MOTECK CM42 User manual

Control Box
CM42
www.moteck.com
User Guide
2022.06_V1.4
Revision
Technical changes may be made to improve the product without notice!
1
2
4
5
7
8
I/O Introduction
Installation
SET mode (Dedicated setting handset is needed)
Operation
Status and Disposal
Battery Replacement
Table of Contents

www.moteck.com
1
• Please do not expose the product to places where there is concern about overheating,
fires, or direct sunlight.
• Please keep product away from places suspected of static electricity or water leakage to
avoid electric shock or short circuit.
• The weight of the control box is not light. In order to prevent falling damage or personal
injury, please ensure that there is enough working space when installing the product, and
install it firmly in an appropriate way.
• If you find that the product is overheating, smoking or smelling, please stop operating
immediately and press the emergency stop button on the top of the control box. If
abnormalities occur during charging, immediately unplug the power cord to stop charging.
Do not ignore this situation, it may cause the danger of fire or electric shock.
• Do not damage or modify the power cord, or forcefully bend, pull, twist, or squeeze it.
• Do not touch the plug of the charging cable with wet hands, otherwise it may cause electric
shock.
• Please press the emergency stop button before performing maintenance. And do not
perform cleaning and maintenance during charging to avoid electric shock or injury.
• Use a soft and clean damp cloth to wipe the surface dirt. Do not use strong solvents or
rinse directly with large amounts of water.
• The functions and parameters described in this user guide are based on the design of the
CM42 standard version firmware. If it is a customized firmware, some content may be different.
Notice
I/O Introduction
AC in
Handset
Actuator for High/Low (M1)
Actuator for Leg Adjustment (M2)
Lowering Button
Emergency Stop Button
Cable Hook
Indicator

240.5 +2
-0
2
www.moteck.com
Installation
●Preparation for Mounting
Prior to installation, please ensure that you have sufficient space to safely install the CM42 and to avoid the
risk of falling. At the mounting position on the hoist, two M6 screw holes with a distance of 240.5~242.5 mm
must be prepared in advance. When you install and operate, pay attention to safety. Do not place the product
near explosive, flammable, corrosive materials or under humid environments.
●Installation of Cable Hook
1. Fasten the cable hook to the main body with two screws.
2. Please ensure the screws are tightened.

3
www.moteck.com
●Mount CM42 on the hoist
1. Mount CM42 on the hoist frame with 2 fixing screws.
2. Please ensure the screws are tightened securely.
3. Connect the handset and actuators to the control box.
• The battery should be fully charged before using. Refer to the “Battery Charging” for
proper charging instructions.
Notice

1-
2- 1+
2+
Dedicated H2T setting handset
LED indicator
SET
Method 1: Self detect and learning
1. The current consumption value of the actuator has a great relationship with the load weight. Therefore, please
put the weight that is required for future use on the hoist before starting this detection learning function.
2. Press "1+" for 1 second to start detection learning in SET mode.
3. Actuator for High/Low (M1) extends automatically for 2.5 seconds. The indicator light on H2T will turn
on for 2.5 seconds.
4. During self-learning mode, the LED indicator on the CM42 will turn orange for 2.5 seconds.
Method 2: Manual setting
1. If you know the normal current consumption value of the actuator used with it, you can directly
set it in this function.
2. Press “2+“ to increase the current limit on handset in SET mode.
3. Press “2-” to decrease the current limit on handset
4. The available range is from 5~9A, 1A per step. The actuator current will display on the battery level bar on H2T.
Value 5A
Level bar
6A 7A 8A 9A
4
www.moteck.com
●Enter SET mode
To enter the SET mode, press and hold the SET button for 2 seconds.
●Exit SET mode
Hold down the SET button for 2 seconds, or if the user does not
press any button for more than 10 seconds, the set data will be
saved automatically.
SET mode (Dedicated setting handset is needed)
●Actuator current limit setting
There are 2 ways to set the protection limit for M1 actuator in SET mode. CM42 will stop immediately if actuator's
consumption current exceeds the set limit.
• If you press the emergency stop button or unplug the handset in SET mode, all newly
set data will be deleted without saving.
Notice

