Moog EXSS7C2-2 User manual

EXO Corrosion Resistant HD Camera
High Denition Network Camera Systems for Harsh Environments
EXSS7C2-2 Stainless Steel 1080P HD PTZ camera system, 20x optic zoom, H.264 support, ONVIF, extended temperature range, surge protection
EXSS7C2-3 Stainless Steel 1080P HD PTZ camera system, 30x optic zoom, H.264 support, ONVIF, extended temperature range, surge protection
EXSP7C2-2 Stainless Steel Pressurized 1080P HD PTZ camera system, 20x optic zoom, H.264 support, ONVIF, extended temperature range,
surge protection
Installation and Operation Instructions
Before attempting to connect or operate this product, please read these instructions completely.
Moog Inc. •Sensor and Surveillance Systems •2525 Park Central Boulevard, Decatur, GA 30035 USA •+1 770.987.7550 •www.moogS3.com
© 2013, Moog Inc. All Rights Reserved
81-IN5513 06/24/13

IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS
UNPACKING
SERVICE
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with damp cloth.
7 Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions.
8 Cable Runs- All cable runs must be within permissible distance.
9 Mounting - This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit.
Accordingly:
a. This installation should be made by a qualied service person and should conform
to all local codes.
b. Care should be exercised to select suitable hardware to install the unit, taking into
account both the composition of the mounting surface and the weight of the unit.
10 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus ( including ampliers) that produce heat.
11 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
12 Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
13 Only use attachment/ accessories specied by the manufacturer.
14 Use only with a cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
15 Unplug this apparatus during lighting storms or when unused for long periods of time.
16 Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled of objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Be sure to periodically examine the unit and the supporting structure to make sure that the integrity
of the installation is intact. Failure to comply with the foregoing could result in the unit separating
from the support structure and falling, with resultant damages or injury to anyone or anything struck
by the falling unit.
Unpack carefully. Electronic components can be
damaged if improperly handled or dropped. If an item
appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper.
Be sure to save:
1 The shipping carton and packaging material.
They are the safest material in which to make future
shipments of the equipment.
2 These Installation and Operating Instructions.
If technical support or service is needed, contact us at
the following number:
The lightning ash with an arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of non-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk to persons.
Este símbolo se piensa para alertar al usuario a la presencia
del “voltaje peligroso no-aisIado” dentro del recinto de los
productos que puede ser un riesgo de choque eléctrico.
Ce symbole est prévu pour alerter I’utilisateur à la presence
“de la tension dangereuse” non-isolée dans la clôture de
produits qui peut être un risque de choc électrique.
Dieses Symbol soll den Benutzer zum Vorhandensein der
nicht-lsolier “Gefährdungsspannung” innerhalb der
Produkteinschließung alarmieren die eine Gefahr des
elektrischen Schlages sein kann.
Este símbolo é pretendido alertar o usuário à presença “di
tensão perigosa non-isolada” dentro do cerco dos produtos
que pode ser um risco de choque elétrico.
Questo simbolo è inteso per avvertire I’utente alla presenza
“di tensione pericolosa” non-isolata all’interno della
recinzione dei prodotti che può essere un rischio di scossa
elettrica
.
The exclamation point within an equilateral
triangle is intended to alert the user to
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Este símbolo del punto del exclamation se piensa para
alertar al usuario a la presencia de instrucciones importantes
en la literatura que acompaña la aplicación.
Ce symbole de point d’exclamation est prévu pour alerter
l’utilisateur à la presence des instructions importantes dans
la littérature accompagnant l’appareil.
Dieses Ausruf Punktsymbol soll den Benutzer zum
Vorhandensein de wichtigen Anweisungen in der Literatur
alarmieren, die das Gerät begleitet.
Este símbolo do ponto do exclamation é pretendido alertar o
usuário à presença de instruções importantes na literatura
que acompanha o dispositivo.
Questo simbolo del punto del exclamaton è inteso per
avvertire l’utente alla presenza delle istruzioni importanti nella
letteratura che accompagna l'apparecchio.
TECHNICAL SUPPORT
AVAILABLE 24 HOURS
1- 800-554 -1124
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER ( OR BACK). NO USER- SERVICE-
ABLE PARTS INSIDE. REFER SEVICING
TO QUALIFIED SERVICE PERSONNEL.
MADEIN
BUY AMERICA COMPLIANT • COUNTRY OF ORIGIN U.S.A.
USA

