Motorline professional MA115 Operation and installation manual

v3.0
REV. 01/2020
MA115
MA115
EN
INSTALLER AND USER’S MANUAL

1A 1B
1B
4A
4A
4B
4B
5
6
8A
12
7
ENEN
00. CONTENT
INDEX
MA AND MB
INSTALLATION MAP
ANTENNA INSTALLATION
INICIAL SETTING
TAG MEMORIZE
CONNECTION SCHEME
TECHNICAL CHARACTERISTICS
DIMENSIONS
PACKING
. SAFETY INSTRUCTIONS
. PRODUCT
. INSTALLATION
. PROGRAMMING
. CONNECTIONS
ATTENTION:
01. SAFETY INSTRUCTIONS
This product is certified in accordance with European
Community (EC) safety standards.
This product complies with Directive 2011/65/EU of the
European Parliament and of the Council, of 8 June 2011, on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
(Applicable in countries with recycling systems).
This marking on the product or literature indicates that the
product and electronic accessories (eg. Charger, USB cable,
electronic material, controls, etc.) should not be disposed
of as other household waste at the end of its useful life. To
avoid possible harm to the environment or human health
resulting from the uncontrolled disposal of waste, separate
these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material
resources. Home users should contact the dealer where they
purchased this product or the National Environment Agency
for details on where and how they can take these items
for environmentally safe recycling. Business users should
contact their vendor and check the terms and conditions
of the purchase agreement. This product and its electronic
accessories should not be mixed with other commercial
waste.
This marking indicates that the product and electronic
accessories (eg. charger, USB cable, electronic material,
controls, etc.) are susceptible to electric shock by direct or
indirect contact with electricity. Be cautious when handling
theproductandobserveallsafetyproceduresinthismanual.

2EN
GENERAL WARNINGS
•This manual contains very important safety and usage information.
very important. Read all instructions carefully before beginning the
installation/usage procedures and keep this manual in a safe place
that it can be consulted whenever necessary.
•This product is intended for use only as described in this manual. Any
other enforcement or operation that is not mentioned is expressly
prohibited, as it may damage the product and put people at risk causing
serious injuries.
•This manual is intended firstly for specialized technicians, and does not
invalidate the user’s responsibility to read the “User Norms” section in
order to ensure the correct functioning of the product.
•The installation and repair of this product may be done by qualified
and specialized technicians, to assure every procedure are carried
out in accordance with applicable rules and norms. Nonprofessional
and inexperienced users are expressly prohibited of taking any action,
unless explicitly requested by specialized technicians to do so.
•Installations must be frequently inspected for unbalance and the
wear signals of the cables, springs, hinges, wheels, supports and other
mechanical assembly parts.
•Donotuse the productifitisnecessary repair oradjustmentisrequired.
•When performing maintenance, cleaning and replacement of parts, the
product must be disconnected from power supply. Also including any
operation that requires opening the product cover.
•The use,cleaning and maintenance ofthisproduct maybe carriedout by
any persons aged eight years old and over and persons whose physical,
sensorial or mental capacities are lower, or by persons without any
knowledge of the product, provided that these are supervision and
instructions given by persons with experienced in terms of usage
of the product in a safe manner and who understands the risks and
dangers involved.
•Children shouldn’t play with the product or opening devices to avoid
the motorized door or gate from being triggered involuntarily.
WARNINGS FOR TECHNICIANS
•Before beginning the installation procedures, make sure that you have
all the devices and materials necessary to complete the installation of
the product.
•You should note your Protection Index (IP) and operating temperature
to ensure that is suitable for the installation site.
•Provide the manual of the product to the user and let them know how
to handle it in an emergency.
•If the automatism is installed on a gate with a pedestrian door, a door
locking mechanism must be installed while the gate is in motion.
•Do not install the product “upside down” or supported by elements do
not support its weight. If necessary, add brackets at strategic points to
ensure the safety of the automatism.
•Do not install the product in explosive site.
•Safety devices must protect the possible crushing, cutting, transport
and danger areas of the motorized door or gate.
•Verify that the elements to be automated (gates, door, windows,
blinds, etc.) are in perfect function, aligned and level. Also verify if the
necessary mechanical stops are in the appropriate places.
•The central must be installed on a safe place of any fluid (rain, moisture,
etc.), dust and pests.
•You must route the various electrical cables through protective tubes,
to protect them against mechanical exertions, essentially on the power
supply cable. Please note that all the cables must enter the central
from the bottom.
•If the automatism is to be installed at a height of more than 2,5m from
the ground or other level of access, the minimum safety and health
requirements for the use of work equipment workers at the work of
Directive 2009/104/CE of European Parliament and of the Council of 16
September 2009.
01. SAFETY INSTRUCTIONS

