Motorola DCT700 User manual

USER GUIDE MANUAL
DCT700
One-way Application

i
CAUTION
RISK OF ELECTRIC SHOCK
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
CAUTION:
Graphical symbols and supplemental warning marking
locations on bottom of terminal.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRICAL SHOCK, DO NOT USE
THIS (POLARIZED) PLUG WITH AN EXTENSION
CORD, RECEPTACLE, OR OTHER OUTLET UNLESS
THE BLADES CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point, within an
equilateral triangle, is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
Product identification and supply rating is provided on
the label found on the bottom of the unit.
This installation should be made by a qualified service
person and should conform to all local codes.

ii
REPAIRS
If you find the unit in need of repair, contact your
system operator for repair or replacement.
NOTE TO SYSTEM INSTALLER
This reminder is provided to call the system installer’s
attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to
the grounding system of the building, as close as
possible to the point of cable entry as practical.
IMPORTANT SAFETY INSTRUCTIONS
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings.
Install in accordance with the
manufacturers instructions.
•Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
•Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong is
provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.

iii
•Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
•Only use attachments/accessories specified by
the manufacturer.
•Unplug this apparatus during lightning storms or
when unused for long periods of time.
•Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as the
power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
IMPORTANT SAFETY CONSIDERATIONS
Be sure to follow these requirements during
transportation and installation.
The plug is the main disconnect device. It shall
remain readily accessible and operable.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
DURING TRANSPORTATION TO THE
SUBSCRIBER HOME
Transport the cable terminal in its shipping box or an
equally padded container.
Do not expose the terminal to rain or moisture.

iv
DURING INSTALLATION
•Do not place the cable terminal in an
enclosed area where the cooling vents are
blocked or impede the flow of air through
the ventilation openings.
•Install the terminal so that its position does
not interfere with its proper ventilation. For
example, do not place the terminal on a bed,
sofa, rug, or similar surface that could block
the ventilation openings.
•Install the terminal away from heat sources
such as radiators, heat registers, and stoves.
Installation of the terminal near consumer
electronics devices, such as stereo
receiver/amplifiers and televisions, is
permitted as long as the air surrounding the
terminal does not exceed 40º C (104º F).
•Place the terminal on a flat surface not
prone to vibration or impact.
•Do not install the terminal in an area
where condensation occurs.
•To prevent the temporary loss of guide
data and cause a temporarily non-
responding terminal, do not plug the AC
power cord into a switched power outlet.
FCC COMPLIANCE
Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a

v
residential installation. This equipment generates
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly
approved by Motorola for compliance could void the
user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC DECLARATION OF CONFORMITY
Motorola Inc., Connected Home Solutions, 101
Tournament Drive, Horsham, PA 19044, 1-215-323-
1000, declares that the DCH70 receiver complies
with 47 CFR Parts 2 and 15 of the FCC rules as a
Class B digital device.

vi
Canada Industry Canada (IC)
This Class B digital device complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
US PATENT
4476584, 4546387, 4575755, 4621285, 4558464,
4603349, 4613901, 4634808, 4712238, 4792973,
4864615, 4933898, 5083293, 5144664, 5111504,
5406228, 5497112, 5485577, 5091782, 5068724,
5093720, 5376968, 5345408, 5565922, 5517250,
5566089, 4908859, 5396518, 5511096, 5511082,
4631603, 4819098, 4577216, 5363408
© 2007 Motorola, Inc. All rights reserved. No part
of this publication may be reproduced in any form
or by any means or used to make any derivative
work (such as translation, transformation, or
adaptation) without written permission from
Motorola, Inc.
All rights reserved. No part of this publication may
be reproduced in any form or by any means or used
to make any derivative work (such as translation,
transformation or adaptation) without written
permission from Motorola, Inc.
Motorola reserves the right to revise this
publication and to make changes in content from
time to time without obligation on the part of
Motorola to provide notification of such revision or
change. Motorola provides this guide without
warranty of any kind, either implied or expressed,
including but not limited to, the implied warranties
of merchantability and fitness for a particular
purpose. Motorola may make improvements or

vii
changes in the product(s) described in this manual
at any time.
MOTOROLA and the Stylized M Logo are
registered in the US Patent & Trademark Office.
Manufactured under license from Dolby
Laboratories. "Dolby" and the double-D symbol are
registered trademarks of Dolby Laboratories. All
other product or service names are the property of
their respective owners. MediaCipher is a
registered trademark of Motorola, Inc.

