Moree CUBE LED PRO ACCU 06-01-01 Multicolour User manual

Version GB 3.0 © 2009 Moree Ltd.
Instruction Manual
Mod. 06-01-01 Multicolour
www.moree.de
Moree Ltd.
Kaiserswerther Markt 11
40489 Düsseldorf
Germany
Designed and produced in Germany © 2006
Products are subject to change.
Distribution CUBE LED PRO ACCU
Disposal/ Ecology
Packaging material and appliance are made from recyclable
materials. Seperation of the remaining waste materials into
different types facilitates the recycling of valuable raw mate-
rials.
When the appliance is to be no longer used please dispose of
the appliance in the proper manner. Rechargeable batteries
which are dead or defective should not be disposed of in
the household rubbish; always take them to a special waste
disposal.
You can obtain information on disposal from your local autho-
rity.
Warranty
Dear customer,
The vendor provides warranty for perfect material and error
free manufacturing for 12 months, starting from the day of
purchase on the following conditions:
The warranty is void with interference by the customer or
through a third party. Damage caused by inappropriate
treatment, natural causes or causes beyond control do not
fall under the warranty. In response to complaints, we will
replace/repair defect parts or the whole product. Replaced
parts will be retained. No further claims exist due to the war-
ranty. The warranty claim needs to be proven with the pur-
chase receipt by the customer.
IN THE CASE OF WARRANTY THE PRODUCT CAN ONLY
BE RETURNED AND ACCEPTED PROVIDING THAT IT IS
IN ITS ORIGINAL (INTACT) PACKAGING !
•Before using the product, please read the instruction manual fully.
•Keep the manual for the entire life of the product.
Inclusive
Remote Control
and Charger

Instruction Manual
SAFETY PRECAUTIONS - LED PRODUCT
Dear customer,
we are delighted that you have chosen a Moree product.
GB
Before using the product, please read the safety precautions fully.
Keep the manual for the entire life of the product.
IMPORTANT:
THIS PRODUCT IS FOR INDOOR USE ONLY! The product may
only be charged and used in dry rooms. Do not allow liquids or
foreign objects to enter the product. There must be no moisture on
the charging point.
The product may only be used when positioned horizontally, with
the top facing upwards on rm, non-ammable ground and should
not be covered.
The product may only be charged with the supplied charger.
Make sure your voltage corresponds to the voltage printed on the
product.
Stop operating the product immediately if it emits smoke, a
strange smell, or otherwise behaves abnormally.
The product may only be used after correct installation. Disconnect
the product from the mains supply before opening.
Do not allow dirt or metal objects (such as keys) to contact the
charging point.
Avoid dropping or subjecting the product to severe impact.
Max. load is 100 kg. Do not pull on any cables !
Do not alter the product in any way. Faulty or unqualied repair
work may cause injury to the user.
If the appliance (including cord and charger) shows any defect, stop
using it and only replace damaged components with specic ones
that are available from the manufacturer or a representative.
Moree product appliances meet European safety standards.
CAUTION!
WHEN DISASSEMBLING DO NOT LOOK DIRECTLY INTO THE
OPERATING LIGHT SOURCE - RISK OF IRREVERSIBLE EYE
DAMAGE!
Wipe the product with a soft, damp cloth only. Do not use
abrasives, alcohol or solvent based cleaners.
Maintenance
SAFETY PRECAUTIONS - CHARGER
This unit corresponds to the directive for electromagnetic
compatibility and to the low voltage directive.
ATTENTION! THE UNIT IS SUPPLIED WITH HAZARD-
OUS MAINS VOLTAGE (230 V~). LEAVE SERVICING TO
SKILLED PERSONNEL ONLY.
UNQUALIFIED HANDLING MAY CAUSE AN ELECTRIC
SHOCK HAZARD. FURTHERMORE, ANY GUARANTEE
CLAIM WILL EXPIRE IF THE UNIT HAS BEEN OPENED.
- Use only recommended power sources.
- Only use the unit for recharging 12 V lead batteries.
- The unit is suitable for indoor use only. Protect it against
any water contact, high air humidity and heat (admissible
ambient temperature range 0 – 40 °C).
- Do not place any objects lled with liquid on the unit, e.g.
a glass.
- Do not allow dirt or metal objects (such as keys) to contact
the charger terminals or plug. This could result in re, electri-
cal shock or other damage.
- The heat generated within the unit must be cooled. There-
fore, never cover the housing.
- Unplug the battery charger from the power outlet after re-
charging is complete, or when you are not using it.
