Morgensen MSI200A Series User manual

MSI200A SERIES
INVERTER
USER MANUAL

1

2
Preface
Thanks for choosing our products.
MSI200A series inverters are newly-designed by our co pany for controlling asynchronous
AC inductance otors. Applying the ost advanced speedless sensor vector control
technology, DSP control syste , and our product enhances its reliability to eet the
adaptability to the environ ent, custo ized and industrialized design with ore opti ized
functions, ore flexible application and ore stable perfor ance.
The vector control perfor ance of MSI200A series inverters is as outstanding as that of the
leading sophisticated inverters on worldwide arket. Its speed and torque control can be
si ultaneously, co paring with the other kinds, its function of anti-trip and strong adaptability
to worse grid, te perature, hu idity and dust ake it eet the high perfor ance require ent
of the custo er application.
MSI200A series inverters apply odularized design to eet the specific de and of custo ers,
as well as the de and of the whole industry flexibly and follow the trend of industrial
application to the inverters on the pre ise of eeting general need of the arket. Powerful
speed control, torque control, si ple PLC, flexible input/output ter inals, pulse frequency
reference, traverse control can realize various co plicate high-accuracy drives and provide
integrative solution for the anufacturers of industrial devices, which contributes a lot to the
cost reducing and i proves reliability.
MSI200A series inverters can eet the de and of environ ental protection which focuses
on low noise and weakening electro agnetic interference in the application sites for the
custo ers.
This anual provides installation and configuration, para eters setting, fault diagnoses and
daily aintenance and relative precautions to custo ers. Please read this anual carefully
before the installation to ensure a proper installation and operation and high perfor ance of
MSI200A series inverters.
Our co pany reserves the right to update the infor ation of our products.

3
Content
Preface ........................................................................................... 2
Content ........................................................................................... 3
1 Safety Precautions ....................................................................... 7
1.1 What this chapter contains ................................................. 7
1.2 Safety definition ................................................................. 7
1.3 Warning sy bols ............................................................... 7
1.4 Safety guidelines ............................................................... 8
2 Quick Start-up ............................................................................. 11
2.1 What this chapter contains ................................................ 11
2.2 Unpacking inspection ........................................................ 11
2.3 Application confir ation .................................................... 11
2.4 Environ ent ..................................................................... 11
2.5 Installation confir ation ....................................................12
2.6 Basic co ission .............................................................12
3 Product Overview........................................................................13
3.1 What this chapter contains ................................................13
3.2 Basic principles .................................................................13
3.3 Product specification .........................................................14
3.4 Na e plate .......................................................................15
3.5 Type designation key ........................................................15
3.6 Rated specifications ..........................................................16
3.7 Structure diagra .............................................................17
4 Installation Guidelines .................................................................19
4.1 What this chapter contains ................................................19
4.2 Mechanical installation ......................................................19
4.3 Standard wiring .................................................................23
4.4 Layout protection ..............................................................29
5 Keypad Operation Procedure ......................................................31
5.1 What this chapter contains ................................................31
5.2 Keypad .............................................................................31

4
5.3 Keypad displaying.............................................................33
5.4 Keypad operation..............................................................33
6 Function Para eters ...................................................................35
6.1 What this chapter contains ................................................35
6.2 MSI200A general series function para eters ....................35
7 Basic Operation Instruction .......................................................100
7.1 What this chapter contains ..............................................100
7.2 First powering on ............................................................100
7.3 Vector control..................................................................102
7.4 Torque control .................................................................103
7.5 Para eters of the otor .................................................104
7.6 Start-up and stop control .................................................104
7.7 Frequency setting ...........................................................105
7.8 Si ple PLC ....................................................................107
7.9 Multi-step speed running .................................................107
7.10 PID control ....................................................................108
7.11 Pulse counter ................................................................ 110
8 Fault Tracking ........................................................................... 111
8.1 What this chapter contains .............................................. 111
8.2 Alar and fault indications .............................................. 111
8.3 How to reset ................................................................... 111
8.4 Fault history .................................................................... 111
8.5 Fault instruction and solution........................................... 111
8.6 Co on fault analysis .................................................... 115
8.6.1 The otor does not work.............................................. 115
8.6.2 Motor vibration ............................................................. 116
8.6.3 Overvoltage ................................................................. 116
8.6.4 Undervoltage fault ........................................................ 117
8.6.5 Abnor al otor heat .................................................... 117
8.6.6 Inverter overheating ..................................................... 118
8.6.7 Stall during the acceleration of the otor...................... 118

