Motcom T5622 User manual

1
English
CONTENTS
PRODUCT SAFETY AND RF EXPOSURE
FOR PORTABLE TWO-WAY RADIOS
Charger Safety Instructions . . . . . . . . . . . . . . . . .3
GETTING STARTED
Your New Radio . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Batteries and Battery Charging . . . . . . . . . . . . . .5
Turning Your Radio On and Off . . . . . . . . . . . . . .6
Battery Meter and Battery Alert . . . . . . . . . . . . . . 6
Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
TALKING AND LISTENING
Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Talk Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Monitoring Channel Activity . . . . . . . . . . . . . . . . . 7
Selecting a Radio Channel . . . . . . . . . . . . . . . . . 8
Interference Eliminator Code . . . . . . . . . . . . . . . . 8
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Nuisance Delete . . . . . . . . . . . . . . . . . . . . . . . . . 8
Hands Free Use (VOX) . . . . . . . . . . . . . . . . . . . . 9
Vibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Time-out Timer . . . . . . . . . . . . . . . . . . . . . . . . . 10
Keypad Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ALERTS
Channel Busy Indicator . . . . . . . . . . . . . . . . . . .10
Call Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Talk Confirmation Tone . . . . . . . . . . . . . . . . . . .10
FURTHER INFORMATION
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .11
Use and Care . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Warranty Information . . . . . . . . . . . . . . . . . . . . .14
Copyright Information . . . . . . . . . . . . . . . . . . . . .14
APPROVED ACCESSORIES LIST
Approved Accessories List . . . . . . . . . . . . . . . . .15
6864227V01-A_EN.fm Page 1 Thursday, April 6, 2006 2:37 PM

English
2
PRODUCT SAFETY AND
RF EXPOSURE FOR PORTABLE
TWO-WAY RADIOS
ATTENTION!
Before using this product, read the RF energy
awareness information and operating instructions in
the Product Safety and RF Exposure booklet to ensure
compliance with RF energy exposure limits.
Before using this product, read the
operating instructions for safe usage
contained in the Product Safety and RF
Exposure booklet enclosed with your
radio.
!
C a u t i o n
6864227V01-A_EN.fm Page 2 Thursday, April 6, 2006 2:37 PM

3
English
Charger Safety Instructions
Before using the battery charger, read all instructions
and cautionary markings on:
• the battery
• the battery charger, and
• the radio using the battery.
To reduce the risk of injury, only
charge the Motorola approved
rechargeable battery for this product.
Other types of batteries may burst,
causing personal injury and damage.
SAVE THESE INSTRUCTIONS
1.Do not expose the charger to rain or snow.
2.Do not operate or disassemble the charger if it has
received a sharp blow, or has been dropped or
damaged in any way.
3.Never alter the AC cord or plug provided with the
unit. If the plug will not fit the AC outlet, have the
proper outlet installed by a qualified electrician. An
improper condition can result in a risk of electric
shock.
4.To reduce the risk of damage to the cord or plug, pull
the plug rather than the cord when disconnecting the
charger from the AC outlet
5.To reduce the risk of electric shock, unplug the
charger from the AC outlet before attempting any
maintenance or cleaning.
6.Use of an attachment not recommended or sold by
Motorola may result in a risk of fire, electric shock, or
personal injury.
7.Make sure the cord is located so it will not be
stepped on, tripped over, or subjected to damage or
stress.
8.An extension cord should not be used unless
absolutely necessary. Use of an improper extension
cord could result in a risk of fire and/or electric
shock. If an extension cord must be used, make
sure:
• That the pins on the plug of the extension cord are the
same number, size, and shape as those on the plug of
the charger.
• That the extension cord is properly wired and in good
electrical condition, and
• That the cord size is 18 AWG (1 mm
2
) for lengths up to
100 feet (30 metres) and 16 AWG (1.3 mm
2
) for lengths
up to 150 feet (45 metres).
9.The supply cord of this charger cannot be replaced.
If the cord is damaged please return to your place of
purchase.
!
C a u t i o n
6864227V01-A_EN.fm Page 3 Thursday, April 6, 2006 2:37 PM