Limited Warranty for Moog Products
Moog - Decatur Operations, subsequently referred to as “Manufacturer,” warrants these products to be free from defects in material or workmanship as follows:
During the labor warranty period, to repair the Product, Purchaser will either return the defective product, freight prepaid, or deliver it to Manufacturer at Moog, Decatur
Operations, 2525 Park Central Boulevard, Decatur, Georgia, 30092. The Product to be repaired is to be returned in either its original carton or a similar package affording
an equal degree of protection with a RMA # (Return Materials Authorization number) displayed on the outer box or packing slip. To obtain a RMA# you must contact our
Technical Support Team at 800.554.1124, extension 101. Manufacturer will return the repaired product freight prepaid to Purchaser. Manufacturer is not obligated to
provide Purchaser with a substitute unit during the warranty period or at any time. After the applicable warranty period, Purchaser must pay all labor and/or parts charges.
The limited warranty stated in these product instructions is subject to all of the following terms and conditions.
TERMS AND CONDITIONS
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation
of the claim shall be given promptly by Purchaser to Manufacturer. All claims for warranty service must be made within the warranty period. If after investigation,
Manufacturer determines the reported problem was not covered by the warranty, Purchaser shall pay Manufacturer for the cost of investigating the problem at its then
prevailing per incident billable rate. No repair or replacement of any Product or part thereof shall extend the warranty period of the entire Product. The specic warranty on
the repaired part only shall be in effect for a period of ninety (90) days following the repair or replacement of that part or the remaining period of the Product parts warranty,
whichever is greater.
2. EXCLUSIVE REMEDY: ACCEPTANCE: Purchaser’s exclusive remedy and Manufacturer’s sole obligation is to supply (or pay for) all labor necessary to repair any Product
found to be defective within the warranty period and to supply, at no extra charge, new or rebuilt replacements for defective parts.
3. EXCEPTIONS TO LIMITED WARRANTY: Manufacturer shall have no liability or obligation to Purchaser with respect to any Product requiring service during the warranty
period which is subjected to any of the following: abuse, improper use, negligence, accident, lightning damage or other acts of God (i.e., hurricanes, earthquakes),
modication, failure of the end-user to follow the directions outlined in the product instructions, failure of the end-user to follow the maintenance procedures recommended
by the International Security Industry Organization, written in product instructions, or recommended in the service manual for the Product. Furthermore, Manufacturer
shall have no liability where a schedule is specied for regular replacement or maintenance or cleaning of certain parts (based on usage) and the end-user has failed to
follow such schedule; attempted repair by non-qualied personnel; operation of the Product outside of the published environmental and electrical parameters, or if such
Product’s original identication (trademark, serial number) markings have been defaced, altered, or removed. Manufacturer excludes from warranty coverage Products sold
AS IS and/or WITH ALL FAULTS and excludes used Products which have not been sold by Manufacturer to the Purchaser. All software and accompanying documentation
furnished with, or as part of the Product is furnished “AS IS” (i.e., without any warranty of any kind), except where expressly provided otherwise in any documentation or
license agreement furnished with the Product. ANY COST ASSOCIATED WITH REMOVAL OF DEFECTIVE PRODUCT AND INSTALLATION OF REPLACEMENT PRODUCT IS NOT
INCLUDED IN THIS WARRANTY.
4. PROOF OF PURCHASE: The Purchaser’s dated bill of sale must be retained as evidence of the date of purchase and to establish warranty eligibility.
PRODUCT CATEGORY PARTS \ LABOR
All Enclosures and Electronics* Five (5) Years
Accessory Brackets Five (5) Years
Controllers Three (3) Years
Power Supplies / IR Illuminators Three (3) Years
Poles / PolEvators™ / CamEvator Three (3) Years
Warrior Series™ / Q-View™Three (3) Years
SView Series™Three (3) Years **6 months if used in auto scan/tour operation
DeputyDome™, NiteTrac™, Igloo Dome, PurgeDome™Three (3) Years **6 months if used in auto scan/tour operation
EXO Series™Dome and Fixed Camera Systems Three (3) Years **6 months if used in auto scan/tour operation
DISCLAIMER OF WARRANTY
EXCEPT FOR THE FOREGOING WARRANTIES, MANUFACTURER HEREBY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO ANY AND/OR ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY WARRANTY WITH REGARD TO ANY
CLAIM OF INFRINGEMENT THAT MAY BE PROVIDED IN SECTION 2-312(3) OF THE UNIFORM COMMERCIAL CODE AND/OR IN ANY OTHER COMPARABLE STATE STATUTE.
MANUFACTURER HEREBY DISCLAIMS ANY REPRESENTATIONS OR WARRANTY THAT THE PRODUCT IS COMPATIBLE WITH ANY COMBINATION OF NON-MANUFACTURER
PRODUCTS OR NON-MANUFACTURER RECOMMENDED PRODUCTS PURCHASER MAY CHOOSE TO CONNECT TO THE PRODUCT.
LIMITATION OF LIABILITY
THE LIABILITY OF Manufacturer, IF ANY, AND PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR DAMAGES FOR ANY CLAIM OF ANY KIND WHATSOEVER, REGARDLESS
OF THE LEGAL THEORY AND WHETHER ARISING IN TORT OR CONTRACT, SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE OF THE PRODUCT WITH RESPECT
TO WHICH SUCH CLAIM IS MADE. IN NO EVENT SHALL MANUFACTURER BE LIABLE TO PURCHASER FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION, REPLACEMENT LABOR COSTS, REIMBURSEMENT, OR DAMAGES ON ACCOUNT OF THE LOSS
OF PRESENT OR PROSPECTIVE PROFITS OR FOR ANY OTHER REASON WHATSOEVER.
Form 500-911 0413