5
8.6.8 Overcurrent.................................................................. 119
8.7 Inverter syste interference troubleshooting ................... 119
3. ................................................................................................. 119
8.8 Maintenance and hardware diagnostics ..........................120
8.8.1 Overcurrent..................................................................120
8.8.2 Cooling fan ..................................................................122
8.8.3 Capacitors ...................................................................123
8.8.4 Power cable .................................................................124
9 Co unication Protocol ...........................................................125
9.1 What this chapter contains ..............................................125
9.2 Brief instruction to MODBUS protocol .............................125
9.3 Application of the inverter ................................................125
9.4 RTU co and code and co unication data illustration 128
Appendix A Technical Data ...........................................................142
A.1 What this chapter contains .............................................142
A.2 Ratings ...........................................................................142
A.3 Electric power network specification ...............................143
A.4 Motor connection data ....................................................143
A.5 Applicable standards ......................................................143
A.6 EMC regulations .............................................................144
Appendix B Di ension Drawings .................................................146
B.1 What this chapter contains .............................................146
B.2 Keypad structure ............................................................146
B.3 Inverter chart ..................................................................147
Appendix C Peripheral Options and Parts ..................................151
C.1 What this chapter contains .............................................151
C.2 Peripheral wiring ............................................................151
C.3 Power supply .................................................................152
C.4 Cables ...........................................................................152
C.5 Breaker, electro agnetic contactor and leakage protection
switch ...................................................................................155

6
C.6 Reactors ........................................................................157
C.7 Filters Filters selection table ...........................................158
C.8 Braking syste ..............................................................158
C.9 Other optional parts ........................................................162
Appendix D Further Infor ation ...................................................163

7
1 Safety Precautions
1.1 What this chapter contains
Please read this anual carefully and follow all safety precautions before oving, installing,
operating and servicing the inverter. If ignored, physical injury or death ay occur, or da age
ay occur to the devices.
If any physical injury or death or da age to the devices occurs for ignoring to the safety
precautions in the anual, our co pany will not be responsible for any da ages and we are
not legally bound in any anner.
1.2 Safet definition
Danger: Serious physical injury or even death ay occur if not follow relevant
require ents
Warning: Physical injury or da age to the devices ay occur if not follow
relevant require ents
Note: Physical hurt ay occur if not follow relevant require ents
Qualified
electricians:
People working on the device should take part in professional
electrical and safety training, receive the certification and be fa iliar
with all steps and require ents of installing, co issioning,
operating and aintaining the device to avoid any e ergency.
1.3 Warning s mbols
Warnings caution you about conditions which can result in serious injury or death and/or
da age to the equip ent, and advice on how to avoid the danger. Following warning sy bols
are used in this anual:
S mbols Name Instruction Abbreviation
Danger
Electrical
Danger
Serious physical injury or even death
ay occur if not follow the relative
require ents
Warning
General
danger
Physical injury or da age to the
devices ay occur if not follow the
relative require ents
Do not
Electrostatic
discharge
Da age to the PCBA board ay
occur if not follow the relative
require ents
Hot sides
Hot sides
Sides of the device ay beco e hot.
Do not touch.
Note Note Physical hurt ay occur if not follow
the relative require ents Note