English
4
GETTING STARTED
Use P to:
• Turn radio on/off
• Adjust volume
Use ^ to:
• Transmit call tone
Use \ to:
• Scroll through menus
• Lock and unlock the keypad
(when held down and not in a
menu)
LED Indicator Light
Use
M
to:
• Talk
• Save a setting
Accessory Jack Cover
Use
J to:
• Monitor channel activity
• Scan
Use [ and ] to:
• Scroll through available settings
Microphone
Speaker
6864227V01-A_EN.fm Page 4 Thursday, April 6, 2006 2:37 PM

5
English
Your New Radio
The Motorola T5622 two-way radio operates on
PMR446 frequencies, and can be used in any country
where PMR446 frequencies are authorized, subject to
applicable regulations. This license-free, two-way radio
service is for family and group recreational use. Use of
this radio outside the country where it was intended to
be distributed is subject to government regulations and
may be prohibited. Read this manual carefully and
make sure you know how to operate the radio properly
before use.
Please retain your original dated sales receipt for your
records. For warranty service of your Motorola two-way
radio you will need to provide a copy of your dated
sales receipt to confirm warranty status.
Batteries and Battery Charging
The T5622 radio operates with 3 AA Alkaline batteries
or a Nickel-Metal Hydride (NiMH) rechargeable battery
pack (supplied with your radio).
Caution: Do not disassemble the NiMH battery
pack.
Note: Remove batteries before storing your radio for
extended periods. Batteries corrode over time
and may cause permanent damage to your
radio. Exercise caution when handling batteries
that are leaking. Dispose of exhausted batteries
at a designated battery disposal unit and not in
the household waste.
Installing the Batteries
1.Lift battery latch to release the battery cover.
2.Insert 3 AA batteries as shown by the markings
inside the battery compartment. Alternatively insert
the NiMH pack so that the charge contacts are facing
outwards to connect with contacts on the battery
cover.
3.Reposition battery cover and press down until it
clicks into place.
Charging Desk Stand
The charging desk stand provides drop-in charging
convenience. The charging desk stand can be placed
on any flat surface, such as a desk or workbench.
Charge the NiMH battery overnight (16 hours) before
using it for the first time.
1.With the radio OFF, remove the battery cover.
2.Insert the battery pack as indicated on the battery
pack label.
3.Replace the battery cover.
4. Plug the wire on the AC power supply into the plug
on the desk stand.
5.Plug the AC power supply into a standard wall
socket.
6.Slide the radio into one of the desk stand charging
pockets, facing forward. The red light will glow if the
radio is properly inserted.
6864227V01-A_EN.fm Page 5 Thursday, April 6, 2006 2:37 PM

English
6
7.The radio/battery will be fully charged within 14
hours.
You can also charge the battery pack separately from
the radio,as follows:
1.Plug the wire on the AC power supply into the plug
on the desk stand.
2.Plug the AC power supply into a standard wall outlet.
3.Insert the battery pack into the desk stand charging
pocket using the charging pocket insert provided.
4.Make sure that the contacts on the side of the
battery pack align with the metal contacts in the
pocket of the desk stand. The red light will glow if
they have been properly inserted.
The radio/battery will be fully charged within 14 hours.
Charging Status
5.The solid red light indicator shows that the radio and/
or the NiMH battery is charging. A depleted battery
will recharge to full capacity within 14 hours.
Note: When moving between hot and cold
environments, do not charge the battery until
the battery temperature acclimates (usually
about 20 minutes). For optimal battery life,
remove the radio or battery from the charger
within 16 hours. Do not store the radio or the
battery in the charger.
Turning Your Radio On and Off
1.Turn Pclockwise to turn your radio on.
2.The radio chirps and the display will show all feature
icons that your radio has available for a brief period.
The display will show the channel 1.8, the
interference eliminator code 0.38 and the battery
meter.
3.Turn Panticlockwise to turn your radio off.
Battery Meter and Battery Alert
The battery meter located in the top left hand corner of
the display indicates how much battery power you have
remaining. The radio will power off when the voltage
drops below a predetermined level, to protect the
rechargeable battery. When the battery meter displays
c, the radio chirps every 10 minutes and after
releasing M.
Battery Life
The approximate (typical) battery life for:
• AA Alkaline batteries is 35 hours
•
NiMH batteries is 14.5 hours
This is based on a 5% transmit, 5% receive and 90%
standby cycle.
Note: Battery life will be reduced if you regularly use
Hands-Free (VOX) accessories.
6864227V01-A_EN.fm Page 6 Thursday, April 6, 2006 2:37 PM

