MC9190-NI
FOR UL CLASS I,
II, III / DIVISION 2, ATEX
ZONE 2
USER GUIDE

2MC9190-NI
Zebra reserves the right to make changes to any product to improve reliability, function, or design.
Zebra does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent,
covering or relating to any combination, system, apparatus, machine, material, method, or process in which
Zebra products might be used. An implied license exists only for equipment, circuits, and subsystems contained
in Zebra products.
Warranty
For the complete Zebra hardware product warranty statement, go to: http://www.zebra.com/warranty.
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a
problem with the equipment, they will contact the Zebra Support at: http:www.zebra.com/support.
For the latest version of this guide go to: http://www.zebra.com/support.
Software Support
Zebra wants to ensure that customers have the latest release of entitled software at the time of product
purchase.
To confirm that your Zebra device shipped with the latest release of entitled software, visit:
www.zebra.com/support. Check for the latest software from Software Downloads > Product Line/Product > Go.
If your device does not have the latest entitled software release as of your product purchase date, please e-mail
a request to Zebra at: [email protected].
You must include the following essential device information with your request:
• Model number
• Serial number
• Proof of purchase
• Title of the software download you are requesting.
If it is determined by Zebra that your device is entitled to the latest software release, you will receive an e-mail
containing a link directing you to a Zebra Web site to download the appropriate software.

User Guide 3
Notes on this Guide
The user guide is a constituent part of the product and must be kept in the direct vicinity of the device and
accessible at all times to installation, operating and maintenance personnel.
It contains important notes, safety instructions and test certificates which are necessary for perfect functioning
when the devices are being operated and handled. It is written for technically qualified personnel.
Familiarity with and the technically perfect implementation of the safety instructions and warnings described in
this manual are preconditions for safe installation and commissioning. The safety notes and warnings given in
this documentation are given in a general way and only qualified personnel will have the necessary specialised
know-how to interpret and implement them correctly in specific cases.
Qualifications of the Personnel Working with the Devices
The user guide is written for all people who carry out assembly, installation, commissioning and service work on
the product, whereby the directives and standards 99/92/EC, EN 60079-17, EN 60079-19 for the gas area and
EN 61241-17 and EN 61241-19 for the dust area must be observed.
Handling the Product
The product described in this guide has been tested and left the factory in perfect condition as regards meeting
safety requirements.
To maintain this condition and ensure that this product operates perfectly and safely, it may be used only in the
manner described by the manufacturer. Appropriate transportation, suitable storage and careful operation are
also essential for the perfect and safe operation of this product.
Use for the Intended Purpose
NOTE The versions, components, screens and windows illustrated in this User Guide are examples only
and can deviate from the actual display.
The information treated in this guide relates to the explosion protected version of the MC9190-NI
Series.
This guide contains all important information concerning explosion protection. In addition, the
original user manuals and product information from Zebra are also available and these contain
information about handling and operation. In the event of information overlap, the information in
this guide supersedes the other guides.

4MC9190-NI
Documentation Set
The documentation set for the MC9190-NI is divided into guides that provide information for specific user needs.
•MC9190-G User Guide - describes how to use the MC9190-G.
•MC9190-G Integrator Guide - describes how to set up the MC9190-G and the accessories.
•EMDK Help File - provides API information for writing applications.
Safety Instructions
Marking
Particularly important points in these instructions are marked with a symbol:
IMPORTANT Safety instructions and warnings are specially highlighted in this manual and marked by
symbols.
The safety instructions and warnings are assigned to the individual work steps. Careful
handling and consistent observation of the instructions will prevent accidents, personal
injuries and damage to property.
The adherence to all directions and safety instructions in this manual is a precondition for
safe working and the correct handling of the device.
The graphic representations in these instructions serve to show the information being
described and are not necessarily true to scale and they may deviate slightly from the actual
construction of the device.
WARNING!Non-observance leads to death or serious physical injury.
The necessary safety measures must be taken.
CAUTION Warning of damage to property and financial and penal disadvantages (e.g. loss of guarantee
rights, liability etc.).
ATTENTION Important instructions and information on preventing disadvantageous behavior.
NOTE Important instructions and information on effective, economical and environmentally compatible
handling.