8
1.4 Safet guidelines
 Only qualified electricians are allowed to operate on the inverter.
 Do not carry out any wiring and inspection or changing co ponents when the
power supply is applied. Ensure all input power supply is disconnected before
wiring and checking and always wait for at least the ti e designated on the
inverter or until the DC bus voltage is less than 36V. Below is the table of the
waiting ti e:
Inverter model Minimum waiting time
380V 1.5kW-110kW 5 inutes
380V 132 kW-315 kW 15 inutes
380V above 350 kW 25 inutes
 Do not refit the inverter unauthorized; otherwise fire, electric shock or other
injury ay occur.
 The base of the heat sink ay beco e hot during running. Do not touch to
avoid hurt.
 The electrical parts and co ponents inside the inverter are electrostatic. Take
easure ents to avoid electrostatic discharge during relevant operation.
1.4.1 Deliver and installation
 Please install the inverter on fire-retardant aterial and keep the inverter
away fro co bustible aterials.
 Connect the braking optional parts (braking resistors, braking units or
feedback units) according to the wiring diagra .
 Do not operate on the inverter if there is any da age or co ponents loss to
the inverter.
 Do not touch the inverter with wet ite s or body, otherwise electric shock ay
occur.
Note:
 Select appropriate oving and installing tools to ensure a safe and nor al running of
the inverter and avoid physical injury or death. For physical safety, the erector should
take so e echanical protective easure ents, such as wearing exposure shoes and
working unifor s.
 Ensure to avoid physical shock or vibration during delivery and installation.
 Do not carry the inverter by its cover. The cover ay fall off.
 Install away fro children and other public places.
 The inverter cannot eet the require ents of low voltage protection in IEC61800-5-1 if
the sea level of installation site is above 2000 .
 Please use the inverter on appropriate condition (See chapter Installation
Environment).
 Don't allow screws, cables and other conductive ite s to fall inside the inverter.

9
 The leakage current of the inverter ay be above 3.5 A during operation. Ground with
proper techniques and ensure the grounding resistor is less than 10Ω. The conductivity
of PE grounding conductor is the sa e as that of the phase conductor (with the sa e
cross sectional area).
 R, S and T are the input ter inals of the power supply, while U, V and W are the otor
ter inals. Please connect the input power cables and otor cables with proper
techniques; otherwise the da age to the inverter ay occur.
1.4.2 Commission and running
 Disconnect all power supplies applied to the inverter before the ter inal
wiring and wait for at least the designated ti e after disconnecting the
power supply.
 High voltage is present inside the inverter during running. Do not carry out
any operation except for the keypad setting.
 The inverter ay start up by itself when P01.21=1. Do not get close to the
inverter and otor.
 The inverter can not be used as “E ergency-stop device”.
 The inverter can not be used to break the otor suddenly. A echanical
braking device should be provided.
Note:
 Do not switch on or off the input power supply of the inverter frequently.
 For inverters that have been stored for a long ti e, check and fix the capacitance and
try to run it again before utilization (see Maintenance and Hardware Fault
Diagnose).
 Cover the front board before running, otherwise electric shock ay occur.
1.4.3 Maintenance and replacement of components
 Only qualified electricians are allowed to perfor the aintenance,
inspection, and co ponents replace ent of the inverter.
 Disconnect all power supplies to the inverter before the ter inal wiring.
Wait for at least the ti e designated on the inverter after disconnection.
 Take easures to avoid screws, cables and other conductive atters to
fall into the inverter during aintenance and co ponent replace ent.
Note:
 Please select proper torque to tighten screws.
 Keep the inverter, parts and co ponents away fro co bustible aterials during
aintenance and co ponent replace ent.
 Do not carry out any isolation and pressure test on the inverter and do not easure
the control circuit of the inverter by ega eter.
 Carry out a sound anti-electrostatic protection to the inverter and its internal
co ponents during aintenance and co ponent replace ent.

10
1.4.4 What to do after scrapping
 There are heavy etals in the inverter. Deal with it as industrial effluent.

11
2 Quick Start-up
2.1 What this chapter contains
This chapter ainly describes the basic guidelines during the installation and co ission
procedures on the inverter, which you ay follow to install and co ission the inverter quickly.
2.2 Unpacking inspection
Check as followings after receiving products:
1. Check that there are no da age and hu idification to the package. If not, please contact
with local agents or MORGENSEN offices.
2. Check the infor ation on the type designation label on the outside of the package to verify
that the drive is of the correct type. If not, please contact with local dealers or MORGENSEN
offices.
3. Check that there are no signs of water in the package and no signs of da age or breach
to the inverter. If not, please contact with local dealers or MORGENSEN offices.
4. Check the infor ation on the type designation label on the outside of the package to verify
that the na e plate is of the correct type. If not, please contact with local dealers or
MORGENSEN offices.
5. Check to ensure the accessories (including user’s anual, control keypad and extension
card) inside the device is co plete. If not, please contact with local dealers or MORGENSEN
offices.
2.3 Application confirmation
Check the achine before beginning to use the inverter:
1. Check the load type to verify that there is no overload of the inverter during work and
check that whether the drive needs to odify the power degree.
2. Check that the actual current of the otor is less than the rated current of the inverter.
3. Check that the control accuracy of the load is the sa e of the inverter.
4. Check that the inco ing supply voltage is correspondent to the rated voltage of the
inverter.
2.4 Environment
Check as followings before the actual installation and usage:
1. Check that the a bient te perature of the inverter is below 40J. If exceeds, derate 3%
for every additional 1J. Additionally, the inverter can not be used if the a bient te perature
is above 50℃.
Note: for the cabinet inverter, the a bient te perature eans the air te perature inside
the cabinet.
2. Check that the a bient te perature of the inverter in actual usage is above -10J. If not,
add heating facilities.
Note: for the cabinet inverter, the a bient te perature eans the air te perature inside