7
English
Belt Clip
Your radio comes with a swivel belt
clip.
1.To attach, align belt clip post with
hole in the radio back and gently
push until it clicks into place.
2.To remove, push release tab on
top of belt clip down to release
catch and pull belt clip from the
radio back.
TALKING AND LISTENING
Your radio has 8 channels and 38 interference
eliminator codes. If you are in a group and you wish to
talk to each other, all radios must be set to the same
channel and code. If you experience interference and
need to change channel, ensure that you change the
channel and code of all radios in your group.
1.For maximum clarity, hold radio 5 to 7 centimetres
from mouth.
2.Press and hold Mand speak into the microphone.
The LED indicator light glows continuously when
transmitting.
3.To receive messages, release M.
Volume
1.Use Pto adjust your volume to a comfortable listen-
ing level.
Talk Range
Your radio has been designed to maximize
performance and improve transmission range in the
field. It is recommended that you do not use the radios
closer than 1.5 meters apart, to avoid interference.
Talk range depends on the terrain. It will be affected by
concrete structures, heavy foliage and by operating
radios indoors or in vehicles.
Optimal range occurs in flat, open areas, with up to 5
kilometres of coverage. Medium range occurs when
buildings and trees are in the way. Minimal range
occurs when dense foliage and mountains obstruct the
communication path.
Monitoring Channel Activity
It is good radio etiquette to monitor the channel for
activity before you transmit, to ensure that you do not
interrupt other users already on the channel.
Pressing and holding Jallows you to monitor your
channel for activity. If you hear static, the channel is
clear for use. Obstacles that block the signal path may
affect the strength of the incoming signal.
Optimal Range
Outdoors Medium Range Outdoors Minimal Range Outdoors
Flat, open areas Buildings or trees.
Also near
residential
buildings
Dense foliage or
mountains. Also
inside some
buildings
6864227V01-A_EN.fm Page 7 Thursday, April 6, 2006 2:37 PM

English
8
Selecting a Radio Channel
1.Press \. The channel number will begin to flash.
2.Use ]or [to change channel.
3.Press Mto set new channel.
Interference Eliminator Code
Interference eliminator codes help minimize
interference by providing you with a choice of code
combinations.You can specify a different code for each
channel.
1.Press \until the code number begins to flash.
2.Use ]or [to change the code.
3.Press Mto set new code.
You can specify a different code for each channel:
1.To set a channel and code combination, press \
and then press ]or [to select the channel.
2.Press \again and then press ]or [to select
a code.
3.Press Mor press and hold \to exit the menu
and to save the channel and code combination.
4.To set another channel and code combination,
repeat these steps.
Scan
1.To start scanning, briefly press and release the
Jbutton.
2.If you activate scan while your code is set to 0, then
the radio will check for any activity on each channel,
regardless of the code in use on that channel.
3.If you activate scan while the code is set on 1to 38,
the radio will only check for activity on the specific
channel and code combinations that are set on your
radio.
4.While the radio is scanning, hwill be displayed and
the radio will scroll through the channels.
5.When activity is detected on a channel, the radio will
stop scanning and you will hear whatever transmis-
sions are detected. The radio’s display will show the
channel and code on which activity was detected.
6.If you want to respond to the transmission, press M
within 5 seconds.
7.The radio will resume scanning after 5 seconds of
inactivity on the channel.
8.If scan stops on a channel that you don’t want to lis-
ten to,briefly press ]or [to resume scanning for
the next active channel.
9.To stop scanning, briefly press and release J.
Nuisance Delete
1.If scan continuously stops on an undesired channel,
press and hold ]or [for at least 3 seconds, then
release. This will temporarily remove the undesired
channel from the scan list.
6864227V01-A_EN.fm Page 8 Thursday, April 6, 2006 2:37 PM