User Guide 5
Configurations
This guide supports to the following configurations:
Keypad
The following keypads are available:
• 28 key
• 43 key
• 53 key
• 53 key with VT emulation
• 53 key with 3270 emulation
• 53 key with 5250 emulation.
Product Description
Definition
The 9190-NI mobile computer is a compact unit for high-standard bar code scanning in hazardous (potentially
explosive) areas:
• ATEX Zone 2 or
• Class I, II, III Division 2.
This means that even in the hazardous area the user can avail of the extensive communication options that are
already standard in other areas.
Model Wireless Display Memory Data Capture OS Keypad
MC9190-NI WLAN: 802.11 a/b/g
WPAN:Bluetooth
3.7"- Color
display
256 MB
RAM/1 GB
Flash
memory
1D Laser scanner
Standard Range, 1D
Laser scanner Long
Range, 1D /2D
Standard Range
Imager (HD, DL,
SR), 1D /2D Long
Range Imager
Windows
Mobile 6.5
Classic /
Windows
CE 6.0
Keypads:
See below

6MC9190-NI
Figure 1 MC9190-NI
Its ergonomic design and easy operation make it an ideal support for fast data availability in enterprise
processes. A keyboard is available in different versions for manual data capture.
The integrated 1D or 1D/2D scan engine for capturing bar codes is available as another data capture option. The
ergonomically mounted scan triggers on the MC9190-NI allow data to be captured easily in one-hand operation.
Several technologies are available for data communication with other systems and company divisions.
• Wireless LAN (WLAN),
• Wireless PAN (WPAN) (Bluetooth)
These modules, which are integrated in the device, allow seamless transmission of voice and data with easy
integration into the company’s network.
Other advantages in its use are the rugged construction, easy-to-read 3.7" VGA color display with touch
technology and high-performance lithium ion battery.
Fast process execution is ensured by the Marvel PXA320 processor with 806 MHz, which is integrated in the
MC9190-NI, and an easy development of applications is facilitated by the Microsoft®Windows®Mobile 6.5
operating system in conjunction with the Enterprise Mobility Developer Kits (EMDK) from Zebra.

User Guide 7
256 MB RAM and 1 GB Flash drive integrated in the device are available for storing user-defined applications
and data. For larger applications and volumes of data, Zebra offers SD memory cards.
Use
The MC9190-NI is a hand-held piece of electric equipment. It serves the mobile capture, processing and wireless
transmission of data in hazardous areas.
It is used exclusively in combination with operating devices which satisfy the requirements for overvoltage
category I.
The MC9190-NI has been modified for use in the hazardous area of:
• ATEX Zone 2
• UL Class I Division 2 Groups A, B, C and D
• UL Class II Division 2, Groups F and G
• UL Class III
• Non-hazardous area
The MC9190-NI may not be used in locations of:
• ATEX Zone 0
• ATEX Zone 1 and Zone 21
• ATEX Zone 22
• UL Class I, II Division 1
• UL Class II Division 2, Groups E
Technical Data
Table 1 Technical Data
Type Description
Explosion Protection ATEX Zone 2
Ex protection II 3G Ex ic IIC T6
Ambient temperature -20 °C ≤Ta ≤+50 °C
Temperature Code T6