12
the cabinet.
3. Check that the altitude of the actual usage site is below 1000 . If exceeds, derate1% for
every additional 100 .
4. Check that the hu idity of the actual usage site is below 90% and condensation is not
allowed. If not, add additional protection inverters.
5. Check that the actual usage site is away fro direct sunlight and foreign objects can not
enter the inverter. If not, add additional protective easures.
6. Check that there is no conductive dust or fla able gas in the actual usage site. If not,
add additional protection to inverters.
2.5 Installation confirmation
Check as followings after the installation:
1. Check that the input and output cables eet the need of actual load.
2. Check that the accessories of the inverter are correctly and properly installed. The
installation cables should eet the needs of every co ponent (including reactors, input
filters, output reactors, output filters, DC reactors, braking units and braking resistors).
3. Check that the inverter is installed on non-fla able aterials and the calorific
accessories (reactors and braking resistors) are away fro fla able aterials.
4. Check that all control cables and power cables are run separately and the routation
co plies with EMC require ent.
5. Check that all grounding syste s are properly grounded according to the require ents
of the inverter.
6. Check that the free space during installation is sufficient according to the instructions in
user’s anual.
7. Check that the installation confor s to the instructions in user’s anual. The drive ust
be installed in an upright position.
8. Check that the external connection ter inals are tightly fastened and the torque is
appropriate.
9. Check that there are no screws, cables and other conductive ite s left in the inverter. If
not, get the out.
2.6 Basic commission
Co plete the basic co issioning as followings before actual utilization:
1. Select the otor type, set correct otor para eters and select control ode of the
inverter according to the actual otor para eters.
2. Autotune. If possible, de-coupled fro the otor load to start dyna ic autotune. Or if not,
static autotune is available.
3. Adjust the ACC/DEC ti e according to the actual running of the load.
4. Co ission the device via jogging and check that the rotation direction is as required. If
not, change the rotation direction by changing the wiring of otor.
5. Set all control para eters and then operate.

13
3 Product Overview
3.1 What this chapter contains
The chapter briefly describes the operation principle, product characteristics, layout, na e
plate and type designation infor ation.
3.2 Basic principles
MSI200A series inverters are wall, flange and ountable devices for controlling asynchronous
AC inductance otors.
The diagra below shows the ain circuit diagra of the inverter. The rectifier converts three-
phase AC voltage to DC voltage. The capacitor bank of the inter ediate circuit stabilizes the
DC voltage. The converter transfor s the DC voltage back to AC voltage for the AC otor.
The brake pipe connects the external braking resistor to the inter ediate DC circuit to
consu e the feedback energy when the voltage in the circuit exceeds its axi u li it.
Diagra 3-1 The ain circuit diagra (≤30kW)
Diagra 3-2 The ain circuit diagra (≥37kW)
Note:
1. The inverter above 37kW (including 37kW) supports external DC reactor which is an
optional part. Before connecting, it is necessary to re ove the copper row between P1 and
（+）.
2. The inverters (≤30kW) have standard e bedded braking units and the braking resistor is
optional.
3. The inverters (≥37kW) can be installed with optional braking units and the braking unit and
resistor are optional.

