Hizero F801 User manual

4-in-1 Bionic Mop
4-in-1 Bionic Mop (F801)
User Manual
www.hizero.com
Bring the
World into
Bionic
Cleaning Era

1
Take out the trash container Open the cleaning head cover to take out the trash container.
Insert the cleaning roller
Insert the trash container
Assemble the upper and lower body
Insert the battery
Place the lower body on its side, insert the cleaning roller onto the drive motor, then push and x it into
the cleaning head till the lateral button in place.
Note: 1. The maximum open angle of the drive motor is 45°.
2. Please immerse the cleaning roller in clean water if it is not soft.
Place the lower body in an upright position, open the cleaning head cover, insert the trash container and press it in
place, then place one disposable trash container and close up the cleaning head cover.
Remove the quick-mount screw in the body, connect the at cables of upper and lower bodies, make sure the upper
and lower body connect exactly, then insert the quick-mount screw and tighten it with a coin or screwdriver.
Insert the battery into the battery compartment in the lower body and tighten the screw with a coin or screwdriver.
Lock
MAX
Assembling
Quick Start Guide

2
Assemble the charging base
Ready for use
Fill the clean water tank Unlock the appliance
Insert the clean water tank Enjoy your cleaning Empty the dirty water tank
Take out the dirty
water tank
Throw away the
disposable trash
container
Assemble the charging base, insert the foot pads into the holes on the bottom of the charging base.
Connect the power adapter, the excess power line can be stored in the cable slot.
To ensure an effective cleaning, make sure that the trash to be
absorbed is in front of the cleaning head.
Keep charging until the blue light on the indicators panel becomes ON(about 4h),
then enjoy cleaning.
Use the Appliance
Use the Appliance
MAX
40℃
Unlock
4 Hours

Appliance
View
Handle
Display Panel
Battery Indicator
Mode 2 (Strong)
Mode 1 (Normal)
Tank Empty Indicator
(clean water tank)
Tank Full Indicator
(dirty water tank)
Cleaning Roller Status Indicator
Brush Roller Status Indicator
Mode Button
Power Button
Product Label
Body Quick-Mount Screw
Battery Quick-Mount Screw
Li-ion Battery
Release Button of Clean
Water Tank
Release Button of Dirty
Water Tank
Dirty Water Tank
Cap (With Sensor)
Dirty Water Tank
Charging Contactor
Latch Locator
Spindle
Auxiliary Wheel
Power Contactor
Disconnect Button of
Cleaning Head Cover
Locating Stud
Charging Base
Clean Water Tank Cap
Clean Water Tank
Hand Lifting Position
Upper Body
Lower Body
Atmosphere Lamp
Release Button of Cleaning
Head Cover
Cleaning Head
Trash Container
Lock of Cleaning Head Cover
Disconnect Button of
Brush Roller
Brush Roller
Cleaning Roller
Disconnect Button of Cleaning Roller
Body
3

4
Brush Roller Status Indicator
Cleaning Roller Status Indicator
Mode Button
Power Button
Battery Indicator
Mode 2 (Strong)
Mode 1 (Normal)
Tank Empty Indicator(clean water tank)
Tank Full Indicator(dirty water tank)
Charging
In Service
Flashing in red: Appliance is charging
Lighting up in blue: Appliance is fully charged
Lighting up in red: Low battery. The appliance can only operate for about 3 minutes and will automatically
switch-off once the battery runs out.
Lighting up in blue: Battery capacity is good.
Flashing: A. Dirty water tank is full.
B. Dirty water sensor is covered by dirt.
Lighting up continuously: A. Dirty water tank may not be placed properly.
B. The appliance is not functioning properly, please contact after-sales service.
Flashing: A. Cleaning head cover is not well closed.
B. Maybe the brush roller is jammed by outer objects.
Lighting up continuously: The appliance is not functioning properly. Please contact after-sales service.
Flashing: Clean water tank is short of water. The appliance will stop working and automatically switch-off after 30 seconds.
Lighting up continuously: The appliance is not functioning properly. Please contact after-sales service.
Flashing: Maybe the cleaning roller is jammed by outer objects.
Lighting up continuously: Replace the cleaning roller with a new one since the designed life of it has met, then keep
pressing the mode button till the indicator goes out.
Atmosphere lamp shows in blue: The appliance is in normal operation.
Atmosphere lamp shows in red: The appliance is not functioning properly. Please check the indications on the display
panel.
Mode 1: Normal mode, meaning less water consumption for self-cleaning. A full tank of clean water can be used for
approximately 10 minutes.
Mode 2: Strong mode, meaning more water consumption for self-cleaning. A full tank of clean water can be used for
approximately 5 minutes.

