Polaris General Box User manual
General Box
Instruction Manual
2
1
General Box
How to use the manual 4
Terminology and signs 5
Company’s liabilities 7
Guarantee 7
Main parts description 10
Technical details 12
Unboxing 14
How to move the device 14
Environmental conditions 15
Installation 17
General safety 20
Safety measures of device 21
Cleaning 23
Periodical maintenance 23
Suction bag replacement 26
Contents
2
Dear Customer
We thank you for your selectivity and trust in purchasing domes-
tically produced products, and we are pleased that after continu-
ous efforts, we have been able to manufacture General Box and
put it at your disposal.
This product has been designed by our technical and engineer-
ing team of experienced and committed people in the elds of
mechanic, electronics and computer engineering, and by utilizing
updated technology and building upon 25 years of experience in
manufacturing dental equipment, this product has reached pro-
duction of export index quality.
In designing the product, three principles of accuracy, reliability
and safety performance and also user friendly have been consid-
ered, so in order to use the product features correctly and com-
pletely utilize product features, we ask you to read the instruction
manual carefully and if you have any questions or you need more
information, contact the after-sales department.
The instruction manual is a comprehensive reference for the ef-
cient and safe use of the product. Following the instructions of this
manual has a great role in reducing consumable costs, avoiding
risks and ultimately increasing product life. The instruction manual
should always be kept near the product and the user should pe-
riodically read it.
Please impart us with your constructive guidance, so that we can
benet from your comments, recommendations, and gain knowl-
edge about your needs.
We hope that you will nd using General Box to be an enjoyable
and successful experience,
Polaris Engineering and Manufacturing
Introduction
General Box
4
Introduction
(1-1) How to use the manual
This manual presents the instructions about use, installation,
and maintenance of Steam Cleaner made by Polaris Co. It
should be noted that:
•The product should be used according to the instructions of
this manual. Thus, all parts of it should be read carefully before
starting and installing the tool. Special attention should be paid
to the highlighted parts. (see section 2-1).
•Observing the instructions of the manual assures the health
and safe operation of the tool.
•Manual is an integral part of the product. Thus, it should
always come with the product and should be used optimally
as a reference for use during the operation of the product. It
should be available even during the sale of the product, or
even when it is not used.
•In case of losing or damaging the manual, get a replacement
one from the after-sales service department of Polaris Co.
The following are explained in detail in this manual:
•Installation and start-up of the product
•Operation details of the product and its parts
•Maintenance program
•Primary safety and preventive details
5
General Box
(1-2) Terminology and signs
Knowledge of signs meanings is of great importance. A list of
signs has been introduced in the following for initial recognition
and reference to them if necessary.
Danger!
Indicates compulsory warnings.
Warning!
Indicates functional recommendations.
Forbidden!
Indicates forbidden activities.
Caution!
Refers to user instructions of the tool.
General Information
General Box
7
General Box
(2-1) Company liabilities
(2-2) Guarantees
Polaris Co.is not liable for any problem involving the following:
Failure to follow the instructions of this manual (incorrect use
of the product), repair by an unauthorized person and part
replacement without coordination with the after-sales service
department, failure due to power uctuations.
Guarantee of this product includes repairs, supply, and
replacement. If used appropriately, the guarantee of Polaris
Co,will cover all main parts of the device for 18 month.
Following cases and parts are not covered by guaran-
tee:
•power uctuations
•incorrect transportation of device
•inappropriate and frequent use of device despite
having obvious aws
•not observing the maintenance instructions
•installation by unauthorized persons
•any repair or replacement by unauthorized persons.
• power cable and keys
• protective shield
Commutation fees of company representatives to install
or repair during guarantee period will be received from
buyer at site.
The device can’t be used before installation and
insurance of correct operation of protective parts.
It is highly recommended that user has a general
knowledge of this manual before using this device. The
cases which appear to be operation aws in the device
should be registered by user and they should be sent to
the after-sale service department.
8
•Authorized representatives of Polaris Co.
These persons are endorsed by the company to work on the
device under any operational circumstances. They are also
authorized to do any electrical and mechanical adjustment/
repair, maintenance program and authorized parts replace-
ment.