8MC9190-NI
Explosion Protection UL Division 2
Ex protection type Class I Division 2 Groups A, B, C and D
Class II Division 2 Groups F and G
Class III
Ambient temperature -20 °C ≤Ta ≤+50 °C
Temperature Code T6
Characteristics
Dimensions (height x width x depth) approx. 23.1 cm x 9.1 cm x 19.3 cm (9.1 inch x 3.6 inch x 7.6 inch)
Weight including battery approx. 710 g (25 oz)
depending on the version and configuration
Display Transflective 3.7 inch color
Windows Mobile: VGA
Windows CE: QVGA/VGA switchable.
Touchscreen Glass analog resistive touchscreen
Network connections High-speed USB client, full-speed USB host, Ethernet (via cradle),
Bluetooth
Interfaces RS232
USB 2.0 Client / USB 1.1 host
Keyboard variants 28 key, 43 key, 53 key, 53 key with VT emulation, 53 key with 3270
emulation, 53 key with 5250 emulation.
Performance Features
Processor Marvel PXA320 processor with 806 MHz
Memory 256 MB RAM / 1GB Flash
Expansion slot SD card slot
Optional available extension with SD
card
Note: the devices are modified to suit the selected memory versions.
The end user can replace the SD card later.
Operating system Windows Mobile 6.5 or Windows CE 6.0
User Environment
Ambient temperature -20 °C to +50 °C (-4 °F to 122 °F)
Ambient temperature when charging 0 °C to +40 °C (32 °F to 104 °F)
Storage temperature (without battery) -40 °C to +70 °C (-40 °F to 158 °F) outside the hazardous area
Table 1 Technical Data (continued)
Type Description

User Guide 9
Air humidity 5% to 95% (non-condensing)
Protection class (EN 60529) IP 64
Application Development
PSDK (Platform Software Developer Kit)
and EMDK (Enterprise Mobility
Developer Kit) available through Zebra
Support Central Web site.
Available for C, Java and .Net.
More tools are available from Zebra. Rem Capture for processing registry files.
Application Launcher for dividing applications into categories and access
regulation to the individual applications or operating system.
Data Wedge allows data reading by applications that do not support any
scanner.
App Center is an end-user application access control engine that
restricts activity to a set of authorized applications on mobile devices.
Voice and Data Transmission Wireless LAN
Wireless standard Tri Mode IEEE 802.11a/b/g
Output power 100mW U.S. and International
Data rate IEEE802.11a: up to 54 Mbit/sec.
IEEE802.11b: up to 11 Mbit/sec.
IEEE802.11g: up to 54 Mbit/sec.
Frequency range
(country-dependent)
IEEE802.11a: 5 GHz
IEEE802.11b: 2.4 GHz
IEEE802.11g: 2.4 GHz
Safety WPA2 Enterprise, 802.1x; EAP-TLS; TTLS (CHAP, MS-CHAP,
MS-CHAPv2, PAP or MD5); PEAP (TLS, MSCHAPv2, EAP-GTC);
LEAP, EAP-FAST (TLS, MS-CHAPv2, EAP-GTC), WPA2/AES, CCX v4,
FIPS 140-2 and IPv6
Antenna integrated in the device
Voice and Data Transmission Wireless PAN
Bluetooth Bluetooth Version 2.1 with EDR
Antenna Integrated in the device
Table 1 Technical Data (continued)
Type Description

