appareil
s'assurer que le sélecteur d'alimentation est mis à «POE» (24Vac modèles uniquement).
• Stellen Sie alle Verbindungen in der letzten hinteren Hohlraum. Um dies zu tun, drehen Sie den hinteren Deckel durch leichtes Lösen Sie die Schraube (A) gekennzeichnet und vollständig verlieren die Schraube
markiert (B). Dann machen Sie alle notwendigen Kabelverbindungen. Bei Verwendung 24Vac (oder 12Vdc für 12V-Modell) sicherzustellen, dass die Power-Select-Schalter auf "OTHER" drehte. Wenn ein
PoE-Gerät, um das Gerät sicher, dass das Power-Select-Schalter auf "POE" eingeschaltet ist (24Vac Modelle).
• Faça todas as conexões nais na cavidade traseira. Para fazer isso, rodar a tampa traseira ligeiramente por afrouxar o parafuso assinalados com (A) e afrouxar o parafuso completamente marcadas (B). Então,
faça todas as ligações que são necessárias. Se estiver usando 24Vac (ou 12Vdc para o modelo 12V) assegurar o interruptor de seleção é ligada a "outro". Se estiver usando um dispositivo PoE para ligar a
unidade, certique-se a chave seletora de energia está voltada para "POE" (Apenas 24VAC modelos).
• Effettuare tutti i collegamenti nali nella cavità posteriore. Per fare ciò, ruotare il coperchio posteriore leggermente allentando la vite contrassegnata (A) e di sciogliere completamente la vite contrassegnata (B).
Poi, fare tutti i collegamenti necessari. Se utilizzando 24Vac (o 12Vdc per il modello 12V) garantire il selettore di accensione su "ALTRO". Se si utilizza un dispositivo PoE per alimentare l'unità, assicurarsi che
l'interruttore di selezione si accende di "POE" (Solo 24Vac modelli).
(A- Slightly loosen)
(B- Completely loosen)
FACING REAR OF CAMERA
STEP
1
STEP
2
Speaker Audio
Ground Line
Detail M
(+)
Alarm
in1
Alarm
in2 in
POWER INPUT
RJ45 / PoE Input
DETAIL
M
DETAIL
N
Power Select Switch
POE
OTHER
DATA
INPUT/
OUTPUT
Detail N*
Ground24Vac
12Vdc
AC (NEU)
DC (-)
AC (Live)
DC (+)
* NOTE: Power input is set at the factory.
EX*F5C-1 models are factory set to 24Vac or PoE input.
EX*F5C12-1 models are factory set to 12Vdc input (ONLY).
8

The micro SD card slot is found at the front of
the camera, just under the camera on the lower
board.
• Inserte la tarjeta SD.
• Insérez la carte SD.
• Legen Sie die SD-Karte.
• Insira o cartão SD.
• Inserire la scheda SD.
Recommended micro SD card sizes
MIN: 2GB
MAX: 32GB
* Recommended Class 10 rated card
5mm
Allen
Wrench
USE FORCE TO SPERATE
Thoroughly loosen the (2) captive screws (shown in DETAIL A) with provided 5mm Allen Key (included) to remove the front part of the camera system.
• Completamente aoje los dos (2) tornillos (que se muestra en detalle A) con la llave Allen de 5 mm suministrado (incluido) para quitar la parte frontal del sistema de cámaras.
• Complètement desserrer l'(2) vis imperdables (représenté en détail A) avec fourni 5mm Clé Allen (inclus) pour retirer la partie avant du système de caméra.
• Gründlich lockern die (2) unverlierbaren Schrauben (im Detail gezeigt A) versehen mit 5mm Inbusschlüssel (im Lieferumfang enthalten), um den vorderen Teil des Kamera-System zu entfernen.
• Completamente soltar a (2) parafusos (mostrados em detalhe A) fornecido com cinco milímetros Chave Allen (incluído) para remover a parte da frente do sistema de câmera.
• Accuratamente allentare la (2) viti di ssaggio (mostrato in dettaglio A) fornito con 5 millimetri chiave a brugola (inclusa) per rimuovere la parte anteriore del sistema di telecamere.
ALLEN
WRENCH
HOLE
SLOTS
________DETAIL A___________
FACING REAR OF ENCLOSURE
See
DETAIL A
FIRST: MAKE SURE UNIT IS POWERED OFF COMPLETELY
To Access the Micro SD Card Slot:
!!
B
9A
FIRST: MAKE SURE UNIT IS POWERED OFF COMPLETELY
To Access the Micro SD Card Slot:
!!
Loosen (2) screws

