Morris WBW-71011/2 User manual

CONTENTS Page
INSTRUCTION MANUAL
WBW-71011/2
Washing Machine Instruction Manual
A NOTE TO YOU
Thank you for buying a MORRIS appliance.
MORRIS washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
␊Economic washing system
The washing machine determines the water level and washing
time automatically by sensing the amount of laundry and water
temperature in order to minimize energy and water consumption.
␊Low noise system
The washing machine minimizes the spinning noise level by
sensing the amount of unbalance of laundry.
PARTS AND FEATURES ................................................................................................................2
WASHER SAFETY ..........................................................................................................................3
INSTALLATION INSTRUCTIONS ...................................................................................................5
ELECTRICAL REQUIREMENTS ....................................................................................................7
OPERATING YOUR WASHER .......................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL ..............................................................................9
PROGRAMS AND FUNCTIONS ...................................................................................................10
WASHING PROCEDURE AND PROGRAM SELECTION ............................................................11
PRODUCT INFORMATION ...........................................................................................................13
MAINTENANCE ............................................................................................................................14
HOW TO CLEAN THE FILTER .....................................................................................................15
REMOVING STAINS .....................................................................................................................16
TROUBLE SHOOTING .................................................................................................................17
SPECIFICATION ...........................................................................................................................18

2
PARTS AND FEATURES
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models coverd by this book.
Your model may not include all features.
ADJUSTABLE LEG
CONTROL PANEL
DOOR
DETERGENT CASE
INLET HOSE (COLD)
COVER PUMP
POWER CORD
HOSE DRAIN
Accessories
Inlet hose Manual Sticker holder (3EA) Guide Hose Drain
(Option)

3
WASHER SAFETY
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your
washer adhere to the following basic precautions.
• Flammable fluids (dry-cleaning solvents, kerosene, gasoline, etc.)
should not be used or stored in or near your washer.
Do not add flammable fluids to your wash water.These substances
give off vapors that can create a fire hazard or explosion.
• After starting a cycle, do not reach into the washer until all motions
stop.
• Do not tamper with the controls.
• The appliance is not intended for use by young children or infirm
persons without supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, or its service agent or a similarly qualified person in
order to avoid a hazard.
• If the appliance is supplied from a cord extension set or electrical
portable outlet device it should be positioned so that it is not
subjected to splashing or ingress of moisture.
Please ...
• Have only a qualified person install, repair, or replace parts on
washer.
• Maintain washer properly.
• Protect washer from the weather and keep it where the temperature
will not fall below freezing.
• Do not install the washer at a place of extremely high humidity. It
could cause an electric shock or a short circuit.
• Connect washer to the correct outlet, electrical supply, water supply,
and drain supply.
Read all instructions before using your washer

4
WASHER SAFETY
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar
or rust remover) in the same wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your
washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and
cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only cold water
inlet valve, while water temperature is selected as hot or warm,
there can be water leakage from unconnected water inlet valve.
• This appliance must be grounded.
To avoid electrical shock, use a metal pipe for the ground
connection.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or metal
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazard involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• If you want to obtain user manual, please visit our Store, our Web
site http://www.morris.gr.

5
INSTALLATION INSTRUCTIONS
Removing transit bolts
1. Before operating the washer, remove the transit
bolts(3ea) along with the rubber.
• If the bolts are not removed, it may cause heavy
vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex wrench or
spanner or cross-tip screwdriver. Keep the 3 bolts
for a later time.
• When the appliance is transported, transit bolts
will be re-used.
3. Close the holes with sticker holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for correct
installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times.
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make considerable noise,
vibrate severely and cause a malfunction. If the washer is not level, adjust leg up
or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the washer is
installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer and bottom of
upper plate should be at least 3mm.
Inlet hose connection
• The washer should be connected to the water mains using new hose set and old hose sets should not be
reused.
• In case of only one water inlet valve, connect the inlet hose to the cold water tap.
• Periodically check the tightness of the inlet hose.
• Make sure that the inlet hose is not kinked or folded and that it is not crushed.
1. Connect the inlet hose to
the water tap tightly. 2. Connect the inlet hose to the water
inlet valve tightly.
Washer
approx.
2cm
Drain Hose
Laundry
Tub