9
English
2.To restore the channel to the scan list, turn the radio
off and then on.
3.You cannot remove your home channel from the
scan list (your home channel is the channel your
radio was set to when you activated scan).
Hands Free Use (VOX)
VOX allows you to talk
"hands free" when used
withoptional accessories
connected to the radio.
Note: When using audio
accessories with your
radio, turn the volume
of your radio down
before you place the
accessory on your
head or in your ear.
How To Use The VOX Feature
1.Switch off your radio.
2.Open the accessory cover and insert the audio
accessory into the accessory jack.
3.Switch on your radio. The flashing gicon will
appear in the display to indicate that the VOX feature
is active.
4.To transmit, speak into the accessory microphone.
To receive, stop talking.
5.Pressing Mor removing audio accessory will dis-
able VOX operation.
Note: There is a short delay after you start talking,
before the radio transmits.
Setting the Sensitivity Level
Adjusting the VOX and/or microphone sensitivity level
helps to minimize the possibility of unintended noises
triggering a transmission, or enhances the ability to pick
up quiet voices.
If an accessory is fitted to your radio these instructions
will help you to adjust the VOX sensitivity. If no
accessory is fitted the microphone sensitivity will be
adjusted.
1.Press \until gand a flashing number appear in
the display.
2.Select sensitivity level of 1, 2or 3by using ]or
[.
1- If you speak loudly, or are in a noisy environment.
2- Suitable for most applications.
3- If you speak softly, or are in a quiet environment.
Note: When you connect a VOX accessory, the radio
will automatically be set to the last chosen VOX
sensitivity level.
Vibrate
Your radio can be set to vibrate when it receives a call.
Vibrate is then suspended until 30 seconds after
channel activity has finished.
1.Press \until iis displayed
2.Press ]or [to select the Yor <.
6864227V01-A_EN.fm Page 9 Thursday, April 6, 2006 2:37 PM

English
10
Time-out Timer
The Time-out Timer feature helps extend battery life by
preventing the radio from accidentally transmitting. The
radio will emit a continuous warning tone after Mis
pressed for 60 continuous seconds and will stop
transmitting.
Keypad Lock
The keypad lock disables the \, ]and [
buttons. It also disables the scan function but allows
use of the J, M, ^buttons and and to turn the
radio on and off.
1.To lock or unlock the keypad press and hold the \
button for three seconds. When the radio is locked
fwill show in the display.
Backlight
Your radio has a backlight which turns on when a
button is pressed and turns off automatically 4 seconds
after you last pressed a button.
ALERTS
Channel Busy Indicator
The red LED will flash twice per second to indicate that
the channel is in use.
Call Tone
Your radio can transmit different call tones to other
radios, alerting users on the same channel and code
that you are about to talk. Your radio has 10 call tones
to choose from. Setting the call tone to 0disables ^.
1.To set your call tone press \until EIs displayed.
2.Press ]and [to change and hear call tones
while the setting number is flashing.
3.Press Mto set new call tone.
Talk Confirmation Tone
When you turn on this feature, your two-way radio
transmits a chirp when you finish transmitting and
release the M. It's like saying 'Roger' or 'Over', and
lets others know you've finished talking.
1.To enable or disable this tone, press and hold ]as
you turn your radio on.
2.When the roger beep is enabled !will show in the
display.
3.When you release the Mbutton you will hear the
talk confirmation tone.
6864227V01-A_EN.fm Page 10 Thursday, April 6, 2006 2:37 PM