5
Table of Contents
1 Introduction
1.1 Safety Instructions
1.2 Technical and Security Specications
1.3 Self-Protection System
1.4 Intended Use
1.5 Floor Maintenance
3 Preparation
3.1 Charging
3.2 Taking Away Large Objects On the Floor
3.3 Filling the Clean Water Tank
3.4 Locking the Body
4 Operation
4.1 Unlock the Body
4.2 Start Cleaning
4.3 Indicator for A Full/Empty Water Tank
4.4 Emptying the Dirty Water Tank
4.5 Emptying the Trash Container
4.6 Self-Protection System
5 Maintenance & Cleaning
5.1 Maintenance
5.2 Cleaning the Water Tanks
5.3 Cleaning the Brush Roller
5.4 Cleaning the Cleaning Roller
5.5 Cleaning the Trash Container
5.6 Cleaning the Cleaning Head Cover
5.7 Cleaning the Water Sink
5.8 Cleaning/Replacing the Filtering Sponge
6 Storing & Moving
6.1 Storing
6.2 Moving
7 Replacing
7.1 Replacing the Brush Roller
7.2 Replacing the Cleaning Roller
2 Assembling
5
5
6
6
6
6
7
7
8
8
8
8
8
9
9
9
9
10
10
10
10
10
10
11
11
11
12
12
12
12
12
12
13
6
8 Ordering Accessories
9 Caring for the Environment
10 Warranty & Service
11 Troubleshooting
13
13
13
14
1 Introduction
Thank you for choosing HIZERO 4-in-1 Bionic Mop!
HIZERO 4-in-1 Bionic Mop is an intelligent oor cleaning
machine based on innovative bionic technology, which perfectly
integrates the functions of sweeping, mopping, drying and self-
cleaning. Its advent is honored as “The Second Revolution in
Floor Cleaning Field”. Equipped with a built-in rechargeable
battery, the appliance is able to separate solid trash from liquid
trash, and automatically self-clean during operation. After use,
all that needed is to discard the disposable trash container
and empty the dirty water tank. It is featured by extremely high
cleaning efciency, simple operation and easy maintenance.
In this user manual, you will learn some tips to make the
cleaning job as easy and efcient as possible. We hope that you
enjoy using this appliance as much as we enjoyed creating it.
Please read this user manual carefully before you use the
appliance and save it for further reference.
1.1 Safety Instructions
1.1.1 Danger
•To prevent electric shock, never move the appliance over oor/
wall/plugged power extension sockets.
• Keep all parts of the human body or large objects such as
clothes away from the cleaning roller.
1.1.2 Caution
• The appliance must be removed from the charging base
before cleaning or maintenance.
• Always switch off the appliance before you remove water
tanks or open the cleaning head cover.
• To avoid any hazard, do not let the appliance clean
sharp objects.
• To avoid any damage, never immerse the body of the
appliance in water or any other liquid, nor rinse it
under the tap.
• Never use the appliance to clean ammable or combustible
liquid and do not put ammable or combustible liquid in the
clean/dirty water tank.
• Regularly check the appliance and involved parts, stop using if
the appliance or the charging base is damaged. You
must have it maintained by an authorized service center.
• Unless there are supervision and instruction, or the appliance
is neither for children, nor for people with incomplete bodies/
sensory/mental capabilities, or lack of relative experience and
knowledge.
• Children should be supervised to ensure that they do not play
with the appliance.
• Never store the appliance at a temperature lower than 0°C/32°F.