ix
CONTENTS
1 Introduction ........................................................................................................................................................... 1
Front Panel ........................................................................................................................................................ 2
Rear Panel......................................................................................................................................................... 3
Using the Remote Control ...................................................................................................................................... 5
Installing Batteries........................................................................................................................................... 9
Basic Operation ..................................................................................................................................................... 11
Turning Power On and Off............................................................................................................................. 11
Changing Channels........................................................................................................................................ 11
Electronic Program Guide............................................................................................................................. 12
Audio/Video Connections..................................................................................................................................... 13
Connecting Your DCT700 ...................................................................................................................................... 15
Standard TV Cabling ...................................................................................................................................... 15

CONTENTS
x
Standard VCR Cabling....................................................................................................................................16
Composite Baseband.....................................................................................................................................17
Composite VCR Cabling .................................................................................................................................18
Stereo Cabling Diagram (VCR to Stereo) ....................................................................................................19
Stereo Cabling Diagram (TV to Stereo).......................................................................................................20
Troubleshooting......................................................................................................................................................21

1
1 INTRODUCTION
The DCT700:
•Supports services such as
an EPG
•Reclaims bandwidth
allocated to analog channels
•Combats analog piracy
•Offers compatibility with
MediaCipher conditional
access technology
•The DCT700 requires a
remote control to operate
(remote control sold
Congratulations on receiving the DCT700 digital
consumer terminal, one of the most advanced interactive
digital cable terminals available today. It’s simple to set
up and easy to operate.
The DCT700 can provide an Electronic Program Guide
(EPG) menu that allows you to conveniently select and
view programs. You can also purchase Pay-Per-View
special events and recent movies, or Video on Demand.
Video on Demand is similar to renting a video, including
the ability to pause, rewind, and fast-forward.
This guide introduces you to the features and operation
of the DCT700. Access to the DCT700 features is gained
through the electronic program guide.
To get the most out of your DCT700, be sure to read your
electronic program guide instruction manual and remote
control User Guide.

1 INTRODUCTION
2
Front Panel
The DCT700 is controlled by your remote control (sold separately). The
front panel has two LED displays: one to indicate the unit is turned on
and one to indicate a message is present.

1 INTRODUCTION
3
Rear Panel
Before you begin installing the DCT700, take a moment to become
familiar with the rear panel connections. The rear panel includes
connectors for system cabling and a power cord to connect the DCT700
to an electrical power outlet. For cabling diagrams, see “Connecting Your
DCT700”.

1 INTRODUCTION
4
Item Description
1 AUDIO OUT Left/right audio outputs to connect the DCT700 to a TV, VCR, or A/V receiver.
2 VIDEO Composite video output to connect the DCT700 to a TV, VCR, or A/V receiver.
3 RF IN A coaxial input that is connected to the cable wall outlet, see Connecting the
DCT700.
4 TO TV/VCR A coaxial output to connect the DCT700 to the TV or VCR.
5 Power This is the DC power connection.

5
USING THE REMOTE CONTROL
Use the remote control to operate the DCT700, TV, and
VCR.
Your remote control may differ from the one illustrated
here.
For information on operating and programming your
remote control, refer to the remote control User Guide
supplied by your service provider.
The table following this drawing describes the functions
of the remote control. Some of the features described in
the table may not be available. Check with your service
provider to determine which features are being offered in
your area.

USING THE REMOTE CONTROL
6
Key Description
1 AUDIO,
VCR/DVD,
CABLE, OR
TV
Selects a device to control. The selected mode will remain active until you press
another key.
2 HELP Displays the help screen.
3 POWER Turns the currently selected device on or off.
4 PAGE ▲
PAGE ▼
Pages through menu screens and the program guide.
5 EXIT Exits a menu or program guide.
6 ◄▲►▼
CURSOR
Moves the cursor around the program guide and menu screens.
7 OK Selects menu options, Pay-Per-View events or programs from the program guide.

USING THE REMOTE CONTROL
7
8 GUIDE Displays the program guide.
9 VOLUME +
VOLUME -
Increases or decreases the volume of the VCR, TV, or audio device. The device must
be selected before you can increase or decrease the volume.
10 A
B
C
Functionality is determined from services offered by your cable TV service provider.
11 NUMBER
KEYS
Use to directly select a channel.
12 TV/VCR or
BYPASS
When in VCR mode, toggles between television and VCR. Bypass is not available.
13 STOP, PAUSE,
PLAY, REW,
RECORD,
F.FWD
Controls the VCR/DVD or CD player.

USING THE REMOTE CONTROL
8
14 MUTE Toggles the sound on and off.
15 LOCK Use to limit viewing of selected programs or to view the Pay-Per-View menu.
16 INFO Displays the current channel and program information (not supported by all
applications).
17 MENU Displays the main menu.
18 LAST Recalls the last channel or goes back one screen in the menu.
19 CHANNEL +
CHANNEL -
Changes the channels by moving up or down.
20 FAVORITE Displays preset favorite cable channels.
21 ENTER/MUSIC Displays digital music channel menus. On some TV models press to enter channels.
