Morris T71360CAP User manual

EN ELECTRONIC COMBI REFRIGERATOR
Freezer - Fridge
User manual
T71360CAP
R
ΨΥΓΕΙΟΚΑΤΑΨΥΚΤΗΣ ΜΕ
ΗΛΕΚΤΡΟΝΙΚΟ ΕΛΕΓΧΟ ΛΕΙΤΟΥΡΓΙΑΣ
Εγχειρίδιο χρήσης
NO FROST
GR

EN
2

EN
3
Index
BEFORE USING THE APPLIANCE................................. 5
General warnings...................................................................... 5
Old and out-of-order fridges...................................................... 7
Safety warnings ........................................................................ 7
Installing and operating your fridge........................................... 8
Before using your fridge............................................................ 9
Information about new generation cooling technology ............. 9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 10
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 14
Display and control panel ........................................................ 14
Operating your fridge............................................................... 15
Super freeze mode .............................................................. 15
Super cool mode.................................................................. 15
Economy mode.................................................................... 15
Holiday mode....................................................................... 16
Drink cool mode................................................................... 16
Screen saver mode.............................................................. 17
Light cancelling mode .......................................................... 17
Function of child lock ........................................................... 17
Cooler temperature settings ................................................ 18
Freezer temperature settings............................................... 18
Warnings about temperature adjustments............................... 19
Accessories ............................................................................. 20
Freezer box.......................................................................... 20
Chiller shelf .......................................................................... 20
Humidity controler................................................................ 20
Maxi-fresh preserver............................................................ 21
Water dispenser (If available) .................................................. 22
Mounting of the water tank group ....................................... 22
Cleaning the Water Tank...................................................... 23
CLEANING AND MAINTENANCE.................................. 24
Defrosting ................................................................................ 25

EN
4
Replacing LED lighting ............................................................ 25
ARRANGING FOOD IN THE APPLIANCE..................... 26
Refrigerator compartment........................................................ 26
Freezer compartment .............................................................. 27
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION........................................................................ 31
Repositioning the door............................................................. 31
BEFORE CALLING YOUR AFTER SALES SERVICE... 32
TIPS FOR SAVING ENERGY.......................................... 36

EN
5
BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
• If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for
a few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.

EN
6BEFORE USING THE APPLIANCE
- farm houses and by clients in hotels, motels and
other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN
7
BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before
discarding it, because children may get trapped inside it and may
cause an accident.
• Old fridges and freezers may contain isolation material and
refrigerant with CFC or HFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and
using your appliance. We are not responsible for the damage
occurred due to misuse.
• Follow all instructions on your appliance and instruction manual,
and keep this manual in a safe place to resolve the problems that
may occur in the future.
• This appliance is produced to be used in homes and it can only be
used in domestic environments and for the specied purposes.
It is not suitable for commercial or common use. Such use will
cause the guarantee of the appliance to be cancelled and our
company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only
suitable for cooling / storing food. It is not suitable for commercial
or common use and/or for storing substances except for food.
Our company is not responsible for losses to be incurred in the
contrary case.
Safety warnings
• Do not connect your Fridge Freezer to the mains electricity
supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children
to play with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could
cause a short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.

EN
8BEFORE USING THE APPLIANCE
• Do not place explosive or ammable material in your fridge.
Place drinks with high alcohol content vertically in the fridge
compartment and make sure that their tops are tightly closed.
• When removing ice from the ice-making compartment, do not
touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream
or ice cubes immediately after you have taken them out of the
ice-making compartment.
• Do not re-freeze frozen goods after they have melted. This may
cause health issues such as food poisoning.
• Do not cover the body or top of fridge with lace. This affects the
performance of your fridge.
• Secure any accessories in the fridge during transportation to
prevent damage to the accessories.
Installing and operating your fridge
Before using your fridge, you should pay attention to the following
points:
• The operating voltage for your fridge is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due
to ungrounded usage.
• Place your fridge where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas
ovens and heater cores, and at least 5 cm away from electrical
ovens.
• Your fridge should never be used outdoors or exposed to rain.
• When your fridge is placed next to a deep freezer, there should
be at least 2 cm between them to prevent humidity forming on
the outer surface.
• Do not place anything on your fridge, and install your fridge in
a suitable place so that at least 15 cm of free space is available
above it.
• Do not place heavy items on the appliance.
• Use the adjustable front legs to make sure your appliance is
level and stable. You can adjust the legs by turning them in either
direction. This should be done before placing food in the fridge.
• Before using your fridge, wipe all parts with a solution of warm
water and a teaspoon of sodium bicarbonate, then rinse with
clean water and dry. Place all parts in the fridge after cleaning.
• Install the plastic distance guide (the part with black vanes at
the rear) by turning it 90° (as shown in the gure) to prevent the
condenser from touching the wall.
• The refrigerator should be placed against a wall with a free space
not exceeding 75 mm.