6
• Use only clean water or HIZERO recommended cleaner in the
clean water tank of the appliance.
• Neither put acetic acid (vinegar) or unauthorized detergent in
the water tanks nor use the appliance to clean them.
• Never put wax, oil or oor maintenance products that cannot
be diluted in the clean water tank, or use the appliance to clean
them.
• The appliance is only to be used with the power supply unit
provided with the appliance.
• Never use the battery for other purposes other than this
appliance, and never expose it to heat (50°C/122°F), outdoor or
wet conditions.
• When removing or replacing the battery, keep the terminals
away from other metal objects like paper clips, keys, bails,
screws, etc. to avoid any thermal effect, smoke, burn or even
explosion.
• Stop using the battery in case of leakage and call customer
service center for special battery treatment immediately.
• Do not disassemble the battery without authorization in case
of any abnormal situaton.
• Do not discard used batteries at will and special battery
treatment or recycling shall be required.
• Use only HIZERO authorized cleaning solution to prevent any
damage for internal components.
• Never clean the cleaning roller with a sharp object, or the
roller may be damaged while the cleaning performance may be
reduced.
• When there is water in the water tanks, never put the appliance
on its side or upside down in order to prevent any leakage.
• Clean the dirty water tank after every use to prevent the
bacteria breeding or odour.
• Do not clean the cleaning roller, brush roller or water tanks by a
dishwasher or washing machine.
• This appliance is intended for the indoor use of household only.
1.2 Technical and Security Specications
This appliance complies with the current recognized electrical
product technical specications and safety regulations.It is
safe to use the appliance if the user operates according to the
instructions of this user manual.
1.3 Self-Protection System
The appliance is equipped with an active protection system, and
it will stop working and alert automatically if large objects like a
towel or a patch of a curtain are rolled and stuck.
1.4 Intended Use
The appliance is used for the water-
proof hard oors (tile, marble, wooden,
etc.) only. Do not use this appliance
to clean carpet or other oors that are
water-sensitive.
Note: Do not use the appliance for carpet.
1.5 Floor Maintenance
Follow the cleaning and maintaining instructions of the user
manual, and simultaneously refer to the maintenance description
of your oors.
HIZERO cleaning solution can be used to strengthen cleaning
effects. Do not add any unauthorized oor-care product into the
water tank.
??
2 Take out the lower body of the appliance, press the "PRESS"
button of the cleaning head cover to open the cover, then take
out the trash container.
3 Close the cleaning head cover, put the body on its side on
at ground to upturn the disconnect button of the cleaning roller.
1
2
3
2 Assembling
1 Open the package and take out the cleaning roller. Before
installation, please immerse the whole cleaning roller in clean
water (15°C-40°C), and evenly squeeze the entire body of the
cleaning roller until the body is completely soaked, taking about
2-5 minutes. Please note that the water
temperature should not be higher than 50°C. Then, squeeze
excess water out from the cleaning roller.

7
Note: Please ip to the other side of the cable and try
to connect again if the snap joint doesnʼt t.
4 Insert the cleaning roller onto the motor (note: the maximum
open angle of the drive motor is 45°), push and x it into the
cleaning head till the lateral button in place.
8 Insert and tighten the quick-mount screw with a coin or
screwdriver to make the upper and lower body t together
exactly.
9 Insert the battery into battery compartment on the lower body
and tighten the screw with a coin or screwdriver.
10 Assemble the charging base, and insert the foot pads into
the holes on the bottom of the charging base. Connect the power
adapter, and put the excess power line in the special cable slot.
5 Place the lower body in upright position, open the cleaning
head cover, insert the trash container and press it into place,
then place a disposable trash container. Close the cover until
you hear a click which means the cover is closed well.
6 Push the lower body forward lightly until you hear a click
which means the appliance is well locked.
7 Take out the upper body of the appliance and remove the
body quick-mount screw rst. Connect the at cables of upper
and lower bodies.
12
3 4
45º
1
23
4
12
Lock
1
2
3 4
12
12
3 Preparation
1 Make sure the charging base and power adapter are well
connected, and plug the adapter in a properly grounded outlet.
3.1 Charging
2 Place the appliance on the charging base and clasp the latch
locator onto the locating stud. The charging indicator will ash in
red to indicate the appliance is charging.
34