Specications LED Product
Dimensions: approx. L 44 x W 44 x H 45 cm
Material: PE
Colour: translucent white
Weight: approx. 13 Kg
Illuminant: max. 13 Watt
3x high-power multicolour LEDs
Lead Acid Battery: 12V, 18Ah
2x Fuses: Specs.: refer to sticker on product
Operating time: approx. 30h
Protection class: III
Construction Diagram SAFETY PRECAUTIONS - BATTERY
THE PRODUCT MAY ONLY BE CHARGED WITH THE
SUPPLIED CHARGER.
THE BATTERY MUST ONLY BE CHANGED BY QUALI-
FIED PERSONNEL USING THE SAME BATTERY TYPE !
DO NOT ATTEMPT TO DISASSEMBLE, ALTER OR APPLY
HEAT TO THE BATTERY !
In case of leakage, do not allow liquid to come into contact
with skin. If liquid is spilt on clothes or skin immediately wash
off with water. Should problems occur, contact a doctor.
Charging the battery
To charge the battery, rst plug the charger into the charging
point and then connect the charging plug to the power supply.
Before use charge the battery fully.
The product will automatically shut off when the battery is
empty. It will turn on again when the battery is recharged -
this may take up to 3 hours.
In order to maintain a longer battery life, please comply
with the following instructions when using this product:
If the product is not used for a long period of time please
turn it off, because the standby mode will slowly empty the
battery.
When the product is stored under 25°C it can be left for up
to 3 months. If left for longer than this period, make sure to
charge it fully again.
Please replace the battery after the correct time interval
shown below, and do not continue to use the battery after its
recommended replacement time.
Temperature Replacement
of battery surface: time:
Below 25oC (77oF) 6 Years
30oC (86oF) 4 Years
40oC (104oF) 2 Years
If the battery is quickly depleted even after charging, it has
reached the end of its life span. Purchase a new battery.
Remote Control
Off/ reset-button
90 second RGB colour change
program
3 minute RGB colour change
program
White light
Pulse program (single press)
Flash program (double press)
1
2
3
4
5
1
2 3 4
5
Colour selection button; can be used
at any time to choose the colour being
displayed. To activate the previous
program or choose other programs
please push the off/ reset button.
Do not operate the unit or immediately disconnect it
from the mains socket:
1. if there is visible damage to the unit or the mains cable,
2. if a defect might have occurred after the unit was dropped
or suffered a similar accident,
3. if malfunctions occur.
- In any case the unit must be repaired by skilled personel.
- A damaged mains cable must be replaced by the manufac-
turer or authorized, skilled personnel only.
- Never pull the mains cable to disconnect the mains plug
from the socket, always seize the plug.
- For cleaning only use a dry, soft cloth; never use chemicals
or water.
- No guarantee claims for the unit and no liability for any
resulting personal damage or material damage will be ac-
cepted if the unit is used for other purposes than originally
intended, if it is not correctly connected, operated, or not
repaired in an expert way.
Operation
1) Connect the mains plug of the charger to a mains socket.
The LED is illuminated to indicate operation. The charging
process has ended when the LED is lit green.
2) The charging time depends on the capacity and the
charging status of the battery.
TROUBLESHOOTING
1) THE UNIT DOES NOT WORK
When the Battery is empty
Solution: The product turns off automatically when the bat-
tery is empty due continuous use. It will turn itself back on
when the battery has been charged to a minimum level. This
can take approx. 1-3 hours to reach the minimum operating
voltage. Charge the product until the LED is lit green.
When one or both fuses are defect
Solution: Check fuses and replace if necessary. Make sure
that the charger is plugged into the product before plugging
into the mains (otherwise the fuse may blow). Keep product
away from moisture.
When the red light on the charger is not lit
Solution: Check the power supply, if the light on the charger
is still not lit, the charger is faulty.
When the charge is interrupted
Solution: Make sure the charger is correctly plugged into the
socket of the unit !
When the charge is to short
Solution: Charge the product until the LED is lit green.
2) THE REMOTE CONTROLLER DOES NOT WORK
a) The battery is empty or the batteries are inserted the
wrong way round (On/ Off button must be lit red).
b) Point the remote controller at the unit from different
angles.
c) Switch the LED product off or pull the plug to reset it.
3) THE REMOTE CONTROLLER IS BLOCKED
To set the correct code 11233, hold the ‘MAGIC’ button down
until the small light ashes twice. Enter the installation code
according to the table below (the small light lights up twice
after entering the correct installation code)
1 = VOLUME PLUS, 2 = VOLUME MINUS,
3 = CHANNEL PLUS, 4 = CHANNEL MINUS
ON/OFF
button
Cube Base
Charger
Charging
point
Fuses
