Motorola TD1 User manual

Warning: Charge the handset for 16 hours before use.
Digital Cordless
Telephone
Motorola TD1
Models: TD1001, TD1002, TD1003 and TD1004

Welcome...
to your new Motorola TD1 Digital Cordless Telephone!
• Block calls by call type or by number.1
• Do Not Disturb function.
• All handsets fully cordless forlocating anywherewithin range.
• 100 name and number phonebook.
• Bright backlit display.
• Speakerphone for hands-free conversations.
• Caller ID shows you who’s calling and see details of the last 50 callers in a Calls list.1
• Redial up to 10 of the last numbers called.
• Registerup to 4 handsets to a single base.
• Make internal calls, transfer external calls, hold 3-wayconversations between two
internal callers and an external caller.
• Intelligent Charging saving unnecessarypowerusage.
Need help?
If you have any problems setting up or usingyourTD1, please contact Customer
services on: (65) 68412668.
Email: [email protected]
Alternatively, you maynd the answer in the ‘Help’ section at the back ofthis guide.
1You must subscribe to your network provider’s Caller ID service forthis feature to
work. A subscription fee may be payable.
Please note that this equipment is not designed for making emergencytelephone
calls when the power fails. Alternative arrangements should be made foraccess to
emergency services.

This User Guide provides you with all the information you need to get the
most from your phone.
Before you make your rst call you will need to set up your phone. Follow
the simple instructions in ‘Getting Started’, on the next few pages.
IMPORTANT
Only use the telephone line cord supplied.
Got everything?
• Cordless handset
• Cordless base
• Power adaptor for the base
• Telephone line cord
• 2x AAA rechargeable batteries
If you have purchased an TD1 multiple pack you will also have the following
additional items:
• Cordless handset & charger
• Power adaptor for the charger
• 2x AAA rechargeable batteries
ECOMOTO: a convergence of eorts by marketing, design, research, engineering
and supply chain management that leads to better products for everyone.A holistic
view that focuses on both social and environmental responsibility. A passion and a
shared point ofview.
The right thing to do.
• Meets and / or exceeds EMEAenvironmental regulatory requirements.
• Eco friendlypackaging with a minimum 20% post consumer
recycled content.
• Phone housing is built with a minimum of 25% post consumer recycled content plastic.
• Energy eicient chargerthat meets EU Code of Conduct requirements.
• ECO mode function which reducesthe transmitted power and energy consumption,
please refer to page 38.

4
1. Getting started .....................................................................7
2. Getting to know your phone ..............................................11
3. Using the phone .................................................................16
3.1 Make a call .....................................................................................................16
3.2 Pre-dial ...........................................................................................................16
3.3 Dial direct memory numbers 1 to 9...............................................................16
3.4 Call from the phonebook..............................................................................16
3.5 Call from the Calls list....................................................................................16
3.6 Answer a call ..................................................................................................16
3.7 Adjust volume ................................................................................................17
3.8 Mute...............................................................................................................17
3.9 End a call........................................................................................................17
3.10 Switch handset on/o....................................................................................17
3.11 Intercom.........................................................................................................17
3.11.1 Call another handset...........................................................................17
3.11.2 Transferan external call to another handset.......................................18
3.11.3 Three-party conference call ...............................................................18
3.12 Voicemail .......................................................................................................18
4. Phonebook.........................................................................19
4.1 View phonebook entries ...............................................................................19
4.1.1 View and dial an entry.........................................................................19
4.1.2 View an entryduring a call:.................................................................19
4.1.3 View VIP phonebook entries..............................................................19
4.2 Store an entry.................................................................................................20
4.3 Entering names..............................................................................................20
4.4 Character map...............................................................................................21
4.5 Enter a pause .................................................................................................22
4.7 Delete an entry ..............................................................................................22
4.8 List entry.........................................................................................................22
4.9 Delete all entries............................................................................................22
4.10 Store a direct memory number.....................................................................23
4.11 Delete a direct memory number...................................................................23
5. Call block............................................................................24
5.1 Block by call type...........................................................................................24
5.1.1 Block all unknown calls.......................................................................24
5.1.2 Block all international calls..................................................................24
5.1.3 Block all private calls...........................................................................24
5.1.4 Block all payphone calls......................................................................25
5.2 Block by number............................................................................................25
5.2.1 Turn block by number on / o ............................................................25
5.2.2 View a numberin the blocked call list................................................25
5.2.3 Add a number to the blocked call list.................................................26