14
3.3 Product specification
Function Specification
Input
Input voltage (V)
AC 3PH 220V(-15%)~240V(+10%)
AC 3PH 380V(-15%)~440V(+10%)
AC 3PH 520V(-15%)~690V(+10%)
Input current (A) Refer to the rated value
Input frequency (Hz)
50Hz or 60Hz
Allowed range: 47~63Hz
Output
Output voltage (V) 0~Input voltage
Output current (A) Refer to the rated value
Output power (kW) Refer to the rated value
Output frequency (Hz) 0~400Hz
Technical
control
feature
Control ode SVPWM, SVC
Motor type Asynchronous otor
Speed ratio Asynchronous otor 1:100 (SVC)
Speed control
accuracy ±0.2% (sensorless vector control)
Speed fluctuation ± 0.3%(sensorless vector control)
Torque response <20 s(sensorless vector control)
Torque control
accuracy 10%(sensorless vector control)
Starting torque Asynchronous otor: 0.5Hz/150% (SVC)
Overload capability
G type:
150% of rated current: 1 inute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
Digital setting, analog setting, pulse frequency
setting, ulti-step speed running setting, si ple
PLC setting, PID setting, MODBUS co unication
setting.
Shift between the set co bination and set channel.
Auto voltage
adjust ent
Keep a stable voltage auto atically when the grid
voltage transients
Fault protection
Provide over 30 fault protection functions:
overcurrent, overvoltage, undervoltage,
overheating, phase loss and overload, etc.
Speed tracking
Restart the rotating otor s oothly
Note: This function is available for the inverters of
4kW and above 4kW.
Peripheral
interface
Ter inal analog input
resolution ≤ 20 V
Ter inal switch input ≤ 2 s

15
Function Specification
resolution
Analog input 1 channels ( AI2) 0~10V/0~20 A and 1 channel
(AI3) -10~10V
Analog output 2 channels (AO1, AO2) 0~10V /0~20 A
Digital input
8 channels co on input, the Max. frequency:
1kHz, internal i pedance: 3.3kΩ;
1 channel high speed input, the Max. frequency:
50kHz
Digital output
1 channel high speed pulse output, the Max.
frequency: 50kHz;
1 channel Y ter inal open collector pole output
Relay output
2 channels progra able relay output
RO1A NO, RO1B NC, RO1C co on ter inal
RO2A NO, RO2B NC, RO2C co on ter inal
Contactor capability: 3A/AC250V,1A/DC30V
Others
Mountable ethod Wall, flange and floor ountable
Te perature of the
running environ ent
-10~50℃, derate above 40℃
Ingress protection IP20
Cooling Air-cooling
Braking unit
Built-in braking unit for inverters below 30kW
(including 30kW)
External braking unit for others
EMC filter
Built-in C3 filter: eet the degree require ent of
IEC61800-3 C3
External optional filter: eet the degree require ent
of IEC61800-3 C2
3.4 Name plate
Fig 3-3 Na e plate
Note: This is the exa ple of the na e plate for the standard products, and CE\TUV\IP20 will
be arked according to the actual situations.
3.5 T pe designation ke
The type designation contains infor ation on the inverter. The user can find the type

16
designation on the type designation label attached to the inverter or the si ple na e plate.
Fig 3-4 Product type
Ke Instructions
A MSI200A : abbreviation of MSI200A
B, D 3-digit code: output power. “R” eans the deci al point; ”011”:11kW;
“015”:15kW
C, E C G:Constant torque load
E P:Variable torque load
F
Input voltage degree:
2: AC 3PH 220V(-15%)~240V(+10%)
4: AC 3PH 380V(-15%)~ 440V(+10%)
6: AC 3PH 520V(-15%)~690V(+10%)
3.6 Rated specifications
Model
Constant torque Variable torque
Output
power
(kW)
Input
current
(A)
Output
current
(A)
Output
power
(kW)
Input
current
(A)
Output
current
(A)
MSI200A-0R7G-4 0.75 3.4 2.5
MSI200A -1R5G-4 1.5 5.0 3.7
MSI200A -2R2G-4 2.2 5.8 5
MSI200A -004G/5R5P-4 4 13.5 9.5 5.5 19.5 14
MSI200A-5R5G/7R5P-4 5.5 19.5 14 7.5 25 18.5
MSI200A -7R5G/011P-4 7.5 25 18.5 11 32 25
MSI200A -011G/015P-4 11 32 25 15 40 32
MSI200A -015G/018P-4 15 40 32 18.5 47 38
MSI200A -018G/022P-4 18.5 47 38 22 56 45
MSI200A -022G/030P-4 22 56 45 30 70 60
MSI200A -030G/037P-4 30 70 60 37 80 75
MSI200A -037G/045P-4 37 80 75 45 94 92
MSI200A -045G/055P-4 45 94 92 55 128 115
MSI200A -055G/075P-4 55 128 115 75 160 150
MSI200A -075G/090P-4 75 160 150 90 190 180
MSI200A -090G/110P-4 90 190 180 110 225 215
MSI200A -110G/132P-4 110 225 215 132 265 260
MSI200A -132G/160P-4 132 265 260 160 310 305
MSI200A -160G/185P-4 160 310 305 185 345 340
MSI200A -185G/200P-4 185 345 340 200 385 380