EN
9
BEFORE USING THE APPLIANCE
Before using your fridge
• When using your fridge for the rst time, or after transportation,
keep it in an upright position for at least 3 hours before plugging
into the mains. This allows efcient operation and prevents
damage to the compressor.
• Your fridge may have a smell when it is operated for the rst time.
This is normal and the smell will fade away when your fridge
starts to cool.
Information about new generation cooling
technology
Fridges with new generation cooling technology have a different
working system than static fridges. In normal fridges, humid air that
enters into fridge and the water vapor that comes out from the foods,
accumulates frost formation in freezer compartment. In order to melt
this frost, in other words defrost, the fridge has to be stopped. During
the stopping period, to keep the foods cold, user has to extract the
food to outside of fridge and user has to clear the ice during this
period.
In the fridges with new generation cooling technology, situation in
the freezer compartment is completely different. With the aid of fan,
cold and dry air is blown out through many points into the freezer
compartment. As a result of the homogenously blown cold air, even in
the spaces between shelves, foods are frozen equally and correctly.
On the other hand there will be no frost formation.
In the refrigerator compartment, there will be nearly same conguration
with freezer compartment. Air, that is emitted with the fan, located at
the top of refrigerator compartment, is cooled while passing through
the gap behind the air duct. At the same time, air is blown out through
the holes on the air duct so that cooling process is successfully
completed in the refrigerator compartment. Holes on the air duct are
designed such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume and
esthetic appearance.

EN
10
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
A
B
1
2
3
4
5
6
7
9
10
11
12
13
14
8

EN
11
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
A) Fridge compartment
B) Freezer compartment
1) Wine rack *
2) Fridge shelves
3) Chiller *
4) Crisper cover
5) Crisper
6) Freezer top-middle basket
7) Freezer bottom basket
8) Leveling feet
9) Ice tray
10) Freezer glass shelves
11) Bottle shelf
12) Water tank
13) Upper door shelf
14) Egg holder
* In some models
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.

EN
12
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
Front water dispenser group
Top cover of the water dispenser
Valve lever
Water dispenser casing
12
3
4
5
6
Water tank group
1) Tank cover
2) Top cover of the water tank
3) Side Locking covers
4) Water tank
5) Gasket ring
6) Tap detail

EN
13
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
2
3
4

EN
14 THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
Use of control panel
1. It enables the setting of the freezer to be modied and super freeze mode to
be activated, if desired. The Freezer may be set to -16, -18, -20, -22, -24 °C, SF.
2. It enables the setting of the cooler to be modied and super cool
mode to be activated, if desired. The Cooler may be set to 8, 6, 5, 4,
2 °C, SC.
3. It enables the different modes (economy, holiday…) to be activated if desired.
4. Cooler set value screen.
5. Freezer set value screen.
6. Child-lock symbol.
7. Economy mode symbol.
8. Alarm symbol.
9. Holiday mode symbol.
10. Super freeze indicator.
11. Super cooling indicator.
c
c
DEMO