11
English
FURTHER INFORMATION
Troubleshooting
No power or erratic display
• Reposition, replace or recharge batteries.
Message not transmitted
• Make sure that the M button is completely pressed while you transmit.
• Reposition, replace or recharge batteries.
• Shared channel may be in use, try another channel.
Message not received
• Confirm radios have same channel settings and interference eliminator codes
(helps minimize interference).
• Make sure that the
M button is not inadvertently being pressed.
• Reposition, replace or recharge batteries.
• Obstructions, and operating indoors or in vehicles may interfere with
communication. Change your location.
• Check to make sure volume is turned up.
Hearing other conversation or
noise on a Channel
• Shared channel may be in use, try another.
Limited talk range
• Steel or concrete structures, heavy foliage and use in buildings and in vehicles will
decrease range. Check for clear line of sight to improve transmission.
• Wearing radio close to body such as in a pocket or on a belt will decrease range.
Heavy static or interference
• Radios too close. Radios must be at least 1.5 metres apart.
• Radios too far apart. Obstacles interfere with transmission
6864227V01-A_EN.fm Page 11 Thursday, April 6, 2006 2:37 PM

English
12
Use and Care
To clean your radio:
• Use a soft damp cloth.
• Do not immerse in water.
• Do not use alcohol or cleaning solutions.
If your radio gets wet:
• Turn it off and remove batteries.
• Dry with soft cloth.
• Battery contacts may be wiped with a dry, lint-free cloth.
• Do not use until completely dry.
Specifications
Channels 8
Codes 38
Operating Frequency 446.00625-446.09375 MHz
Talk Range Up to 5 kilometres
Power Source NiMH battery pack or 3 AA
alkaline batteries
Type Designation T5622
Transmitter Power
(Watts) 0.5 ERP
Modulation Type Phase (Angle)
Channel Spacing (kHz) 12.5
6864227V01-A_EN.fm Page 12 Thursday, April 6, 2006 2:37 PM

13
English
Warranty Information
The authorized Motorola dealer or retailer where you
purchased your Motorola two-way radio and/or original
accessories will honour a warranty claim and/or
provide warranty service.
Please return your radio to your dealer or retailer to
claim your warranty service. Do not return your radio to
Motorola.
In order to be eligible to receive warranty service, you
must present your receipt of purchase or a comparable
substitute proof of purchase bearing the date of
purchase. The two-way radio should also clearly
display the serial number. The warranty will not apply if
the type or serial numbers on the product have been
altered, deleted, removed, or made illegible.
What Is Not Covered By The Warranty
• Defects or damage resulting from use of the Product in
other than its normal and customary manner or by not
following the instructions in this user manual.
• Defects or damage from misuse, accident or neglect.
• Defects of damage from improper testing, operation,
maintenance, adjustment, or any alteration or
modification of any kind.
• Breakage or damage to aerials unless caused directly
by defects in material or workmanship.
• Products disassembled or repaired in such a manner as
to adversely affect performance or prevent adequate
inspection and testing to verify any warranty claim.
• Defects or damage due to range.
• Defects or damage due to moisture, liquid or spills.
• All plastic surfaces and all other externally exposed
parts that are scratched or damaged due to normal use.
• Products rented on a temporary basis.
• Periodic maintenance and repair or replacement of
parts due to normal usage, wear and tear.
Copyright Information
The Motorola products described in this manual may
include copyrighted Motorola programs, stored
semiconductor memories or other media. Laws in the
United States and other countries preserve for
Motorola, certain exclusive rights for copyrighted
computer programs, including the exclusive right to
copy or reproduce in any form, the copyrighted
Motorola programs.
Accordingly, any copyrighted Motorola computer
programs contained in the Motorola products described
in this manual may not be copied or reproduced in any
manner without express written permission of
Motorola. Furthermore, the purchase of Motorola
products shall not be deemed to grant either directly or
by implication, estoppel, or otherwise, any license
under the copyrights, patents or patent applications of
Motorola, except for the normal non-exclusive royalty
free license to use that arises by operation of law in the
sale of a product.
6864227V01-A_EN.fm Page 13 Thursday, April 6, 2006 2:37 PM

English
14
MOTOROLA, the Stylized M Logo and all other
trademarks indicated as such herein are trademarks of
Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off.
© Motorola, Inc. 2006
For use in:
@6864227V01A@
6864227V01A
6864227V01-A_EN.fm Page 14 Thursday, April 6, 2006 2:37 PM