10 MC9190-NI
Options for Data Capture
Scan engines: SE960 1D Standard Range Scan Engine
SE1524-ER 1D Long Range Scan Engine
SE4600 1D/2D Long Range Imager Engine
SE4500-SR 1D/2D Imager Engine
SE4500-DL 1D/2D Imager Engine
SE4500-HD 1D/2D Imager Engine
SE960 1D Standard Range Scan Engine
Reading range up to approx. 5.1 m (17 feet)
SE1524-ER 1D Long Range Scan Engine
Reading range up to approx. 13.7 m (45 feet)
SE4600 1D/2D Long Range Imager Engine
Reading range near up to approx. 20.3 cm (8 inch)
Reading range far up to approx. 9.1 m (30 feet)
SE4500-SR 1D/2D Imager Engine
Reading range near up to approx. 5.3 cm (2.1 inch)
Reading range far up to approx. 62.7 cm (24.7 inch)
SE4500-DL 1D/2D Imager Engine
Reading range near up to approx. 6.8 cm (2.7 inch)
Reading range far up to approx. 50.0 cm (19.7 inch)
SE4500-HD 1D/2D Imager Engine
Reading range near up to approx. 4.0 cm (1.6 inch)
Reading range far up to approx. 28.2 cm (11.1 inch)
Decodable Bar Code Types
Laser Decode Capability MC9190-NI
with SE960 1D-Standard Range Scan
Engine and SE1524-ER 1D Long Range
Scan Engine
Code 39, Code 128, Code 93, Codabar, Code 11, Discrete 2 of 5,
Interleaved 2 of 5, EAN-8, EAN-13, MSI, UPCA, UPCE, UPC/EAN
supplementals, Coupon code, Trioptic 39, Web code, Chinese 2 of 5,
GS1 DataBar, GS1 DataBar Truncated, GS1 DataBar Limited, GS1
DataBar Stacked, GS1 DataBar Expanded, GS1 DataBar Expanded
Stacked, GS1 DataBar Expanded Stacked Omni
Table 1 Technical Data (continued)
Type Description

User Guide 11
Imaging Decode Capability MC9500-NI
with SE4500 1D/2D Imager Engine and
SE4600 1D/2D Imager Engine
Code 39, Code 128, Code 93, Codabar, Code 11, Discrete 2 of 5,
Interleaved 2 of 5, EAN-8, EAN-13, MSI, UPCA, UPCE, UPC/EAN
supplementals, Coupon code, Trioptic 39, Web code, Chinese 2 of 5,
GS1 DataBar, GS1 DataBar Truncated, GS1 DataBar Limited, GS1
DataBar Stacked, TLC39, Composite AB, Composite C, Micro PDF-417,
Macro PDF-417, (Macro) Micro PDF-417, QR Code, Data Matrix,
microQR, Maxi Code, PDF-417, US Postnet, US Planet, UK 4-state,
Australian 4-state, Canadian 4-state, Japanese 4-state, USPS 4-state
(US4CB), Aztec
Technical Data Battery
Battery (rechargeable only in safe area)
Type 21-65587-03-NI
Lithium-ion 7.4 V/2200 mAh
Operating temperature
during charging
during discharging
0 °C to +40 °C (32 °F to 104 °F)
-20 °C to +50 °C (-4 °F to 122 °F)
Storage temperatures
≤1 year
≤3 months
≤1 months
-25 °C to +20 °C (-13 °F to 68 °F)
-25 °C to +45 °C (-13 °F to 113 °F)
-25 °C to +60 °C (-13 °F to 140 °F)
Relative air humidity 20% - 85% (non-condensing)
Backup battery Ni-MH battery 3.6 V/15 mAh, rechargeable
Integrated in the device and replaceable only in the factory.
CAUTION The battery may only be charged and changed outside the hazardous area.
Table 1 Technical Data (continued)
Type Description

12 MC9190-NI
Technical Data External Interface
Figure 2 I/O Pin-out
CAUTION Operating the 17-pin data interface is only permissible outside the hazardous area and only
with devices specified by the manufacturer.
Operating of the headset port is only permissible outside the hazardous area and only with
devices specified by the manufacturer.
Table 2 I/O Pin-out Signal Descriptions
Pin Signal Name Description
1 USB_GND USB
2 USB_D_Plus USB
3 TxD RS232C
4 RxD RS232C
5 DCD RS232C
6 RTS RS232C
7 DSR RS232C
8 GND earth, 2.5 A max.
9 RI RS232C
10 Cradle_DET Grounded by cradle when in cradle
11 DTR RS232C
12 Not assigned Not assigned
13 Power_IN 12 V / 2.5 A max.
14 CTS RS232C
15 USB_5V_DET USB
16 USB_D_Minus USB
17 EXT_Power_OUT 3.3 V @ 500 mA