8
3 Before rst use, please charge the appliance. When the
battery runs out, it requires approximately 4 hours of charging to
gain full battery.
3 Put back and turn the cap clockwise to x it. Install back the
clean water tank into the appliance until you hear a click which
means the tank is well installed. To prevent the appliance from
toppling over, hold it upright with one hand and place the clean
water tank with your other hand.
12
Note: For your safety, please keep the charging base in a dry
situation, and do not touch the charge port.
Note: To avoid the water tank from creeping down during
cleaning, please make sure it is well placed and locked.
Note: If detergent is needed, only environmental friendly
detergent authorized by HIZERO is allowed. First, add the
detergent or tablet according to the indication on the bottle
package, then ll the clean water tank with water.
Note: During locking and unlocking the body, the click sound is
normal.
Before you clean your oor, take away large objects such as
toys, power cords and shoes.
Hold the handle of the appliance, push it forward lightly until you
hear a click, then the appliance is locked in parking position.
Don't push it any further, or it will cause the machine to be
damaged.
Fill the clean water tank before every use. Under Mode 1, a full
tank of clean water can be used for about 10 minutes (normally it
is enough to clean an area of about 50m /450sqf).
3.2 Taking Away Large Objects On the Floor
3.4 Locking the Body
3.3 Filling the Clean Water Tank
1 Press the release button while pulling the clean water tank
to take it out. To prevent the appliance from toppling over, hold
it upright with one hand and take out the clean water tank with
your other hand.
2 Turn the cap anticlockwise and remove it from the clean
water tank. Fill the clean water tank with cold or warm
water(should not be higher than 40°C/104°F). If needed,
appropriate detergent may be added (please refer to 1.5 Floor
Maintenance).
12
MAX
40℃
12
12
12
Lock
4 Operation
Lift up the appliance from the charging base, hold the handle
and x the cleaning head with one foot, and slowly pull back the
body until you hear a click which means the body is unlocked.
Press the power button to start the appliance.
4.1 Unlock the Body
12
3 4
Unlock
2

9
Note: To avoid the water tank from creeping down during
cleaning, please make sure it is well placed and locked. To
avoid any bad connection, please make sure to wipe the metal
sensor plate with a soft and dry cloth rst.
4.3 Indicator for A Full/Empty Water Tank
4.2 Start Cleaning
4.4 Emptying the Dirty Water Tank
1 Make sure that the trash to be absorbed is always in front of
the cleaning head, or it may not be cleaned effectively.
1 Press the release button of dirty water tank to take it out. To
prevent the appliance from toppling over, hold it upright with one
hand and take out the dirty water tank with your other hand.
2 Remove the cap of dirty water tank, pour the dirty water out,
and be careful of water overow and spilling.
3 Rinse the empty dirty water tank and its cap under the tap,
and wipe the metal sensor plate with a soft and dry cloth. Then
place the tank back into the appliance until you hear a click. To
prevent the appliance from toppling over, hold it upright with one
hand and place the dirty water tank with your other hand.
2 To avoid inefcient cleaning, the cleaning path shown in the
following pictures is recommended.
3 To remove stains, move the appliance back and forth
repeatedly.
4 Please do not lay the
machine as the picture shows.
5 If the cleaning roller is stuck by objects, please press the
power button to switch off the appliance.
1 The indicator starts ashing
when the clean water tank is
empty. Please switch off the
appliance and ll the clean water
tank (please refer to 3.3 Filling the
Clean Water Tank). Then re-start
the appliance.
2 The indicator starts ashing
and the appliance stops operating
when the dirty water tank is full.
Empty the dirty water tank (please
refer to 4.4 Emptying the Dirty
Water Tank) and re-start the
appliance.
12
4.5 Emptying the Trash Container tank
1 Open the cleaning head cover, take out the disposable trash
container, then throw it away into a dustbin.