3EN
•Attach the permanent label for the manual release as close as possible
to the release mechanism.
•Disconnect means, such as a switch or circuit breaker on the electrical
panel, must be provided on the product’s fixed power supply leads in
accordance with the installation rules.
•If the product to be installed requires power supply of 230Vac or
110Vac, ensure that connection is to an electrical panel with ground
connection.
•The product is only powered by low voltage satefy with central (only
at 24V motors)
WARNINGS FOR USERS
•Keep this manual in a safe place to be consulted whenever necessary.
•If the product has contact with fluids without being prepared, it must
immediately disconnect from the power supply to avoid short circuits,
and consult a specialized technician.
•Ensure that technician has provided you the product manual and
informed you how to handle the product in an emergency.
•Ifthesystemrequiresanyrepairormodification,unlocktheautomatism,
turn off the power and do not use it until all safety conditions have
been met.
•In the event of tripping of circuits breakers of fuse failure, locate
the malfunction and solve it before resetting the circuit breaker or
replacing the fuse. If the malfunction is not repairable by consult this
manual, contact a technician.
•Keep the operation area of the motorized gate free while the gate in in
motion, and do not create strength to the gate movement.
•Do not perform any operation on mechanical elements or hinges if the
product is in motion.
RESPONSABILITY
•Supplier disclaims any liability if:
•Product failure or deformation result from improper installation
use or maintenance!
•Safety norms are not followed in the installation, use and
maintenance of the product.
•Instructions in this manual are not followed.
•Damaged is caused by unauthorized modifications
•In these cases, the warranty is voided.
01. SAFETY INSTRUCTIONS
SYMBOLS LEGEND:
• Important safety
notices
• Useful information
• Programming
information
• Potentiometer
information
• Connectors
information
• Buttons
information

4A 4B
08•
01•
07•
06•
05•
02•
445mm 382mm
445mm 70mm
40mm
382mm
ENEN
The MA is a long-range RFID antenna, designed to work as a vehicle or even a personal access control,
provided it is accompanied with an MB programmed for that antenna. The dimensions of the MA are as follows:
In the kit you will find these components:
The MB is an RFID tag with adhesive that can be attached to the car's windscreen, forklift, or personal
belongings (eg purse or mobile phone).
It only works connected to the MCA /  control panel or to an access control device with
built-in relay (eg MLB).
02. PRODUCT 02. PRODUCT
MA115 AND MB3
TECHNICAL CHARACTERISTICS
PACKING
TECHNICAL CHARACTERISTICS
01• 01 MA
02• 01 Fixing bracket
03• 01 Power Supply
04• 01 RS232 cable
05• 04 Screws DIN933 M8x20
06• 04 Power rammers DIN127 M8
07• 04 Washers DIN125 M8
08• 01 Wall bracket
MA115 Technical Data
• Working frequency
US: – MHz (America)
CH: – MHz (China)
EU: – MHz (Europe)
• Worhing voltage 12Vdc
• Reading distance 5-15m (réglable)
• Protocols MA MOTORLINE, ISO-B, (EPC GEN)
• Environment temperature -25~55C
• Environment humidity 20% ~ 95% (IP54)
• Power 2.4W standby 14W TAG reading: 14W
• Antenne dB to dBi
• Interface Wiegand-bit, Wiegand-bit
• Signal power 0 ~ 30dBm (réglable)
• Reading Sensitivity Dual polarization reading
• Working indication Sonnerie et LED

5EN
. INSTALLATION MAP
INSTALLATION GUIDE
PC
(optional)
MCA
(optional)
EF380
Electromagnetic
lock
MA115
MB3
MLS
Controller
of Access
Possible angles
MB3 in automobiles should be fixed to the car glass away from the metal frame of the
vehicle. On motorcycles it must be fixed to the plastic front frame.
15°-20°

6
3
12
3
3
4
5
1
2
EN
. INSTALLATION
MARKING THE HOLES
Position the wall bracket at the desired installation location between a height of 1.5m and
2m.
DRILL HOLES
Drill holes. Replace the wall bracket and attach the two brackets to the wall through the
bracket.
FIX THE ANTENNA
Attach the antenna to the fixing bracket with the four screws, force rings and washers
successively, provided in the kit
POSITION THE ANTENNA
Position the antenna at the angle that is most convenient for you to read the MB3.
CONNECTING ANTENNA
Connect the antenna to the MCA, the RS232 cable to the computer and the power supply
according to the diagrams on the following pages.
STEPS TO FOLLOW
The same antenna can not be used for inputs and outputs. You will need to get an
antenna for each effect.