5
www.moteck.com
1. Stop: Firmly press the red button until you hear a “click” sound, then the button locks and cuts off power.
It stops the actuator immediately.
2. Release: Turn the red button in the clockwise direction to release the button, and the power will restore.
Operation
Emergency Stop Button
●General Control
1. Hold 1+ button, M1 extends, release the button to stop
the movement.
2. Hold 1- button, M1 retracts, release the button to stop
the movement.
3. Hold 2+ button, M2 extends, release the button to stop
the movement.
4. Hold 2- button, M2 retracts, release the button to stop
the movement.
5. During operation, the LED indicator of CM42 and the
battery level indicator of HS12L will be on, and the
indicators will turn off when operation stops.
6. If it is not used for about 1 minute, the control box will turn
into sleeping state and automatically power off. Press any
button to wake up.
●Lowering Button
Hold lowering Button, M1 retracts, release the button to stop
the movement.
LED indicator on CM42
M1 retracts
(Lowering Button)
2-
HS12L
1- 1+
2+
Battery level
indication
●Over duty protection on M1(On/OFF)
1. The actuator and the control box need to rest properly to dissipate heat, to avoid damage caused by
continuous and excessive operation. The control box has a protection function. When continuous operation is
too long or the operation frequency is too high, it will perform protection and temporarily turn off operation.
2. Active / inactive the "Over duty Protection on M1".
Press "2+" & "2-" at the same time in SET mode. “Over duty protection on M1” is ON by default and the
indicator will be on.
1. Press "1+" & "1-" at the same time and hold for 2.5 seconds in SET mode, the system will return to all default
settings. There will be a long beep.
2. Default value settings: Key tone and soft start are off, over duty protection is active, current limit is 7A.
●Reset

6
www.moteck.com
HS12L
AC in
●Battery Charging
1. After connecting the charging cable, charging will start automatically, and the LED indicator on CM42 will flash
red. The battery indicator on the HS12L hand controller will also flash at the same time.
2. When charging is completed, it will stop automatically, and the LED indicator of CM42 is continuously lit green.
The battery indicator on HS12L handset is continuously lit green as shown below.
3. After unplugging the charging cable or the AC plug, the CM42 system will process for optimization automatically.
During this time, the CM42 is still temporarily unable to operate for about 15 seconds, and the LED indicator
and HS12L battery indicator will flash continuously until it goes out to return to the normal standby state.
2. When the buzzer of the control box sounds intermittently for 4 times and stops for 4 seconds, and the LED
on CM42 flashes red at the same time, it means that the battery power is low, so as to remind the user to
charge the control box as soon as possible. After the control box enters the sleeping state and is powered off,
the buzzer reminder will temporarily turn off.
1. When the "1+" or "1-" button on the handset is pressed to control the movement of the lift actuator,
the battery level is indicated as below:
●Battery level indication
<20V 20~23.8V 23.8-24.5V 24.5-25.5V >25.5VValue
LED on CM42
Level bar on HS12L
• Please fully charge the battery before using it for the first time, so that the battery can
perform normally.
• The batteries must be charged at least every 3 month. Otherwise, batteries may be
damaged due to over self-discharge.
Notice

