PARTS IDENTIFICATION
SPECIFICATIONS
1. Front Grille
2. Spinner
3. Blade
4. Plastic Nut
5. Rear Grille
6. Housing
7. Control Switch
8. Base
C O N T E N T S
3
3
4
5
5
6
Parts Idenfication
Specifications
Safety Precautions
Assembly Instructions
Operation Instructions
Trouble Shooting
MODEL MFC-12T1 MTF-16T1
RATED OLTAGE / FREQUENCY 220-240 ~ 50Hz
RATED WATTAGE 45W 55W
SIZE 300MM 400MM
MTF-12T1(IM)260717.qxp_Layo t 1 8/1/17 2:21 PM Page 2

4 5
ASSEMBLY INSTRUCTIONS
Congratulations on your purchase of another quality Morgan product. We seek to
excel by designing products with innovation, quality and safety of our customers in
mind.
• Do not use outdoors. our appliance is intended solely for household use only.
• Do not operate the appliance if power cord or power plug has been damaged, It must
be replaced by the manufacturer or its service agent or a similarly qualified person in
order to avoid any hazards.
• Never leave the appliance within reach of children without supervision. The use of this
appliance by young children or the physically challenged must always be supervised.
• Unplug the fan before cleaning, transportation and after you have finished operating
the fan.
• Never immerse the appliance, the power cable or the power plug in water or in any
other liquids. Never spray liquids onto fan.
• Deformation or operational failure may take place when the appliance is used on
unstable surfaces or close to places with heating sources.
• Avoid contact with moving parts.
• Do not operate in the presence of explosives or flammable fumes.
NOTE
• Always ensure fan is properly fitted before use.
• The use of attachments not recommended by the manufacturer may be hazardous.
• Always use on a dry, flat surface.
• If appliance malfunctions or has been damaged in any manner, do not attempt to
repair this appliance yourself but return it to the agent for examination, repair or
adjustment.
SAFETY PRECAUTIONS
ASSEMBLY OF FAN PEDESTAL ONTO BASE
1. Insert the fan pedestal into the base and press the pedestal firmly into position.
2. On the underside of the base, tighten pedestal and base firmly together.
ASSEMBLY OF BLADES AND GRILLES
1. Unscrew the spinner clockwise and the nut counter-clockwise then remove the
plastic sleeve around the motor shaft.
2. Place the rear grille in proper position with the handle facing upwards.
3. Screw on the plastic nut tightly to the attached fan grille.
4. Discard sleeve on shaft.
5. Slide the blade onto the shaft until it contacts the retaining pin.
6. Screw the spinner onto the motor shaft in a counter-clockwise direction.
7. Loosen the screw on the plastic ring with a screw driver. Mount the front grille (logo
place in the proper direction) with the rear grille and fasten the plastic ring.
OPERATING INSTRUCTIONS
1. Fan speed is controlled by pressing the control switch.
2. To oscillate, push down the knob on the motor housing.
3. To stop oscillation, pull up the knob.
4. To adjust vertical angle, tilt fan head upwards or downwards as desired.
MTF-12T1(IM)260717.qxp_Layo t 1 8/1/17 2:21 PM Page 3

6
TROUBLE SHOOTING
PROBLEM SOLUTION
No oscillation Check if oscillation knob is depressed
Not functioning Check power plug, ensure that power is switched on and
Speed selector is turned to either one of the three speeds.
Noisy Ensure that the fan blade is properly inserted into shaft pins.
Ensure that plastic nut for rear grille is tightened.
Ensure fan blade knob is securely tightened.
Ensure fan grille ring is securely tightened.