7
12V GND
GND P1
12VGNDS1GND COMNONCS2GND COMNONC
D1
D0 LED
12V GND
D1
D0 LED
DR1
DR2
SYS
IN
ERR
POWER
LINK ACT
JD1
JD2
J12
GND
P2
12VGND
D1
D0LED12V
GND
D1
D0LED
EF380
MB17
MA115
RS232
USB
+12V
GND
+12V
GND
HA0488
HA0488
EF30
EF380
+12V
GND
EF30
EN
. CONNECTIONS
CONNECTION SCHEME
Power Supply
Power Supply
Power Supply
 card reader
(In)  card reader
(Exit)
Red
Black
Yellow or white
Brown and blue
Green
 Door
Exit Button
Interface of
alarm and
fire control
 Door
Exit Button
Red
Red
Black
Black
Yellow or white
Yellow or white
Green
Green
Brown and blue
Brown and blue
Fio
Card
reader (In)
Card
reader (Exit)
Connecting the antenna to
the computer is required
for configuration only.
Once configured, it is not
necessary to continue
using the antenna
connected to a computer.
In EF, in case
of electrical
failure the door
will open.
MA ANTENNA WIRE
Nº Wire color Description
(standard version) Description (LAN version)
1Red +12V +12V
2Black 0V 0V
3Brown RS_TXD RS_TXD
4Yellow RS_RXD RS_RXD
5Blue RS_GND RS_GND
6Gray TRIGGER TRIGGER
7White DATA RX
8Green DATA RX-
9Orange 485R+ (Not used) TX+
10 Violet 485R- (Not used) TX-
Red
Black
Yellow or white
Brown and blue
Green
Switch or Hub

8A 8B
5
7
6
3
4
ENEN
. PROGRAMMING . PROGRAMMING
INITIAL SETTING INITIAL SETTING
When using the device for the first time, you must program the device:
1
• Connect the RS232 to the
computer.
Note •The kit has an RS232 to USB
converter in case your computer
does not have an RS232 port.
2 • Download the software.
3 • Select the input port. To find
out which is the gateway, go to My
Computer> Device Manager.
4 • Select communication speed:
9600.
5
• Select the auto switch.
6 • To confirm that communication
has been made, check the status
in the lower right corner.
Note • From this moment on, you
can change the language.
7 • Press on the "Base settings" tab.

9A 9B
11
10
8
9
ENEN
. PROGRAMMING . PROGRAMMING
INITIAL SETTING INITIAL SETTING
8 • Select "Active" in "Work Mode".
9 • Select the "Power Size" by
choosing a power level between 
and  dBm.
10
• You can enable or disable the
antenna buzzer.
11 • You can change the type of
output. For Motorline control
boards, you should choose WG26.

10A 10B
12
12
13 15
14
ENEN
. PROGRAMMING . PROGRAMMING
INITIAL SETTING INITIAL SETTING
12 • This parameter allows you to
select the type of trigger we will
use. The reader will recognize a
tag if there are links and a set
interval time. In case we have no
shot, we use the "Close" mode.
13 • Select "EPC (GEN) SINGLE TAG"
in "CARD TYPE".
14 • In this parameter you can set
the interval time when reading
different tags.
Example: If you set 50 every 50ms,
the antenna will try to read any
tag in their reach.
15
• In this parameter you can set
the time frame for reading the
same tag.
Example: When a vehicle
approaches an antenna, the tag
is recognized and the opening
order occurs. While the opening
is in progress, that vehicle's tag
remains detectable but does not
execute a new order for the time
you set in this parameter.

11A 11B
16
17
18
ENEN
. PROGRAMMING . PROGRAMMING
INITIAL SETTING INITIAL SETTING
16 • Select one of the 3 available
regions (already have frequencies
already set) or set the desired
frequency manually.
17 • To complete and save all
changes, press "Set & Save To".
18
• To confirm that the data was
successfully recorded, press the
"Default All" button (all factory
settings appear) and then press
"Get To" (the values you recorded
appear).

12
1
4
2
3
EN
. PROGRAMMING
TAG MEMORIZE
1 • Select the "EPC (GEN 2)
READ&WRITE" tab.
2 • Choose the desired Wiegand
-Bit card ID format.
3 • Fill in the number you want to
write in the tag.
4 • If the tag is stored, a green
message appears.