●Switch ON/OFF for Soft start & key tone
Function Operation Indication
Soft Start
Key Tone
(For 2-motor
model)
Hold 1+, 1- button simultaneously
for 3 seconds in order to switch on
and off.
Press 2+, 2- buttons on handset for
3 seconds at the same time.
ON
OFF
ON
OFF
The LED indicator blinks in
red 4 times
The LED indicator blinks in
red twice
The LED indicator blinks in
green twice, beep once.
The LED indicator blinks in
green twice, no sound.
7
www.moteck.com
Status and Disposal
Information DisposalPhenomena
M1 actuator is over load Look for and remove obstruction
or improper load. Please call the
agency if the situation continues.
●There is a short beep when
any button is pressed and the
actuator does not move.
● Indicator of overload warning
on HS12L continuous on
(Fig. 3)
Battery charging reminder,
battery voltage is low
The control box can continue
to be used temporarily, but should
be charged after use
● The LED indicator on CM42
blinks in red (Fig. 1)
● The buzzer sounds
intermittently for 4 times and
stops for 4 seconds
The low voltage protection
function is triggered, indicating
that the instantaneous voltage of
the battery is lower than 20V DC
Charge the battery immediately
●M1 actuator can only be
retracted
● The LED indicator on CM42
blinks in red (Fig. 1)
Indicator of
usage warning
Indicator of
overload warning
Fig. 1 Fig. 2 Fig. 3
M1 actuator is over duty
(after 4mins continuous
operating)
Stop operation for a while. The
error message will be gone
automatically after sufficient rest.
● The LED indicator on CM42
blinks in orange (Fig. 2)
● Indicator of usage warning on
HS12L blinks for 2 sec (Fig. 3)

Important safety instructions
6. Place the batteries upright.
5. Take the sponges out, and keep them aside.
8
www.moteck.com
Battery Replacement
1. Push down the emergency button.
2. Unplug all external cables from the control box.
3. Dismount the CM42 from the lift frame, and place it on a flat table.
4. Remove 6 screws at back side. Then, open the back cover, place as shown below.
●Steps of Replacement
sponge
6 screws
• End users please contact your dealer to arrange batteries replacement.
• If the battery replacement method is incorrect, electric shock or short circuit may occur.
Therefore, before replacing the battery, please read the following safety instructions and
follow the replacement steps.
1. Verify that the Charging Power Supply to the battery is off and that all power is
disconnected from the power source.
2. Remove watches, rings or other metal objects.
3. Use tools with insulated handles to prevent inadvertent shorts.
4. Do not lay tools or metal parts on top of batteries.
5. Verify circuit polarities before making connections.
Notice

7. Disconnect the wires from each terminal of the batteries. Please be careful not to damage the wire and plugs.
8. Then, replace batteries of the same type and size.
12 V 12 V
2.9 Ah 5.0 Ah
Total Height (mm/inch) 104 / 4.09 107 / 4.21
Shell Height (mm/inch) 98.5 / 3.88 101 / 3.98
Length (mm/inch) 79 / 3.11 90 / 3.54
Width (mm/inch) 55.5 / 2.19 70 / 2.76
Nominal Voltage
Rated Capacity
Dimensions
Specifications
9
www.moteck.com
9. The batteries must towards the same direction as shown below, then connect the positive and negative poles
between the two batteries with black wires.
5Ah 2.9Ah
• There are two options for CM42 batteries: 2.9Ah and 5Ah. For new batteries, always
follow the same specifications.
• To avoid abnormally shortening the service life of the batteries, please do not mix old
and new batteries or different brands.
Notice
• Please note that red is positive(+) pole and black is negative(-) pole.
• The battery replacement instructions in this user guide are based on the 5Ah battery as
an example, and the 2.9Ah battery polarity is opposite to the 5Ah battery (as shown in
the figure below). Please be careful to identify the battery polarity when replacing.
Notice

11. After connecting all the wires, place the batteries as shown in the photo below. Organize all the wires and
put them into the groove on the side, then put back the sponges.
12. When closing the back cover, make sure that no wires are pinched.
sponge
10. Connect another black wire to the negative pole, and the last red wire connects to the positive pole.
www.moteck.com
Terms of Use
The user is responsible for the suitability of MOTECK products, and the products listed on the MOTECK website are subject to change without notice. MOTECK reserves the right to terminate sales or
delete any products displayed on the website or listed in its catalog.
MOTECK MO-I-0078-V1.410
• Never connect positive and negative poles of the same battery.
Notice
• When screwing the six screws back to the back cover, to avoid damaging the original
tapping, insert the screw into the hole, and then turn counterclockwise until your finger
feels a slight but clear "thread engagement".
• After the thread is "engaged", turn the screw clockwise to the end with an appropriate
force, but avoid over tightening.
• For protecting earth and environment, please recycle used batteries through authorized
channel.
Notice