User Guide 13
Safety Instructions
Warnings for MC9190-NI
CAUTION The device may not be opened by the user outside the hazardous area either. The user may
not make any alterations to the device. Do not exchange or replace components and do not
retrofit any components on internal plug connectors or slots.
NOTE Exception: SD card, battery and keypad, screen protector.
CAUTION If components other than those specified are used, the protection against explosions can no
longer be assured.
Substitution of any components may impair suitability for Class I, II, III Division 2 as well as for
ATEX Zone 2.
To prevent ignition of flammable or combustible atmospheres disconnect power before
servicing!
Do not open or charge the device in the hazardous area!
Operating of the 17-pin data interface is only permissible outside the hazardous area and only
with devices specified by the manufacturer!
Operating of the headset port is only permissible outside the hazardous area and only with
devices specified by the manufacturer!
Protect the device from impact effects! Do not expose the operating equipment to any
caustic/aggressive liquids, vapors or mist! In the event of malfunctioning or damage to the
enclosure, take the equipment out of the potentially explosive atmosphere immediately, bring it
into a safe area and decommission it by removing the battery!
If on account of adverse effects or conditions (e.g. penetration of water, fluids, exposure to
temperatures outside the specified range etc.) there is a danger of not being able to operate the
equipment safely, switch off the equipment instantly and remove the battery.
Avoid the influence of heat that is higher or lower than the specified temperature range. Do not
place the devices anywhere near sources of heat, such as for example heaters, air exit
openings in air-conditioners, or near cookers or other devices (including amplifiers) that radiate
heat.
Avoid the effects of moisture.
Do not put any objects into the device, into the enclosure or other openings in the Mobile
Computer. Openings in the device may not be blocked, obstructed or covered.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.

14 MC9190-NI
Warnings for Battery
Laser Devices
Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated
June 24, 2007, EN60825-1: 2007 and IEC60825-1 (Ed. 2.0). The laser classification is marked on one of the
labels on the device. Class 1 Laser devices are not considered to be hazardous when used for their intended
purpose.
ATTENTION Equipment that is damaged in any way or that does not function properly must instantly be
removed from the hazardous area and sent in for inspection/repair!.
Take the device out of the hazardous areas before wiping it with a dry cloth or cleaning it!
General statutory regulations or directives on safety at work; accident prevention regulations
and environmental protection legislation must be complied with, e.g. Ordinance on industrial
health and safety (BetrSichV) or the national ordinances.
Ensure safe handling of the equipment during operation by making sure the device in a
steady position and the user has sufficient space to move!
When transporting the equipment in vehicles, it must be placed in appropriate compartments
or fittings so that it cans neither fall off during the drive nor be exposed to extreme vibrations.
The rules for hazardous areas (see NEC Article NFPA 70) must be observed. In particular,
appropriate clothing and footwear should be worn in view of the risk of dangerous
electrostatic charges. Do not wear rubber gloves or suchlike during operation!
CAUTION The battery may only be charged and changed outside the hazardous area!
It must be ensured that only original batteries of the following type/s are used in safety-oriented
operation. 21-65587-03-NI with 7.4 V/2200 mAh.
The use of imitation batteries or batteries from other manufacturers will render the type of
ignition protection ineffective and there will then be a risk of fire or explosion.
Keep away from children.
The battery may explode if disposed of in fire.
DO NOT short circuit or disassemble battery.
The battery may only be used for the purposes stated in the user manual and is only suitable
for use in the MC9190-NI.
If used incorrectly, there is a risk of burning. The battery should not be disassembled over a
temperature higher than +50 °C (122 °F). If the battery is damaged, battery acid can escape
from the cells and cause corrosion. For that reason, extreme care must be taken in handling
and disposing of a damaged or leaking Li-ion battery.
Defective batteries must be disposed of immediately, whereby the battery disposal regulations
that apply to the respective region must be observed.

User Guide 15
Caution: Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous laser light exposure.
Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as the sun,
the user should avoid staring directly into the light beam. Momentary exposure to a Class 2 laser is not known to
be harmful.
LED Devices
Complies with IEC/EN60825-1:2001 & IEC/EN62471:2006.
Health and Safety Recommendations
Ergonomic Recommendations
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Installation in Vehicles
RF signals can have a negative impact on electronic systems in vehicles (including safety systems) if they have
not been installed correctly or shielded adequately. If you have any questions about your vehicle, please get in
touch with the manufacturer or with a sales representative. You can find out from the manufacturer if any
additional equipment has been installed in the vehicle. An airbag inflates with great force. DO NOT PLACE ANY
objects, such as mounted or mobile wireless equipment in the area above the airbag or in the airbag deployment
area. If the wireless equipment in the vehicle was not installed properly, serious injuries can occur when the
CAUTION Use only the accessories, batteries and battery chargers approved by Zebra. Do not attempt to
charge damp or wet MC9190-NI devices or batteries. All components must be dry before they
are connected to an external power supply.
CAUTION In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations
below. Consult with your local Health & Safety Manager to ensure that you are adhering to
your company's safety programs to prevent employee injury.

16 MC9190-NI
airbag is deployed. Position the device within reach. Make sure you have access to the device without having to
take your eyes off the road.
Safety on the Road
Do not take notes or use the device while driving. Jotting down a “to do” list or flipping through your address book
takes attention away from your primary responsibility, driving safely.
When driving a car, driving is your first responsibility - Give full attention to driving. Check the laws and
regulations on the use of wireless devices in the areas where you drive. Always obey them.
When using a wireless device behind the wheel of a car, practice good common sense and remember the
following tips:
1. Get to know your wireless device and any features such as speed dial and redial. If available, these features
help you to place your call without taking your attention off the road.
2. When available, use a hands free device.
3. Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow, ice, and even heavy traffic can be hazardous.
4. Dial sensibly and assess the traffic; if possible, place calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be stationary. If you need to make a call while moving, dial only a
few numbers, check the road and your mirrors, then continue.
5. Do not engage in stressful or emotional conversations that may be distracting. Make people you are talking
with aware you are driving and suspend conversations that have the potential to divert your attention from the
road.
6. Use your wireless phone to call for help. Dial the Emergency services, (9-1-1 in the US, and 1-1-2 in Europe)
or other local emergency number in the case of fire, traffic accident or medical emergencies. Remember, it is
a free call on your wireless phone! The call can be made regardless of any security codes and depending on
a network, with or without a SIM card inserted.
7. Use your wireless phone to help others in emergencies. If you see an auto accident, crime in progress or
other serious emergency where lives are in danger, call the Emergency Services, (9-1-1 in the US, and 1-1-2
in Europe) or other local emergency number, as you would want others to do for you.
8. Call roadside assistance or a special non-emergency wireless assistance number when necessary. If you see
a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency
wireless number.
“The wireless industry reminds you to use your device / phone safely when driving”.
NOTE Connection to an alert device that will cause a horn to sound or a light to flash on receipt of an
incoming call on public roads is not permissible.

User Guide 17
RF Exposure Guidelines
Safety Information
Reducing RF Exposure – Use Properly
Only operate the device in accordance with the instructions supplied.
International
The device complies with internationally recognized standards covering human exposure to electromagnetic
fields from radio devices. For information on “International” human exposure to electromagnetic fields refer to the
Zebra Declaration of Conformity (DoC) at http://www.zebra.com/doc.
Europe
Handheld Devices
This device was tested for typical body-worn operation. Use only Zebra tested and approved belt-clips, holsters,
and similar accessories to ensure EU Compliance.
US and Canada
Co-located statement
To comply with FCC RF exposure compliance requirement, the antenna used for this transmitter must not be
co-located or operating in conjunction with any other transmitter/antenna except those already approved in this
filling.
Handheld Devices
This device was tested for typical body-worn operation. Use only Zebra tested and approved belt-clips, holsters,
and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar
accessories may not comply with FCC RF exposure compliance requirements, and should be avoided.
NOTE The MC9190-NI must be switched off before it may be carried on the body.
NOTE The MC9190-NI must be switched off before it may be carried on the body.

18 MC9190-NI
Warnings and Information about Wireless Devices
Radio Modules
The device contain approved radio module(s). These module(s) are identified below.
Zebra WLAN radio 802.11 a/b/g Type(s): 21-92955.
Country Roaming
This device incorporates the International Roaming feature (IEEE802.11d) which will ensure the product
operates on the correct channels for the particular country of use.
Ad-Hoc Operation (5 GHz Band)
Ad-Hoc operation is limited to Channels 36-48 (5150 - 5250 MHz). Use of this band is restricted to Indoor Use
Only, any other use will make the operation of this device illegal.
Frequency of Operation – FCC and IC
5 GHz Only
The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150 -5250 MHz band is restricted to
Indoor Use Only; any other use will make the operation of this device illegal.
2.4 GHz Only
The available channels for 802.11 b/g operation in the US are Channels 1 to 11. The range of channels is limited
by firmware.
Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN’s, for use through the EEA, have the following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the frequency range 2.400 -2.4835 GHz.
• France, outside usage is restricted to 2.4 – 2.454 GHz.
• Italy requires a user license for outside usage.
CAUTION Operation of the device without regulatory approval is illegal.
NOTE The use of wireless devices might be forbidden or restricted. This applies above all when you are
aboard aeroplanes, in hospitals, near explosives or in other dangerous conditions. If you are not
sure which regulations apply to the use of the device, ask for permission before switching it on.

User Guide 19
Bluetooth®Wireless Technology for use through the EEA has the following restrictions:
• Maximum radiated transmit power of 100mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 10mW EIRP
• Italy requires a user license for outside usage.
Radio Frequency Interference Requirements-FCC
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Radio Frequency Interference Requirements- Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Transmitters
For RLAN Devices:
The use of 5 GHz RLAN’s, for use in Canada, have the following restrictions:
• Restricted Band 5.60 – 5.65 GHz
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Label Marking: The Term “IC:” before the radio certification only signifies that Industry Canada technical
specifications were met.

20 MC9190-NI
Country-specific Approvals
Regulatory markings, subject to certification, are applied to the device signifying the radio(s) is/are approved for
use in the following countries: United States, Canada, Japan, China, S. Korea, Australia, and Europe 1, 2.
You will find detailed information on the test marks for other countries in the EC Declaration of Conformity.
•Note 1: For 2.4GHz or 5GHz Products: Europe includes, Austria, Belgium, Bulgaria, Czech Republic,
Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak
Republic, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
•Note 2: The use of RFID Devices have varying restrictions of use; please refer to the EC Declaration of
Conformity for details.
Warnings about the Use of Wireless Devices
Observe all warnings which refer to the use of wireless devices.
Safety in Aircraft
Switch off your wireless device whenever you are asked to do so by airport or airline staff. If your device offers a
flight mode or similar function, ask the flight crew about its proper use.
Safety in Hospitals
Wireless devices radiate radio frequencies and can cause interference in electrical medical devices. If you are in
a hospital, clinic or public health service, please turn off wireless devices if asked to do so. This is to prevent any
interference with sensitive medical equipment.
Cardiac Pacemakers
The manufacturer recommends a minimum distance of 15 cm between a portable handheld wireless device and
a Cardiac Pacemaker to avoid potential interference. This guideline is in accordance with independent research
results and recommendations from Wireless Technology Research.
People with implanted pacemakers:
• Should ALWAYS keep the switched-on device at a distance of at least 15 cm away from themselves.
• Should not put the device into your breast pocket.
• The device should be held at the ear furthest away from the cardiac pacemaker.
• If you have reason to suspect interference, SWITCH OFF your device immediately.
Hearing Aids
The wireless device can cause interference with hearing aids. If there is any interference, contact the hearing aid
manufacturer to ask about solutions.