When pressurizing unit be sure to set the gauge or regulator
slightly above the housing pressure target of 5-7psi (0.35-0.5bar).
• Al presurizar la unidad esté seguro de jar el calibrador o el regulador levemente
sobre la blanco de la presión de la cubierta de 5-7psi (0.35-0.5bar).
• En pressurisant l'unité soyez sûr de placer la mesure ou le régulateur légèrement
au-dessus de la cible de pression de logement de 5-7psi (0.35-0.5bar).
• Wenn Sie Maßeinheit unter Druck setzen, seien Sie sicher, die Lehre oder den
Regler über das Gehäusedruckziel von 5-7psi (0.35-0.5bar) etwas einzustellen.
• Ao pressurizar a unidade seja certo ajustar ligeiramente o calibre ou o regulador
acima do alvo da pressão da carcaça de 5-7psi (0.35-0.5bar).
• Nel pressurizzare l'unità sia sicuro regolare un po'il calibro o il regolatore sopra
l'obiettivo di pressione dell'alloggiamento di 5-7psi (0.35-0.5bar).
PSI
0
50
100
150
200
250
300
Nitrogen
Tank
Hose
Regulator
Air Chuck
10
Pressurize the Unit (NOT required for the Non-Pressurized Vandal Unit)
Pressure Fill Schraeder Valve
Air Chuck
Place the air chuck on the ll valve
and begin lling with inert gas such
as nitrogen until pressure relief
valve opens.
• Coloque la tirada del aire en la válvula del tanque y
comience a llenar hasta que la válvula de descarga
de presión se abra.
• Placez le mandrin d'air sur la valve de réservoir et
commencez à remplir jusqu'à ce que la valve de
décompression s'ouvre.
• Setzen Sie die Luftklemme auf das Behälterventil
und fangen Sie an zu füllen, bis Druckablassventil
sich öffnet.
• Coloc o mandril do ar na válvula do tanque e
comece a encher-se até que a válvula de escape de
pressão abra.
• Disponga il mandrino dell'aria sulla valvola del carro
armato e cominci a riempire no a che la valvola
limitatrice della pressione non si apra.
Over Relief Valve
(5-7psi)
Pressurize the Unit Cont.
11
Reinstall front of enclosure and tighten the (2) screws from
step 9A.
• Vuelva a instalar delante del gabinete y apriete los (2) tornillos del paso 9A.
• Réinstaller l'avant de l'enceinte et serrer les vis (2) de l'étape 9A.
• Installieren Sie vor der Gehäuse und ziehen Sie die (2) Schrauben aus Schritt 9A.
• Installieren Sie vor der Gehäuse und ziehen Sie die (2) Schrauben aus Schritt 9A.
• Reinstallare Frontale della custodia e stringere le (2) viti dal passo 9A.
C

Depress the ll valve. Drain all air
from the housing and repeat 3 times
to remove all moisture.
• Presione la válvula del terraplén. Salga todo el aire
de la cubierta y de la repetición 3 veces de quitar
toda la humedad.
• Enfoncez la valve de sufsance. Évacuez tout l'air le
logement et la répétition 3 fois d'enlever toute
l'humidité.
• Drücken Sie das Fülleventil nieder. Lassen Sie alle
Luft aus dem Gehäuse und der Wiederholung 3mal,
alle Feuchtigkeit zu entfernen ab.
• Comprima a válvula da suciência. Saia todo o ar da
carcaça e da repetição 3 vezes remover toda a
umidade.
• Deprima la valvola del materiale di riempimento.
Tolga tutta l'aria dall'alloggiamento e dalla
ripetizione 3 volte rimuovere tutta l'umidità.
Depress to Purge
Pressure Fill Schraeder Valve
12
After purging and relling, check
the housings pressure. It should be
around 5-7psi (0.35-0.5bar).
• Después de purgar y de rellenar, compruebe la
presión de las cubiertas. Debe estar alrededor de
5-7psi (0.35-0.5bar).
• Après la purge et le remplissage, vériez la pression
de logements. Elle devrait être autour de 5-7psi
(0.35-0.5bar).
• Nachdem Sie bereinigt haben und wieder gefüllt
haben überprüfen Sie den Gehäusedruck. Er sollte
um 5-7psi (0.35-0.5bar) sein.
• Após a remoção e o reenchimento, veric a pressão
das carcaças. Deve ser em torno de 5-7psi
(0.35-0.5bar).
• Dopo l'eliminazione dell'inceppo ed il riempimento,
controlli la pressione degli alloggiamenti. Dovrebbe
essere intorno a 5-7psi (0.35-0.5bar).
Over - Pressure
Relief Valve
Connectors
PSI
0
5
10
15
20
25
30
Fill Valve Pressure Gauge
NOT INCLUDED
Air Chuck
13

Replacement Parts List
EXO Fixed HD Camera
FRONT BODY ASSEMBLY
with WINDOW included
RP40-EXFF01 (PRESSURIZED)
RP40-EXFF02 (VANDAL RESISTANT)
WINDOW
RP30-VL4489 (PRESSURIZED)
RP30
-VL4464 (VANDAL RESISTANT)
REAR BODY ASSEMBLY
CONTACT MOOG FOR REPAIR/REPLACEMENT
EXFRP01
EXFRV01
WALL MOUNT GASKE
T
RP96-GK3880
WALL MOUNT ASSEMBLY
RP40-PFHWMG
If the pressure in housing is more
than 5-7psi, drain the valve until
you reach the specied level of
5-7psi.
• Si la presión en la vivienda es más que el 5-7 psi,
la válvula de desagüe hasta que llegue al nivel
especicado de 5-7 psi.
• Si la pression dans le logement est plus que 5-7 psi,
vidanger le robinet jusqu'à ce que vous atteignez le
niveau spécié de 5-7 psi.
• Wenn der Druck im Gehäuse ist mehr als 5-7psi,
lassen Sie das Ventil, bis Sie die angegebene Höhe
der 5-7psi erreichen.
• Se a pressão na carcaça é mais do que 5 7psi,
escorra a válvula até chegar ao nível especicado
de 5-7psi.
• Se la pressione nel contenitore è superiore a 5-7psi,
la valvola di scarico no a raggiungere il livello
specicato di 5-7psi.
Depress to Purge
Pressure Fill Schraeder Valve
14

TABLE OF CONTENTS
Software Sections
Moog Discovery Tool ...................................................... ..................................................................................................... 1.0.0