6
• When installing the drain hose to tub(sink), secure it tightly with a string.
• Proper securing of the drain hose will protect the floor from damage due to water leakage.
• When the drain hose is too long, do not force it back into the washer.
This will cause abnormal noise.
Level adjustment
1If the washer is installed on an
unsuitable floor, it could make
considerable noise, vibrate and
cause a malfunction.
Drain system
• Never forget to install drain hose before operating your washer.
• Open the packing box, and the drain hose is tied at backside of washer.
• If you use the laundry tub, Top of laundry tub must be at least 60cm high and no higher than
100cm from bottom of washer.
2Adjust the level of washer using adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Adjust the level of washer by turning
adjustable legs. And make it sure that there is
no swaying of washer.
• After the adjustment is finished, turn the fixing
nuts up tightly so that the washer maintains
the adjustment.
3Make it sure that the washer does not sway when you press
down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no swaying of washer and all the
adjustable legs should stick to the floor closely.
Laundry tub
max. 100 cm
min. 60 cm
ca. 105 cm
Hose
Retainer
Tie
strap
max. 100 cm
min. 60cm
max. 100 cm
min. 60cm

7
OPERATING YOUR WASHER
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
ELECTRICAL REQUIREMENTS
• Electrical earth is required on this washer.
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the washer is properly earthed.
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’ having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating
earthing-type wall receptacle ‘C’. If a mating wall receptacle is not available, it is
the personal responsibility and obligation of the customer to have the proper
earthed wall receptacle installed by a qualified electrician.
WARNING Electrical shock hazard : Failure to follow these instructions could result in death
or serious injury.
C
B
A
Recommended earthing method
• Close zippers, snaps, and hooks to avoid
snagging other items.
Remove pin, buckles, and other hard
objects to avoid scratching the washer
interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic knits
inside out to avoid pilling.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains.
(See 'REMOVING STAINS' on page 14)
Preparing clothes for washing

8
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together.
• Separate dark colors from light colors, colorfast items from non-colorfast item.
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lights, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Sorting
• Drop items into washer loosely. Items should move
easily through wash water for best cleaning and
wrinkle-free results.
• Load washer properly and select correct load size
setting.
Overloading and selecting a setting too small for
the wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
• Mix large and small items in each load. Load evenly
to maintain washer balance.
An unbalanced load can make the washer vibrate
during spin.
• Reduce wash time when using a small load size
setting. Load with only a few small items needs
less wash time.
• Use a large load size setting to reduce wrinkling
with permanent press clothes and some synthetic
knits. These items should have more room to
move in the water than heavy items. (towels, jeans)
Loading
1Detergent case 2Adding fabric softener
• If desired, add measured liquid fabric
softener to the softener inlet.
• Pour liquid fabric softener into the
dispenser using the amount
recommended on the package.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of
the fabric softener which could stain
clothes.
• Do not open the detergent case when
water is supplied.
• Avoid pouring fabric softener directly on
the clothes.
Adding detergent
Main wash Pre wash Fabric softener
• Please use only the powder detergent for the front loader washing machine.
• Please use the proper amount of detergent in conformity with the instruction of the detergent manufacturer.
• A use of a large amount of detergent more than the recommended amount can cause many soapsuds and
the overload to the motor. In addition to, this will deteriorate the washing and rinse performance.
• If too much detergent used, it can occur that the detergent directly falls down to the inside cavity. In this
case, remove the detergent case and clean the cavity after washing cycle is finished. (See page 13)