15
English
APPROVED ACCESSORIES LIST
Please contact your dealer or retailer to purchase these accessories
Earbud with Push-To-Talk
Microphone 00174
Discreet, lightweight earpiece
with hand-operated lapel or
collar mounted microphone.
Allows clear communication
without disturbance or
interference.
Waterproof Bag 00178
Clear plastic waterproof bag
offers protection from the
elements and submersion
while still enabling your radio
to be operated. A must for
watersports fans.
Rechargeable NiMH 00226
It is always nice to know you
have good back up. A
rechargeable battery pack -
have one spare for those
busy times. Supplied with
charger adaptor cover.
Nylon Carry Case 00173
Nylon pouch with a loop that
attaches to your belt to hold
your radio securely. Supplied
with extra loops so you can
fix to rucksacks or bikes. Can
be used with audio
accessories.
Charging Desk Stand
00197
Charger Transformer
00204 (UK)
00205 (EURO)
Replacement transformer.
Headset with Boom
Microphone 00179
Comfortable, lightweight
headset eliminates
background noise. Provides
access to the voice activated
transmission (VOX) mode.
Ideal for situations which
require hands-free operation.
6864227V01-A_EN.fm Page 15 Thursday, April 6, 2006 2:37 PM

English
16
6864227V01-A_EN.fm Page 16 Thursday, April 6, 2006 2:37 PM

1
Français
CONTENTS
SÉCURITÉ ET EXPOSITION AUX
FRÉQUENCES RADIO POUR PORTATIFS
ÉMETTEURS-RÉCEPTEURS
Mode d'emploi de sécurité du chargeur. . . . . . . . . . 3
DEMARRAGE
Votre nouveau poste . . . . . . . . . . . . . . . . . . . . . .5
Installation des piles et chargement de la batterie
NiMH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pour allumer et éteindre le poste . . . . . . . . . . . . . 6
Niveau de charge et avertissement . . . . . . . . . . .6
Pince de ceinture . . . . . . . . . . . . . . . . . . . . . . . . . 7
PARLER ET ECOUTER
Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Portée de communication . . . . . . . . . . . . . . . . . . 7
Ecoute de l’activité sur un canal . . . . . . . . . . . . . 7
Sélection d’un canal de communication . . . . . . . 8
Code d’élimination des interférences . . . . . . . . . . 8
Balayage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Suppression de canal nuisible . . . . . . . . . . . . . . . 9
Mode mains-libres (VOX) . . . . . . . . . . . . . . . . . . . 9
Vibreur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Limiteur de temps d’émission . . . . . . . . . . . . . . 10
Verrouillage du clavier . . . . . . . . . . . . . . . . . . . . 10
Rétroéclairage . . . . . . . . . . . . . . . . . . . . . . . . . . 10
AVERTISSEMENTS
Indication de canal occupé . . . . . . . . . . . . . . . .10
Tonalité d’appel. . . . . . . . . . . . . . . . . . . . . . . . . .10
Tonalité de confirmation . . . . . . . . . . . . . . . . . . .10
INFORMATIONS SUPPLÉMENTAIRES
Dépistage des problèmes . . . . . . . . . . . . . . . . . 12
Utilisation et soins . . . . . . . . . . . . . . . . . . . . . . .13
Caractéristiques techniques . . . . . . . . . . . . . . . .13
Informations sur la garantie . . . . . . . . . . . . . . . .14
Informations sur les droits d'auteur . . . . . . . . . .14
LISTE DES ACCESSOIRES APPROUVÉS
Liste des accessoires approuvés . . . . . . . . . . . . 16
6864227V01-A_FR.fm Page 1 Thursday, April 6, 2006 2:28 PM