EN
15
THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
c
c
Operating your fridge
Super freeze mode
How would it be used?
• Press the Freezer Set Button until SF is shown on the screen.
The buzzer will sound twice and the mode will be set.
• The freezer temperature segment will show “SF”.
During this mode:
• The temperature of the Cooler and Super Cool Mode may be
adjusted. In this case, Super Freeze Mode continues.
• Economy and Holiday Mode cannot be selected.
• Super Freeze Mode can be cancelled in the same way that it
was selected.
Super cool mode
How would it be used?
• Press the Cooler Set Button until SC is shown on the screen. The
buzzer will sound twice and the mode will be set.
• The Cooler temperature segment will show “SC”.
During this mode:
• The temperature of the Freezer and Super Freeze Mode may be
adjusted. In this case, Super Cool Mode continues.
• Economy and Holiday Mode cannot be selected.
• Super Cool Mode can be cancelled in the same way it was
selected.
Economy mode
How would it be used?
• Push the “Mode Button” until a circle appears around economy
symbol.
• If no button is pressed for 1 second, the mode will be set. The
circle will blink 3 times and the buzzer will sound twice.
• The Freezer and Refrigerator temperature segments will show
“E”.
• The circle of the Economy Symbol and E will illuminate until the
mode nishes.
During this mode:
• The Freezer may be adjusted. When Economy Mode is cancelled,
the selected setting values will remain.
• The Cooler may be adjusted. When Economy Mode is cancelled,
the selected setting values will remain.
• Super Cool and Super Freeze modes can be selected. Economy
Mode is automatically cancelled and the selected mode is
activated.

EN
16 THE VARIOUS FUNCTION AND POSSIBILITIES
c
• Holiday Mode can be selected after cancelling the Economy
Mode. The selected mode is activated.
• To cancel, press the Mode Button.
Holiday mode
How would it be used?
• Push the Mode Button until a circle appears around the plane
symbol.
• If no button is pressed for 1 sec, the mode will be set. The Circle
will blink 3 times and the buzzer wil beep twice.
• The Freezer temperature segment will show “H”.
• The Circle of the plane symbol and H will be illuminated until the
mode nishes.
During this mode:
• The Freezer may be adjusted. When Holiday Mode is cancelled,
the selected setting values will remain.
• The Cooler may be adjusted. When Holiday Mode is cancelled,
the selected setting values will remain.
• Super Cool and Super Freeze Modes can be selected. Holiday
Mode is automatically cancelled and the selected mode is
activated.
• Economy Mode can be selected after cancelling the Holiday
Mode. Then, the selected mode is activated.
• To cancel, press the Mode Button.
Drink cool mode
When would it be used?
This mode is used to cool the drinks within adjustable time.
How would it be used?
• Press the freezer button for 3 seconds.
• "dc" will be seen on freezer screen and 05 blinks on the cooler
screen.
• Press the cooler button to adjust the time (05 - 10 - 15 - 20 - 25
- 30 minutes).
• When you select the time the numbers will blink 3 times on
screen and the buzzer will sound twice.
• If no button is pressed within 2 seconds the time will be set.
• The countdown starts from the adjusted time minute by minute.
• The remaining time blinks on the screen.
• To cancel this mode, press the freezer set button for 3 seconds.

EN
17
THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
Screen saver mode
How to use?
• This mode will be activated when you press the mode button for
5 seconds.
• If no button is pressed within 5 seconds when the mode is active,
the lights of the control panel will go out.
• If you press any button when the lights of control panel are off,
the current settings will appear on the screen, and then you can
maket the adjustment you want. If you do not cancel the screen
saver mode or press any button within 5 seconds, the control
panel will go off again.
• To cancel screen saver mode, press the mode button for 5
seconds again.
• When screen saver mode is active, you can also activate child
lock.
• If you do not press any button for 5 seconds after activating child
lock, the lights of the control panel will go off. Then, you can view
the previous settings and that child lock is active by pressing any
button.You can cancel child lock as described in the instructions
for that mode.
Light cancelling mode
When would it be used?
• Select this mode if you want to cancel the cooler lights.
• This mode is selected by pressing the freezer, cooler or mode
buttons or by opening and closing one of the doors 3 times. From
then on, the lights will not come on until the mode is cancelled
(or after 24 hours).
• If you want to cancel this mode, repeat the same process. This
mode will automatically cancel itself after 24 hours.
Function of child lock
When would it be used?
Child lock is available on the appliance to prevent children from
playing with the buttons and changing the settings you have
made.
Activating Child Lock
Simultaneously press the Freezer and Cooler buttons for 5
seconds.
Deactivating Child Lock
Simultaneously press the Freezer and Cooler buttons for 5
seconds.
Note: Child lock will also be deactivated if the electricity supply is
interrupted or the fridge is unplugged.
c
c