Contents of Box
24 VAC
3.2 Amps
Total Power: 75 Watts
Tools Required: .100” Flat Head Screwdriver
Phillips Head Screwdriver
7/16” Wrench or Socket
24 VAC
3.2 amperios
Energía Total: 75 vatios
Las Herramientas Requirieron: Destornillador Principal Plano Del 100"
Destornillador Principal Phillips
24 VCA
3.2 ampères
Puissance Totale : 75 watts
Les Outils besoin : Tournevis Principal Plat De 100"
Tournevis Principal Phillips
24 VAC
3.2 Ampere
Gesamtenergie: 75 Watt
Werkzeuge Erforderten: 100"Flacher Hauptschraubenzieher
Kreuzkopfhauptschraubenzieher
24 VAC
3.2 ampères
Poder Total: 75 watts
As Ferramentas Requereram: Chave de fenda Principal Lisa Do 100"
Chave de fenda Principal Phillips
24 VAC
3.2 ampère
Alimentazione Totale: 75 watt
Attrezzi Richiesti: Cacciavite Capo Piano Del 100"
Cacciavite Capo "phillips"
Electrical Specifications
Power 24VAC
Class 2 Only
!!
EXPF7
EXSS7
EXSP7
EXRHW(P)7
Français
Deutsch
Italiano
Portuguese
Español
English
Remove Insert
From Dome

Wall mount bracket is designed for straight conduit. If
this tting is desired, install it rst. Otherwise, use the
thru mount wiring provision.
• Soporte de pared está diseñado para conducción recta. Si se desea
este ajuste, se debe instalar primero. De lo contrario, utilice el
suministro de cableado de montaje a través.
• Support mural est conçu pour les conduit tout droit. Si cette mise en
place est souhaitée, d'abord l'installer. Sinon, utilisez la mise à
disposition de câblage montage par.
• Wandhalterung ist für gerade Leitung entworfen. Wenn diese Montage
gewünscht wird, installieren Sie es zuerst. Andernfalls verwenden Sie
den Mount-thru Verdrahtung Bestimmung.
• Suporte de parede é projetado para canal em linha reta. Se esse ajuste
for desejada, instalá-lo primeiro. Caso contrário, use o fornecimento de
ação através de montagem.
• Staffa di montaggio a parete è progettato per tubo dritto. Se si desidera
questa tting, installare prima. In caso contrario, utilizzare la fornitura di
cablaggio attraverso mount.
1” Straight Conduit
Trim wires no longer than 5” outside mount.
• Alambres del ajuste no más que” montaje del exterior 5.
• Fils d'équilibre plus que » bâti de l'extérieur 5.
• Ordnungsdrähte nicht mehr als“ Einfassung der Außenseite 5.
• Fios da guarnição já não do que da” montagem parte externa 5.
• Legare della disposizione più che„ supporto della parte esterna 5.
5”
1
3
If required, install provided sunshield with
phillips screwdriver.
• Si procede, instale el sunshield proporcionado con
destornillador Phillips.
• S'il y a lieu, installez le sunshield fourni avec le tournevis Phillips.
• Wenn erforderlich bringen Sie zur Verfügung gestelltes sunshield
mit Kreuzkopfschraubenzieher an.
• Se requerido, instale o sunshield fornecido com chave de fenda Phillips.
• A richiesta, installi il sunshield fornito con il cacciavite "phillips".
X3 PLACES
Run connection wires through mount and attach to wall
with suitable mounting hardware.
• Funcione con los alambres de la conexión a través del montaje y
átelos a la pared con hardware de montaje conveniente.
• Courez les ls de raccordement par le bâti et les attachez au mur
avec le matériel de support approprié.
• Lassen Sie Anschlussdrähte durch Einfassung laufen und bringen
Sie zur Wand mit verwendbarer Montage-Hardware an.
• Funcione os da conexão através da montagem e una-os à parede
com ferragem de montagem apropriada.
• Faccia funzionare i legare del collegamento tramite il supporto ed
attacchi alla parete con i ssaggi di montaggio adatti.
1
2
4
➟