5
5.2.4 Edit a number inthe blocked call list .................................................26
5.2.5 Delete a number from the blocked call list........................................26
5.2.6 Delete the blocked calls list................................................................27
5.3 Change PIN ...................................................................................................27
6. Caller ID and calls list..........................................................28
6.1 Calls list..........................................................................................................28
6.1.1 View the calls list .................................................................................28
6.1.2 Dial from the calls list ..........................................................................29
6.1.3 Save a numberfrom the calls list to the phonebook..........................29
6.1.4 Delete a calls list entry ........................................................................29
6.1.5 Delete entire calls list..........................................................................29
6.1.6 Block a calls list entry ..........................................................................29
6.2 Redial .............................................................................................................30
6.2.1 Redial the last number........................................................................30
6.2.2 View and dial a numberin the redial list.............................................30
6.2.3 Copy a redial number to the phonebook..........................................30
6.2.4 Delete a redial list entry......................................................................30
6.2.5 Delete entire redial list........................................................................30
7. Clock & Alarm ....................................................................31
7.1 Set date and time...........................................................................................31
7.2 Set alarm ........................................................................................................31
7.3 Set alarm melody...........................................................................................31
7.4 Switch auto clock on / o..............................................................................32
8. Personal settings.................................................................33
8.1 Handset tones................................................................................................33
8.1.1 Ring volume........................................................................................33
8.1.2 Ring melody........................................................................................33
8.1.3 Key tones on/o..................................................................................33
8.1.4 Docking tones on/o..........................................................................33
8.2 Handset name................................................................................................34
8.3 Auto pick up...................................................................................................34
8.4 Auto hang up .................................................................................................34
8.5 Display language ...........................................................................................34
8.6 Backlight on/o..............................................................................................35
8.7 Keypad lock ...................................................................................................35
8.8 Do Not Disturb...............................................................................................35
9. Advanced settings..............................................................36
9.1 Call List...........................................................................................................36
9.2 Conference ...................................................................................................36
9.3 Auto prex .....................................................................................................36
9.4 Recall time .....................................................................................................36
9.5 Dial mode.......................................................................................................37

6
9.5.1 Temporarily switch from Pulse toTone dialling..................................37
9.6 Registration....................................................................................................37
9.7 Register a handset .........................................................................................37
9.8 De-register a handset ....................................................................................38
9.9 PIN..................................................................................................................38
9.10 Reset ..............................................................................................................38
9.11 ECO mode ....................................................................................................38
9.12 Eco plus..........................................................................................................39
9.13 Call barring....................................................................................................39
9.13.1 Switch call barring on/o....................................................................39
9.13.2 Set a number to be barred..................................................................40
9.14 Default settings..............................................................................................40
10. Help.....................................................................................41
11. General information...........................................................42

7Getting started
1. Getting started
IMPORTANT
Do not place yourTD1 in the bathroom or other humid areas.
Location
You need to place yourTD1 base within 2 metres ofthe mains power socket and telephone
wall socket so that the cables will reach.The socket-outlet should be installed near the
equipment and should be easily accessible.
Make sure it is at least 1 metre away from other electrical appliancesto avoid interference.
YourTD1 works by sending radio signals between the handset and base.The strength of
the signal depends on whereyou place the base. Putting it as high as possible ensures the
best signal.
HANDSET RANGE
The unit has a range of up to 300 metres outdoors when there is a clear line of sight
between the base and handset. Any obstruction between the base and handset will
reduce the range signicantly. With the base indoors and the handset either indoors or
outdoors, the range will normally be up to 50 metres. Thick concrete and stone walls can
severely aect the range.
SIGNAL STRENGTH
The icon on your handset indicates that you are within range of the base. When out
of range of the base, the icon disappears. If you are on a call, you will hear a warning
beep.
If you are on a call, the line will hang up if the handset moves out of range of the base.
Move back within range. The handset will automatically re-connect to the base.
Setting up
IMPORTANT
The base station must be plugged into the mains power at all times. Do not connect the
telephone line cord into the wall socket until the handset is fully charged. Use only the
power adaptor and telephone line cord supplied with the product.