17
Model
Constant torque Variable torque
Output
power
(kW)
Input
current
(A)
Output
current
(A)
Output
power
(kW)
Input
current
(A)
Output
current
(A)
MSI200A -200G/220P-4 200 385 380 220 430 425
MSI200A -220G/250P-4 220 430 425 250 485 480
MSI200A -250G/280P-4 250 485 480 280 545 530
MSI200A -280G/315P-4 280 545 530 315 610 600
MSI200A -315G/350P-4 315 610 600 350 625 650
MSI200A -350G/400P-4 350 625 650 400 715 720
MSI200A -400G-4 400 715 720
MSI200A -500G-4 500 890 860
Note:
1. The input current of 1.5~315kW inverters is easured when the input voltage is 380V and
no DC reactor and input/output reactor.
2. The input current of 350~500kW inverters is easured when the input voltage is 380V and
the circuit is with input reactor.
3. The rated output current is defined as the output current when the output voltage is 380V.
4. In the allowable voltage range, the output power and current can not exceed the rated
output power and current in any situation.
3.7 Structure diagram
Below is the layout figure of the inverter (take the inverter of 30kW as the exa ple).
4
6
7
1
2
3
13
9
10
11
12
8
5
Fig 3-5 Product structure diagra

18
Serial
No. Name Illustration
1 Keypad port Connect the keypad
2 Upper cover Protect the internal parts and co ponents
3 Keypad See Keypad Operation Procedure for detailed
infor ation
4 Cooling fan See Maintenance and Hardware Fault Diagnose for
detailed infor ation
5 Wires port Connect to the control board and the drive board
6 Na e plate See Product Overview for detailed infor ation
7 Side cover
Optional part. The side cover will increase the
protective degree of the inverter. The internal
te perature of the inverter will increase, too, so it is
necessary to derate the inverter at the sa e ti e
8 Control ter inals See Electric Installation for detailed infor ation
9 Main circuit ter inals See Electric Installation for detailed infor ation
10 Main circuit cable entry Fix the ain circuit cable
11 POWER light Power indicator
12 Si ple na e plate See Product Overview for detailed infor ation
13 Lower cover Protect the internal parts and co ponents

19
4 Installation Guidelines
4.1 What this chapter contains
The chapter describes the echanical installation and electric installation.
 Only qualified electricians are allowed to carry out what described in this
chapter. Please operate as the instructions in Safety Precautions. Ignoring
these ay cause physical injury or death or da age to the devices.
 Ensure the power supply of the inverter is disconnected during the operation.
Wait for at least the ti e designated until the POWER indicator is off after the
disconnection if the power supply is applied. It is reco ended to use the
ulti eter to onitor that the DC bus voltage of the drive is under 36V.
 The installation and design of the inverter should be co plied with the
require ent of the local laws and regulations in the installation site. If the
installation infringes the require ent, our co pany will exe pt fro any
responsibility. Additionally, if users do not co ply with the suggestion, so e
da age beyond the assured aintenance range ay occur.
4.2 Mechanical installation
4.2.1 Installation environment
The installation environ ent is i portant for a full perfor ance and long-ter stable functions
of the inverter. Check the installation environ ent as followings:
Environment Conditions
Installation site Indoor
Environ ent
te perature
-10~+50℃
If the a bient te perature of the inverter is above 40J, derate 3%
for every additional 1J.
It is not reco ended to use the inverter if the a bient
te perature is above 50J.
In order to i prove the reliability of the device, do not use the
inverter if the a bient te perature changes frequently.
Please provide cooling fan or air conditioner to control the internal
a bient te perature below the required one if the inverter is used
in a close space such as in the control cabinet.
When the te perature is too low, if the inverter needs to restart to
run after a long stop, it is necessary to provide an external heating
device to increase the internal te perature, otherwise da age to
the devices ay occur.
Hu idity
RH≤90%
No condensation is allowed.
The
axi u
relative hu ility should be equal to or less than