2
GND Green/White
RJ45
24VAC
1
3
24Vac
24Vac
Red
Orange
POWER
75 Watts
AUDIO
1
2
3
Speaker +
Audio GND
MIC +
Gray
Brown
White
ALARM
1
2
Alarm IN
GND
Blue
Violet
A
B
C
D
BCD
A
Make the appropriate male and female connections.
• Haga las conexiones masculinas y femeninas apropiadas.
• Établissez les rapports masculins et femelles appropriés.
• Stellen Sie die passenden männlichen und weiblichen Beziehungen her.
• Faça as conexões masculinas e fêmeas apropriadas.
• Faccia i collegamenti maschii e femminili adatti.
Complete all wiring connections.
• Termine todas las conexiones del cableado.
• Accomplissez tous les raccordements de câblage.
• Schließen Sie alle Verdrahtungsanschlüsse ab.
• Termine todas as conexões da ação.
• Completi tutti i collegamenti dei collegamenti.
Secure lanyard from dome housing to clip on
wall mount.
• Acollador seguro de la bóveda que contiene al clip en el
montaje de la pared.
• Lanière bloquée du dôme logeant à l'agrafe sur le bâti de mur.
• Sichere Abzuglinie von der Haube, die zum Klipp auf Wandeinfassung
unterbringt.
• Colhedor seguro da abóbada que abriga ao grampo na montagem
da parede.
• Cordicella sicura dalla cupola che alloggia alla clip sul supporto
della parete.
56
7

Disconnect cables, and remove
Pan / Tilt from base bracket in housing.
• Desconecte los cables y retire la cacerola / de la inclinación
del soporte de base en materia de vivienda.
• Débranchez les câbles, puis retirez Pan / Tilt de support de
base en matière de logement.
• Ziehen Sie die Kabel, und entfernen Pan / Tilt aus Grundträger
im Gehäuse.
• Desconecte os cabos e remover Pan / Tilt do suporte de
base em habitação.
• Scollegare i cavi e rimuovere Pan / Tilt dalla staffa base in custodia.
Power Network Cables
CAPTIVE SCREW
To remove, loosen captive screw.
• Para quitarlo, tornillo cautivo suelto.
• Pour l'enlever, vis captive lâche.
• Zum Entfernen loser unverlierbare Schraube.
• Para remover, parafuso solto.
• Per rimuovere, sciolto vite imperdibile.
Engage the thread and rotate housing assembly
clockwise into wall mount tting until tight.
• Enganche el hilo y gire conjunto de la caja hacia la derecha en el
accesorio de montaje en pared hasta que quede apretado.
• Engager le l et tourner ensemble boîtier dans le sens horaire dans
le raccord mural en serrant bien.
• Aktivieren Sie den Faden und drehen Gehäuse Baugruppe in
Wandhalterung passend bis im Uhrzeigersinn fest.
• Envolver o o e gire no sentido horário em conjunto da carcaça
de montagem montagem na parede até apertado.
• Inserire il lo e ruotare in senso orario nel gruppo alloggiamento
Lato montaggio a parete no stretto.
Fasten trim ring assembly to main housing
with a phillips screwdriver.
• Sujete el montaje del anillo del ajuste a la cubierta principal
con un destornillador Phillips.
• Attachez l'anneau d'équilibre au logement principal avec un
tournevis Phillips.
• Befestigen Sie OrdnungsRing am Hauptgehäuse mit einem
Kreuzkopfschraubenzieher.
• Prenda o conjunto do anel da guarnição à carcaça principal
com uma chave de fenda Phillips.
• Fissi l'assemblea dell'anello della disposizione ad alloggiamento
principale con un cacciavite "phillips".
X3 PLACES
8
10
9
11