10
2 If a disposable trash container was not used, please take
out the trash container, and use the cleaning brush to sweep the
trash into a dustbin.
a disposable trash container
is used
a disposable trash container is
not used
4.6 Self-Protection System
The self-protection system has been designed to identify
abnormal conditions. When the system is activated, the
appliance will stop operating immediately to prevent damage to
the object and appliance.
To continue cleaning, follow the instructions below!
5.2 Cleaning the Water Tanks
We strongly advise you to empty the tanks before storing the
appliance.
To disassemble and assemble the clean water tank, please refer
to 3.3 Filling the Clean Water Tank . The removed clean water
tank and cap can be rinsed under the tap. To disassemble and
assemble the dirty water tank, please refer to 4.4 Emptying the
Dirty Water Tank. The removed dirty water tank and cap can be
rinsed under the tap.
5.3 Cleaning the Brush Roller
5.4 Cleaning the Cleaning Roller
Method 1
Note: The appliance must be! removed from the
charging base and switched off before cleaning or
maintaining.
4.6.1 Brush Roller Self Protection
The brush roller indicator starts to ash when the brush roller
doesnʼt work properly.
1 Open the cleaning head cover and remove the jammed
object.
2 If the jammed object is not easy to nd, please disassemble
the brush roller to have a better check.
3 After clearing obstruction, reinstall the brush roller and re-
start the appliance. To disassemble and assemble the brush
roller, please refer to 7.1 Replacing the Brush Roller.
5 Maintenance & Cleaning
!
5.1 Maintenance
1 Regularly clean the outer body of the appliance with a soft
damp cloth. Do not use a scouring pad or abrasive cleaning
agent to clean the outer body, or the outer body may be
scratched.
2 To avoid any damage, never immerse the body in water or
any other liquid, nor rinse it under the tap.
4 Regularly check the power adapter to ensure the power
cable is intact and safe to use.
3 Regularly check the cleaning roller and brush roller.
Note: Clean the dirty water tank after each use to prevent the
growth of bacteria.
1 To disassemble and assemble the brush roller, please refer
to 7.1 Replacing the Brush Roller.
1 Before cleaning, ll up the clean water tank, add HIZERO
cleaning solution if needed, and empty the dirty water tank.
2 Make sure the body of the appliance and cleaning head are
locked. Start the appliance and switch to Mode 2.
2 Cut entanglements like hairs off the brush roller and remove
them.
3 Clean the brush roller with cleaning solution. Let the brush
roller dry before reassembling.
12

11
3 As per the following gures, lift the appliance up from the
oor or put it on the charging base, and then keep it operating
under Mode 2 until the clean water tank is empty.
4 Step 1 to 3 could be repeated for two to three times to
achieve better cleaning effect.
Note: Keep the appliance upright when the cleaning roller is
self-cleaning.
Note: Empty the dirty water tank before the aforementioned steps.
Method 2
1 Refer to 7.2 Replacing the Cleaning Roller to dismantle the
cleaning roller for cleaning.
12
5.5 Cleaning the Trash Container
5.7 Cleaning the Water Sink
5.6 Cleaning the Cleaning Head Cover
1 Take out the trash container, then empty and wash it under
the tap. The cleaning brush can be used to sweep off the trash.
Let it dry before reassembling.
1 Open the cleaning head cover, take out the trash container,
then turn the cleaning head over and take out the cleaning roller.
2 Find the removable water sink in the groove of the bottom
shell, gently pull out with the special hook, then remove the
black ltering sponge placed in the water sink.
3 Clean the water sink with clean water, and it is ne to add
some daily cleaning solvent if necessary.
1 Open the cleaning head cover, press the release button to
take it out, then remove the brush roller.
12
2 Clean the cover with a soft damp cloth.
3 Reinstall the brush roller into the cover, then x the cover
back to the cleaning head.
1 2
12
3

12
4 Place back the ltering sponge at the left end (the further
position from the cleaning roller motor) of the water sink.
2 To move the appliance, use the hand lifting position at the
appliance’ s back, or lean the appliance backward a little and
move by the auxiliary wheels.
1 Switch off the appliance, lock it in an upright position.
2 Open the cleaning head cover, press the square button at
the lateral side to take out the brush roller (Maximum open angle
of the drive motor is 30°. Please use appropriate strength and
method to avoid any damage).
3 Insert a new brush roller onto the motor, push and x it into
the cleaning head till the lateral button is in place.
If you want to continue to benet from the best cleaning results,
make sure you always use the original HIZERO brush roller, and
we recommend you to replace it every six months.
5 Place the water sink back correctly, making sure the
positioning holes on the water sink match rightly with the
machine body, then slightly press the water sink from left to right
to check if it is xed well, and lastly make both ends of the water
sink ush.
6 Finish the rest installation steps.
5.8 Cleaning/Replacing the Filtering Sponge
1 Take out the water sink (refer to the Section 5.7).
1 Before storing, switch off the appliance, lock the body and
place it onto the charging base.
1 Make sure the appliance is switched off and locked in upright
position.
2 Please clean the inside of the cleaning head before storing
to avoid bacteria breeding.
3 Before storing, please make sure the water tanks are empty.
4 If the appliance will be out of service for above one week,
please cut the power off, remove the cleaning roller and store it
after drying.
2 Clean/Replace the ltering sponge.
3 Put back the water sink (refer to the Section 5.7).
4 Finish the rest installation steps.
Note: The ltering sponge should be placed at the left end of the
water sink to improve the cleaning efciency, and it is suggested
to replace the ltering sponge every 2 weeks.
Note: If there is sand or sharp objects on the floor, do not
operate the appliance to avoid any possible scratch.
Note: Do not let the appliance standby on wooden oors for a
long time to avoid any possible damage to the oors.
Note: The maximum open angle of the drive motor is 30°. Please
operate it carefully.
6 Storing & Moving
7 Replacing
6.1 Storing
7.1 Replacing the Brush Roller
6.2 Moving
1
2
3
30º
45
67