9
THE FUNCTIONS OF THE CONTROL PANEL
Program selector
For switching the washing machine on and off and
for selecting the program.
Can be rotated in both direction.
Even if the program selector rotates while the
program is running, the program is not changed
(except for off ) .
(All program is electronically controlled by PCB)
Indicator light
The respective indicator lights up, when the
required program segment runs.
Time delay
To pre-engage time for washing.
As the button is pressed, the delayed time is
repeated as following;
2hours ➝3hours ➝4hours ➝• • •
➝10hours ➝11hours ➝max 12hours
This option is enabled with COTTON, COTTON Eco,
SYNTHETIC, Speed Wash, Intensive, Sports wear,
Rinse+Spin and Baby care programs.
Button for options
(in addition to the program if required)
Intensive wash Extended washing time.
Rinse + Extra rinse cycle.
Rinse Hold No final spin cycle
• The indicator lamp of the buttons lights up if
options are active.
• Canceling options : Press button again.
Start/Hold button
For starting the washing cycle.
(program must have been selected)
Note
The washing time may vary by the amount of laundry, water pressure, water temperature and other
washing conditions. If an unbalanced load is detected the washing time maybe extended. (Maximum
increasing time is about 1 hour.)
By turning right the Program Selector, the program is selected in order of
COTTON COLD ➝COTTON 40°C ➝COTTON 60°C ➝COTTON 95°C/Pre ➝SYNTHETIC 20°C ➝
Sports wear ➝Baby Care ➝Speed Wash ➝Wool Cold ➝Cotton Eco 40°C ➝Cotton Eco 60°C ➝
Tub Clean ➝Rinse+Spin ➝Spin ➝Drain ➝OFF ➝COTTON COLD ➝COTTON 40°C
Spin selector
You can select the spin programs(Spin 400rpm,
600rpm, 800rpm, 1000rpm) by pressing the
Program selector.
400rpm of spin velocity is selected automatically
with WOOL / TUB CLEAN program in order to
protect damage on laundry.
800rpm of spin velocity is selected automatically
with COTTON / SYNTHETIC / Baby care / Speed
Wash / Tub Clean / Sportswear / Spin /
Rinse+Spin programs.
1000rpm of spin velocity is selected automatically
with COTTON Eco 40 & 60°C.
*Warning : If value of unbalance is extremely high,
spin speed can't reached that r.p.m of
selected by spin selector.

10
Cold
40°C
60°C
95°C/Pre
20°C
Cold
30°C
Cold
Cold
Cold
95°C
40°C
60°C
Program Fabric type Proper
Temp. Degree of soiling Option Max.
Load Remark
Colorfast garments
(shirts, night dresses,
pajamas...) and lightly
soiled white cotton
(underwear...).
Made of polyamide,
acrylic, polyester,
(synthetic or blended
fabrics).
Machine washable wool
and wool-rich textiles or
silk.
Colored laundry.
Use to clean the Tub
and Drum.
Lightly soiled fast and
thin laundry.
Baby clothes
Colorfast garments
(shirts, night dresses,
pajamas...) and lightly
soiled white cotton
(underwear...).
Lightly
soiled
Normally
to heavily
soiled
Heavily
soiled
Lightly
soiled
Lightly
soiled
Lightly
soiled
-
Lightly
soiled
Normally
soiled
Lightly
soiled
Normally to
heavily
soiled
Rinse+
Rinse Hold
Intensive
Rinse+
Rinse Hold
Intensive
Intensive
Rinse+
Rinse Hold
Intensive
Rinse+
Rinse Hold
Intensive
Rinse+
Rinse Hold
Intensive
Rinse+
Rinse Hold
Intensive
Rinse+
Rinse Hold
Intensive
Rating
2.5kg
1.0kg
1.0kg
without
load
Rating
Rating
Rating
First Check if
laundry is
washable.
First Check if
laundry is
washable.
Short program
(Fast washing
time)
First Check if
laundry is
washable.
PROGRAMS AND FUNCTIONS
COTTON
SYNTHETIC
WOOL
Speed
Wash
Tub Clean
Sportswear
Baby care
Cotton eco
Programs and functions
NOTICE : Set program at "COTTON 40°C Eco" and "COTTON 60°C Eco" for test in accordance or
in conformity with EN60456 and IEC60456 . This option has longer setting time for
washing.