After Camera installation. Attach lanyard to the
trim ring assembly.
• Después de la instalación de la cámara. Ate el acollador al montaje
del anillo del ajuste.
• Après installation d'appareil-photo. Attachez la lanière à l'anneau
d'équilibre.
• Nach Kamerainstallation. Bringen Sie Abzuglinie zum OrdnungsRing an.
• Após a instalação da câmera. Una o colhedor ao conjunto do anel
da guarnição.
• Dopo l'installazione della macchina fotograca. Attacchi la cordicella
all'assemblea dell'anello della disposizione.
SD card slot is located at the base
of Pan / Tilt unit.
• Ranura para tarjetas SD se encuentra en la base? De la unidad
Pan / Tilt.
• Fente pour carte SD se trouve à la base? De l'unité de Pan / Tilt.
• SD-Kartensteckplatz an der Basis liegt der Pan / Tilt-Einheit.
• Slot para cartão SD está localizado na base? De Pan / Tilt unidade.
• Slot per scheda SD si trova alla base? Del Pan / Tilt unità.
SD Card Slot
SD card slot is located at the base of Pan / Tilt unit.
• Ranura para tarjetas SD se encuentra en la base? De la unidad
Pan / Tilt.
• Fente pour carte SD se trouve à la base? De l'unité de Pan / Tilt.
• SD-Kartensteckplatz an der Basis liegt der Pan / Tilt-Einheit.
• Slot para cartão SD está localizado na base? De Pan / Tilt unidade.
• Slot per scheda SD si trova alla base? Del Pan / Tilt unità.
SD Card
1312
14

Replacement Parts List
PART NUMBER PRODUCT DISCRIPTION
1 RPVL4025 HOUSING
2 RP76VL2024 SURGE/CONNECTION PCB
3 RPVL3414 HGS BKT
4A RP762030 PCB NETWORK DAUGHTER PCB 4B RP76ENE100 PCB-NETWORK CARD PCB
5 RPFD072 HEATER 24VAC
6 RPFD080 BLOWER 7 RPVL4106 EXO BASE BKT 8 RP762021 TILT PCB 9 RPEX4281 LINER ASSEMBLY 2 PARTS
10 RPVL4028 CLAMPING RING(S)
11 RP96RSRG16 INNER O-RING 8"
12 RP96RS0RG23 OUTER O-RING 9"
13 CLEAR NYLON DOME 14 RPVL4024 STAINLESS LOWER TRIM RING
N/S RPVL4029 SUNSHIELD

SOFTWARE SETUP
1.0.0 Moog Discovery Tool
By factory default, the Moog EXO Camera is congured in DHCP. If you are not using a DHCP server it will automatically allocate itself
an APIPA (Automatic Private IP Addressing) address in the range 169.254.0.1 to 169.254.255.254 with subnet mask 255.255.0.0.
Initial device network conguration is done via the Moog Discovery Tool (MDT), a tool provided by Moog that can be found on the
company’s web site and on the ash drive supplied with each camera system. The ash drive also contains a copy of Microsoft
Silverlight 5. Both programs should be installed on the your local server.
The MDT plays 3 important roles:
1. Discovery of all Moog EXO Cameras
2. Allows for remote conguration of the IP address and subnet mask
3. Permits batch rmware upgrade of all common EXO devices
Note: Silverlight is a free plug in and is required to interface with the Moog EXO Web brower.
Once your device is installed on your network and powered up, launch MDT from any computer on the network and the following window
will be displayed:
The MDT supports 2 ways to discover a device. The rst way doesn’t need any conguration and uses the Bonjour discovery protocol.
In order to be able to discover a device via Bonjour, the network must support multicast delivery.
If it is not the case, you can use the second way, which is the Unicast Discovery. The Unicast Discovery can be congured by using the
“Unicast Discovery” conguration form. This conguration form is available via the Admin / Unicast Discovery menu option.