General Information
Device Introduction
General Box
10
The main parts of the General box product are the following:
(3-1) Main parts description
1.Base
2.ABS sheet
3.Pedal
4.Outlet suction insoles
5.Micro-motor panel
6.Blower
7.Protective shield (overlay)
8.Drawer (tri)
9.Sheet hook
10.Hand-piece socket
11.Light
12.Electricity outlet
13.Pedal socket
14.Plastic Pad
15.Hand-piece
16.Suction bag
(3-1) Main parts description
Device Introduction
3
1
2
15
4
5
6
11 7
10
14
9
8
Technical Features
General Box
12
(4-2) Technical details
Power supply 210-240V AC 50/60 Hz
Power 1400 W
Device height 860-1000 mm
Device width 600 mm
Device depth 1100 mm
Net weight 90 Kg
Part Number
Hand-piece 1
Plastic Pad --
Suction bag 1
Pedal 1
Table.The device technical specications
Table 1
A list of product accessories
Table 2
Technical specications of the General Box are given in
Table 1:
Accessories
The device box includes General Box device, electricity cable,
and this instruction manual.
Technical Features
Transportation and
installation
General Box
14
(5-1) Unboxing
Having received the device, make sure that the main box is
sealed and intact. Otherwise, inform the after-sales service de-
partment of Polaris Co, or its authorized representatives.
In order to avoid accidents, it is really important to follow the
following instructions during the installation and xing of equip-
ment. All steps are explained in detail:
(5-2) How to move the device
The device should be moved as follows:
1.Unplug it from the power source
2.Disconnect all the connections.
3.Empty the contents.
4.Put the device in the designated box and if the box is not
available, follow safety instructions for protection, because
the company is not exposed to transportation risk and has
no obligations towards it.
5.The device should remain in a vertical position during
movement. For more safety and prevention of any injury due
to neglecting the technical details, refer to section 4-2.
Failure to follow the aforementioned instructions results
in device being damaged, and Polaris Co, won’t be
held liable.
Transportation and installation
15
General Box
(5-3) environmental circumstances
It is important to choose an appropriate environment with
following conditions during installation and operation for
personal safety, correct operation and long lifetime.
Workplace temperature: 0-40C
Maximum humidity: 75%
The device should not be used in a place where there is
danger of explosion or ring
The light of the place should be high enough so
that all parts of the device can be seen clearly.
The device should never be exposed directly to sunlight
or humidity of rain, etc.
Device Application
General Box
17
General Box
•Put the table on a stable and smooth surface
•Connect air branches to the air inlet.
•If the device has a turbine, it must be connected to the met-
ropolitan water,
•plug the device
In this stage, the user must adjust the General Box for appli-
cation:
1.Power button: to turn on the device
2.FOOT and Hand buttons: to change the hand-piece function
in pedal or manual mode
3.Clockwise-counterclockwise button: to adjust the condition
of hand-piece rotation to Rev and For modes.
4.Lamp button:
5.Suction or vacuum cleaner button: It is used to turn the sock-
et on and off (In manual mode).
It should be mentioned that by pressing this button for a few
seconds, the system enters suction adjustment mode and by
pressing the arrows, suction can be adjusted between 0-100
and by pressing the suction key, the desired speed can be
saved.
6.Autokey: This key is used to place the system in automatic
mode so that the hand-piece rotation and suction work at the
same time.
7.Arrow keys: They are used to adjust the used elements (hand-
piece speed, LCD light, suction power and etc)
Device Application
(6-1) Device initiation
(6-2) Device settings and application
18
8.Stop and Run button: This button is used to start or stop
the hand-piece rotation, so when the system is in Hand
mode, by pressing this key, micro-motor start rotating and
by pressing again, it stops.
9.To adjust the LCD light, press Manual and Auto buttons at
the same time and you can adjust it between 0-100.
In case of hanging or locking of the panel, you can press
Auto and down arrow to reset to factory settings.
All the sent and installed panels are checked for quality and
are calibrated.
In order to start-up the device, you need at least 5 bar com-
pressor air, metropolitan gas and electricity with earth con-
nection.