8 Getting started
Connecting the base
1. Plug the telephone line cord into the socket marked on the underside of the base.
2. Plug the poweradaptor into the socket marked on the underside of the base and
plug the other end into the mains powerwall socket. Switch on the mains power.
Installing and charging the handset
1. Remove the battery coverfrom the back of the handset and insert the rechargeable
Ni-MH battery cells supplied. Please note the ’+’and ’-’ markings inside the battery
compartment and insert in the correct direction.
2. Slide the batterycover back into place.
3. If you are charging the batteries for the rst time, place the handset on the base to
charge forat least 16 hours continuously.
4. When the handset is fullycharged, icon will appear steady on the display. Plug the
other end ofthe telephone line cord (make sure that one end is alreadyplugged into
the base) into the telephone wall socket.
Press down
1
Slide
2

9Getting started
Connecting the handset and charger
(for multi-pack only)
If you have purchased a multiple pack, you will need to carryout this process for all the
handsets and chargers.
1. Plug the poweradaptor into the socket marked on the underside of the charger
and plug the other end into the mains powerwall socket.
2. Remove the battery coverfrom the back of the handset and insert the 2 x AAA Ni-MH
rechargeable batteries supplied. Please note the ’+’ and ’-’markings inside the battery
compartment and insert in the correct direction.
3. Slide the batterycover back into place.
4. If you are charging the batteries for the rst time, place the handset on the charger to
charge forat least 16 hours continuously. When the handset is fully charged,the S
icon will appear steady on the display.
IMPORTANT
Warning! Use only the approved rechargeable Ni-MH battery cells (2 x AAA Ni-MH 550mA
rechargeable batteries) supplied with your TD1. Do not use alkaline or non rechargeable
batteries. It may cause permanent damage to the product and void the warranty.
BATTERY LOW WARNING
If you hear a warning beep every 2 minutes during a call, you will need to recharge the
handset before you can use it again.
When charging, the S icon will scroll on the display. Once charged scrolling will stop.
BATTERY PERFORMANCE
In ideal conditions, fully charged batteries should give up to 14 hours talk time or up to 220
hours standby time on a single charge.1
Note that new batteries do not reach their full capacity until they have been put to normal
use for several days.

10 Getting started
To keep your batteries in the best condition, leave the handset o the base for a few hours
at a time.
Running the batteries right down at least once a week will help them last as long as
possible.
The charge capacity of the rechargeable battery will reduce with time as it wears out,
giving the handset less talk / standby time. Eventually it will need to be replaced.
After charging your handset for the rst time, subsequent charging time is about 6–8 hours
a day. Batteries and the handset may become warm during charging. This is normal.
1All talk and standby times are approximate and depend on features selected and usage
pattern.
Setting up your TD1
Date and time
If you have subscribed to a CallerID Service and Auto Clock is set to on (see page 32),
the date and time is set automaticallyfor all handsets whenyou receiveyour rst call. If
Auto Clock is set to othe time and date does not set automatically.
If you do not have a Caller ID service,you can set the date and time manually.
NOTE
In either case the year has to be manually set.
1. Press M, scroll dto Clock/Alarm and press M.
2. Date & Time is displayed. Press M.
3. Enterthe date using the format DD-MM-YY e.g. 27/08/16 for27 August 2016 and press
M.
4. Enter the time using the 24 hour format HH:MM , e.g. 14:45 for 02.45pm and press M.
5. Press eto return to standby.
Your TD1 is now ready for use.

11Getting to know your phone
2. Getting to know your phone
Overview of your handset
A Earpiece
B Display
See page 13 for display icons.
C Menu / OK
Enterthe main menu.
Select the option displayed on screen.
Conrm menu option – OK is displayed on screen.
D Call List / Scroll Up / Volume up
Press uto enter the Call List .
Scroll up through lists and settings.
Increase the earpiecevolume during a call.
A
B
C
D
E
F
G
H
I
J
K
M
L
N

12 Getting to know your phone
E Talk / Hands-free key
Make oranswer a call.
Activate and deactivate hands-free during a call.
IMPORTANT
Hands-free activation can suddenly increase thevolume in the earpiece to a very high
level. Make sure the handset is not too close to your ear.
F Pulse to Tone Dialling / * / Intercom
During a call, press to switch from pulse dialling to tone dialling.
Dial a *.
Press and hold to make an internal call.
G Redial
Open the redial list.
H Microphone
I Clear / Mute / Back
Delete characters and digits when entering names and numbers.
Mute / unmute the microphone during a call.
Go back to previous menu level, is displayed on the screen.
J End call / Exit / Switch handset on/o
End a call.
When in a menu, go back to standbymode.
Press and hold to switch handset o (when in standby) or on.
K Phonebook / Scroll Down / Volume down
Open the phonebook list.
Scroll down through lists and menus.
Decrease the earpiece volume.
L Recall / # / Change case
Use recall (R) functions.
When on an external call, press to access a Call Waiting Line when you hearthe call
waiting prompt signal. Press again to toggle between the two calls.
Press to get a fresh dial tone.
Dial a #.
When entering letters / editing, press and hold to change the case from Abc to abc or
ABC mode.
M Keypad lock / Space
In standby mode press and hold to lock/unlock the keypad.
Press to inset a space in text / number editing.
N Do Not Disturb / Pause
Press to turn on Do Not Disturb.
When dialling or storing a number, press and hold to entera pause (P).

