I.S. BRAKE WIRE REPAIR INSTRUCTIONS
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
The Puma Pause (20.2 & 20.3) Independent Suspension System has four (4) individual hubs/axles
attached to four (4) independent swing-arms. The inspection interest can be found at the point
where each electric brake wire exits from each swing-arm.
INTRODUCTION
INSTRUCTIONS
Step 1
Using the Garmin Tablet:
Select the suspension icon on the lower
right corner of the tablet - highlighted blue
in the picture.
Select the camping icon on the left side
of the screen – highlighted orange in the
picture.
Select the “KNEEL” option to lower the
trailer.
a.
b.
c.
Tools Required:
• (2) Floor Jacks
• (1) Jack Stand
• 3/4" Socket (Lug Nuts)
• 7/8" Socket (U-Bolts)
• Torque Wrench
• Wheel Chocks
• Wire Strippers and Crimping Tool(s)
U-Bolts
Lock Nuts
3' length Brake Wire
Gel Cap Wire Splice Connector
Heat Shrink Waterproof Butt Splice Connectors (yellow)
Item Qty Part
1
2
3
4
5
4
8
1
2
2
Kit Includes:
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
INSTRUCTIONS CONTINUED
Step 2
Once Kneeled, disable power/communication to the
suspension system by removing the 30amp Compressor fuse.
Step 3
Ensure that the wheels on the non-aected side of the trailer
have been chocked.
Step 4
On the aected side of the trailer, lift the frame slightly then
support with a jack stand.
Step 5
Use a floor jack to support the swing-arm of the aected axle.
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
INSTRUCTIONS CONTINUED
Step 6
With the aected wheel o the ground, spin the tire, then
engage the brake to determine whether or not the brake is
functioning properly.
Step 7
Remove both forward and rear wheel from the aected side.
Step 9
Remove aected axle from the swing-arm by removing 8 lock
nuts and 4 U-Bolts that secure the axle.
If the brake IS functioning properly, lift the axle and inspect the
wire. If there is no damage to the wire, proceed to Step 16 for
reassembly. If the brake is NOT functioning properly, or upon
inspection it is determined that the wire is damaged in any
way, cut/sever (at the butt connector) the aected brake wire
and proceed to Step 10.
Step 8
If in Step 6 the brake IS functioning properly, DO NOT cut/
sever the brake wire yet. If the brake IS NOT functioning
properly, cut/sever (at the butt connector) the aected brake
wire.
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
INSTRUCTIONS CONTINUED
Step 10
Locate and remove access cover located near the front of the
swing-arm on the road-side of the coach.
Step 11
Pull/free excess brake wire free of spray foam from the belly pan.
Step 12
Pull aected brake wire through/out of it's entrance point
located at the front of the swing-arm.
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
INSTRUCTIONS CONTINUED
Step 13
If you are replacing the wire on the curb-side of the trailer,
you will need to use the damaged wire to pull the new
wire through the crossmember to the wire access on the
road-side of the coach. Then you can feed the wire through
the grommet and the swing-arm. It is easier to feed the
wire through the grommet with the grommet loose from the
swing-arm, then once the wire is all the way through the
swing-arm, use a screwdriver to insert the grommet into the
hole in the swing-arm.
Step 14
Cut/sever aected brake wire at the gel cap connection and
splice in new/replacement wire with the gel cap connectors
supplied in the kit.
Step 15
Replace access cover.
Step 16
Prior to re-seating axle, ensure that the brake wire rests
against the swing-arm tube wall out of the way/free of
the axle locator.
Step 17
Ensuring that the replacement brake wire is free of the
axle locator, position the axle back into the swing-arm
– ensuring that the locator is appropriately seated on/
around the locator bolt.
Locater Bolt
PUMA PAUSE TRAILER
I.S. BRAKE WIRE REPAIR INSTRUCTIONS
574.293.1581 • MORryde.com
INSTRUCTIONS CONTINUED
Step 18
Using four (4) U-Bolts and eight (8) Lock Nuts provided
in the kit, secure the axle to the swing-arm and torque
lock nuts to 80ft lbs, consistent with the diagram
provided at the end of this instruction.
NOTE: As U-Bolts are being tightened, ensure that the
brake wire remains clear of the axle locator/seat.
Step 19
Ensure that the new brake wire has free fore-aft
movement in the swing-arm.
Step 20
Using the supplied butt connectors, splice connect the
brake wires to the hub – once crimped, apply heat to
the connectors to activate the heat-shrink.
Step 21
Reattach the wheels on aected side and tighten (not
torque) the lug nuts.
Step 22
Remove jacks/support from each swing-arm.
Step 23
Remove jack/support from frame, then torque lug nuts
to 100ft lbs, consistent with the diagram provided
below at the end of this instruction.
Step 24
Restore power to suspension system by reinserting fuse.
Step 25
Test brakes.