13
1 Switch off the appliance, take out the trash container, empty
or remove the water tanks.
2 Put the body on its side on at ground let the side which has
the square button upwards. Press the lateral square button of
the cleaning roller and take it out.
3 Insert a new cleaning roller onto the motor, push and x it
into the cleaning head till the lateral button is in place.
To insert a new cleaning roller, please refer to 2 Assembling.
If you want to continue to benet from the best cleaning results,
make sure you always use original HIZERO cleaning roller, and
replace it every four months.
To purchase accessories for the appliance, please visit our
website www.hizero.com or www.amazon.com, or contact
HIZERO Consumer Care Centre in your country.
Do not throw away the appliance as the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the environment.
If you need service or if you have any question, please visit our
website: www.hizero.com or contact HIZERO Consumer Care
Centre in your country.
Your 4-in-1 Bionic Mop has been designed and developed
with the greatest possible care. In the unfortunate case that
the appliance needs repair, the Consumer Care Centre in your
country will help you by arranging any necessary repairs in the
shortest possible time and with maximum convenience.
Note: The used brush roller and the cleaning roller are plastic
wastes. Please properly dispose and recycle them according to
local environmental protection regulations.
The maximum open angle of the drive motor is 45°, please
operate carefully.
7.2 Replacing the Cleaning Roller
2
34
1
45º
56
45º
A
B
C
D
8 Ordering Accessories
9 Caring for the Environment
10 Warranty & Service
HIZERO is not liable for all damages caused
by improper use or disassembly by customer
themselves.
!

14
11 Troubleshooting
This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem
with the information below, please contact the Consumer Care Centre in your country or visit our FAQ page on www.hizero.com.
Problem
The wheels cannot move or move
with big noise.
The trash cannot be cleared up
when cleaning.
The indicator for a full water tank
doesn’t show any indication when
the dirty water tank if full.
The indicator for a full water tank
lights up continuously.
Cleaning roller status indicator
lights up continuously.
There is a gap between upper and
lower body.
The appliance leaks water on the
oor.
The appliance fails to boot.
The indicator for a empty water tank
lights up continuously.
Possible cause
A. The wheels get jammed.
A. The trash container is full.
The sensor for the dirty water level
may be broken.
Appliance may malfunction.
C. The trash container may be
broken.
B.The connection cable has not be
assembled properly.
The cleaning roller has reached its
useful life.
The connection cable is stuck.
The cleaning roller may be broken.
A.The battery runs out.
Appliance may malfunction.
B. The wheels have not been
assembled properly.
B. There are outer objects at the
bottom of the trash container, which
causes the trash container not
assembled properly.
C.The battery has not be well
inserted.
Solution
Remove outer objects.
Empty the trash container.
Please contact Consumer Care Centre.
Please contact Consumer Care Centre.
Replace it with a new trash container.
Reassemble the cable.
Please replace it with a new cleaning roller,
then long press the mode button until the indicator
goes out.
If a new cleaning roller is not available temporarily,
please directly long press the mode button until the
indicator goes out.
Disassemble the upper and lower body, put the
connection cable into the line slot. Insert and
tighten the quick-mount screw to ensure the upper
and lower body t together exactly.
Please check if the cleaning roller is deformed
or damaged, if yes, please replace it with a new
cleaning roller.
Charge the appliance and restart it.
Please contact Consumer Care Centre.
Adjust the wheels or reassemble them.
Remove the outer objects , replace the trash
container and press it into place.
Reinsert the battery.

www.hizero.com
M8900000103

用户手册
马小容
2018.11.22
F801
148mm×210mm
M8900000103
V09
封面 128g 铜板纸，四色印刷
内页 80g 轻型纸，专色印刷 骑马钉
装订，正反面印刷
* 注：此页面无需印刷