E100-3100-4000-0010 169.254.1101 ION-E100 2.1.07 In: 1 Out: 0 In: 1 Out: 1 In: 2 Out: 1 1
To congure the Unicast Discovery, add one or more IP address ranges. The Unicast Discovery tries to reach a device at a specic IP
address in the congured ranges. The discovery can be a long process if the range of IP addresses is large and the device is at the end
of the range. To accelerate the discovery, add several small ranges of IP addresses. The ping timeout option can be increased for a high
latency network.
The MDT will display as many devices as it discovers on the network
If no DHCP server was able to assign an IP address to an Moog EXO Camera, it will appear in the MDT device list with an APIPA address
(169.254.*.*). If an Moog EXO Camera displays an APIPA address it must be congured with a valid IP address before it can be remotely
congured by selecting the ‘’Assign IP address’’ from the selection list and conguring the TCP / IP settings.

Assign IP Address(es)
Once the IP information is set, the Silverlight web application served by the EXO Camera can be launched from the MDT or directly in your
web browser by typing the device’s IP address in the address bar. You can start to use your networked video management system for nal
system conguration or you can congure advanced parameters using the Moog EXO web based management.
To assign IP Address, update rmware, or congure Moog web interface, right click on highlighted serial number / Mac Address.

2.0.0 Using the Moog EXO Web Application
Application
When entering the Web Application, the following window will be displayed. You will be asked a username and password. The default User
name and Password is ‘admin’.
(To reset the user name and password see / Congurations / User Accounts)

Upon successfully logging into the web interface, a welcome screen will be displayed. The welcome screen shows general devices health
status as well as rmware version and system uptime.
Status Window
1. System Status - 2.1.0
2. Conguration - 2.2.0
Main Menu Tabs
3. Maintenance - 3.0.0
4. Live Viewer - 4.0.0
5. Recording - 5.0.0
2.1.0 System Status

2.2.0 System Conguration
Conguration / System
Under the Conguration section, select the System tab to perform the following operations:
•View product model information, current rmware version and serial number.
•Specify a custom name; this name can be used by third-party software to display a selected name for the device.
- Enable edge recording by checking the box “Use Recorder Module” checkbox. Disabling edge recording will accelerate
the device’s boot time.
-
To enable edge recording an SD card must be added to the camera interface card, located on the EXO pan/tilt device.
SD cards are not provided as a standard feature standard option. Directions for installing the SD card are provided
in the rst section of this installer manual Block 11. Edge recording set up is done through the Recording Tab in the Live
Viewer EXO screen.
-Note: Recording menu will only be displayed when user recorder module check box is selected. You must save,
and then reboot to complete selection.
-SD Card: Use 2GB to 32 GB Micro SD Card of class 6 or above. You must make sure the card is formatted to
FAT32 or EXT3.

2.2.1 Conguration / Date Time
2.2.2 Conguration / Network
Under the Conguration section, select the Date Time tab to perform the following operations:
•Set the time zone in which the device is operating.
•Manually set the current date and time for the device’s internal clock.
•Note: For an accurate time stamp, you must sync UTC Time.
Conguration / Network

2.2.3 Conguration / Network / DHCP
Under the Conguration section, select the Network tab to perform the following operations:
•Set the encoder’s IP parameters; DHCP or static IP information.
•Congure an NTP server to allow the device to automatically update its internal clock using an NTP server.
2.2.4 Conguration / Network / Host Name Conguration-NPT
NPT Server- use when desiring to have local network time as default, to do so you must…….
2.2.5 Conguration / Network / HTTP
•Change the device’s HTTP conguration, Note: Avoid changing these settings unless absolutely necessary.

2.2.7 Conguration / Network / SNMP Conguration
2.2.8 Conguration / Network / RTSP Conguration
2.2.6 Conguration / Network / API- Boujour
NOTE:
•
To control the EXO Camera system with a VMS software system, you must enable the required Network APIs. Enable PSIA
or GENETEC API depending on which VMS platform you intend to use with the device. Disabling any unrequired APIs will
accelerate boot time. Milestone VMS will link through the PSIA API.
•Note: ONVIF is standard built in and does not require activation. If using ONVIF you do not need to select an API.
•Set Bonjour discovery protocol settings.
•Modify SNMP settings to match with any SNMP software you wish to use for monitoring the device.
If using Mulitcast output, Insert Multicast start IP, and select start port.
2.2.9 Conguration / Network / Multicast

2.3.0 Conguration / Video In
2.3.1 Conguration / Video In / Video Input
Under the Conguration section, select the Video In tab to perform the following operations:
Digital format – choices are, 720 30fps, 720 60fps, 1080 30fps, 1080 25fps. Note max camera output with WDR Active is 15fps (1080p).
2.3.2 Conguration / Video In / Sensor
Congure camera bloc / sensor parameters. These parameters will also be saved to the camera bloc itself if possible:
