Motorola ASTRO APX MOBILE O2 CONTROL HEAD User manual

Ideal for outside use
Warning: Charge the handset for 16 hours before use.
Motorola O2
Digital Cordless Telephone
with Answering Machine
For: O211, O212, O213 and O214
Handset: Motorola O21-HS
Base: Motorola O21-B
Charger: Motorola O21-C

Safety information
Important
This equipment is not designed for making emergency telephone calls when
the power fails. Alternative arrangements should be made for access to
emergency services.
This product is intended for connection to analogue public switched telephone
networks and private switchboards in the US.
Important safety instructions
Follow these safety precautions when using your phone to reduce the risk of
fire, electric shock, and injury to persons or property:
• Keep all slits and openings of the phone unblocked. Do not set the phone
on a heating register or over a radiator. Ensure that proper ventilation is
provided at the installation site.
• Do not allow anything to rest on the power cord. Place the power cord so
that it will not be walked on.
• Never insert objects of any kind into the product vents as that may result in
fire or electric shock.
• Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
• Do not disassemble this product. If service or repair work is required,
contact the customer service helpline found in this user’s Guide.
• Do not overload wall outlets and extension cords.
• Avoid using during an electrical storm. Use a surge protector to protect the
equipment.
• Do not use this phone to report a gas leak, especially if you are in the
vicinity of the gas line.
• For pluggable equipment, the socket-outlet (power adaptor) shall be
installed near the equipment and shall be easily accessible.
• Do not use while wet or while standing in water.
• Do not use the product near water (for example, near a bath tub, kitchen
sink, or swimming pool).
Save these instructions
Important
To reduce the risk of fire, use only the supplied AC power adaptor.
Unplug this cordless phone immediately from an outlet if:
• The power cord or plug is damaged or frayed.
• Liquid has been spilled on the product.
• The product has been exposed to rain or water. Do not retrieve the handset
or base until after you have unplugged the power and phone from the wall.
Then retrieve the unit by the unplugged cords.

• The product has been dropped or the cabinet has been damaged.
• The product exhibits a distinct change in performance.
Installation Guidelines
• Read and understand all instructions and save them for future reference.
• Follow all warnings and instructions marked on the product.
• Do not install this product near a bath tub, sink, or shower.
• Operate this phone using only the power source that is indicated on the
marking label. If you are unsure of the power supply to your home, consult
with your dealer or local power company.
• Do not place this product on an unstable cart, stand, or table. This product
may fall, causing serious damage to the product.
• Adjust only those controls that are covered by the operating instructions.
Improper adjustment of other controls may result in damage and will often
require extensive work to restore the product to normal operation.
• Clean this product with a soft, damp cloth. Do not use chemicals or
cleaning agents to clean this phone.
• Use only the power supply that came with this unit. Using other power
supplies may damage the unit.
• Because this phone operates on electricity, you should have at least one
phone in your home that could operate without electricity in the case the
power in your home goes out.
• To avoid interference to nearby appliances, do not place the base of the
phone on or near a TV, microwave oven, or VCR.
Battery Safety Instructions
• Do not burn, disassemble, mutilate, or puncture the battery. The battery
contains toxic materials that could be released, resulting in injury.
Important
Warning! Use only the approved rechargeable Ni-MH battery cells (2.4VDC
750mAh Ni-MH rechargeable battery pack) supplied with your O211, O212,
O213 or O214.
Caution
There is a risk of explosion if you replace the battery with an incorrect battery
type. Use only the battery pack that came with your phone or an authorized
replacement recommended by the manufacturer.
• Keep battery packs out of the reach of children.
• Do not dispose of battery packs in fire, which could result in explosion.
• The rechargeable battery packs that power this product must be disposed
of properly and may need to be recycled. Refer to your battery’s label
for battery type. Contact your local recycling center for proper disposal
methods.
Save these instructions

Welcome...
to your new Motorola O2 Digital Cordless Telephone with
answering machine!
• Ultra long cordless 360orange, up to 650 meters.1
• Rugged design and sturdy composition makes your Motorola O2 phone
ideal for outdoor use.
• Dust and water resistant. Submersible in up to 1 meter of water for up to 30
minutes. Perfect for very wet environments (IP67 rated).
• Belt clip or lanyard options for flexibility when carrying around.
• Wall mountable location free base and handset charger cradle.
• Zoom font when dialing for improved legibility.
• Inductive charging.
• Answering machine with up to 25 minutes digital recording time.
• 200 name and number phonebook.
• Copy phonebook entries between handsets.
• Caller ID shows you who’s calling and see details of the last 50 callers in a
Calls Lists.2
• Make internal calls, transfer external calls, hold a 3-way conversation
between two internal callers and an external caller.
• Register up to 11 handsets to a single base and register each handset with
up to 4 dierent bases.
• All handsets are fully cordless for locating anywhere within range.
Need help?
If you have any problems setting up or using your O2, please contact
Customer Services on 1-833-468-1468.
Alternatively, you may find the answer in the ‘Help’ section at the back of
this guide.
1When there is a clear line of sight between the base and handset.
Any obstruction between the base and handset will reduce the range
significantly.
2You must subscribe to your network provider’s Caller ID service for this
feature to work. A subscription fee may be payable.
Please note that this equipment is not designed for making emergency
telephone calls when the power fails. Alternative arrangements should be
made for access to emergency services.

This User Guide provides you with all the information
you need to get the most from your phone.
Before you make your first call you will need to set
up your phone. Follow the simple instructions in
‘Getting started’, on the next few pages.
Important
Only use the telephone line cord supplied.
Got everything?
• O2 handset • 1 x Belt clip (pre-installed)
• Antenna • Telephone line cord
• O2 base • Screws and plugs for wall mounting
• O2 charger cradle • AC power adaptor for the base
• 750mAh Ni-MH battery
pack (pre-installed)
• AC power adaptor for the charger cradle
If you have purchased an O2 multiple pack you will also have the
following additional items:
• O2 handset • 1 x Belt clip (pre-installed)
• Antenna • Screws and plugs for wall mounting
• O2 charger cradle • AC power adaptor for the charger cradle
• 750mAh Ni-MH battery
pack (pre-installed)

6