EN
18 THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
Cooler temperature settings
• The initial temperature value for the Cooler Setting Indicator is
+4 °C.
• Press the cooler button once.
• When you rst press the button, the previous value appears on
the setting indicator of the cooler.
• Whenever you press the button, lower temperatures will be set.
(+8°C, +6°C, +5°C, +4°C, +2°C, supercool).
• If you press the cooler set button until the supercool symbol
appears on the Cooler Setting Indicator and do not press any
buttons within 1 second, Super Cool will ash.
• If you continue to press the button, it will restart from +8°C.
• The temperature value selected before Holiday Mode, Super
Freeze Mode, Super Cool Mode or Economy Mode is activated,
will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
c
c
Freezer temperature settings
• The initial temperature value for the Freezer Setting Indicator is
-18°C.
• Press the freezer set button once.
• When you rst press the button, the previous value will blink on
screen.
• Whenever you press on this button, lower temperatures will be
set (-16°C, -18°C, -20°C, -22°C, -24°C superfreeze).
• If you press the freezer set button until the superfreeze symbol
appears on the Freezer Setting Indicator and do not press any
buttons within 1 second, Super Freeze will ash.
• If you continue to press the button, it will restart from -16°C.
• The temperature value selected before Holiday Mode, Super
Freeze Mode, Super Cool Mode or Economy Mode is activated,
will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.

EN
19
THE VARIOUS FUNCTION AND POSSIBILITIES
Warnings about temperature adjustments
• Your temperature adjustments will not be deleted when an energy breakdown
occurs.
• It is not recommended that you operate your fridge in environments colder
than 10°C in terms of its efciency.
• Temperature adjustments should be made according to the frequency of door
openings and the quantity of food kept inside the fridge.
• Do not move to another adjustment before completing the current adjustment.
• In order to allow your fridge to reach the operating tempearture after being
plugged in, do not open the doors frequently or place large quantities of food
in the fridge. Please note that depending on the ambient temperature, it may
take 24 hours for your fridge to reach the operating temperature.
• A 5 minute delay function is applied to prevent damage to the compressor of
your fridge when unplugging or plugging in, or when an energy breakdown
occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals
stated in the standards, according to the climate class displayed on the
information label. We do not recommend operating your fridge out of the
stated temperature limits in terms of cooling effectiveness.
• This appliance is designed for use at an ambient temperature within the 10°C
- 43°C range.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Note: If the temperature of the environment is higher than 38°C, the freezer
partition temperature cannot be adjusted to -22°C and -24°C. It can only be
adjusted to the values of -16°C, -18°C, -20°C.

EN
20
Accessories
Freezer box
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
! Make the inverse of the same operation for the resetting
the sliding compartment.
Note: Always Keep the handle of box while removing the box.
Chiller shelf
Keeping food in the Chiller compartment instead of the
freezer or refrigerator compartment allows food retain
freshness and avour longer, while preserving its fresh
appearance. When chiller tray becomes dirty, remove
it and wash it with water.
(Water freezes at 0°C, but foods containing salt or
sugar freeze at temperature lower than that)
Normally people use the chiller compartment for raw
sh, lightly pickled, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
Humidity controler
When the humidity controler in the closed position,
it allows fresh fruit and vegetables to be stored
longer.
In case of the crisper is totally full, the fresh dial is
located in front of crisper, should be opened. By
means of this the air in the crisper and humidity
rate will be controlled and endurance life will be
increased.
If you see any condensation on glass shelf, humidity control should be taken into
the open positions.
THE VARIOUS FUNCTION AND POSSIBILITIES
(In some models)