13Getting to know your phone
Handset display
Display icons
On when the line is in use.
Flashes when there is an incoming call.
Flashes when you have newvoicemail messages.2
O when you have no voicemail messages.
Flashes when you have missed calls and new number(s) are inthe Calls list.1
Phonebook is open.
The alarm clock has been set. Flashes when the alarm is ringing.
Hands-free mode is activated.
Handset ringer is o.
Steadywhen the handset is registered andwithin range of the base. Disappears
when the handset is out of range and flashes when searching forthe base.
Displays when ECO mode is on.
Displays when ECO PLUS is on.
The approximate power levels ofyour battery are indicated as below:
Battery is fully charged.
Battery is partially charged.
Battery is running low.
Battery is almost empty. The batteryicon will flash and emit a warning beep every
2 minutes during a call.
1For this feature to work,you must subscribe to Caller ID Service from yournetwork
operator. A subscription fee may be payable.

14 Getting to know your phone
2This feature is dependent onyour Network Service provider supporting the service.A
subscription fee maybe payable.
Overview of the base
A Paging key
Paging is a useful wayto nd lost handsets.
1. Press pon the base.
All handsets ring.
2. Press pagain to cancel the paging call or press anykey on the handset to stop the
paging call.
B Charging LED
Navigating the menus
The basic steps of navigating through the menu and on-screen options.
1. From the standbyscreen, press M.
The main menu is opened.
2. Use the top of the navigational button (u)to scroll up and the bottom (d)
to scroll down through the menu.
3. Soft key options OK and are displayed.
Press Mto select OK and open a sub-menu or validate an option.
Press bto go back to previous menu level, correct a character orcancel an action.
4. Press eto return to standby.
NOTE
If you do not press any button on the handset for 30 seconds the display will automatically
return to standby. It will also return to standby when the handset is placed on the base or
charger.
A
B

15Getting to know your phone
Menu map
Phonebook
List Entry
When no entry is stored List empty
is shown, if entries are stored
scroll to the required entry and
press OK .
Edit
Delete
ViewVIP
New Entry
Delete All
Direct Mem
Call Block
Press OK and then enterthe PIN
By CallType
Blacklist
Change PIN
Clock/Alarm
Date & Time
Set Alarm
Alarm Tone
Auto clock
Personal Set
Handset Tone
Ring Volume
Ring Melody
Key Tone
Docking tone
Handset Name
Auto Pick-Up
Auto Hang-Up
Language
Backlight
Advanced Set
Call List
Conference
Auto prex
Digit Detect
Prex Num.
Recall Time
Dial Mode
Register
Unregister
PIN
Reset
ECO Mode
Eco plus
Range select
Call Barring

16 Using the phone
3. Using the phone
3.1 Make a call
1. Press t.
2. Dial the telephone number.
3.2 Pre-dial
1. Enterthe phone number (maximum 24 digits). If you make a mistake press b.
2. Press tto dial the phone number entered.
3.3 Dial direct memory numbers 1 to 9
1. Press and hold a key from 1 to 9 until the numberis displayed and dialled.
NOTE
To store a direct memory number see page 23.
3.4 Call from the phonebook
1. Press d.The rst entry in the phonebook is displayed.
2. Scroll uor dto the entry you want.
3. Press tto dial the number.
4. Press tagain to dial over hands-free.
NOTE
Instead of scrolling to browse the phonebook entries, press the numeric key corresponding
to the rst letter of the entry you wish to locate. For example, pressing 2will show the
entries starting with A. Pressing 2twice will show the entries starting with B, etc...
3.5 Call from the Calls list
NOTE
You need to subscribe to your network’s Caller ID service to be able to see the caller’s
number in the calls list. See “Calls list” on page 28 for more details.
1. Press uto enter the Call List . The most recent call is displayed.
2. Scroll uor dto the entry you want.
3. Press tto dial the number.
4. Press tagain to dial over hands-free.
3.6 Answer a call
1. When the phone rings and flashes in the display, press tto answer the call.
2. Press tagain to answer the call via hands-free.
3. To switch between hands-free and the earpiece press t.