Français
2
SÉCURITÉ ET EXPOSITION AUX
FRÉQUENCES RADIO POUR
PORTATIFS ÉMETTEURS-
RÉCEPTEURS
ATTENTION!
Avant d’utiliser ce produit, vous devez lire les
informations sur l’énergie électromagnétique HF et les
instructions d’utilisation dans le livret « Sécurité des
équipements et exposition HF » pour connaître et
appliquer les limites d’exposition à l’énergie HF.
Avant d’utiliser ce produit, vous devez
lire les instructions de sécurité
présentées dans le livret « Sécurité
des équipements et exposition HF »
fourni avec votre poste.
!
C a u t i o n
ATTENT ION!
6864227V01-A_FR.fm Page 2 Thursday, April 6, 2006 2:28 PM

3
Français
Mode d'Emploi de Sécurité du Chargeur
Avant d'utiliser le chargeur, lisez bien tout le mode
d'emploi et les avertissements sur:
• La pile
• Le chargeur de pile et
• La radio utilisant la pile.
Attention: Pour diminuer le risque de blesser, ne
rechargez que la pile rechargeable Motorola
approuvée pour ce produit. D'autres types de piles
peuvent éclater, causant des blessures
personnelles et des endommagements.
CONSERVEZ CE MODE D'EMPLOI
1.N'exposez pas le chargeur à la pluie ou à la neige.
2.N'utilisez pas ou ne démontez pas le chargeur s'il a
reçu un coup ou est tombé ou a été endommagé de
quelque façon que ce soit.
3.N'apportez aucune modification au cordon ou à la
fiche secteur fourni(e) avec l'unité. Si la fiche n'entre
pas dans la prise secteur, faîtes installer une prise
adéquate par un électricien qualifié. Une installation
incorrecte expose l'utilisateur au risque de chocs
électriques.
4.Pour diminuer le risque d'endommagement du cordon
ou de la fiche, tirez par la fiche plutôt que par le cordon
lorsque vous débranchez le chargeur de la sortie
secteur.
5.Pour diminuer le risque de chocs électriques,
débranchez le chargeur de la prise secteur avant toute
tentative d'entretien ou de nettoyage.
6.L'utilisation d'un accessoire non recommandé ou
vendu par Motorola peut entraîner un risque
d'incendie, de chocs électriques ou de blessure
corporelle.
7.Assurez-vous que le cordon est placé à un endroit où
personne ne peut endommager ou tordre le câble , ni
marcher ou trébucher dessus.
8.Une rallonge ne devra pas être utilisée à moins qu'elle
ne soit absolument nécessaire. L'usage d'une rallonge
inadaptée pourrait entraîner un risque d'incendie et/ou
de chocs électriques. Si une rallonge s'avère
nécessaire, vérifiez :
• Que les broches de la fiche de la rallonge ont le même
numéro, la même taille et la même forme que celles de
la fiche du chargeur.
• Que la rallonge est correctement posée et en bonne
condition électrique et
• Que la taille du cordon est de 18 AWG (1 mm
2
) pour
des longueurs de jusqu'à 30 mètres (100 pieds) et de
16 AWG (1,3 mm
2
) pour des longueurs de jusqu'à 45
mètres (150 pieds).
9.Le cordon d'alimentation de ce chargeur ne peut pas
être remplacé. Si le cordon est endommagé, veuillez
le renvoyer à votre lieu d'achat.
6864227V01-A_FR.fm Page 3 Thursday, April 6, 2006 2:28 PM

Français
4
DEMARRAGE
Appuyez sur P pour :
• Allumer et éteindre le
poste
• Régler le volume
Appuyez sur
^ pour :
• Transmettre une tonalité
d’appel
Appuyez sur
\ pour :
• Faire défiler les menus
• Verrouiller et déverrouiller le
clavier (maintenir cette touche
quand aucun menu n’est ouvert)
Témoin lumineux
Appuyez sur
Mpour :
• Parler
• Enregistrer un réglage
Cache protecteur du
connecteur d’accessoire
Appuyez sur J pour :
• Ecouter l’activité sur un canal
• Balayage
Appuyez sur
[ et ] pour :
• Faire défiler les réglages
disponibles
Microphone
Haut-parleur
6864227V01-A_FR.fm Page 4 Thursday, April 6, 2006 2:28 PM
