USER MANUAL
Garmen
S eamer MSI-GB206
E-mail: [e-mail]
www.morgan.my
Market Expansion
Services by
www.dksh.com.my
facebook.com/morganappliances
MSI-GB206(IM)110117.qxp_Layou 1 1/17/17 12:37 PM Page 1

2
Thank y u f r purchasing a quality MORGAN appliance. We trust that y u will have a
pleasant experience with y ur new pr duct. T guarantee safety and best efficiency,
please read this manual carefully and keep a c py f r future reference.
3
GENERAL SAFETY INSTRUCTIONS
IMPORTANT!
• Read these instructions carefully before using the appliance and save them for
future reference.
• This appliance complies with international safety standards
T reduce the risk f pers nal injury r damage t pr perty, basic safety precauti ns
must be bserved including the f ll wing:
1. Before using for the first time, ensure that the voltage specified on the rating label
corresponds to your home’s power voltage. This appliance must be connected to an
earthed socket.
2. If it is necessary to use an extension cable, ensure that it is suitable for 10amp or
more and has a socket with an earth connection.
3. This appliance must only be used for the purposes it was designed for. Any other
use will be considered as improper and consequently dangerous. The manufacturer
will not be held responsible for any damage arising from misuse or improper use.
4. Turn off the appliance and unplug from the power supply when not in use and
before assembling or disassembling parts, and before cleaning. Remove by
grasping the plug; do not pull on the cord.
5. Do not leave the appliance exposed to weather conditions (rain, sun, frost etc.)
6. Do not leave the appliance unattended while it is plugged in.
7. Keep the appliance out of children’s reach.
8. This appliance is not intended to be used by persons (including children) with
reduced physical, sensory or mental capacities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
9. Children should be supervised to ensure that they do not play with the appliance.
10. Remove the plug from the socket before filling the appliance with water or before
pouring out the remaining water after use.
11. Never immerse the appliance in water or any other fluid.
12. The appliance must never be placed under the running water to fill with water.
13. Never put any aromatic oils or perfumes, chemicals, alcohol or detergent products,
vinegar or other descaling agents into the water tank.
14. It is recommended to use distilled or pure water in the water tank.
C O N T E N T S
3-4
4
5
6
6
7
7
General safety instructions
Specifications
Parts Identification
Assembly Instructions
Operating instructions
Cleaning and Maintenance
Troubleshooting
MSI-GB206(IM)110117.qxp_Layou 1 1/17/17 12:37 PM Page 2

4
GENERAL SAFETY INSTRUCTIONS
SPECIFICATIONS
5
PARTS IDENTIFICATION
15. In the event of any malfunction, do not attempt to repair any part of the appliance
on you own.
16. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person to avoid a hazard.
17. Do not allow the power cord to hang over the edge of a table, bench top or contact
with hot surfaces.
18. Do not direct the handle at other persons or towards yourself, while using the
“steam” function.
19. The appliance must be used and placed on a stable surface.
20. The appliance should not to be used if it has been dropped, if there are visible signs
of damage or if it is leaking water. It must be checked by an authorized Technical
ervice Centre before it can be used again.
21. The use of attachments or accessories not included with the appliance is strictly not
recommended as they may be hazardous to person(s) or property.
CAUTION: The steam h se can get very h t when used!!
This appliance has been designed exclusively f r d mestic use and must n t be used
f r pr fessi nal purp ses.
MODEL MSI-GB206
RATED VOLTAGE / FREQUENCY 220-240V~ 50/60H
RATED WATTAGE 1350-1650W
1
2
3
4
5
6
7
8
10 9
12
13
14
15
16
11
1. Handle Hook
2. Handle
3. Clothes rack
4. Clothes rack button
5. Pants clamp
6. Telescopic pole
7. Flexible fabric hose
8. Pole Connector
9. Water Tank
10. Hose connector
11. Power switch
12. Lint pad
13. Fabric brush
14. Trouser line clamp
15. Co-worker
16. Insulation glove
MSI-GB206(IM)110117.qxp_Layou 1 1/17/17 12:37 PM Page 3

6
ASSEMBLY INSTRUCTIONS
1. Carefully remove all contents from the packaging and ensure all components and
parts are in good order.
2. Insert pole onto the top of unit. Match the grooves on the pole with the notches in
the pole connector and push down. ecurely screw the cap on the pole over the
connector by turning it clockwise
3. To attach the clothes rack, align tabs in clothes rack with grooves on pole and push
down.
4. Fully extend the telescopic pole by opening the 3 clips on the pole and pulling the
pole upwards. When fully extended close the clips. Ensure that the pole is securely
locked into place and cannot be pushed downwards.
5. Insert and turn on the hose connector until it is locked. You may hang the steamer
handle on the Handle Hook
NOTE: D n t hang the h se n the hanger attachment until after it has been
c nnected n the base t prevent the h se fr m falling.
OPERATING INSTRUCTIONS
1. Remove the water tank from the unit by grasping the handle and turning it upside
down. Unscrew the cap from the bottom of the water tank. Position and hold the
water tank under cold running water and fill to the desired level. After filling, screw
the cap back on and turn over. Place water tank back into unit and make sure it is
properly and securely positioned in the cavity.
NOTE: Only fill the water tank with c ld water, DO NOT use h t water.
2. Insert the power plug into the power supply.
3. Press the power switch, and the light will illuminate. team will emit in 40-45
seconds.
4. When finished with garment steaming, press the power switch to power off the
appliance and remove the power plug from the power supply.
7
CLEANING AND MAINTENANCE
1. Make sure the appliance has cooled down completely. Unplug the unit from the
power supply and remove the steam hose from the main unit. Collapse the telescopic
pole.
2. Fill the water tank with fresh water and attach it to the main unit again, allowing
water to fill the boiler.
3. Remove the water tank from main unit and empty the water from the boiler
through the open hose connector into a sink. cale to remove and rinse away
residues.
4. Repeat teps 2 and 3 several times until scale has been removed.
PROBLEM POSSIBLE CAUSE SOLUTION
teamer fails to heat teamer not plugged into power Plug into a power supply
supply
The appliance is not connected to Press the power switch
the power supply
No steam Water level is low Power off the appliance and refill
the water tank
team is intermittent ediment build-up in container Clean the appliance
Water drips from Condensation inside hose Hold the hose vertically and allow
nozzle water to drain back into tank
Nozzle gurgles Condensation inside hose Hold the hose vertically and allow
water to drain back into tank
TROUBLESHOOTING