17Using the phone
IMPORTANT
When the phone is ringing, avoid holding the earpiece too close to your ear as it may
damage your hearing.
NOTE
If auto pick up mode (see page 34) is on, simply lift up the handset from its base to
answer the call. The default setting is O. See all “Default settings” on page 40.
An incoming call has priority over other events. Whenever there is an incoming call, other
operations in progress such as phone settings, menu navigation, etc. will be ended.
3.7 Adjust volume
1. During a call, press uor dto adjust the earpiece or hands-free volume. The level is
shown in the handset display.
3.8 Mute
Mute the microphone so that you can talk to someone else in the room without your caller
hearing you.
1. During a call, press b.The microphone is muted.
2. Press bagain to turn the microphone back on.
3.9 End a call
1. Press e.
Afteryou hang up, the duration the phone is o-hook is displayed for 2 seconds.
NOTE
If auto hang-up is o (see page 34) you must press eto end the call. The default setting
is On .
3.10 Switch handset on/o
1. Press and hold eto switch the handset on or o.
3.11 Intercom
This feature is onlyavailable when there are at least 2 registered handsets. It allowsyou
to make internal calls,transfer external calls from one handset to another and use the
conference option.
3.11.1 Call another handset
1. Press and hold *.
• If you have two handsets,the other handset is called automatically.
• If more than two handsets are registered to the base,the rst handset number is
displayed. Scroll dthe number ofthe handset you want to call and press Mor
press *to ring all handsets.
2. Press eto hang up.

18 Using the phone
NOTE
If the handset does not belong to TD1 range, this function may not be available.
3.11.2 Transfer an external call to another handset
1. During an external call, press and hold *.
Your caller is put on hold.
2. Scroll dthe number ofthe handset youwant to call and press Mor press *to
ring all handsets.
If there are only two handsets, the other handset is called automatically.
3. When the other handset answers, announce the caller then press eto transfer the
call. If the otherhandset does not answer, press and hold *to talk to your caller
again.
3.11.3 Three-party conference call
1. During an external call, press and hold *.
Your caller is put on hold.
2. Scroll dthe number ofthe handset youwant to call and press Mor press *to
ring all handsets.
If there are only two handsets, the other handset is called automatically.
3. When the other handset answers, announce the call then press Mto connect both
calls. If the otherhandset does not answer, press and hold *to talk to your caller
again.
4. Press eto hang up.
3.12 Voicemail
If you have subscribed toyour network’s voicemail service (if available), your TD1 displays
when you have a new message.1
NOTE
You can turn o the icon. When viewing the Calls list, press and hold 5.
1This feature is dependent onyour Network Service provider supporting the service.A
subscription fee maybe payable.

19Phonebook
4. Phonebook
The TD1 phonebook can store up to 100 names and numbers.
Numbers can be up to 24 digits long and names up to 12 characters long. Entries are
stored in alphabetical order.
4.1 View phonebook entries
4.1.1 View and dial an entry
1. Press d. Displayshows the rst entry.
2. Scroll uor dto the entry you want.
Or
To search alphabetically, press dthen press the key with the rst letter of the name,
e.g. if the name beginswith N, press 6twice.
The display shows the rst entry beginning with N. If required, press uor dto scroll
to the exact entry.
3. Press tto dial the entry displayed.
4.1.2 View an entry during a call:
1. Press Mto open the phonebook list.
2. Enterthe rst letter of the name you wantthen scroll uor dif necessary tothe exact
name. Press Mto display the number.
3. Press eto cancelthe phonebook display.
4. Press eagain to end the call.
4.1.3 View VIP phonebook entries
1. Press M. Phonebook is highlighted.
2. Press M . Scroll dto View VIP and press M.
3. The rst number in the phonebook VIP list is displayed. Scroll uor dto the entry you
want.
Or
To search alphabetically, press dthen press the key with the rst letter of the name,
e.g. if the name beginswith N, press 6twice.
The display shows the rst entry beginning with N. If required, press uor dto scroll
to the exact entry.
4. Press bto see the number.
5. Press eto return to standby.

20 Phonebook
4.2 Store an entry
1. Press M. Phonebook is displayed.
2. Press M. Scroll dto New Entry .
3. Press M. Enter Name is displayed.
4. Enter a name and press M.
If you make a mistake press bto delete a character or press and hold bto delete
all characters.
5. Enter a number and press M.
If you make a mistake press bto delete a digit or press and hold bto delete all
digits.
6. The display shows ADD TO VIP? If you want to add the number to theVIP list press M
if you don’t want to store tothe VIP list press b. The number is saved.
7. Press eto return to standby.
NOTE
Cancel storing an entry by pressing eat any time during the process.
4.3 Entering names
Use the alphanumeric keypad to enter names in the phonebook.
For instance to enter the name Paul.
P Press 7once
A Press 2once
U Press 8twice
L Press 5three times
To enter a space press 0.
Press bto delete a character or press and hold bto delete all characters.
